Seite 1/6
서브우퍼 사용 설명서
Buku Panduan Pemilik Subwoofer
低音用户手册
Bruksanvisning för subwoofer
Manual do proprietário do subwoofer
Instrukcja obsługi subwoofera
Subwoofer Gebruikershandleiding
Manuale utente del Subwoofer
Alibassokaiuttimen ohjekirja
Subwoofer Bedienungsanleitung
Manual del propietario del subwoofer
Betjeningsvejledning til subwoofer
Mode d'emploi du caisson de graves
Subwoofer Owner's Manual
Subwoofer Kullanım Kılavuzu
CLUB SUBWOOFER
ENCLOSURES
EN
FR
DA
DE
ES
FI
IT
NL
PL
PT
SV
TR
ZH-CN
ID
KO
CLUB 1000D
CLUB 1200D
CLUB 1000P
CLUB 1200P
* JBL Club1200P/JBL Club1000P
*
THANK YOU FOR CHOOSING THIS
JBL PRODUCT
This product has been designed to deliver great bass performance
from a compact, easily installed enclosure. To get the best
performance from your enclosure, we strongly recommend that you
entrust installation to a qualified professional. Although these
instructions explain how to install your enclosure in a general
sense, they do not show specific installation methods that may be
required for your particular vehicle. If you do not have the
necessary tools or experience, do not attempt the installation
yourself. Instead, please ask your authorized JBL car audio dealer
about professional installation. To help us serve you better if your
enclosure ever requires warranty service, please retain your original
sales receipt and serial number.
INSTALLATION WARNINGS AND TIPS
INSTALLATION TIPS
• Always wear protective eyewear when using tools.
• Turn off all audio components and other electrical devices before
you start. Disconnect the negative (–) lead from your vehicle’s
battery.
• Check clearances on both sides of a planned mounting surface.
Be sure that screws or wires will not puncture brake lines, fuel
lines or wiring harnesses, and that wire routing will not interfere
with the safe operation of the vehicle.
• When making electrical connections, make sure they are secure
and properly insulated.
• Before drilling or cutting holes, use a utility knife to remove unwanted
fabric or vinyl, to keep material from snagging in a drill bit or saw.
• Do not mount speakers where they will get wet.
CHOOSING A MOUNTING LOCATION FOR THE ENCLOSURE
Choose a mounting location that doesn’t interfere with cargo, the
fold-down rear seat or the trunk lid. The best location is usually a
corner of the trunk or cargo area. Securely mount the enclosure to
the mounting surface.
WARNING: Playing loud music in an automobile can
permanently damage your hearing as well as hinder your ability
to hear traffic. Listening at low levels while driving is
recommended. HARMAN International accepts no liability for
hearing loss, bodily injury or property damage resulting from
use or misuse of this product.
CLUB SUBWOOFER
ENCLOSURES
EN
SPEAKER CONNECTIONS
Co ec e mi al clo e o li ie vi g olann t th + ter and n s n n o the e sur t the amp f r’s o erutputs, obs n proper p rity. Use at least 4mm 2 (11 AWG) speaker
wire for the connections to the enclosure of Club 1000P, Club 1200P. And 5mm 2 (10 AWG) speaker wire for the connections to the enclosure
of Club 1000D, Club 1200D.
GENERAL CARE
The loudspe be le ned ith mp cloth. any cl ventsaker may c a w a da D e o not us eaners or sol .
A va i mber ired fo a e i c is desi ed o o a i o o c c o o lid ser al nu is requ r rrwa nty coverag . Th s produ t gn for m bi tile applica ns nd s n t intended f r onne ti n t
the mains.
HEAD UNI T
AMP
BATTERY
Speaker Out
Remote
Turn-On
RL
SPECIFICATIONS
CLUB ENCLOSURES
CLUB 1000P CLUB 1000D CLUB 1200P CLUB 1200D
Subwoofer: 1x 10" (250mm) Polypropylene
Driver
2x 10" (250mm) Polypropylene
Driver
1x 12" (300mm) Polypropylene
Driver
2x 12" (300mm) Polypropylene
Driver
Power Handling: 350W RMS, 1050W peak 700W RMS, 1400W peak 400W RMS, 1200W peak 800W RMS, 1600W peak
Sensitivity (1W/1m): 83dB 86dB 86dB 89dB
Frequency Response (-6dB): 35Hz – 400Hz 30Hz – 400Hz 30Hz – 400Hz 30Hz – 400Hz
Nominal Impedance: 2 ohms 2 ohms 2 ohms 2 ohms
Voice Coil Diameter: 2" (50mm) 2" (50mm) 2" (50mm) 2" (50mm)
Enclosure dimensions: 264.8mmD1 x 345.2mmD2 x
447mmW x 379mmH
10-7/16"D1 x 13-5/8"D2 x
17-5/8"W x 14-15/16"H
351.8 mmD1 x 432.25mmD2 x
660mmW x 358 mmH
13-7/8"D1 x 17 "D2 x 26"W x
14-1/8"H
353.8 mmD1 x 434.2mmD2 x
555mmW x 378mmH
13-15/16"D1 x 17-1/8"D2 x
21-7/8"W x 14-7/8"H
357.8mmD1 x 434.2mmD2 x
815mmW x 383mmH
14-1/16"D1 x 17-1/8"D2 x
32-1/16"W x 15-1/16"H
Enclosure materials: 11/16" (18mm) MDF with black
carpet covering
13/16" (21mm) MDF with black
carpet covering
11/16" (18mm) MDF with black
carpet covering
13/16" (21mm) MDF with black
carpet covering
EN
