Automatic Screwdriver
Model W 4YD
Handling instructions
Note:
Before using this Electric Power Tool, carefully read through these
HANDLING INSTRUCTIONS to ensure efficient, safe operation. It is
recommended that these INSTRUCTIONS be kept readily available
as an important reference when using this power tool.
1
GENERAL SAFETY RULES
WARNING!
Read all instructions
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
The term “power tool” in all of the warnings listed below
refers to your mains operated (corded) power tool or battery
operated (cordless) power tool.
SAVE THESE INSTRUCTIONS
1) Work area
a) Keep work area clean and well lit.
Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust.
Power tools create sparks which may ignite the dust
of fumes.
c) Keep children and bystanders away while operating
a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection.
Safety equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Avoid accidental starting. Ensure the switch is in
the off position before plugging in.
Carrying power tools with your finger on the switch
or plugging in power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance
at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts.
Loose clothes, jewellery or long hair can be caught
in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used.
Use of these devices can reduce dust related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power
tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power
tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tools
operation.
If damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.,
in accordance with these instructions and in the
manner intended for the particular type of power
tool, taking into account the working conditions
and the work to be performed.
Use of the power tool for operations different from
intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.
2
PRECAUTIONS ON USING AUTOMATIC
SCREWDRIVER
1. This automatic screwdriver is designed for
tightening and loosening screws. Use it only for
these operation.
2. One-hand operation is extremely dangerous; hold
the unit firmly with both hands when operating.
3. Use original bits specifically for the automatic
screwdriver.
Use no bits other than the original bits specifically
for the automatic screwdriver. Use of any other
bit can result in screws sticking out and screw
feed malfunctioning.
4. After installing the driver bit, pull lightly out the
bit to make sure that it does not come loose. If
the bit is not installed properly, it can come loose
during use, which can be dangerous.
5. Screw in screws with the main unit held straight.
If the driver is slanted relative to the screw, the
screw head can be damaged and the bit worn.
Moreover, the prescribed torque is not transmitted
to the screw, resulting in screws left sticking out.
STANDARD ACCESSORIES
(1) Screw feed attachment ........................................... 1
(Assembled in main body)
(2) No. 2 Plus Bit .......................................................... 1
(Assembled in main body)
(3) Hook ........................................................................... 1
(4) Sheet .......................................................................... 2
(5) Rubber cover ............................................................ 1
(6) Plastic case ................................................................ 1
Standard accessories are subject to change without
notice.
APPLICATIONS
䡬Screw driving into indoor gypsum board.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
Place the drive straight against the screw and
screw in.
6. Use the prescribed screws.
Do not use any other screws. They can cause
abnormal work (screws fallen over or sticking out)
and break downs (screw jamming and bit wear).
7. Protect your eyes with protective glasses.
Always wear protective glasses while working.
Drilling scatters plaster powder and tape dust,
which are dangerous if they get into your eyes
8. Watch out for wires and pipes in walls and ceilings.
When working on floors, walls, or ceilings, check
for wires and pipes ahead of time. Work carefully
to avoid shocks and explosions.
9. When the screw feed attachment is removed,
always use the correct driver bit for the screw size.
10. When the screw feed attachment is removed, if
the screwdriver is positioned at an angle against
the tightening screw, the head of the screw may
be damaged or the fixed tightening force will not
transfer to the screw. Always position the
tightening screw and the screwdriver at a straight
angle and then tighten the screw.
SPECIFICATIONS
* Be sure to check the nameplate on product as it is subject to change by areas.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operation immediately, which could cause
a serious accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Preparing and checking the work environment
Make sure that the work site meets all the conditions
laid forth in the precautions.
5. Preparing the screws
Select screws appropriate to the application.
6. Bit checking and replacement
A No. 2 Plus bit is installed on this machine as a
standard accessory. Always inspect the bit to make
sure it is not damaged. Using worn bits can cause
screw-in malfunctions. Inspect the bit before work
and quickly replace it with a new one when it starts
to wear out. When the bit must be replaced due
to bit damage or any other reason, replace it
according to the instructions in Bit installation and
removal.
Voltage (by areas)* (230V, 240V)
Power input 470 W
No-load speed 4700 / min.
Capacity Screw size 4 mm
Screw length 25 – 41 mm
Bit shank size 6.35 mm Hex.
Weight (without cord) 1.7 kg
