Models
KM-1301SAJ/3, SWJ/3, SRJ/3
KM-1601SAJ/3, SWJ/3, SRJ/3
KM-1900SAJ/3, SWJ/3, SRJ/3
KM-2200SWJ3, SRJ3
KM-2600SWJ3, SRJ3
Modular Crescent Cuber
Service Manual
Number: 73216
Issued: 10-27-2017
Revised: 3-14-2018
hoshizakiamerica.com
2
WARNING
Only qualied service technicians should install and service the appliance. To
obtain the name and phone number of your local Hoshizaki Certied Service
Representative, visit www.hoshizaki.com. No installation or service should be
undertaken until the technician has thoroughly read this Service Manual. Likewise,
the owner/manager should not proceed to operate the appliance until the installer
has instructed them on its proper operation. Failure to install, operate, and
maintain the appliance in accordance with this manual will adversely affect safety,
performance, component life, and warranty coverage and may result in costly water
damage. Proper installation is the responsibility of the installer. Product failure or
property damage due to improper installation is not covered under warranty.
Hoshizaki provides this manual primarily to assist qualied service technicians in the
installation, maintenance, and service of the appliance.
Should the reader have any questions or concerns which have not been satisfactorily
addressed, please call, send an e-mail message, or write to the Hoshizaki Technical
Support Department for assistance.
Phone: 1-800-233-1940; (770) 487-2331
Fax: 1-800-843-1056; (770) 487-3360
E-mail: techsupport@hoshizaki.com
618 Highway 74 South
Peachtree City, GA 30269
Attn: Hoshizaki Technical Support Department
NOTE: To expedite assistance, all correspondence/communication MUST include the
following information:
• Model Number
• Serial Number
• Complete and detailed explanation of the problem.
3
CONTENTS
Important Safety Information 6 .................................................................................................
I. Construction and Water/Refrigeration Circuit Diagram 8 .......................................................
A. KM Construction............................................................................................................ 8
1. Air-Cooled Models (SAJ/3) 8 .......................................................................................
2. Water-Cooled Models (SWJ/3) 9 ................................................................................
3. Remote Models (KM-1301SRJ/3 and KM-1601SRJ/3) .......................................... 10
4. Remote Models (KM-1900SRJ/3, KM-2200SRJ3, KM-2600SRJ3) ........................11
B. Bin Control .................................................................................................................. 12
1. Single Bin Control .................................................................................................. 12
2. Stacked Bin Control ............................................................................................... 12
C. Water/Refrigeration Circuit Diagram ............................................................................ 13
1. Air-Cooled Models (SAJ/3) ..................................................................................... 13
2. Water-Cooled Models (SWJ/3) .............................................................................. 14
3. Remote Models (SRJ/3) ........................................................................................ 15
II. Sequence of Operation and Service Diagnosis ............................................................... 16
A. Sequence of Operation Flow Chart ............................................................................. 16
1. Operation Flow Chart ............................................................................................ 16
2. Shutdown Flow Chart ............................................................................................ 17
3. Freeze-Time Correction Chart ............................................................................... 18
B. Service Diagnosis ....................................................................................................... 19
C. Freeze-Time Correction Cycle (90 min.) 26 .....................................................................
D. Control Board Check 28 ...................................................................................................
E. Bin Control Check 29 .......................................................................................................
1. Bin Control Check 29 ..................................................................................................
2. Bin Control Cleaning 30 ..............................................................................................
F. Float Switch Check and Cleaning 31 ................................................................................
1. Float Switch Check 31 ................................................................................................
2. Float Switch Cleaning 32 ............................................................................................
G. Thermistor Check ........................................................................................................ 33
H. Control Switch 33 .............................................................................................................
I. Diagnostic Tables .......................................................................................................... 34
J. Freeze-Up Check List 38 ..................................................................................................
IMPORTANT
This manual should be read carefully before the appliance is serviced. Read
the warnings and guidelines contained in this manual carefully as they provide
essential information for the continued safe use, service, and maintenance of the
appliance. Retain this manual for any further reference that may be necessary.
