VM-4DKT Quick Start

P/N:

2900- 301544QS

Rev:

Scan for full manual

VM-4DKT Quick Start Guide

This guide HELPS you install and use your VM-4DKT for the first time.

Go to www.kramerav.com/downloads/VM-4DKT to download the latest user manual and check if firmware

upgrades are available.

Step 1: Check in the b what’s ox

VM-4DKT 1:4 4K HDMI/DGKAT Distribution Amplier Transmitter

4 Rubber feet

1 Quick start guide

1 Power cord and adapter

IMPORTANT NOTICE!

We highly recommend using only Kramer UNIKAT cables with these products. If using 3

rd party shielded CAT-6A cables, both ends of the

shield must be soldered to the connectors for the products to function properly. Do not use any jumpers, unshielded wall plates or mid-

span cable connections. These extenders are not compatible with HDBaseT technologies. Prior to signal extension, ensure that the

extension line cable is lying straight and not coiled.

Step 2: Get to know your -4DKT VM

Feature

Function

STATUS LED

Red Power . –up

Green Power is –on.

ACTIVE EDID LED

The LED color indicates the active EDID type. When ashing, the state is in the

process of being activated.

Yellow Default EDID. –

Blue Output-acquired EDID. –

Green Custom EDID. –

INPUT LED

On Input signal detected. –

Flashing Source connected, but no signal detected. –

HDMI IN Connector

Connect to an HDMI source.

LOOP Connector

Connect to a local HDMI display.

DGKAT2 OUTPUTS Connectors (x4)

Connect to a DGKat-2.0 receiver (for example, ) using twisted pair cable. PT-872xr

SERVICE 3-pin terminal block

Connect to a serial controller.

SETUP DIP-switches

Sets the device behavior (see Step 6: Operate -4DKTVM ).

Fan Vent

For heat ventilation.

12V DC Power Connector

Connect the V DC power adapter into the device and then connect it to the 12

mains.

Step 3: Mount -4DKT VM

Install -4DKT using one of the following methods: VM

• Attach the rubber feet and place the unit on a at

surface.

• Ensure that the environment (e.g., maximum ambient temperature & air ow) is

compatible for the device.

• Avoid uneven mechanical loading.

• Appropriate consideration of equipment nameplate ratings should be used for avoiding

overloading of the circuits.

• Reliable earthing of rack-mounted equipment should be maintained.

• Maximum mounting height for the device is 2 meters.

Step 4: Connect inputs and outputs

Always switch OFF the power on each device before connecting it to your . VM-4DKT

Wiring the RJ-45 Connectors

This section denes the DGKAT pinout, using a straight pin- -pin cable to

with RJ-45 connectors.

EIA /TIA 568B

Wire Color

Orange / White

The ground shielding must be connected/soldered to the

connector shield.

Orange

Green / White

Blue

To achieve specied extension distances, use the

recommended Kramer cables available at

www.kramerav.com/product/VM-4DKT.

Using third-party cables may cause damage!

Blue / White

Green

Brown / White

Brown

Step 5: Connect power

Connect the power adapter the and then plug it into the mains electricity. to VM-4DKT

Safety Instructions (See for updated safety information)www.kramerav.com

Caution:

• For products with relay terminals and GPI\O ports, please refer to the permitted rating for an external connection, located next to the terminal or in the User Manual.

• There are no operator serviceable parts inside the unit.

Warning:

• Use only the power cord that is supplied with the unit.

• Disconnect the power and unplug the unit from the wall before installing.

Step 6: Operate -4DKT VM

Set the -4DKT DIP-switches: VM

A DIP-switch that is down is on, up is o. Changes to the DIP-switches take eect immediately.

Function

Status

Active EDID source

ON (down) Default EDID (default) –

OFF (up) 1st OUT EDID –
