Quick Guide

THANK YOU FOR BUYING A INDESIT PRODUCT

In order to receive a more complete assistance,

please register your product on

www.indesit.com/register

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

CONTROL PANEL

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

DETERGENT DISPENSER DRAWER

Compartment 1: Do not pour detergent into the

compartment . 1

Detergent should only be poured into the

compartment .2

Compartment 2: Washing detergent (powder

or liquid)

Liquid detergent should only be poured in

immediately prior to the start of the wash cycle.

Compartment 3: Additives (fabric softener,

etc.)

The fabric softener should not overow the grid.

Note: If a “tablet detergent” is used, always follow the manufacturer’s

instructions.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

Maximum load 8 kg

Power input in o mode 0.5 W / in left-on mode 8 W Detergents and

Additives Recommended

detergent

Residual

dampness %

(**)

Energy

consumption

kWh

Total water lt

Laundry

temperature °C

Wash cycle Temperature Max.

spin speed

(rpm)

Max.

load for

washing

(kg)

Duration

(h : m)

Drying

Max.

load for

drying

(kg)

Wash Fabric

softener

Powder

Liquid

Setting Range 2 3

1 Mix Colours 59’ 40 °C - 40 °C 1000 8,0 * 6,0   –– – – –

2 Synthetics 59’ 30°C - 30 °C 1000 3,5 * 3,5   –– – – –

3 Cotton 45’ 40 °C - 40 °C 1200 4,5 * 4,5   –– – – –

4 Wash&Dry 90’ 30°C 30°C 1200 2,0 * 2,0   –– – – –

5 Wash&Dry 45’ 30°C 30°C 1400 1,0 * 1,0   –– – – –

6 Cotton (2) 40 °C - 60 °C 1400 8,0 3:55 6,0     49 1,400 105 45

7 Synthetics (3) 40 °C - 60 °C 1200 4,0 2:55 4,0     35 0,800 55 43

8 Wool 40 °C - 40 °C 800 2,0 * 2,0   –– – – –

9Eco 40-60 (1)

(Wash) 40 °C 40°C

1351 8,0 3:30 

6,0

    53 0,770 54 33

1351 4,0 2:45      53 0,650 52 36

1351 2,0 2:10      53 0,450 37 33

10 20°C 20 °C - 20 °C 1400 8,0 1:50 6,0   –49 0,160 90 22

11 White 60°C - 90 °C 1400 8,0 2:45 6,0     49 0,900 90 55

12 Cotton Dry – – – 6,0 * 6,0 – – – – – – – –

13 Synthetics Dry – – – 4,0 * 4,0 – – – – – – – –

14 Rinse – – 1400 8,0 * 6,0 – – – – – – –

15 Spin – – 1400 8,0 * 6,0 – – – – – – – –

16 Drain – – – 8,0 * – 6,0 – – – – – – – –

  Required dosage Optional dosage

9Eco 40-60 (4)

(Wash & Drying) 40 °C 40 °C 1351 6.0 9:20 6.0     0 3,800 75 33

1351 3.0 5:10 3.0     0 1,980 47 32

7 6

ДДДДДДД

DISPLAY

1. ON/OFF button

2. TEMPERATURE button

3. OPTION buttons and indicator lights

4. START/PAUSE button and indicator light

5. DRYING button

6. SPIN button

7. WASH CYCLE SELECTOR KNOB

8. Detergent dispenser drawer

For all testing institutes:

2) Long cotton cycle: set programme 6 at temperature 40°C.

3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.

* The duration of the wash cycles can be checked on the display.

** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected.The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation

2019/2014. The most ecient programme in terms of energy and water consumption for

washing normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in

the table.

Eco 40-60 (Drying)-

Test drying cycle in compliance with EU Ecodesign regulation

2019/2014

. To access “wash and dry” cycle select “Eco 40-60” wash programme and set

“Drying” option level to

“

”.

The most ecient programme in terms of energy and water

consumption for washing and drying normally soiled cotton laundry. At the end of cycle the

garments can be immediately stored to the cupboard.

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Mix Colours 59’

To wash mixed and coloured items together.

Synthetics 59’

Suitable for washing moderately soiled garments made of synthetic bres

(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Cotton 45’

short cycle designed to wash delicate cotton items.

Wash&Dry 90’

The cycle guarantees the washing and drying performances for a 2 kg

load in 90 minutes (level “ ” Iron dry); for larger loads, the cycle’s A1

duration increases in order to guarantee the cycle performances.

Wash&Dry 45’

Select programme 5 for washing and drying lightly soiled garments

(Cotton and Synthetic) in a short time. This cycle may be used to wash

and dry a laundry load of up to 1 kg in just 45 minutes (level “ ” Iron A1

dry). To achieve optimum results, use liquid detergent and pre-treat cus,

collars and stains.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of

resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Specic for synthetic items. If the dirt is dicult to remove, the temperature

can be increased up to 60° and powder detergent can be used too.

Wool

All wool garments can be washed using programme 8, even those

carrying the “hand-wash only” label. For best results, use special

detergents and do not exceed 2 kg of laundry.

Eco 40-60

For washing normally soiled cotton garments declared to be washable at 40 °C

or 60 °C, together in the same cycle. This is the standard cotton programme

and the most ecient in terms of water and energy consumption.

! The cycle runs only at 40°C as per regulation.

20°C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

White

For heavily soiled whites and resistant colours.

Cotton Dry

Designed for drying cotton fabrics.

Synthetics Dry

Designed for drying Synthetics fabrics.

Rinse

Designed for rinsing and spinning.

Spin

Designed to spin and drain the water.

Drain

Designed for draining the water.

DISPLAY

The display is useful when programming the machine and provides a

great deal of information. B

The duration of the available programmes and the remaining time of a

running cycle appear in section ; if the DELAY TIMER option has been A

set, the countdown to the start of the selected programme will appear.

Furthermore, pressing the corresponding button allows you to view the

maximum temperature, spin speed and drying level or time values

attained by the machine during the selected cycle.

The phases scheduled for the selected cycle and, once the cycle has

begun, the current phase of the wash cycle (and drying cycle, if

applicable) appear in section .B

Wash

Rinse

Spin / Drain

Drying

The icons corresponding to “temperature” , “Drying” and “spin”

appear in section from top to bottom:C

If the symbol lights up, the display will visualise the set “temperature”

value.

The symbol lights up while the drying settings are being adjusted.

If the symbol lights up, the display will visualise the set “spin” value.

DOOR LOCKED INDICATOR

When lit, the symbol indicates that the door is locked. To prevent any

damage, wait until the symbol turns o before opening the door .

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is o, the door can be opened .

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst

time, run a wash cycle with detergent and no laundry, by setting the “Auto

Clean” cycle.

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

- Press the ON/OFF button ; the START/PAUSE indicator light will

ash slowly green.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the Wash Cycle Table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER”

section.

- Close the door.

- Select the desired wash cycle.

- Set the washing temperature.

- Set the drying cycle if necessary.

- Select the desired options.

STARTING CYCLE

Press the START/PAUSE button.

The machine will lock the door ( symbol on) and the drum will start to

rotate; the door will be unlocked ( symbol o) and then locked again

( symbol on) as preparation phase of each washing cycle. The “Clicking”

noise is part of the door locking mechanism. Water will enter the drum

and start the washing phase once the door is locked.

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash amber. If the symbol is not lit, the door may be

opened . To start the wash cycle from the point at which it was

interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the symbol turns on to signal that the door cannot

be opened. While a wash cycle is running, the door remains locked. To

open the door while a cycle is under way, for example, to add or remove

garments, press the START/PAUSE button to pause the cycle; the

indicator light will ash amber. If the symbol is not lit, the door may be

opened . Press the START/PAUSE button again to continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washer-dryer

using the START/PAUSE button (the relative indicator light will ash

amber), then select the desired cycle and press the START/PAUSE

button again.

! To cancel a cycle that has already begun, press and hold the ON/OFF

button. The cycle will be stopped and the machine will switch o.

END OF THE CYCLE

Once the cycle terminates the indicator light will light up; when the END

symbol switches o, the door may be opened . Open the door, unload the

laundry and switch o the machine. If you do not press ON/OFF button,

the washer-dryer will switch o automatically after about a 10 minutes. .

Close the water tap, open the door and unload the washer-dryer. Leave the

door ajar to allow the drum to dry.

OPTIONS

- If the selected option is not compatible with the programmed wash

cycle, the indicator light will ash and the option will not be activated.

- If the selected option is not compatible with another option which

has been selected previously, the indicator light corresponding to the

rst option selected will ash and only the second option will be

activated; the indicator light corresponding to the enabled option will

remain lit.

Extra Wash

Enable the

Extra Wash

option for very dirty items, where compatible.

Press this option to let the cycle automatically re-adjust all wash

parameters through a longer lasting cycle. The option always leaves the

temperature unchanged, while the spin cycle is automatically brought

back to maximum levels. The user can set the spin cycle back to the

desired value at any time.

Easy Iron

By selecting this function, the wash and spin cycles will be modied in

order to reduce the formation of creases. At the end of the cycle the

washing machine will perform slow rotations of the drum; the indicator

lights for the EASY IRON and START/PAUSE options will ash (the rst

one green, the second orange).

To end the cycle, press the START/PAUSE button or the EASY IRON button.

Note: If you also want to run the drying cycle, this option is enabled only

if combined with level “ ”(Iron dry).A1

Extra rinse

By selecting this option, the eciency of the rinse is increased and

optimal detergent removal is guaranteed. It is particularly useful for

sensitive skin.

Start Delay

To set a delayed start for the selected cycle, press the corresponding

button repeatedly until the required delay period has been reached.

When this option is enabled, the corresponding indicator light will remain

lit. To remove the delayed start setting, press the button until the text

“OFF” appears on the display.

Temperature

Each wash cycle has a pre-dened temperature. To modify the

temperature, press the button. The value will appear on the display.

Spin

Each wash cycle has a pre-dened spin speed. To modify the spin speed,

press the button. The value will appear on the display.

Drying cycle

The rst time the button is pressed, the machine will automatically

select the maximum drying cycle which is compatible with the selected

wash cycle. Subsequent presses will decrease the drying level and then

the drying time, until the cycle is excluded completely (“OFF”).

Drying may be set as follows:

A - Based on the desired laundry dryness level:

Iron dry “A1”: suitable for clothes which will need ironing afterwards. the

remaining dampness softens creases, making them easier to remove.

Hanger dry “A2”: ideal for clothes which do not need to be dried fully.

Cupboard dry “A3”: suitable for laundry which can be put back in a

cupboard without being ironed.

Extra dry “A4”: suitable for laundry which can be put back in a cupboard

without being ironed.

B 30 180 - Based on a set time period: between and minutes.

If your laundry load to be washed and dried is much greater than the

maximum stated load (see Wash Cycle Table), perform the wash cycle, and

when the cycle is complete, divide the garments into groups and put

some of them back in the drum.

At this point, follow the instructions provided for a cycle. Drying only

Repeat this procedure for the remainder of the load.

N.B: a cooling-down period is always added to the end of each drying cycle.

Drying only

Use the cycle selector knob to select a drying cycle ( - ) in accordance 12 13

with the type of fabric. The desired drying level or time may also be set

using the DRYING button .

TIPS AND SUGGESTIONS

Divide the laundry according to:

Type of fabric (cotton, mixed bres, synthetics, wool, garments to be

hand-washed). Colour (separate coloured garments from whites, wash new

coloured garments separately). Delicates (small garments – such as nylon

stockings – and items with hooks – such as bras: insert them in a fabric bag).

Empty the pockets:

Objects such as coins or lighters can damage the washer-dryer and the

drum. Check all buttons.

Follow the dosage recommendation / additives

It optimizes the cleaning result, it avoids irritating residues of surplus detergent

in your laundry and it saves money by avoiding waste of surplus detergent.

Use low temperature and longer duration

The most ecient programmes in terms of energy consumption are

generally those that perform at lower temperatures and longer duration.

Observe the load sizes

Load your washing machine up to the capacity indicated in the “Wash Cycle

Table” table to save water and energy.

Noise and remaining moisture content

They are inuenced by the spinning speed: the higher the spinning speed

in the spinning phase, the higher the noise and the lower the remaining

moisture content.

CARE AND MAINTENANCE

Before performing cleaning and maintenance, switch the washer-dryer o

and disconnect it from the mains power. Do not use ammable liquids to

clean the washer-dryer. Clean and maintain your washer-dryer periodically

(at least 4 times per year).

Disconnect the water and power supplies

Close the water tap after every wash. This will limit wear on the hydraulic

system inside the washer-dryer and help to prevent leaks.

Unplug the washer-dryer when cleaning it and during all maintenance

work.

Clean the washer-dryer

The outer parts and rubber components of the appliance can be cleaned

using a soft cloth soaked in lukewarm soapy water. Do not use solvents or

abrasives.

The washer-dryer has a “Auto Clean” programme for its internal parts that

must be run with no load in the drum.

For maximum performance you may want to use either the detergent (i.e.

a quantity 10% the quantity specied for lightly-soiled garments) or

special additives to clean the washer-dryer. We recommend running a

cleaning programme every 40 wash cycles.

To start the programme press buttons and simultaneously for

5 seconds.

The programme will start automatically and will last approximately 70

minutes.

Clean the detergent dispenser drawer

Wash it under running water; this operation should be repeated

frequently.

Care for the door and drum

Always leave the porthole door ajar in order to prevent unpleasant odours

from forming.

Clean the pump

The washer-dryer is tted with a auto-cleaning pump that does not

require any maintenance. Small items (such as coins or buttons) may

sometimes fall into the protective pre-chamber situated at the base of the

pump.

! Make sure the wash cycle has ended and unplug the appliance.

To access the pre-chamber:

1. remove the cover panel on the front of the machine by rst pressing it

in the centre then pushing downwards on both sides to extract it;

2. loosen the drainage pump cover by turning it anti-clockwise: it is

normal for some water to leak out;

3. clean the inside thoroughly;

4. screw the cover back on;

5. put the panel back in place, making sure the hooks slot in place before

pushing the panel onto the appliance.

Check the water inlet hose

Check the water inlet hose at least once a year. If it is cracked or broken, it

must be replaced: during wash cycles, the high pressure of the water

could suddenly split the hose open.

! Never use hoses that have already been used.

LOAD BALANCING SYSTEM

Before every spin cycle, to avoid excessive vibrations before every

spin and to distribute the load in a uniform manner, the drum rotates

continuously at a speed which is slightly greater than the washing

rotation speed. If, after several attempts, the load is not balanced

correctly, the machine spins at a reduced spin speed. If the load is

excessively unbalanced, the washer-dryer performs the distribution

process instead of spinning. To encourage improved load distribution and

balance, we recommend small and large garments are mixed in the load.

ACCESSORIES

Contact our Technical Assistance Service to check whether the following

accessories are available for this washer-dryer model.

Stacking kit

With this accessory you can secure the tumble dryer to the upper part of

your washer-dryer to save space and facilitate loading and unloading of

the tumble dryer.

TRANSPORT AND HANDLING

Do not lift the washer-dryer by gripping it from the upper section.

Unplug the appliance and close the water tap. Check that the door and

detergent dispenser drawer are tightly closed. Detach the lling hose

from the water tap then detach the drain hose. Empty all the water

remaining in the hoses and secure the latter so that they do not get

damaged during transport. Apply the transport bolts back on. Repeat, in

reverse order, the transport bolt removal procedure described in the

“Health & Safety and Installation Guides”.

Produktspezifikationen

Marke:	Indesit
Kategorie:	Wäschetrockner
Modell:	EWDE 861483 W UK

Brauchst du Hilfe?

Wenn Sie Hilfe mit Indesit EWDE 861483 W UK benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Wäschetrockner Indesit

Indesit IDV 75 B K (UK) Bedienungsanleitung

14 Oktober 2024

Indesit YT M11 82 X UK Bedienungsanleitung

14 Oktober 2024

Indesit IDPE 845 A1 ECO (UK) Bedienungsanleitung

9 Oktober 2024

Indesit TG 1270 Bedienungsanleitung

8 Oktober 2024

Indesit EDCE 85 B TM Bedienungsanleitung

3 Oktober 2024

Indesit BDE 961483X W UK Bedienungsanleitung

3 Oktober 2024

Indesit IDC 8T3 B (UK) Bedienungsanleitung

22 September 2024

Indesit BDE 96436X W UK N Bedienungsanleitung

16 September 2024

Indesit YT M11 92K RX SPT Bedienungsanleitung

13 September 2024

Indesit YT M08 71 R SP Bedienungsanleitung

10 September 2024

Bedienungsanleitung Wäschetrockner

Neueste Bedienungsanleitung für -Kategorien-

GE Profile PFD95GSPTDS Bedienungsanleitung

16 Oktober 2024

Maytag MGD7100DC Maxima Bedienungsanleitung

16 Oktober 2024

Bosch WTA4000 Bedienungsanleitung

16 Oktober 2024

Bauknecht TRKP 7950 Bedienungsanleitung

16 Oktober 2024

Hoover DX C9DKG-80 Bedienungsanleitung

16 Oktober 2024

Teka THPD80 Bedienungsanleitung

16 Oktober 2024

BEKO B3T41242 Bedienungsanleitung

16 Oktober 2024

BEKO BM5T49243W Bedienungsanleitung

16 Oktober 2024

BEKO B3T67110 Bedienungsanleitung

16 Oktober 2024

BEKO BM3T48249W Bedienungsanleitung

16 Oktober 2024
