Models
Undercounter
Worktop
Prep Table
Refrigerated Kitchen Equipment
Steelheart B Series
Instruction Manual
Issued: 1-4-2021
hoshizakiamerica.com
2
WARNING
Only qualied service technicians should install and service the appliance. To
obtain the name and phone number of your local Hoshizaki Certied Service
Representative, visit www.hoshizaki.com. No installation or service should be
undertaken until the technician has thoroughly read this Instruction Manual.
Likewise, the owner/manager should not proceed to operate the appliance until the
installer has instructed them on its proper operation. Failure to install, operate, and
maintain the appliance in accordance with this manual may adversely affect safety,
performance, component life, and warranty coverage. Proper installation is the
responsibility of the installer. Product failure or property damage due to improper
installation is not covered under warranty.
Hoshizaki provides this manual primarily to assist qualied service technicians in the
installation, maintenance, and service of the appliance.
Should the reader have any questions or concerns which have not been satisfactorily
addressed, please call, send an e-mail message, or write to the Hoshizaki Technical
Support Department for assistance.
Phone: 1-800-233-1940; (770) 487-2331
Fax: 1-800-843-1056; (770) 487-3360
E-mail: techsupport@hoshizaki.com
618 Highway 74 South
Peachtree City, GA 30269
Attn: Hoshizaki Technical Support Department
Web Site: www.hoshizaki.com
NOTE: To expedite assistance, all correspondence/communication MUST include the
following information:
• Model Number
• Serial Number
• Complete and detailed explanation of the problem.
3
IMPORTANT
This manual should be read carefully before the appliance is installed and operated.
Read the warnings and guidelines contained in this manual carefully as they
provide essential information for the continued safe use and maintenance of the
appliance. Retain this manual for any further reference that may be necessary.
CONTENTS
Important Safety Information 4 .................................................................................................
I. Installation Instructions 8 .......................................................................................................
A. Location 8 ........................................................................................................................
B. Checks Before Installation 9 .............................................................................................
C. Setup 9 .............................................................................................................................
D. Solid Door Reversal..................................................................................................... 16
E. Door/Drawer Location Reversal .................................................................................. 19
F. Glass Door Reversal 29 ....................................................................................................
G. Electrical Connection 30 ..................................................................................................
H. Final Checklist 31 .............................................................................................................
II. Operating Instructions 32 ......................................................................................................
A. Important Notes About Usage 32 .....................................................................................
B. Startup 35 ........................................................................................................................
C. Controls and Adjustments 35 ...........................................................................................
1. Temperature Reading ............................................................................................. 35
2. Adjusting the Temperature ..................................................................................... 35
3. Control Module 36 ......................................................................................................
D. Defrost 37 .........................................................................................................................
1. Undercounter and Worktop Refrigerators 37 ...............................................................
2. Prep Table Refrigerators 37 ........................................................................................
3. Undercounter and Worktop Freezers 38 .....................................................................
E. Food Storage............................................................................................................... 39
F. Safety Devices 40 .............................................................................................................
G. Cooling Performance 40 ..................................................................................................
H. Cabinet Condensation 40 ................................................................................................
III. Cleaning and Maintenance Instructions 41 ..........................................................................
A. Cleaning 41 ......................................................................................................................
1. Exterior 41 ...................................................................................................................
2. Cabinet Interior 41 ......................................................................................................
3. Door/Drawer Gaskets 41 ............................................................................................
4. Shelves 41 ..................................................................................................................
5. Glass Door 41 .............................................................................................................
6. Drawers 42 .................................................................................................................
7. Worktop (Worktop Models) 42 .....................................................................................
8. Cutting Board (Prep Table Models) 42 ........................................................................
9. Rail, Rail Hood, and Rail Cover (Prep Table Models) 43 ............................................
10. Spill Guard 43 ...........................................................................................................
B. Maintenance 43 ................................................................................................................
IV. Preparing the Appliance for Periods of Non-Use 44 ............................................................
V. Disposal 45 ...........................................................................................................................
4
DANGER
Risk of Fire or Explosion
Flammable Refrigerant Used
• Follow handling instructions carefully
in compliance with U.S. government
regulations.
• Do not use mechanical devices to defrost.
• Do not puncture refrigerant tubing. Risk
of re or explosion due to puncture
of refrigerant tubing; follow handling
instructions carefully.
• Component parts shall be replaced with
like components.
• Servicing shall be done by factory
authorized service personnel to minimize
the risk of possible ignition due to
incorrect parts or improper service.
• Consult instruction manual/service manual
before attempting to install or service this
product. All safety precautions must be
followed.
• Dispose of properly in accordance with
federal or local regulations.
• Do not place any potential ignition sources
in or near the appliance.
Important Safety Information
Throughout this manual, notices appear to bring your attention to situations which could
result in death, serious injury, damage to the appliance, or damage to property.
DANGER Indicates a hazardous situation that, if not avoided, will result in
death or serious injury.
WARNING Indicates a hazardous situation that, if not avoided, could result
in death or serious injury.
NOTICE Indicates a situation that, if not avoided, could result in damage
to the appliance or property.
IMPORTANT Indicates important information about the use and care of the
appliance.
Risque De Feu Ou D'Explosion
Le Frigorigène Est Inammable
• Suivre attentivement les instructions
de manipulation conformément à la
réglementation gouvernementale.
• Ne pas utiliser d'appareils mécaniques
pour dégivrer le réfrigérateur.
• Ne pas perforer la tubulure contenant le
frigorigène. Risque de feu ou d'explosion
si la tubulure contenant le frigorigène
est perforée; suivre les instructions de
manutention avec soin.
• Les pièces des composants doivent être
remplacées par des pièces et accessoires
équivalents.
• L’entretien doit être effectué par le
personnel de service autorisé par le
fabricant an de minimiser les risques
d’inammation attribuables à l’installation
d’une pièce inadéquate ou à la mauvaise
exécution du service.
• Consulter le manuel du propriétaire/
guide de réparation avant de tenter une
réparation. Toutes les mesures de sécurité
doivent être respectées.
• Éliminer conformément aux règlements
fédéraux ou locaux.
• Ne placez aucune source d’inammation
potentielle dans ou près de l’appareil.
5
WARNING
The appliance should be destined only to
the use for which it has been expressly
conceived. Any other use should be
considered improper and therefore
dangerous. The manufacturer cannot be
held responsible for injury or damage
resulting from improper, incorrect, and
unreasonable use. Failure to install,
operate, and maintain the appliance
in accordance with this manual will
adversely affect safety, performance,
component life, and warranty coverage.
To reduce the risk of death, electric
shock, serious injury, or re, follow
basic precautions including the
following:
• Only qualied service technicians should
install and service the appliance.
• Wear appropriate personal protective
equipment (PPE) when servicing the
appliance.
• The appliance must be installed in
accordance with applicable national, state,
and local codes and regulations.
• Appliance is heavy. Use care when
lifting or positioning. Work in pairs when
needed to prevent injury or damage. Do
not lift using the top section or the doors/
drawers.
• To reduce the risk of electric shock, do not
touch the plug with damp hands.
• Unplug the appliance before servicing.
• The appliance requires an independent
power supply of proper capacity. See the
nameplate for electrical specications.
Failure to use an independent power
supply of proper capacity can result in a
tripped breaker, blown fuse, damage to
existing wiring, or component failure. This
could lead to heat generation or re.
• THE APPLIANCE MUST BE
GROUNDED. The appliance is equipped
with a NEMA5-15 three-prong grounding
plug to reduce the risk of potential
shock hazards. It must be plugged into a
properly grounded, independent 3-prong
wall outlet. If the outlet is a 2-prong outlet,
it is your personal responsibility to have
a qualied electrician replace it with a
properly grounded, independent 3-prong
wall outlet. Do not remove the ground
prong from the power cord and do not use
an adapter plug. Failure to follow these
instructions may result in death, electric
shock, or re.
• Do not use an extension cord.
• Do not use an appliance with a damaged
power cord. The power cord should not be
altered, jerked, bundled, weighed down,
pinched, or tangled. Such actions could
result in electric shock or re. To unplug
the appliance, be sure to pull the plug, not
the cord, and do not jerk the cord.
• The GREEN ground wire in the
factory-installed power cord is connected
to the appliance. If it becomes necessary
to remove or replace the power cord, be
sure to connect the power cord's ground
wire.
• Do not splash, pour, or spray water
directly onto or into the appliance. This
might cause short circuit, electric shock,
corrosion, or failure.
• Do not make any alterations to the
appliance. Alterations could result in
electric shock, injury, re, or damage to
the appliance.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory, or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for their
safety.
6
• Do not block air inlets or outlets, otherwise
cooling performance may be reduced.
• Do not tightly pack the cabinet. Allow some
space between items to ensure good air
ow. Also allow space between items and
interior surfaces.
• Do not put warm or hot foods in the cabinet.
Let them cool rst, or they will raise the
cabinet temperature and could deteriorate
other foods in the cabinet or overload the
appliance.
• Food storage and handling must comply
with applicable codes and regulations.
• All foods should be wrapped in plasticlm
or stored in sealed containers. Otherwise
foods may dry up, pass their smells onto
other foods, cause frost to develop, result
in poor appliance performance, or increase
the likelihood of cross-contamination.
Certain dressings and food ingredients,
if not stored in sealed containers, may
accelerate corrosion of the evaporator,
resulting in failure.
• Do not store items near air outlets.
Otherwise, items may freeze up and
crack or break causing a risk of injury or
contamination of other food.
WARNING, continued
• Children should be properly supervised
around the appliance.
• Do not climb, stand, or hang on the
appliance or doors/drawers or allow
children or animals to do so. Do not climb
into the appliance or allow children or
animals to do so. Death or serious injury
could occur or the appliance could be
damaged.
• Be careful not to pinch ngers when
opening and closing the doors/drawers
or rail cover (prep table models) or when
handling food pans. Be careful when
opening and closing the doors/drawers or
rail cover when children are in the area.
• Open and close the doors/drawers and
rail cover (prep table models) with care.
Opening the doors/drawers or rail cover
too quickly or forcefully may cause injury
or damage to the appliance or surrounding
equipment.
• Do not use combustible spray or place
volatile or ammable substances in or near
the appliance. They might catch re.
• Keep the area around the appliance clean.
Dirt, dust, or insects in the appliance could
cause harm to individuals or damage to
the equipment.
• Do not throw anything onto the shelves or
load any single shelf with more than 120lb.
(54.5 kg) of product. They might fall off and
cause injury.
• Do not load any single drawer with more
than 75 lb. (34 kg) of product. Depending
on the weight of product in the drawers,
secure the unit as necessary to prevent it
from overturning. Do not open more than
one drawer at a time.
• The appliance is designed only for
temporary storage of food. Employ sanitary
methods. Use for any other purposes (for
example, storage of chemicals or medical
supplies such as vaccine and serum)
could cause deterioration of stored items.
7
NOTICE
• Protect the oor when moving the
appliance to prevent damage to the oor.
• Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction. Do not
place anything on top of the appliance in
an undercounter installation. There must
be at least 1.5" (4 cm) overhead clearance
for proper ventilation. The factory-installed
rear bumpers must be in place to ensure
proper rear clearance. Blockage of airow
could negatively affect performance and
damage the appliance.
• Do not allow the appliance to bear any
outside weight.
• To prevent deformation or cracks, do not
spray insecticide onto the plastic parts or
let them come into contact with oil.
• To avoid damage to the gasket, use only
the door/drawer handle when opening
and closing.
• To avoid damage to the top seal, do not lift
the appliance by the top panel or remove
the top panel.
Additional Notice for Prep Table
Models
• Do not place anything on top of the rail
hood or rail cover and do not lift the
appliance by the rail hood or rail cover.
The rail hood and rail cover are not
designed to bear any outside weight.
WARNING, continued
Additional Warnings for Prep Table
Models
• The entire rail must always be covered
by rail dividers and pans (1/6 size, up to
6"(15cm)deep). Otherwise, the appliance
will not cool properly.
• Use only 1/6 size pans up to 6"(15cm)
deep. Do not use damaged pans.
• Ingredients must be pre-chilled to 37°F
(3°C) or less before placing in rail.
• Keep the rail cover closed when not actively
preparing food.
• The rail is for keeping ingredients cool while
preparing food. If not actively preparing
food for a long period such as overnight,
seal pans with plastic wrap in addition
to closing the rail cover. Depending on
conditions, the cabinet temperature setting
may need to be adjusted to prevent items
from freezing. Alternatively, seal ingredients
and store them in a refrigerator or freezer.
8
I. Installation Instructions
WARNING
• The appliance must be installed in accordance with applicable national, state, and
local regulations.
• Appliance is heavy. Use care when lifting or positioning. Work in pairs when needed
to prevent injury or damage. Do not lift using the top section or the doors/drawers.
• Do not tilt the appliance more than 45°.
A. Location
WARNING
• The appliance is not intended for outdoor use.
• Undercounter and Worktop: Certied to maintain NSF temperatures up to 100°F
(38°C).
• Prep Tables: Certied to maintain NSF temperatures between 45°F to 86°F (7°C to
30°C) and engineered to maintain NSF temperatures up to 100°F (38°C).
• Operation of the appliance, for extended periods, outside of this normal
temperature range may affect appliance performance.
For best operating results:
• The appliance should not be located next to ovens, grills, or other high heat producing
equipment.
• The location should provide a rm and level foundation for the appliance.
• The appliance should not be located in a corrosive environment.
• The factory-installed rear bumpers must be in place to ensure proper rear clearance.
For undercounter and worktop models, a minimum of 1.5" (4 cm) overhead clearance
should be provided for proper ventilation. For prep table models, a minimum of
10"(25cm) clearance above the rail hood should be provided to allow the rail cover to
open.
9
B. Checks Before Installation
WARNING
Refer to the nameplate for electrical specications. The nameplate is located on
the right side wall of the cabinet interior. For more electrical connection details, see
"I.G. Electrical Connection." We reserve the right to make specication and design
changes without prior notice.
• Visually inspect the exterior of the shipping package and immediately report any damage
to the carrier. Upon opening the package, any concealed damage should also be
immediately reported to the carrier.
• Remove the shipping carton, tape, and packing material. Also remove the protective plastic
lm from both the exterior panels and the interior door/drawer panel. If the appliance is
exposed to the sun or to heat, remove the lm after the appliance cools.
• Remove all accessory containers before discarding the packing materials. Dispose of all
packing materials in a proper and environmentally responsible manner.
• Check for missing or damaged accessories.
C. Setup
1. Caster Installation, Leveling the Appliance, and Door Alignment
a) Caster Installation
1) Move as close to the nal location as possible.
2) Remove the 2 bolts securing the appliance to the pallet, then remove the appliance
from the pallet. Block the appliance securely at a height of 8" (20 cm) off the oor. Do
not lay the appliance down.
Nameplate
10
Door
Locking Casters
in Front
Fig. 1
3) Attach the casters to the bottom of the appliance. Locking casters should be attached
to the front of the appliance. See Fig. 1. NOTICE! Ensure casters are completely
threaded into appliance and tight.
Fig. 2
Caster
Fig. 3
Shim Plates
Rotate each shim plate 90°
from the adjoining shim
plate. Maximum of 3 shim
plates per caster.
Caster
3) Position the necessary number of shim plates in place (no more than 3 per caster).
If using more than one shim plate, rotate each additional shim plate 90° from the
adjoining shim plate so that the slots are not aligned. See Fig. 3.
Note: Do not shim the rear of the appliance higher than the front as this could affect
door performance.
b) Leveling the Appliance and Door Alignment
After installing the casters, lower the appliance to the oor and check the level of the
appliance and the alignment of the doors. If the appliance is out of level or the doors are
out of alignment, follow the steps below. Otherwise, continue to the next section.
1) Secure the doors. Raise and block the appliance. Make sure the appliance is stable.
2) Unscrew the appropriate caster to the approximate desired height. See Fig. 2.
11
Fig. 5
2. Check the Refrigeration Circuit
• Visually check that the refrigerant lines do not rub or touch other lines or surfaces and
that the condenser fan blade turns freely.
• Check that the compressor is securely attached.
3. Position the Appliance and Lock the Front Casters
The front casters on the appliance are lockable. After positioning the appliance in its nal
location, lock the front casters.
4. Install the Shelves and Cabinet Thermometer
1) For each shelf, place the shelf support clips into the pilasters at the desired height
(4 shelf support clips per shelf). See Fig. 5.
2) Place the shelves in position on the support clips.
3) Remove the cabinet thermometer from the accessory bag. Place the cabinet
thermometer on the shelf as shown in Fig. 5. Note: Placement of the cabinet
thermometer may be moved based on use.
Shelf Support Clip
Pilaster
Shelf
Shim Plates
Caster
Fig. 4
4) Tighten the caster. See Fig. 4. NOTICE! Make sure the caster is tight and no slack is
left between the caster, shim plates, and appliance.
5) Repeat the procedure for other casters as needed.
6) Lower the appliance to the oor.
Caster Tight Against
Shim Plates and Unit
Shelf Support Clip
Cabinet Thermometer
12
5. Install the Rail Dividers and Pans (Prep Table Models)
Install the rail dividers and 1/6 size pans included with the appliance. See Fig. 6 and the
table below. The entire rail must always be covered by rail dividers and pans. Otherwise,
the appliance will not cool properly. Use pans with a depth of up to 6"(15cm). Do not use
damaged rail dividers or pans.
Pans
Rail Dividers
Fig. 6
Rail Divider Layout
-8 Models
SR27B-8 SR48B-8, SR60B-8
Front-to-Back: HS-5187 (13-3/4"; 348 mm) Qty 1
Side-to-Side: HS-5185 (12-1/2"; 319 mm) Qty 2
Front-to-Back: HS-5188 (12-5/8"; 322 mm) Qty 1
Side-to-Side: HS-5189 (13-5/8"; 346 mm) Qty 2
-10, -15M Models
SR36B-10 SR36B-15M
Front-to-Back: HS-5187 (13-3/4"; 348 mm) Qty 2
Side-to-Side (Outer): HS-5185 (12-1/2"; 319 mm) Qty 1
Side-to-Side: HS-5186 (Center) (12-1/2"; 316 mm) Qty 1
Front-to-Back: HS-5184 (20-3/4"; 526 mm) Qty 2
Side-to-Side (Outer): HS-5185 (12-1/2"; 319 mm) Qty 2
Side-to-Side: HS-5186 (Center) (12-1/2"; 316 mm) Qty 2
-12, -12M Models
SR48B-12, SR60B-12, SR72B-12 SR27B-12M, SR48B-12M, SR60B-12M
Front-to-Back: HS-5188 (12-5/8"; 322 mm) Qty 2
Side-to-Side (Outer): HS-5189 (13-5/8"; 346 mm) Qty 2
Side-to-Side (Center): HS-5190 (13-1/2"; 344 mm) Qty 1
Front-to-Back: HS-5184 (20-3/4"; 526 mm) Qty 1
Side-to-Side: HS-5185 (12-1/2"; 319 mm) Qty 4
13
Rail Divider Layout, continued
-16 Models
SR60B-16, SR72B-16
Front-to-Back: HS-5188 (12-5/8"; 322 mm) Qty 3
Side-to-Side (Outer): HS-5189 (13-5/8"; 346 mm) Qty 2
Side-to-Side (Center): HS-5190
(13-1/2"; 344 mm)
Qty 2
-18, -18M Models
SR72B-18 SR48B-18M, SR60B-18M, SR72B-18M
Front-to-Back: HS-5188 (12-5/8"; 322 mm) Qty 2
Side-to-Side (Outer): HS-5191 (20-5/8"; 523 mm) Qty 2
Side-to-Side (Center): HS-5192 (20-1/2"; 520 mm) Qty 1
Front-to-Back: HS-5184 (20-3/4"; 526 mm) Qty 2
Side-to-Side: HS-5185 (Outer) (12-1/2"; 319 mm) Qty 4
Side-to-Side: HS-5186 (Center) (12-1/2"; 316 mm) Qty 2
-24M Models
SR60B-24M, SR72B-24M
Front-to-Back: HS-5184 (20-3/4"; 526 mm) Qty 2
Side-to-Side: HS-5185 (12-1/2"; 319 mm) Qty 8
-30M Models
SR72B-30M
Front-to-Back: HS-5184 (20-3/4"; 526 mm) Qty 3
Side-to-Side (Outer): HS-5185 (12-1/2"; 319 mm) Qty 8
Side-to-Side (Center): HS-5186 (12-1/2"; 316 mm) Qty 2
14
6. Install the Rail Cover (Prep Table Models)
1) Install and tighten the pivot pins, washers, and pivot screws on the rail hood with the
pivot pin shafts facing inward towards the open rail area. See Fig. 7.
2) Models with Two Rail Covers: Install and tighten the pivot pins, washers, and pivot
screws to the center hinge brackets, then secure the center hinge brackets using the
4×8 screws provided. See Fig.8.
3) Install the rail cover(s) by squeezing in slightly on the rail cover side panels and aligning
the holes in the rail cover side panels with the pivot pins. See Fig. 9.
Fig. 7
Pivot Screw
Rail Hood
Pivot Pin
Fig. 8
Fig. 9 Rail Hood
Rail Cover
Pivot Pins
4×8 Screws
Pivot Screw
Pivot Screw
Pivot Pin
Pivot Pin
4×8 Screws Center Hinge
Bracket
For Models with Two Rail Covers
Center Hinge
Bracket
Washer
Washer
Washer
15
Outer Cutting Board Brackets
and 5×10 Screws
Cutting Board
7. Attach the Cutting Board Brackets and Cutting Board (Prep Table Models)
1) Remove the screws from the cutting board bracket mounting locations on the appliance.
See Fig. 10a for Sandwich Top models and Fig. 10b for Mega Top models.
2) Use the screws removed in step 1 to attach the cutting board brackets.
3) Slide the cutting board into the cutting board brackets. WARNING! Make sure the
cutting board brackets and cutting board are secure. Otherwise, the cutting board
could come off and cause injury.
Inner Cutting Board Brackets and 5×12 Screws
Quantity:
2 for SR27B and SR36B Mega Top Models
3 for SR48B and SR60B Mega Top Models
4 for SR72B Mega Top Models
Fig. 10a
Use Upper Hole
Sandwich Top Models
Outer Cutting Board Brackets
and 5×10 Screws
Cutting Board
Inner Cutting Board Brackets and 5×12 Screws
Quantity:
1 for SR27B and SR36B Sandwich Top Models
2 for SR48B Sandwich Top Models
3 for SR60B and SR72B Sandwich Top Models
Fig. 10b
Mega Top Models
16
5) Remove the lower hinge bracket. See Fig. 13. Be sure to leave the thrust washer in
place.
6) Clear the foam from the lower hinge bracket mounting holes prior to securing lower
hinge bracket in its new location. Install the lower hinge bracket in its new location. Be
sure the lower hinge bracket is pushed all the way in and the thrustwasher is in its
original position.
D. Solid Door Reversal
The appliance is provided with a cabinet design which, after being delivered to the
installation location, permits changing of the door swing from left to right or right to left. To
change the door swing, follow the steps below. Example shows change from right hinged
to left hinged.
WARNING
• Wear proper PPE (personal protection equipment) when executing these
procedures (safety glasses and gloves).
• Keep ngers away from edge of upper hinge bracket. Spring cartridge can cause
the upper hinge bracket to move suddenly with extreme force.
Door and Lower Hinge Removal and Relocation
1) Remove all items from the appliance. Make sure the appliance is unplugged from the
electrical outlet. Move the appliance out for ease of access then lock the casters.
2) With the door closed, loosen, but do not remove, the upper hinge bracket outer screw.
See Fig. 11. Next, open the door to the fully open position and remove the upper hinge
bracket inner screw. See Fig. 12.
3) Slide the upper hinge bracket out from under the outer screw and remove the door.
WARNING! Keep away from upper hinge bracket. Upper hinge bracket may spring
closed.
4) Replace the upper hinge bracket inner screw in its original position and tighten, then
tighten the upper hinge bracket outer screw.
Fig. 11 Fig. 12
Upper Hinge
Bracket Inner
Screw
Door Fully Open
WARNING! Upper
hinge bracket may
spring closed
Upper Hinge Bracket
Outer Screw
Door Closed
Upper Hinge Bracket
Upper Hinge
Bracket
Lower Hinge Bracket
Fig. 13
Bolts
Thrust
Washer
Lower Hinge Bracket
Bolts
Thrust Washer
Lower Hinge
Bracket
Mounting Holes
17
Upper Hinge Bracket Removal and Spring Cartridge Relocation
7) While preventing the upper hinge bracket from rotating, remove the upper hinge bracket
from the spring cartridge. See Fig. 14. Note which side of the upper hinge bracket is
facing up.
8) Remove the ller cap, ller screws, and spring cartridge. See Fig. 15. Leave the thrust
washers in place on the spring cartridge. NOTICE! Spring cartridge may be difficult
to remove. Be careful not to damage the nish.
9) Clear foam from the spring cartridge hole to allow for spring cartridge installation.
See Fig. 16. Install the spring cartridge in its new location. Reinstall the ller cap and
ller screws on the opposite side of the door.
Lower Door Prep and Upper Hinge Bracket Relocation
10) Remove the ller cap and nylon bearing from the bottom of the door. SeeFig.17.
Reinstall on the opposite side.
11) Make sure the thrust washers are in place on the spring cartridge, then ip the upper
hinge bracket over from its original position and install onto the spring cartridge in
the door open position. See Fig. 18. The upper hinge bracket should be positioned as
shown.
Upper Hinge
Bracket
Door
Fig. 14
Screw
Washer Filler Cap Door
Spring Cartridge
Filler Screws
Thrust Washers
Screws
Fig. 15
Filler Screws
Filler Cap
Door
Spring Cartridge
Screws
Fig. 16
Spring Cartridge Hole
Upper Hinge Bracket
Inside of
Door
Screw
Washer
Fig. 17 Fig. 18
Filler Cap
Nylon Bearing
Thrust Washers
Upper Hinge
Bracket Inner
Screw Hole
Upper Hinge
Bracket Outer
Screw Slot
18
Door Installation
12) Remove the black plastic ller cap located from the hole above where the spring
cartridge screw will line up. Note: The black plastic ller cap is not reusable.
13) Remove the upper hinge bracket screws from the new location and apply Loctite
Threadlocker Blue 242 or 243 to the threads. Next, start the upper hinge bracket
outer screw into the appliance. Rotate a few threads into the appliance; do not tighten
thescrew. See Fig. 19.
14) Be sure the lower hinge bracket thrust washer is in place, then place the door on the
lower hinge bracket in the fully open position. Slide the door upper hinge bracket outer
slot onto the upper hinge bracket outer screw. See Fig. 20.
15) Install the upper hinge bracket inner screw and tighten.
Fig. 19
Upper Hinge Bracket
Outer Screw
Upper Hinge
Bracket Inner
Screw
Black Plastic Filler Cap Upper Hinge
Bracket Outer
Screw
Fig. 20
Door Fully Open
Lower Hinge Bracket
Upper Hinge Bracket
Outer Screw
Upper Hinge
Bracket Outer
Screw
Door Fully Open
Upper Hinge
Bracket
Upper Hinge
Bracket Inner
Screw
Upper Hinge
Bracket WARNING! Upper
hinge bracket may
spring closed
Thrust
Washer
19
16) Close the door and tighten the upper hinge bracket outer screw.
See Fig. 21.
Fig. 21
Upper Hinge
Bracket
Upper Hinge Bracket
Outer Screw
Door Fully Closed
17) Check the door operation to assure it opens and closes properly. Note: Hold door at
45°angle from closed position and release. Door should close on its own. If not, adjust
hinge bracket.
18) Unlock the casters and move the appliance back into its original position. Lock the
casters once in position, then plug the appliance back into the electrical outlet. Allow the
appliance to cool down prior to putting product back in.
E. Door/Drawer Location Reversal
The appliance is provided with a cabinet design which, after being delivered to the
installation location, permits changing of the drawer and door locations. To change the
drawer and door locations, follow the steps below. Example shows UR48B-D2.
WARNING
• Wear proper PPE (personal protection equipment) when executing these
procedures (safety glasses and gloves).
• Keep ngers away from edge of upper hinge bracket. Spring cartridge can cause
the upper hinge bracket to move suddenly with extreme force.
Drawer and Drawer Frame Removal
1) Remove all items from the appliance. Make sure the appliance is unplugged from the
electrical outlet. Move the appliance out for ease of access then lock the casters.
See Fig. 22.
Fig. 22 Casters
Model Shown: UR48B-D2
20
2) Remove the drawers. Pull the drawer out to its fully extended position. Open the safety
clips (one on each side) by sliding them forward, then rotating them up. See Fig. 23.
Lift up on the handle slightly, then pull to disengage the drawer. Be sure to support the
rear and front of the drawer while removing it. WARNING! Be sure to close the safety
clips when reinstalling the drawer.
Fig. 24
Horizontal Mullion Screws
Horizontal Mullion
Silicone
Horizontal Mullion Silicone
Horizontal Mullion
Upper Drawer
Lower Drawer
Drawer
Slides
3) Remove the 4 horizontal mullion screws, then cut the horizontal mullion silicone loose
and remove the horizontal mullion. See Fig. 24.
Fig. 23
Safety Clips
Safety Clip
Closed
Safety Clip
Open
21
4) Remove the hex-bolts from the 2 right (front and rear) and 2 left (front and rear) brackets
(2 hex-bolts per bracket), then remove the right and left drawer frames. See Fig. 25.
Fig. 25
Right Rear
Hex-Bolts
Right Front
Hex-Bolts
Left Drawer
Frame
Right Drawer
Frame
Right Drawer Frame
Left Rear
Hex-Bolts
Left Front
Hex-Bolts
Left Drawer Frame
Left
Rear
Bracket
Left Front
Bracket
Right
Rear
Bracket
Right Front
Bracket
Left
Rear
Bracket
Left Front
Bracket
Left
Rear
Bracket
Left Front
Bracket
Right
Rear
Bracket
Right Front
Bracket
Left Drawer
Frame
Right
Rear
Bracket
Right Front
Bracket
Right Drawer Frame
22
Pilaster and Inner Brackets Relocation
5) Remove the shelf from the door section, then remove the pilasters.
See Fig. 26.
7) Remove the vertical mullion bracket. Rotate 180 degrees and mount it in the vertical
mullion right mounting holes. See Fig. 28.
Shelf
Right Side Pilasters
Fig. 26
Fig. 28
6) Remove the center rear drawer frame bracket and the ller screw. See Fig. 27. Slide the
center rear drawer frame bracket over to the new location and secure it. Place the ller
screw in the former center rear drawer frame bracket hole.
Fig. 27
Center Rear
Drawer Frame
Bracket
Center Rear
Drawer Frame
Bracket
Center Rear
Drawer Frame
Bracket
Vertical Mullion
Bracket
Vertical Mullion Bracket Rotation
Vertical Mullion Vertical Mullion
Vertical Mullion
Pilaster
Center Rear
Pilaster
Vertical
Mullion
Bracket
New Center
Rear Drawer
Frame Bracket
Location
Vertical Mullion
Bracket
Vertical Mullion
Right Mounting
Holes
Vertical Mullion
Filler Screw
Filler Screw
Vertical Mullion Left
Mounting Holes
23
8) Place and secure the pilasters and shelf support clips in their new location. See Fig. 29.
Replace the shelf.
Door Relocation
9) With the door closed, loosen, but do not remove, the upper hinge bracket outer screw.
See Fig. 30. Next, open the door to the fully open position and remove the upper hinge
bracket inner screw. See Fig. 31.
10) Slide the upper hinge bracket out from under the outer screw and remove the door.
WARNING! Keep away from upper hinge bracket. Upper hinge bracket may spring
closed.
11) Replace the upper hinge bracket inner screw in its original position and tighten, then
tighten the upper hinge bracket outer screw.
Upper Hinge
Bracket Outer
Screw
Door Closed
Upper Hinge
Bracket Inner
Screw
Door Fully Open
WARNING! Upper
hinge bracket may
spring closed
Fig. 30
Upper Hinge Bracket
Upper Hinge Bracket
Fig. 31
Left Side Pilasters
Center Rear
Pilaster
Vertical Mullion Pilaster
Center Rear Drawer
Frame Bracket
Vertical Mullion
Vertical Mullion
Bracket
Fig. 29
24
12) Remove the lower hinge bracket. See Fig. 32. Be sure to leave the thrust washer in
place.
13) Install the lower hinge bracket in its new location. Be sure the lower hinge bracket is
pushed all the way in and the thrust washer is in its original position.
Lower Hinge Bracket
Bolts
Thrust
Washer
Lower Hinge Bracket
Bolts
Thrust Washer
Fig. 32
Fig. 33
Upper Hinge Bracket
Outer Screw Upper Hinge
Bracket Inner
Screw
Black Plastic Filler Cap
Upper Hinge
Bracket Outer
Screw
Lower Hinge
Bracket
Mounting Holes
14) Remove the black plastic ller cap located from the hole above where the spring
cartridge screw will line up. Note: The black plastic ller cap is not reusable.
15) Remove the upper hinge bracket screws from the new location and apply Loctite
Threadlocker Blue 242 or 243 to the threads. Next, start the upper hinge bracket
outer screw into the appliance. Rotate a few threads into the appliance; do not tighten
thescrew. See Fig. 33.
16) Be sure the lower hinge bracket thrust washer is in place, then place the door on the
lower hinge bracket in the fully open position. Slide the door upper hinge bracket outer
slot onto the upper hinge bracket outer screw. See Fig. 34.
17) Install the upper hinge bracket inner screw and tighten.
Upper Hinge
Bracket Inner
Screw
Door Fully Open
WARNING! Upper
hinge bracket may
spring closed
Fig. 34
Upper Hinge
Bracket Outer
Screw
Upper Hinge
Bracket Outer
Screw
Door Fully
Open
Lower Hinge
Bracket
Upper Hinge
Bracket
Thrust Washer
Upper Hinge
Bracket
25
18) Close the door and tighten the upper hinge bracket outer screw. See Fig. 35.
Upper Hinge Bracket
Outer Screw
Upper Hinge Bracket
Door Fully Closed
Fig. 35
19) Check the door operation to assure it opens and closes properly. Note: Hold door at
45°angle from closed position and release. Door should close on its own. If not, adjust
hinge bracket.
26
Center Rear
Drawer Frame
Bracket
Fig. 36
Vertical
Mullion
Hex-Bolts
Drawer Relocation
Left Drawer Frame Relocation
20) Place the left rear bracket in place on the center rear drawer frame bracket with
hex-bolts removed in step4. Leave loose, do not tighten at this time. See Fig. 36.
21) Place the left front bracket in place on the vertical mullion bracket with the hex-bolts
removed in step 4. See Fig. 36. Leave loose, do not tighten at this time.
Left Rear
Bracket
Left Front Bracket
Vertical Mullion
Bracket
Left Rear
Bracket
Center Rear
Drawer Frame
Bracket
Left Front Bracket
Vertical
Mullion
Vertical Mullion
Bracket
22) Place the left drawer frame in the appliance and align under the left rear bracket and
tighten, then align under the left front bracket and tighten. See Fig. 37.
Note: Be sure the left drawer frame is under both the left rear bracket lip and left front
bracket lip.
Left Drawer Frame
Fig. 37
Left Rear Bracket Lip
Left Front Bracket Lip
27
Right Drawer Frame Relocation
23) Place the right rear bracket in place on the right side panel with the hex-bolts removed
in step4. Leave loose, do not tighten at this time. See Fig. 38.
24) Place the right front bracket in place on the right side panel with the hex-bolts removed
in step4. Leave loose, do not tighten at this time. See Fig. 38.
Vertical
Mullion
Hex-Bolts
Right Rear
Bracket
Right Front Bracket
Right Rear
Bracket
Right Front Bracket
Vertical
Mullion
25) Place the right drawer frame in the appliance and align under the right rear bracket and
tighten, then align under the right front bracket and tighten. See Fig. 39.
Note: Be sure the right drawer frame is under both the right rear bracket lip and right
front bracket lip.
Fig. 38
Fig. 39
Right Drawer Frame
Right Rear
Bracket Lip
Right Front
Bracket Lip
28
Fig. 40
Horizontal Mullion
Silicone Location for
Horizontal Mullion
Horizontal Mullion Replacement
26) Place the horizontal mullion in its correct position and secure with screws removed in
step3.
27) Place a bead of food grade silicone down the 2 outside vertical gaps between the
mullion and appliance. See Fig. 40.
Silicone Location for
Horizontal Mullion
Model Shown: UR48B-D2
29
28) Place the lower drawer in the lower drawer slides and the upper drawer in the upper
drawer slides. See Fig. 41. WARNING! Be sure to close the safety clips when
reinstalling the drawer.
29) Make sure all gaskets are making good contact. Using a ashlight, check that there are
no openings around all gaskets.
30) Unlock the casters and move the appliance back into its original position. Lock the
casters once in position, then plug the appliance back into the electrical outlet. Allow the
appliance to cool down prior to loading it with food products.
Fig. 41
Model Shown: UR48B-D2
F. Glass Door Reversal
This appliance is provided with a cabinet design which, after being delivered to the
installation location, permits changing of the door swing from left to right or right to left.
To change the door swing, an HS kit from your local Hoshizaki distributor is required.
See the table below. NOTICE! Improper installation of the HS kit may result in the
doors not closing completely and/or the gaskets not sealing correctly. For further
details, contact your local Hoshizaki distributor or Hoshizaki Technical Support at
1-800-233-1940.
Door Type Convert HS Kit Number
Glass Door Right Hinge to Left Hinge HS-5258
Left Hinge to Right Hinge HS-5259
30
G. Electrical Connection
WARNING
• Electrical connection must meet national, state, and local electrical code
requirements. Failure to meet these code requirements could result in death,
electric shock, serious injury, re, or severe damage to equipment.
• The appliance requires an independent power supply of proper capacity. See the
nameplate for electrical specications. Failure to use an independent power supply
of proper capacity can result in a tripped breaker, blown fuse, damage to existing
wiring, or component failure. This could lead to heat generation or re.
• THE APPLIANCE MUST BE GROUNDED. The appliance is equipped with a
NEMA5-15 three-prong grounding plug to reduce the risk of potential shock
hazards. It must be plugged into a properly grounded, independent 3-prong wall
outlet. If the outlet is a 2-prong outlet, it is your personal responsibility to have a
qualied electrician replace it with a properly grounded, independent 3-prong wall
outlet. Do not remove the ground prong from the power cord and do not use an
adapter plug. Failure to follow these instructions may result in death, electric shock,
orre.
• To reduce the risk of electric shock, do not touch the plug with damp hands.
• Do not use an extension cord.
• Do not use an appliance with a damaged power cord. The power cord should not
be altered, jerked, bundled, weighed down, pinched, or tangled. Such actions could
result in electric shock or re. To unplug the appliance, be sure to pull the plug, not
the cord, and do not jerk the cord.
• The GREEN ground wire in the factory-installed power cord is connected to the
appliance. If it becomes necessary to remove or replace the power cord, be sure to
connect the power cord's ground wire.
• Usually an electrical permit and services of a licensed electrician are required.
• The maximum allowable voltage variation is ±10 percent of the nameplate rating.
31
H. Final Checklist
1) Is the appliance level?
2) Have the casters been properly installed and have the front casters been locked?
3) Is the appliance in a site where the ambient temperature is constantly within 45°F to
100°F (7°C to 38°C)?
4) Have the shipping carton, tape, and packing material been removed from the
appliance? Hasthe protective plastic lm been removed from both the exterior panels
and the interior door/drawer panel?
5) Have the appliance and accessories been checked for shipping damage?
6) Are the factory-installed rear bumpers in place to ensure proper rear clearance? For
undercounter and worktop models, is there at least 1.5" (4 cm) overhead clearance for
proper ventilation? For prep table models, is there at least 10"(25cm) clearance above
the rail hood to allow the rail cover to open?
7) For prep table models, have the rail dividers, pans, rail cover, cutting board brackets,
and cutting board been properly installed?
8) Has the power supply voltage been checked or tested against the nameplate rating?
Is the power supply a properly grounded, independent wall outlet? Does the electrical
connection meet all national, state, and local code and regulation requirements?
9) Have the refrigerant lines been checked to make sure they do not rub or touch other
lines or surfaces? Has the condenser fan blade been checked to make sure it turns
freely? Is the compressor securely attached?
10) Have the shelves been adjusted to the desired height?
11) Has the end user been given the instruction manual, and instructed on how to operate
the appliance and the importance of the recommended periodic maintenance?
12) Has the end user been given the contact information of an authorized service agent?
13) Has the warranty card been lled out and forwarded to the factory for warranty
registration?
32
II. Operating Instructions
A. Important Notes About Usage
DANGER
Risk of Fire or Explosion
Flammable Refrigerant Used
• Do not use mechanical devices to defrost.
• Do not puncture refrigerant tubing. Risk
of re or explosion due to puncture
of refrigerant tubing; follow handling
instructions carefully.
• Do not place any potential ignition sources
in or near the appliance.
Risque De Feu Ou D'Explosion
Le Frigorigène Est Inammable
• Ne pas utiliser d'appareils mécaniques
pour dégivrer le réfrigérateur.
• Ne pas perforer la tubulure contenant le
frigorigène. Risque de feu ou d'explosion
si la tubulure contenant le frigorigène
est perforée; suivre les instructions de
manutention avec soin.
• Ne placez aucune source d’inammation
potentielle dans ou près de l’appareil.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory, or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
• Children should be properly supervised
around the appliance.
• Do not climb, stand, or hang on the
appliance or doors/drawers or allow
children or animals to do so. Do not climb
into the appliance or allow children or
animals to do so. Death or serious injury
could occur or the appliance could be
damaged.
• Be careful not to pinch ngers when
opening and closing the doors/drawers
or rail cover (prep table models) or when
handling food pans. Be careful when
opening and closing the doors/drawers or
rail cover when children are in the area.
• Open and close the doors/drawers and
rail cover (prep table models) with care.
Opening the doors/drawers or rail cover
too quickly or forcefully may cause
injury or damage to the appliance or
surrounding equipment.
• Do not use combustible spray or place
volatile orammable substances in or
near the appliance. They might catch re.
• Keep the area around the appliance clean.
Dirt, dust, or insects in the appliance
could cause harm to individuals or
damage to the equipment.
• Do not throw anything onto the shelves
or load any single shelf with more than
120lb. (54.5 kg) of product. They might fall
off and cause injury.
• Do not load any single drawer with more
than 75 lb. (34 kg) of product. Depending
on the weight of product in the drawers,
secure the unit as necessary to prevent it
from overturning. Do not open more than
one drawer at a time.
WARNING
• Only qualied service technicians should
install and service the appliance.
• Wear appropriate personal protective
equipment (PPE) when servicing the
appliance.
• Failure to install, operate, and maintain
the appliance in accordance with this
manual may adversely affect safety,
performance, component life, and
warranty coverage.
• To reduce the risk of electric shock, do
not touch the plug with damp hands.
• Do not splash, pour, or spray water
directly onto or into the appliance. This
might cause short circuit, electric shock,
corrosion, or failure.
33
WARNING, continued
• The appliance is designed only for
temporary storage of food. Employ
sanitary methods. Use for any other
purposes (for example, storage of
chemicals or medical supplies such
as vaccine and serum) could cause
deterioration of stored items.
• Do not block air inlets or outlets, otherwise
cooling performance may be reduced.
• Do not tightly pack the cabinet. Allow
some space between items to ensure
good airow. Also allow space between
items and interior surfaces.
• Do not put warm or hot foods in the
cabinet. Let them cool rst, or they will
raise the cabinet temperature and could
deteriorate other foods in the cabinet or
overload the appliance.
• Food storage and handling must comply
with applicable codes and regulations.
• All foods should be wrapped in plastic
lm or stored in sealed containers.
Otherwise foods may dry up, pass their
smells onto other foods, cause frost
to develop, result in poor appliance
performance, or increase the likelihood of
cross-contamination. Certain dressings
and food ingredients, if not stored in
sealed containers, may accelerate
corrosion of the evaporator, resulting in
failure.
• Do not store items near air outlets.
Otherwise, items may freeze up and
crack or break causing a risk of injury or
contamination of other food.
Additional Warnings for Prep Table
Models
• The entire rail must always be covered
by rail dividers and pans (1/6 size, up
to 6"(15cm)deep). Otherwise, the
appliance will not cool properly.
• Use only 1/6 size pans up to 6"(15cm)
deep. Do not use damaged pans.
• Ingredients must be pre-chilled to 37°F
(3°C) or less before placing in rail.
• Keep the rail cover closed when not
actively preparing food.
• The rail is for keeping ingredients cool
while preparing food. If not actively
preparing food for a long period such
as overnight, seal pans with plastic
wrap in addition to closing the rail cover.
Depending on conditions, the cabinet
temperature setting may need to be
adjusted to prevent items from freezing.
Alternatively, seal ingredients and store
them in a refrigerator or freezer.
34
NOTICE
• Protect the oor when moving the
appliance to prevent damage to the oor.
• Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction. Do not
place anything on top of the appliance
in an undercounter installation. There
must be at least 1.5" (4 cm) overhead
clearance for proper ventilation. The
factory-installed rear bumpers must be
in place to ensure proper rear clearance.
Blockage of airow could negatively
affect performance and damage the
appliance.
• Do not allow the appliance to bear any
outside weight.
• To prevent deformation or cracks, do not
spray insecticide onto the plastic parts or
let them come into contact with oil.
• To avoid damage to the gasket, use only
the door/drawer handle when opening
and closing.
• To avoid damage to the top seal, do not
lift the appliance by the top panel or
remove the top panel.
• Do not leave the doors/drawers open.
Additional Notice for Prep Table
Models
• Do not place anything on top of the rail
hood or rail cover and do not lift the
appliance by the rail hood or rail cover.
The rail hood and rail cover are not
designed to bear any outside weight.
35
Fig. 42 Cabinet Temperature Control Dial
(shown in "OFF" position)
Cabinet Thermometer
(located on shelf)
B. Startup
WARNING
All parts are factory-adjusted. Improper adjustments may adversely affect safety,
performance, component life, and warranty coverage.
1) Plug the appliance into the electrical outlet. WARNING! To reduce the risk of electric
shock, do not touch the plug with damp hands. At startup, there is a slight delay
before the compressor starts.
2) Allow the appliance to cool down prior to loading it with food products. For prep table
models, the entire rail must be covered by rail dividers and pans (1/6 size, up to
6"(15cm)deep) and the rail cover must be closed. Otherwise, the appliance will not
cool properly. Leave the pans empty until the appliance cools down. Wash the pans
and cutting board before use. WARNING! Make sure the cutting board brackets and
cutting board are secure. Otherwise, the cutting board could come off and cause
injury.
C. Controls and Adjustments
1. Temperature Reading
A thermometer with both °F and °C scales is mounted in the cabinet. See Fig. 42.
2. Adjusting the Temperature
The appliance features a cabinet temperature control dial. The warmest setting is 1 and
the coldest setting is 9. See the table below for default settings.
Model Default
Temperature
Setting
Approximate
Default
Temperature
Undercounter/Worktop Refrigerator 5 34°F (1°C)
Undercounter/Worktop Freezer 7 -5°F (-21°C)
Prep Table 5 34°F (1°C)
36
3. Control Module
Control Module LED Operation:
The control module has 3 LEDs that illuminate based on the status of the thermistors.
Red (R), Yellow (Y), and Green (G).
a) Cabinet Thermistor Above Setpoint Temperature - Power ON: All 3 LEDs turn on for
2sec. then turn off. Next, yellow (Y) LED turns on for 10 sec.
b) Cabinet Thermistor Above Setpoint Temperature - Compressor energizes: Yellow (Y)
LED turns off, green (G) LED turns on (normal cooling cycle).
c) Cabinet Thermistor at or Below Setpoint Temperature - Compressor de-energizes:
Green (G) LED ashing (normal off cycle).
d) 2-min. Compressor ON/OFF Startup Delay - Yellow (Y) LED ashing.
e) Defrost Intitiated or Defrost Thermistor Failure: Red (R) and Green (G) LEDs turn on.
f) Control Dial placed in the "OFF" position: Red (R), Yellow (Y), and Green (G) cycling.
g) Cabinet Thermistor Fault: Yellow (Y) and Green (G) LED ashing. Note: On cabinet
thermistor fault, appliance cycles 5-min. on, 5-min. off until cabinet thermistor
replaced.
CONTROL MODULE LED OPERATION
LEDs LED OPERATION
R Y G
OFF ON OFF 10-SEC. DELAY
OFF OFF ON SYSTEM ON
OFF OFF CTh SATISFIED; SYSTEM OFF
OFF OFF 2-MIN. ON/OFF DELAY
ON OFF ON DEFROST/DTh FAULT
SYSTEM OFF
OFF CTh FAULT
LED OPERATION LEGEND
CYCLING (R-on/off, Y-on/off, G-on/off repeat)
FLASHING
CTh CABINET THERMISTOR
DTh DEFROST THERMISTOR
37
D. Defrost
DANGER
Risk of Fire or Explosion Flammable Refrigerant Used
• Do not use mechanical devices to defrost.
• Do not puncture refrigerant tubing. Risk of re or explosion due to puncture of
refrigerant tubing; follow handling instructions carefully.
Risque De Feu Ou D'Explosion Le Frigorigène Est Inammable
• Ne pas utiliser d'appareils mécaniques pour dégivrer le réfrigérateur.
• Ne pas perforer la tubulure contenant le frigorigène. Risque de feu ou d'explosion si la
tubulure contenant le frigorigène est perforée; suivre les instructions de manutention
avec soin.
1. Undercounter and Worktop Refrigerators
Off-Cycle Defrost: Undercounter and worktop refrigerators defrost naturally between run
cycles and also have a 5-hr. cumulative non-heated defrost cycle. The 5-hr. cumulative
compressor run time defrost timer starts once compressor is energized.
• 5-hr. Cumulative Compressor Run Time Defrost: After 5 hrs. of cumulative
compressor run time, defrost initiates.
The minimum defrost time is 5 min.
The maximum defrost time is 45 min.
• When the 5-hr. cumulative compressor run timer terminates, the minimum 5-min.
defrost timer and the maximum 45-min. defrost timer starts. Compressor and
condenser fan motor de-energize. Evaporator fan motor remains energized.
• When the defrost thermistor reaches 44°F (6.7°C), or the maximum 45-min. defrost
timer terminates, defrost terminates. Evaporator fan motor remains energized and
compressor and condenser fan motor energize.
2. Prep Table Refrigerators
Off-Cycle Defrost: Prep table refrigerators defrost naturally between run cycles and also
have a 5-hr. cumulative heated defrost cycle. The 5-hr. cumulative compressor run time
defrost timer starts once compressor is energized.
• 5-hr. Cumulative Compressor Run Time Defrost: After 5 hrs. of cumulative
compressor run time, defrost initiates.
The minimum defrost time is 5 min.
The maximum defrost time is 45 min.
• When the 5-hr. cumulative compressor run timer terminates, defrost initiates and
the minimum 5-min. defrost timer and the maximum 45-min. defrost timer starts.
Defrost heater energizes. Compressor, condenser fan motor, and evaporator fan
motor(s) de-energize.
• When the defrost thermistor reaches 46°F (7.7°C), or the maximum 45-min. defrost
timer terminates, defrost terminates. Defrost heater de-energizes, compressor,
condenser fan motor, and evaporator fan motor(s) energize.
38
3. Undercounter and Worktop Freezers
Heated Defrost: Freezers utilize a 5-hr. cumulative compressor run time initiated,
temperature-terminated defrost cycle. The 5-hr. cumulative compressor run time defrost
timer starts once compressor is energized.
• 5-hr. Cumulative Compressor Run Time Defrost: After 5 hrs. of cumulative
compressor run time, defrost initiates.
The minimum defrost time is 5 min.
The maximum defrost time is 1 hr.
• When the 5-hr. cumulative compressor run timer terminates, defrost initiates and
the minimum 5-min. defrost timer and the maximum 1-hr. defrost timer starts.
Defrost heater energizes. Compressor, condenser fan motor, and evaporator fan
motor(s) de-energize.
• When the defrost thermistor reaches 55°F (12.7°C), or the maximum 1-hr. defrost
timer terminates, defrost terminates. Defrost heater de-energizes. 3-min. drip
time starts. Once the 3-min. drip timer terminates the compressor and condenser
fan motor energize. When defrost thermistor achieves 10°F (-12.2°C) or 3-min.
evaporator fan motor delay timer terminates, evaporator fan motor(s) energize.
39
E. Food Storage
WARNING
• Storage of foods should follow all local codes and regulations.
• The appliance is designed only for temporary storage of food. Employ sanitary
methods. Use for any other purposes (for example, storage of chemicals or
medical supplies such as vaccine and serum) could cause deterioration of stored
items.
• Do not block air inlets or outlets, otherwise cooling performance may be reduced.
• Do not tightly pack the cabinet. Allow some space between items to ensure good
air ow. Also allow space between items and interior surfaces.
• Do not put warm or hot foods in the cabinet. Let them cool rst, or they will raise
the cabinet temperature and could deteriorate other foods in the cabinet or
overload the appliance.
• All foods should be wrapped in plastic lm or stored in sealed containers. Otherwise
foods may dry up, pass their smells onto other foods, cause frost to develop, result
in poor appliance performance, or increase the likelihood of cross-contamination.
Certain dressings and food ingredients, if not stored in sealed containers, may
accelerate corrosion of the evaporator, resulting in failure.
• Do not store items near air outlets. Otherwise, items may freeze up and crack or
break causing a risk of injury or contamination of other food.
Additional Information for Prep Table Models
• The entire rail must always be covered by rail dividers and pans (1/6 size, up to
6"(15cm)deep). Otherwise, the appliance will not cool properly.
• Use only 1/6 size pans up to 6"(15cm) deep. Do not use damaged pans.
• Ingredients must be pre-chilled to 37°F (3°C) or less before placing in rail.
• Keep the rail cover closed when not actively preparing food.
• The rail is for keeping ingredients cool while preparing food. If not actively preparing
food for a long period such as overnight, seal pans with plastic wrap in addition
to closing the rail cover. Depending on conditions, the cabinet temperature
setting may need to be adjusted to prevent items from freezing. Alternatively, seal
ingredients and store them in a refrigerator or freezer.
40
F. Safety Devices
1. Compressor External or Internal Protector
If combined temperature/amperage value is above the limit specied by the
compressor manufacturer, the compressor protector operates independently to turn
off the compressor. The compressor protector de-energizes the compressor until the
temperature/amperage value returns to an acceptable level.
2. Short-Cycle Protection
There is a 2-minute minimum off-time and on-time for the compressor.
Note: Time may vary with compressor overload or high-pressure switch activation.
G. Cooling Performance
Be sure the appliance is properly installed and located for optimum cooling performance.
If cooling performance is not at its optimum level, check the following items:
• Doors/drawers opened too often.
• Doors/drawers left open. Close.
• Cabinet too tightly packed or air inlets/outlets blocked. Allow some space between items
to ensure good air ow.
• Warm or hot foods inside. Take them out until they cool down more.
• Ambient temperature too high. Avoid installation near high heat producing equipment or
exposure to direct sunlight.
• Temperature control setting not cold enough. Adjust to a colder setting. The warmest
setting is 1 and the coldest setting is 9.
• Prep Table Refrigerators and Undercounter and Worktop Freezers: Appliance in defrost
cycle. The cabinet temperature may rise temporarily during the defrost cycle, but this
will not affect the food inside.
Additional Information for Prep Table Models
• Pans and rail dividers not in place. The entire rail must always be covered by rail
dividers and pans (1/6 size, up to 6"(15cm)deep) or the rail will not cool properly.
• Warm or hot ingredients inside. Only load ingredients that have been pre-chilled to 37°F
(3°C) or less.
• Rail cover open when not actively preparing food. When not actively preparing food,
close the rail cover.
H. Cabinet Condensation
In the event condensation develops on the cabinet exterior, check the following items:
• Doors/drawers left open. Close.
• Ambient humidity too high. In high humidity areas it may be necessary to wipe off the
cabinet frame occasionally.
41
III. Cleaning and Maintenance Instructions
A. Cleaning
WARNING
• Unplug the appliance before cleaning to prevent electric shock by unexpected
entrance of water into the appliance or injury by moving parts. To reduce the risk of
electric shock, do not touch the plug with damp hands.
• Before cleaning the appliance, move all foods into another clean refrigerator or
freezer.
• Do not splash, pour, or spray water directly onto or into the appliance. This might
cause short circuit, electric shock, corrosion, or failure.
• Carefully follow instructions provided with cleaning and sanitizing products.
NOTICE
• To prevent damage to the plastic surfaces, do not use the following: hot water,
thinner, benzine, alcohol, petroleum, soap powder, polishing powder, alkaline
cleaner, acid, scouring pad and especially those strong cleaners for use on a
ventilating fan or a cooking range.
• To prevent corrosion and damage to stainless steel surfaces, use only products
formulated for use on stainless steel appliances. Do not use steel wool, abrasive
products, or products containing sodium hypochlorite (chlorine bleach).
• Use a clean cloth for cleaning.
1. Exterior
Wipe the exterior occasionally with a clean, soft cloth. Use a damp cloth containing
a neutral cleaner to wipe off oil or dirt buildup. Clean any rust colored spots using a
non-abrasive cleanser.
2. Cabinet Interior
Spills should be wiped up promptly to avoid unpleasant odors. The cabinet interior should
be cleaned periodically with a mild soap or detergent and warm water.
3. Door/Drawer Gaskets
Door/drawer gaskets should be cleaned regularly with mild soap and warm water to
remove dirt and grease.
4. Shelves
Remove and clean regularly.
5. Glass Door
Wipe occasionally with a clean, soft cloth. Use a damp cloth containing a neutral cleaner
to wipe off oil or dirt buildup.
42
6. Drawers
Drawers and drawer slides are removable.
• To remove a drawer: Remove all items from the drawer. Pull the drawer out to its fully
extended position. Open the safety clips (one on each side) by sliding them forward,
then rotating them up. See Fig. 43. Lift up on the handle slightly, then pull to disengage
the drawer. Be sure to support the rear and front of the drawer while removing it.
WARNING! Be sure to close the safety clips when reinstalling the drawer.
• To remove a drawer slide (center slide containing rollers): Push up on the stop
lever while pulling on the drawer slide. See Fig. 44. Drawer slides do not require
lubrication, but drawer slides should be kept clean and free of food.
Note: Drawer slides are dishwasher safe.
7. Worktop (Worktop Models)
Clean the work surface as often as necessary to maintain a clean, sanitary surface.
Clean any rust colored spots using a non-abrasive cleanser.
8. Cutting Board (Prep Table Models)
Remove and clean the cutting board as often as necessary to maintain a clean, sanitary
work surface. Also clean the space underneath the cutting board as often as necessary
to maintain a clean, sanitary surface. After cleaning, slide the cutting board back into the
cutting board brackets. WARNING! Make sure the cutting board brackets and cutting
board are secure. Otherwise, the cutting board could come off and cause injury.
Fig. 43
Safety Clips
Safety Clip
Closed Stop Lever
Fig. 44
Safety Clip
Open
Stop LeverDrawer Slide
43
9. Rail, Rail Hood, and Rail Cover (Prep Table Models)
Spills and splashes should be wiped up promptly to avoid unpleasant odors. Wipe the rail
area, the rail hood, and the rail cover occasionally with a clean, damp sponge or cloth
containing a neutral cleaner. Clean any rust colored spots using a non-abrasive cleanser.
Do not pour or spray water into the rail area.
WARNING!
• Support the rail cover when cleaning. Otherwise, the rail cover could close
suddenly and cause injury.
• Metal edges can cause cuts. Use care and wear protective gloves when cleaning.
NOTICE!Do not allow any foreign objects to fall into the cabinet while cleaning.
10. Spill Guard
Remove the pans and wipe the spill guard occasionally with a clean, damp sponge or
cloth containing a neutral cleaner. Clean any rust colored spots using a non-abrasive
cleanser. Do not pour or spray water into the rail area.
B. Maintenance
WARNING
• Unplug the appliance before performing maintenance to prevent electric shock or
injury by moving parts. To reduce the risk of electric shock, do not touch the plug
with damp hands.
• Before performing maintenance, move all foods into another clean refrigerator or
freezer.
1. Condenser
Check the condenser once a year and use a brush or vacuum cleaner to clean the
condenser as required. More frequent cleaning may be required depending on conditions.
2. Power Supply Connection
If the plug or power cord is damaged, contact your local Hoshizaki service representative
or local Hoshizaki distributor immediately and ask for repairs.
All other maintenance or service on the appliance should be performed in accordance
with the Hoshizaki Service Manual by a qualied service technician.
44
IV. Preparing the Appliance for Periods of Non-Use
When shutting down the appliance for more than one week, follow the instructions below.
WARNING
When preparing the appliance for long storage, prevent the doors/drawers from
closing to reduce the risk of children getting trapped.
NOTICE
When preparing the appliance for long storage, clean the appliance. See "III.A.
Cleaning" for details.
1) Before shutting down the appliance, move all foods into another clean refrigerator or
freezer.
2) Unplug the appliance. WARNING! To reduce the risk of electric shock, do not touch
the plug with damp hands.
45
V. Disposal
DANGER
Risk of Fire or Explosion Flammable Refrigerant Used
• Follow handling instructions carefully in compliance with U.S. government
regulations.
• Do not puncture refrigerant tubing. Risk of re or explosion due to puncture of
refrigerant tubing; follow handling instructions carefully.
• Dispose of properly in accordance with federal or local regulations.
Risque De Feu Ou D'Explosion Le Frigorigène Est Inammable
• Suivre attentivement les instructions de manipulation conformément à la
réglementation gouvernementale.
• Ne pas perforer la tubulure contenant le frigorigène. Risque de feu ou d'explosion si la
tubulure contenant le frigorigène est perforée; suivre les instructions de manutention
avec soin.
• Éliminer conformément aux règlements fédéraux ou locaux.
WARNING
When preparing the appliance for disposal, remove the doors/drawers to reduce the
risk of children getting trapped. Leave any shelves in place so that children may not
easily climb inside.
The appliance contains refrigerant and must be disposed of in accordance with
applicable national, state, and local codes and regulations. Refrigerant must be
recovered by properly certied service personnel.
618 Hw 74 South, Peachtree City, GA 30269 USA (P 770.487.2331 y. ) (F) 770.487.3360 hoshizakiamerica.com 1A5988-010

Produktspezifikationen

Marke: Hoshizaki
Kategorie: Kühlschrank
Modell: SR48B-18MD4

Brauchst du Hilfe?

Wenn Sie Hilfe mit Hoshizaki SR48B-18MD4 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Kühlschrank Hoshizaki

Hoshizaki

Hoshizaki PT1A-FS-FS Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki WR36A-01 Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki BB95-S Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki UR72B Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki WR48A-01 Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki BB80-G Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki BB69-G Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki SR72B-12 Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki SR36B-15M Bedienungsanleitung

29 August 2024
Hoshizaki

Hoshizaki RM-45-SD-HC Bedienungsanleitung

29 August 2024

Bedienungsanleitung Kühlschrank

Neueste Bedienungsanleitung für -Kategorien-

BEKO

BEKO B3RCNA345HW Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO BFBF30116SSIM Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO GNE134590X Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO BFBF30116WHIM Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO BFBF30216SSL Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO BFBF30216SS Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO BFBF30116SS Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO B3RGNE664ZDXB Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO RFNE360W Bedienungsanleitung

4 Dezember 2024
BEKO

BEKO B5RCNE565HXBR Bedienungsanleitung

4 Dezember 2024
