Overview
Dual Portable Wireless Speakers
User’s Guide for Model ISBW2116 v1527-01
Features
• Supports Bluetooth
• Automatic device reconnect
• Bluetooth Wireless range: 33 ft to main speaker/15 ft between speakers
• IPX4 Water Resistance
• Hands free Speakerphone
• Aux In 3.5 mm audio input
• Built in rechargeable lithium ion battery
• Battery life: approx. 5 hrs @50% volume
Includes
• 2 Micro-USB to USB cable
• 3.5mm audio cable
FCC WARNINGS
Warning: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
ADDITIONAL WARNINGS
• WARNING: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the rear or bottom of the apparatus.
• Mains plug is used as disconnect device and it should remain readily operable during intended use. In
order to disconnect the apparatus from the mains completely, the mains plug should be disconnected
form the mains socket outlet completely.
• WARNING: Fire/explosion hazard - Do not overcharge the battery. When charging the battery, do not
leave unattended for long periods of time.
• Battery shall not be exposed to excessive heat such as sunshine, re or the like.
• Lithium batteries, like all rechargeable batteries, are recyclable and should be recycled or disposed
of according to state and local guidelines. They should never be disposed of in normal household
waste, and they should never be incinerated, as they might explode. Contact your local government for
disposal or recycling practices in your area.
• WARNING: This product may contain chemicals known to the State of California to cause birth
defects, or other reproductive harm (California Prop 65). Wash hands after handling.
• This product meets and complies with all Federal regulations.
Top View
Volume Up/Down
Power/Connect
Speaker Indicator
Connect Speakers/
Skip Tracks
Pair Bluetooth/Play/Pause/Speaker
Function Mode
Indicator
Rear View
Power ON/OFF
Micro-USB Power Input
Carry Handle
Mic (front)
Aux In 3.5mm Audio Input
Function LED Indicators (Blue/Green)
Speaker Status Indicator Light
Aux In Solid Green
Pairing Bluetooth Quick Flashing Blue
Reconnecting Bluetooth Slow Flashing Blue
Bluetooth Paired Solid Blue
Speaker Pairing LED Indicators (Yellow)
Speaker Status Indicator Light
Speakers Pairing Flashing Yellow
Speakers Paired Solid Yellow
Battery LED Indicators (Red/Yellow)
Speaker Status Indicator Light
Low Battery Flashing Red/Yellow OFF
Charging Battery Solid Red/Yellow OFF
Battery Fully Charged Red OFF
To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the support
section at: www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes, visite la
sección de apoyo en: www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des questions
fréquemment posées, consultez la rubrique d’assistance sur: www.iLiveElectronics.com
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com
Customer Service: | Email Support: | Email Parts: 1-888-999-4215 prodinfo@dpiinc.com partsinfo@dpiinc.com
Copyright © 2016 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their
respective owners. Specications are subject to change without notice.
INTERNATIONAL SUPPORT
Protect for Today
Sustain for Tomorrow
Made
Green
Power & Charging
DC Power Input
Requires Micro-USB charging cable (included).
Each speaker must be charged independently. Battery life when not in use is
roughly 6 months. The battery must then be fully recharged. Charge each speaker
fully before use.
1. Using a Micro-USB cable (included), connect the larger to the USB plug
USB port of a powered on computer or USB power adaptor (not included).
The speaker should now charge.
Bluetooth
Pairing the Speakers
The speakers should be paired pairing to a Bluetooth device. This should BEFORE
only need to be done upon rst use. Make sure the speakers are fully charged
before beginning the pairing process.
1. Power on the speakers by sliding the power switch to the position on ON
both units.
2. The and Bluetooth Indicator Speaker Connection Indicator will ash
slowly in unison. If the Speaker Connection Indicator is not ashing, but is solid
yellow on both speakers, your speakers are already paired. Skip to the Pairing a
Bluetooth Device section.
3. Press the Connect Speakers button on both speakers simultaneously. The
Speaker Connection Indicators will ash quickly.
4. Wait until both are solid yellow. This Speaker Connection Indicators
indicates that the speakers have successfully paired.
5. For all future uses, please turn on both speakers and wait for them to
connect. If any pairing issues should occur, repeat the above steps.
Note : Pairing speakers does not work in Aux In mode..
Aux In
Using Aux In
Requires a 3.5mm audio cable (included).
Note: Aux In will automatically disable wireless
play modes.
1. Connect a 3.5mm audio cable to the
Aux In on the unit and the Input audio
output on an audio device.
The Pairing/Aux In Indicator will display a
solid green light.
2. Use the controls on the connected device
to select audio. Use the controls on the
device or the speaker to play, pause, skip,
and adjust the volume.
Pairing to a Bluetooth Device
Make sure you have rst followed the instructions for Pairing the Speakers. When
pairing, the device should remain within 3 feet of the speakers.
1. Press the Pair button ONLY ONE on of the speakers (this will be the left
speaker channel). The pair indicator will begin ashing quickly.
2. Using the controls on your Bluetooth device, select in your ISBW2116
Bluetooth settings.
3. If your device requests a password, enter the default password 0 0 0 0 .
4. Refer to the user’s manual for your specic device for instructions on pairing
and connecting Bluetooth devices.
5. When successfully paired, the pairing indicator will stop ashing and will
remain solid.
6. After initial pairing, the unit will stay paired unless unpaired manually by
the user or erased due to a reset of the device.
If your device should become unpaired for any reason, repeat the above steps.
If any pairing issues should occur, un-pair the unit on your Bluetooth device and
repeat the above steps.
If two speakers with the ISBW2116 name appear on the pairing list of your
device, erase one from your Bluetooth device and repeat the above steps.
Water Resistance
This unit has a water resistance rating of IPX4. This rating is suitable for indoor and
outdoor use in the presence of incidental or light exposure to splashing water,
rain, or snow. Water splashing against the enclosure from any angle should have
no harmful eects. It is not recommend to submerge this speaker in water for any
amount of time.
IMPORTANT: To ensure your speaker is prepared for use in a wet environment,
disconnect and remove any power cables, and tightly close the water cap on the
rear of the unit. If the water cap is not properly closed, water resistance will be
compromised and could result in damage to the speaker or personal injury.
WARNING: DO NOT, UNDER ANY
CIRCUMSTANCES, CHARGE THE
SPEAKER WHILE IT IS NEAR WATER,
AND ALLOW AMPLE TIME TO DRY
AFTER BEING SPLASHED.

Produktspezifikationen

Marke: ILive
Kategorie: Lautsprecher
Modell: ISBW2116B
