Models 7222, 7224, 7322 & 7324
FIRE RESISTANT VERTICAL FILE CABINETS
Read this manual carefully and never store it inside the cabinet!
Models 7222, 7224, 7322 & 7324
FIRE RESISTANT VERTICAL FILE CABINETS
Note: During shipment, the gypsum insulation of your Honeywell file
cabinet may create a film of dust on the exterior and interior of the file.
This is a normal settling process. Simply wiping the cabinet and drawers
with a damp cloth will remove the dust. Honeywell files are asbestos free.
PACKAGE CONTENTS
1 – Vertical File Cabinet
1 – Operation Manual
2 – Entry Keys
For missing parts or difficulty operating your
cabinet, please contact our Consumer
Assistance Department by telephone.
US/Canada 1-877-354-5457 (Toll Free)
Australia 0011-800-5325-7000 (Toll Free)
Germany 00-800-5325-7000 (Toll Free)
IMPORTANT: DO NOT RETURN CABINET TO STORE!
Store will not accept returned products without prior authorization. You must
first contact our consumer assistance department.
CABINET SERIAL NUMBER
Whenever contacting our Consumer Assistance Department, you will need to
provide them with the serial number of your cabinet.
The serial number tag is located on the
lower right front corner of the cabinet.
IMPORTANT: Do Not Remove Tags!
These are needed if you lose your keys.
UNPACKING & MOVING CABINET
CAUTION! Honeywell file cabinets and drawers are heavy! For safety
always use proper moving equipment and padding when moving cabinets.
Remove Cabinet from the Pallet
1. Remove rubber stops from the front and sides of the pallet.
2. Spin the cabinet to set sideways across the pallet.
3. Slide the cabinet so that the back of the cabinet will tilt and rest on the floor.
4. Push back on the front of the cabinet to raise front of the bottom of the
pallet.
5. Slide pallet out of the way and set cabinet on the floor
Moving The File Into Place
x Do not use the file’s handle to lift or move the file; damage to the latching
system may result.
x For the lock to function properly, the file must be leveled from side to side
and front to back. Place shims at the bottom corners of the file as
necessary to level the file.
x Moving Honeywell file cabinets into position may be facilitated by removing
the drawers.
DRAWER REMOVAL & INSTALLATION
IMPORTANT: Drawers are very heavy. Two or more persons are required
when handling the drawers. Note that each drawer has a drawer number decal
on the right side of the drawer. Drawers are numbered from top to bottom and
each must be replaced in the same cavity from which it was removed.
Fig. 1 .
DRAWER REMOVAL & INSTALLATION CONTINUED
To Remove Drawers
1. Extend drawer fully out.
2. Grasp front of drawer on each side and lift to release front tabs of slides
from drawer. (Fig. 1)
3. Place one hand underneath the drawer for support and pull one slide
forward to release the rear tab.(Fig. 1), repeat for other slide
4. Holding drawer head with both hands, pull drawer clear of slides and out of
cavity.
5. Push suspensions and stabilizers back into the drawers
To Install Drawers
1. Pull suspensions and stabilizers out until they are fully extended.
2. Place drawer into opening in between slides and align rear tab of slide with
the appropriate notch and insert.
3. Pull drawer forward until front tabs are aligned, insert front tabs
4. Close drawer and check for free movement and equal gap on both sides of
drawer.
If necessary, lightly loosen stabilizer screws and move drawer in direction of
excessive gap. Tighten screws and recheck gap.
LOCKING & UNLOCKING DRAWERS
Do not attempt to close drawer when the lock bolt is extended; damage to
cabinet and/or lock may result.
To Lock
1. Make sure all drawers are
closed before locking
2. Push the lock plunger in until
it snaps into place.
To Unlock
1. Insert key into lock.
2. Turn to the right or left until
the plunger pops out.
LOCK BYPASS FEATURE
Lock Bypass Feature
The lock bypass lever is designed to allow access to certain drawers while
others remain locked.
If one or more of the drawers will not lock, check the lock bypass lever. The
bypass lever needs to be in the deactivated position in order for the drawer
to lock. Below are instructions that will help in activating and deactivating the
lock bypass lever.
To activate bypass:
Lift the lever with your
thumb until it rests above
the dimple at the top of side
catch assembly (Fig. 2).
The drawer will NOT lock
with the lever in this
position.
Fig. 2
To deactivate bypass:
Press down on the lever
until it is positioned below
the dimple and rests on the
channel that is a formed
feature of the side catch
assembly (Fig. 3).
The drawer will now lock
with the lever in this
position
Fig. 3
FILLING THE CABINET DRAWERS
Maximum recommended weight is 60 Lbs. /27 kg per drawer.
The weight should be evenly distributed throughout the file. Exceeding the
maximum recommended capacity may seriously damage your file’s suspension.
U.S. – Letter & Legal Size Files International – A4 Foolscap Files
REMEMBER!
Open drawers do not provide protection. Honeywell cabinets use the latest
technology to protect your valuables. During a fire, the insulation is designed to
release moisture to create a protective barrier. If you are storing valuables that
are sensitive to moisture, such as stamps, money, watches, etc., please place
them in a sealed, humidity resistant container to protect them from moisture
damage
