EN
L42ms QSG | Part No: xxx-xxxx-xxx | Rev 1.0 20230707
© 2023 HARMAN International Industries | Features, Specications, and Appearance subject to change without notice.
Pg 1 of 4
L42ms Integrated Music System
Quick Start Guide
Thank you for choosing JBL
For more than 75 years, JBL has been providing audio equipment for concert halls, recording studios, and movie theaters around the
world and has become the trusted choice of leading recording artists and sound engineers. The L42ms Integrated Music System was
designed to t today’s entertainment lifestyle by showcasing the iconic sound of a pair of JBL loudspeakers in a single cabinet system.
This Quick Start Guide will get you up and running quickly, for additional information on the operation of this product please visit the
JBL L42ms product page for access to the owners manual at jbl.com
Should further assistance be required feel free to contact our Customer Support at the numbers below:
Inside the US and Canada: +1 888.691.4171 Outside the US and Canada: +44 1707 668 012
1. Verify Box Contents
1x L42ms Integrated Music System
1x Speaker Grille
1x RF Remote
1x Safety Booklet
AC Power Cord(s) – Qty and Type Vary by Region
If you suspect that there has been shipping damage or missing any of the reference above contents, report it immediately to your
dealer or contact our Customer Support at the telephone number referenced in the opening introduction.
2. Determine Speaker Location
Set the bass contour switch based on the speakers proximity to side boundaries such as walls and inside a bookcase or cabinet.
When close to a boundary the switch should be in the -3dB position in order to maintain level bass response.
Away from side boundaries such as walls.
BASS
CONTOUR
-3 dB 0 dB
Close to side boundaries such as walls or when the speaker is inside of a
cabinet or bookcase. -3 dB 0 dB
BASS
CONTOUR
3. Connect Physical Sources
L42ms QSG | Part No: xxx-xxxx-xxx | Rev 1.0 20230707
© 2023 HARMAN International Industries | Features, Specications, and Appearance subject to change without notice.
Pg 2 of 4
EN
4. Pair the Remote
From Top Control Panel Press &
Hold > 2 sec
Long Press > 2
sec
From Remote Control Panel
Press & Hold > 3 sec
Long Press > 2
sec
5. Connect to a Network
For a Wired Connection
Connect the Ethernet port on the rear to any of the open ports on your wireless router using a CAT-5e or higher cable.
For a Wi-Fi Direct Connection
1. On your mobile device, download the JBL Premium Audio App.
2. Power on the JBL L42ms Integrated Music System.
3. Open the app to discover it after the L42ms is Ready.
4. Select it and follow the prompts to connect it to your Wi-Fi network.
5. NET icon LED will illuminate WHITE once network is enabled and connected.
Alternatively, you can connect the JBL L42ms to your Wi-Fi network using Apple Airplay Speaker Setup in the Wi-Fi settings of your
Apple device.
Turning O󰀨 Network and Bluetooth
Network and Bluetooth functionality can be turned O󰀨 should it be desired to do so. The same button operation can be used to turn
Network and Bluetooth back On.
Press “Source Selection” & “Volume +” on the top control panel simultaneously. When OFF, NET LED icon will illuminate RED color.
When ON NET LED icon will illuminate WHITE color.
Press Simultaneously > 2 sec
Note: When the Network and Bluetooth are O󰀨 the following conditions exist:
• Speaker cannot be used for Network or Bluetooth streaming.
• The handheld remote is inoperable and the unit can only be used via the top control panel buttons.
• Network icon on top panel with show Red indicating that Network has been turned o󰀨.
EN
L42ms QSG | Part No: xxx-xxxx-xxx | Rev 1.0 20230707
© 2023 HARMAN International Industries | Features, Specications, and Appearance subject to change without notice.
Pg 3 of 4
6. Connect a Source via Bluetooth
From Top Control Panel Select
Bluetooth as Source
Press & Hold Source button > 3 sec
Bluetooth Source light will ash
Select L42ms from your device's
Bluetooth menu
7. Listening to Sources & Control
The JBL L42ms can be connected to and stream audio content through the following apps and services:
• Spotify Connect
• Tidal Connect
• Apple Airplay 2
• Chromecast (requires acceptance of Google terms in the JBL Premium Audio App or additional setup steps in the Google
Home App)
• Roon Ready (requires setup on a Mac, PC, Roon Nucleus, or another server and the Roon Remote App)
• Works With SmartThings (requires setup with a SmartThings Hub and the SmartThings App)
From the JBL Premium Audio App you can access setup favorites and access other services including but not limited to:
• Internet Radio
• Podcasts
• Amazon Music HD
• Qobuz
The JBL L42ms can be connected to local analog and digital components via back-panel connections:
• 1x 3.5mm (1/8”) stereo mini connector
• 1x RCA stereo Left / Right inputs
• 1x HDMI-ARC connection
NOTE: The HDMI-ARC connection on the L42ms does not decode multichannel or Dolby 2ch audio formats. For the
L42ms to play content delivered to the HDMI-ARC connection the television’s audio output must be set to 2ch PCM.
Refer to the owners manual for your television on details about selecting 2ch PCM output.
8. Wireless Speciîšżcation
Bluetooth
• Remote Control Type: BTLE 2402-2480MHz@0.16dBm
• Bluetooth operation in 2402MHz to 2480MHz with max power 9.58dBm e.i.r.p
• Bluetooth LE operation in 2402MHz to 2480MHz with max power 9.20dBm e.i.r.p
Wi-Fi
• 802.11b/g/n operation in 2412MHz to 2472MHz with max power 17.03dBm e.i.r.p
• 5GHz RLAN 802.11a/n/ac: operation in 5180MHz - 5240MHz; 5260MHz - 5320MHz; 5500MHz - 5700MHz with max power:
21.79dBm e.i.r.p
• 5.8G SRD operation in 5745MHz to 5825MHz with max power 11.98 dBm e.i.r.p
Note: The device is restricted to indoor use when operated in the 5150-5350Mhz frequency range
9. Factory Reset
The L42ms can be reset to factory defaults should the need to arise. This will erase all settings for Network and Bluetooth requiring
that all connections be reconîšżgured.
BASS
CONTOUR
RESETSERVICE
Press & Hold > 3 sec until selection indicators
on top panel ash. -3 dB
