Models
AM-50BAJ
AM-50BAJ-DS
AM-50BAJ-AD
AM-50BAJ-ADDS
Self-Contained Cuber
Instruction Manual
Issued: 9-28-2017
Revised: 12-11-2017
hoshizakiamerica.com
2
WARNING
Only qualied service technicians should install and service the icemaker. To obtain
the name and phone number of your local Hoshizaki Certied Service
Representative, visit www.hoshizaki.com. No installation or service should be
undertaken until the technician has thoroughly read this Instruction Manual.
Likewise, the owner/manager should not proceed to operate the icemaker until the
installer has instructed them on its proper operation. Failure to install, operate, and
maintain the icemaker in accordance with this manual will adversely affect safety,
performance, component life, and warranty coverage and may result in costly water
damage. Proper installation is the responsibility of the installer. Product failure or
property damage due to improper installation is not covered under warranty.
Hoshizaki provides this manual primarily to assist qualied service technicians in the
installation, maintenance, and service of the icemaker.
Should the reader have any questions or concerns which have not been satisfactorily
addressed, please call, send an e-mail message, or write to the Hoshizaki Technical
Support Department for assistance.
Phone: 1-800-233-1940; (770) 487-2331
Fax: 1-800-843-1056; (770) 487-3360
E-mail: techsupport@hoshizaki.com
618 Highway 74 South
Peachtree City, GA 30269
Attn: Hoshizaki Technical Support Department
Web Site: www.hoshizaki.com
NOTE: To expedite assistance, all correspondence/communication MUST include the
following information:
• Model Number
• Serial Number
• Complete and detailed explanation of the problem.
3
CONTENTS
Important Safety Information 4 .................................................................................................
I. Specications 6 ......................................................................................................................
A. Construction 6 ..................................................................................................................
B. Electrical Data 7 ...............................................................................................................
C. Dimensions/Connections 8 ..............................................................................................
1. AM-50BAJ ................................................................................................................ 8
2. AM-50BAJ-DS ......................................................................................................... 9
3. AM-50BAJ-AD ....................................................................................................... 10
4. AM-50BAJ-ADDS ...................................................................................................11
II. Installation Instructions .................................................................................................... 12
A. Checks Before Installation ........................................................................................... 12
B. Location ....................................................................................................................... 12
1. General .................................................................................................................. 12
2. Built-In Installation Site .......................................................................................... 13
C. Door ............................................................................................................................ 14
1. AM-50BAJ, AM-50BAJ-AD ..................................................................................... 14
a) Door Reversal ..................................................................................................... 14
2. AM-50BAJ-DS, AM-50BAJ-ADDS ......................................................................... 16
a) Overlay Panel Fabrication and Attachment ......................................................... 16
D. Setup 24 ...........................................................................................................................
E. Electrical Connection 25 ..................................................................................................
F. Water Supply and Drain Connections 26 ..........................................................................
G. Final Checklist 27 ............................................................................................................
III. Operating Instructions 28 .....................................................................................................
A. Important Notes About Usage 28 .....................................................................................
B. Startup 29 ........................................................................................................................
IV. Maintenance 31 ...................................................................................................................
A. Maintenance Schedule 31 ................................................................................................
B. Cleaning and Sanitizing Instructions 32 ...........................................................................
C. Ice Storage Bin Drain 36 ..................................................................................................
D. Condenser 37 ...................................................................................................................
E. Optional Drain Pump HS-5061 37 ....................................................................................
V. Preparing the Icemaker for Periods of Non-Use 39 ..............................................................
VI. Disposal 40 ..........................................................................................................................
IMPORTANT
This manual should be read carefully before the icemaker is installed and operated.
Read the warnings and guidelines contained in this booklet carefully as they
provide essential information for the continued safe use and maintenance of the
icemaker. Retain this booklet for any further reference that may be necessary.
