Instruction booklet

TUMBLE DRYER IDC 8T3 B (UK)

IDC 8T3 B K (UK)

IDC 8T3 B S (UK)

Step 1

Open the door of your dryer.

Step 2

Pull out the ﬁ lter (using the two

ﬁ nger grips).

Step 3

Clean the ﬂ uff off the ﬁ lter and

replace it correctly.

Step 4

Make sure the ﬁ lter is pushed fully home -

NEVER run the dryer without the ﬁ lter in position.

Failure to clean the ﬁ lter after EVERY drying

cycle will affect the drying performance of your

machine.

It will take longer to dry and as a result will use

more electricity during drying.

Step 1

Open the condenser cover.

Step 2

Remove the condenser by turning

the 3 catches and

pulling the condenser

towards you. It is normal for some

residual water to be left in the

condenser unit.

Step 3

Flush the condenser

from the rear with water to remove

any ﬂ uff deposits.

Step 4

Replace the condenser unit and

make sure that all 3 catches are

closed and that the position arrows

on the front of the condenser are

pointing upwards.

Less than 1m

This symbol reminds you to read this booklet

WHERE TO INSTALL THE TUMBLE DRYER

Install the dryer far from

gas ranges, stoves, radiators

or hobs as ﬂ ames may

damage it. If the dryer is

installed below a worktop,

ensure there are 10 mm

between the upper panel of

the dryer and any objects

above it and 15 mm between

the sides of the machine

and the walls or furniture units adjacent to it. This

ensures adequate air circulation.The appliance

must be installed with the rear surface placed

against a wall.

! We do not recommend that the dryer is installed

in a cupboard but the dryer must never be

installed behind a lockable door, a sliding door or

a door with a hinge on the opposite side to that of

the dryer door.

Priming the Water Collection System.

When your dryer is new, the water container will not collect water

until the system is primed. This will take 1 or 2 drying cycles. Once

primed it will collect water during every drying cycle.

WATER DRAINAGE CONNECTION

If the dryer is installed next to a drain the

water can be plumbed into this drain. This

does away with the need to empty the

water container. The height of the drain

must be less than 1m from the bottom of

the dryer. Remove the existing hose from

the dryer and connect it to the drain (if

required add an additional length of hose).

ELECTRICAL CONNECTIONS

The socket must be grounded.

! The power cord must be regularly checked. If

the supply cord is damaged it must be replaced

by the manufacturer, its service agent or similarly

qualiﬁ ed persons in order to avoid a hazard.

BEFORE YOU START USING YOUR DRYER

Once you have installed your dryer and before

you use it clean the inside of the drum to remove

any dust that could have accumulated during

transport.

CONDENSER UNIT

You MUST clean the ﬂ uff from the condenser

EVERY month. Failure to clean the condenser

could cause premature failure of your dryer.

Remove the condenser unit regularly (at least

monthly) and clean off any ﬂ uff deposits.

10 mm

15 mm 15 mm

WATER CONTAINER

You empty the water container after MUST EVERY

drying cycle. Removing the water container:

Step 1 Pull the water container

towards you and remove it

completely from the dryer.

Step 2 Empty all the water in the

water container.

Step 3 Replace the water

container making sure that it is securely ﬁ xed.

! Failure to empty the water container will

cause the machine to stop heating and the

load may still be wet at the end of the drying

cycle. The ‘Empty Water’ light will tell you

that the water container needs to be emptied

FLUFF FILTER

You must clean the ﬂ uff ﬁ lter after EVERY drying cycle.

Control panel

The knob: the position swithes off the dryer.TIMER 0

The HEAT button selects drying temperature.

OUT: LOW IN: HIGH heat heat

Warnings

! This appliance has been designed and built

according to international safety standards.

These warnings are given for safety reasons and

must be followed carefully.

General safety

This appliance can be used by children aged

from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack

of experience and knowledge if they have been

given supervision or instruction concerning use

of the appliance in a safe way and understand the

hazards involved.

This tumble dryer has been designed for home

and not professional, use.

Do not touch the appliance while barefoot or with

wet hands or feet.

Unplug the machine by pulling on the plug, not

the cord.

After using the dryer, turn it off and unplug it.

Keep the door closed to make sure that children

do not use it as a toy.

Children should be supervised to ensure that

they do not play with the dryer.

Cleaning and user maintenance shall not be

made by children without supervision.

Children of less than 3 years should be kept

away from the appliance unless continuously

supervised.

The appliance must be installed correctly and

have proper ventilation. The air intake at the front

of the dryer should never be obstructed

Never use the dryer on carpeting where the pile

height would prevent air from entering the dryer

from the base.

Check to see if the dryer is empty before loading it.

The back of the dryer could become very hot.

Never touch it while in use.

Do not use the dryer unless the ﬁ lter, water-

container and condenser are securely in place

Do not overload the dryer (see Laundry for

maximum loads).

Do not load items that are dripping wet.

Carefully check all instructions on clothing labels

Do not tumble dry large, very bulky items.

Do not tumble dry acrylic ﬁ bres at high

temperatures.

Do not turn off the dryer when there are still

warm items inside.

Clean the ﬁ lter after each use.

Empty the water container after each use.

Clean the condenser unit at regular intervals .

Do not allow lint to collect around the dryer.

Never climb on top of the dryer. It could result in

damage.

Always follow electrical standards and

requirements.

Always buy original spare parts and accessories.

To minimise the risk of ﬁ re in your

tumble dryer, the following should be

observed:

Tumble dry items only if they have been washed

with detergent and water, rinsed and been

through the spin cycle. It is a ﬁ re hazard to dry

items that HAVE NOT been washed with water.

Do not dry garments that have been treated with

chemical products.

Do not tumble dry items that have been spotted

or soaked with vegetable or cooking oils, this

constitutes a ﬁ re hazard. Oil-affected items can

ignite spontaneously,especially when exposed to

heat sources such as a tumble dryer. The items

become warm, causing an oxidisation reaction

with the oil, Oxidisation creates heat. If the heat

cannot escape, items can become hot enough to

catch ﬁ re. Piling, stacking or storing oil-effected

items can prevent heat from escaping and so

create a ﬁ re hazard.If it is unavoidable that fabrics

containing vegetable or cooking oil or those that

have been contaminated with hair care products

be placed in a tumble dryer they should ﬁ rst be

washed with extra detergent - this will reduce,

but not eliminate the hazard. They should not

be removed from the dryer and piled or stacked

while hot.

Do not tumble dry items that have previously

been cleaned in or washed in, soaked in or

soiled with petrol/gasoline, dry cleaning solvents

or other ﬂ ammable or explosive substances.

Highly ﬂ ammable substances commonly used

in domestic environments including cooking

oil, acetone, denatured alcohol, kerosene, spot

removers, turpentine, waxes and wax removers.

Ensure these items have been washed in hot

water with an extra amount of detergent before

being dried in the tumble dryer.

Do not tumble dry items containing foam rubber

(also known as latex foam), or similarly textured

rubber like materials. Foam rubber materials

can, when heated, produce ﬁ re by spontaneous

combustion.

Fabric softener or similar products should not be

used in a tumble dryer to eliminate the effects of

static electricity unless the practice is speciﬁ cally

recommended by the manufacturer of the fabric

softener product.

Do not tumble dry undergarments that contain

metal reinforcements eg. bras with metal

reinforcing wires. Damage to the tumble dryer

can result if the metal reinforcements come loose

during drying.

Do not tumble dry rubber, plastic articles such

as shower caps or babies waterproof covers,

polythene or paper.

Do not tumble dry rubber backed articles, clothes

ﬁ tted with foam rubber pads, pillows, galoshes

and rubber coated tennis shoes.

Remove all objects from pockets such as lighters

and matches.

WARNING: Never stop the dryer before the end

of the drying cycle unless all items are quickly

removed and spread out so that the heat is

dissipated.

Dryer Description

Start

button

Drying time

selector knob

High Heat

button

The knob sets the drying time: rotate it clockwise, TIMER NEVER

COUNTER-CLOCKWISE , until the indictor is pointing to the drying

time you want to select.

The Empty Water indicator light signals that the water container is

full and must be emptied. The light will take a few seconds to go

out after replacing the empty water container, the dryer must be

running for this to happen.

Note: If the water container ﬁ lls up the indicator lights, the heat is

turned off and your laundry will not dry.

CHOOSING A PROGRAMME

1. Plug the dryer into the electrical socket.

2. Sort your laundry according to fabric type.

3. Open the door and make sure the ﬁ lter is clean and in place.

4. Load the machine and make sure items are not in the way of the

door seal. Close door.

5. Set the temperature with the HEAT button. High heat for Cotton.

Low heat for delicates, synthetics and acrylics.

6. Select a drying time by rotating the TIMER knob clockwise.

The tables below show APPROXIMATE drying times in minutes.

Weights refer to dry garment weights.

7. Press the START button to begin.

During the drying programme, you can check on your laundry

and take out items that are dry while others continue drying.

When you close the door again press the START button in order

to resume drying.

8. About 10 minutes before the programme is completed it enters

the ﬁ nal COOL TUMBLE phase (fabrics are cooled) which should

always be allowed to complete.

9. Open the door and take the laundry out. Clean and replace the

ﬁ lter. Empty and replace the water container.

10. Unplug the dryer.

Laundry

MAX LOAD SIZE

Natural ﬁ bres: 8kg max Synthetic ﬁ bre: 3kg max

Standard Cotton - High (full) Heat

This is the most efﬁ cient program in terms of energy consump-

tion (EU 392/2012). To reach maximum efﬁ ciency, select the

highest temperature option.

Drying times 800-1000rpm spin in washing machine

1kg 2kg 3kg 4kg

30-40mins 40-55mins 55-70mins 70-80mins

5kg 6kg 7kg 8kg

80-90mins 95-120mins 120-140mins 130-150mins

Synthetics - Low (gentle) Heat

Drying times on reduced spin in washing machine

1kg 2kg 3kg

40-50mins 50-70mins 70-90mins

WASH CARE LABELS

Look at the labels on your garments when tumble drying. The

following symbols are the most common.

May be tumble dried

Do NOT tumble dry

Tumble dry at high heat setting

Tumble dry at low heat setting

ITEMS NOT SUITABLE FOR TUMBLE

DRYING

1. Articles that contain rubber or rubber-like materials or plastic

ﬁ lm, any ﬂ ammable articles or objects that contain ﬂ ammable

substances.

2. Glass ﬁ bres.

3. Items which have been dry cleaned.

4. Large bulky items (quilts, sleeping bags, etc). These expand

when drying and prevent airﬂ ow through the dryer.

Troubleshooting

Before you call the service centre go through the following

troubleshooting suggestions:

PROBLEM:

The dryer won’t start.

POSSIBLE CAUSES/SOLUTION:

• The plug is not in the socket or making contact.

• There has been a power failure.

• The fuse has blown. Try to plug another appliance into the

socket.

• You are using an extension cord? Try to plug the dryer directly

into the socket.

• The timer knob has not been set properly.

• The start button has not been pressed.

• The door is not closed securely.

PROBLEM:

It is taking a long time to dry.

POSSIBLE CAUSES/SOLUTION:

• The ﬁ lter has not been cleaned.

• The water container needs emptying? The empty water light

is on?

• The condenser needs cleaning.

• The temperature setting is not correct.

• The correct time has not been selected.

• The air intake grill is obstructed.

• The items were too wet.

• The dryer was over loaded.

Produktspezifikationen

Marke:	Indesit
Kategorie:	Trockner
Modell:	IDC 8T3 B S (UK)
Breite:	595 mm
Tiefe:	610 mm
Gewicht:	35200 g
Produktfarbe:	Silber
Steuerung:	Buttons,Rotary
Höhe:	850 mm
AC Eingangsspannung:	220 - 240 V
AC Eingangsfrequenz:	50 Hz
Eingebautes Display:	Nein
Verpackungsbreite:	640 mm
Verpackungstiefe:	670 mm
Verpackungshöhe:	890 mm
Paketgewicht:	36600 g
Geräteplatzierung:	Freistehend
Energieeffizienzklasse:	B
Kabellänge:	1.5 m
Energieeffizienzskala:	A+++ bis D
Trockenprogramme:	Cotton,Synthetics
Startzeitvorwahl:	Nein
Anti-Faltenfunktion:	Nein
Ladetyp:	Frontlader
Anschlusswert:	2400 W
Jährlicher Energieverbrauch:	560 kWh
Wärmequelle:	Elektro
Nennstrom:	13 A
Energieverbrauch:	4.79 kWh
Zykluszeit:	147 min
Nennkapazität:	8 kg
Trocknungsklasse:	C
Geräuschpegel:	68 dB
Trocknungssystem:	Kondensation
Kindersicherung:	Nein
Stromverbrauch (aus):	0 W
Trommelvolumen:	112 l
Trommelinnenbeleuchtung:	Ja
Anzahl Trocknungsprogramme:	16
Filtereinigungsindikator:	Ja
