Seite 1/33
2
ENGLISH
GENERAL SPECIFICATIONS - VDV500-063 TONER-PRO
The Klein Tools VDV500-063 Toner-Pro is a professional-series tone generator for wire identification, wire
tracing and wire pair identification on non-energised wires. It features several tone frequencies and a strong
power output for tracing wires.
• Operating Altitude: 6562' (2000 m) maximum
• Relative Humidity: 10% to 90%, non-condensing
• Operating Temp: 14° to 122°F (-10° to 50°C)
• Storage Temp: -4° to 140°F (-20° to 60°C)
• Dimensions: 2.5" x 5" x 1" (64 x 127 x 25 mm)
• Weight: 7.4 oz (210 g) including batteries
• Battery Type: 4 x 1.5V AAA Alkaline
• Battery Life: Active: 120 hours
Standby/Storage: 3 years
• Auto Power-Off: After 60 minutes of inactivity
• Tones: Constant: 800 Hz, 1000 Hz, 1500 Hz
Alternating: 800/1000 Hz, 1000/1500 Hz
• Tone Power: 8 dBm
• Continuity Indication: Less than 10kΩ
• Voltage Protection: Test Mode: 60 V
Tone Mode:
20 V through external 600 Ω
Specifications subject to change.
T1
TEST MODE Indicator
T9
Power On/Off Button
T2
‘NRM’ (Normal) Polarity Indicator
T10
TEST/TONE Button
T3
‘REV’ (Reverse) Polarity Indicator
T11
Battery Status Indicator
T4
‘CONT’ (Continuity) Indicator
T12
Lanyard Slot
T5
TONE MODE Indicator
T13
RJ11 Test Plug
T6
Tone Frequency Indicators
T14
ABN (Angled Bed-of-Nails) Test
T7
Tone Mode Down selector button
T15
Battery Cover
T8
Tone Mode Up selector button
T16
Battery Cover Screw (No. 2 Phill
T1
T5
T7
T9
T8
T10
T13
T12
T14
T11
T2
T3
T4
T6
FEATURE DETAILS
T16
T15
3
GENERAL SPECIFICATIONS - VDV500-123 PROBE-PRO
The Klein Tools VDV500-123 Probe-Pro is a professional-series tone tracer, featuring an inductive probe with a
speaker for amplification, and an LED light for use in dark spaces. It also features a headphone jack for use in
extreme noise environments.
• Operating Altitude: 6562’ (2000 m) maximum
• Relative Humidity: 10% to 90%, non-condensing
• Operating Temp: 14° to 122°F (-10° to 50°C)
• Storage Temp: -4° to 140°F (-20° to 60°C)
• Dimensions: 1.75" x 8.88" x 1.13" (44 x 226 x 29 mm)
• Weight: 5.7 oz (161.6 g) including batteries
• Battery Type: 4 x 1.5V AAA Alkaline
• Battery Life: Active: 25 hours
Standby/Storage: 3 years
• Auto Power-Off: After 10 minutes of inactivity
Specifications subject to change.
P1
Replaceable Inductive Polymer Tip (VDV999-068)
P10
Lanyard Slot
P2
Worklight
P11
"-" (Negative) Terminal
P3
Worklight On/Off Button
P12
"+" (Positive) Terminal
P4
Signal Strength Indicator
P13
Terminal Release Buttons
P5
Power On/Off Button
P14
Verification Indicator
P6
Volume Increase Button
P15
Battery Cover
P7
Volume Decrease Button
P16
Battery Cover Screw (No. 2 Phillips)
P8
Battery Status Indicator
P17
3.5 mm Headphone Jack*
P9
Speaker
P2
P17
P3
P4
P5
P6
P11 P12
P7
P9
P10
P8
P1
* Excessive volume can cause permanent hearing damage. Use as low a volume as possible.CAUTION:
P14
FEATURE DETAILS
P13
P15
P16
