NETWORK CAMERA
User Manual
XNP-6040H
Copyright
©2017 Hanwha Techwin Co., Ltd. All rights reserved.
Trademark
Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their
respective company.
Restriction
Copyright of this document is reserved. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without
formal authorization.
Disclaimer
Hanwha Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be
provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Hanwha Techwin reserves the
right to change the contents of this document without prior notice.
Design and specications are subject to change without prior notice.
The initial administrator ID is “admin” and the password should be set when logging in for the rst time.
Please change your password every three months to safely protect personal information and to prevent the damage of the information
theft.
Please, take note that it’s a user’s responsibility for the security and any other problems caused by mismanaging a password.
Network Camera
User Manual
English _3
●●overview
important Safety inStructionS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.
(Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents
as they may deform or cause damage to the product.)
7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/ accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lighting storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15. This product is intended to be supplied by a Listed Power Supply Unit marked “Class 2” or “LPS” and rated
from 12 Vdc, 0.8 A or PoE(37-57 Vdc), 0.26 A.
16. Do not install the camera vertically on a wall. This will cause Tilt step-out.
17. If you use excessive force when installing the product, the camera may be damaged and malfunction.
If you forcibly install the product using non-compliant tools, the product may be damaged.
18. Do not install the product in a place where chemical substances or oil mist exists or may be generated. As
edible oils such as soybean oil may damage or warp the product, do not install the product in the kitchen or
near the kitchen table.
This may cause damage to the product.
19. When installing the product, be careful not to allow the surface of the product to be stained with chemical
substance.
Some chemical solvents such as cleaner or adhesives may cause serious damage to the product’s surface.
20. If you install/disassemble the product in a manner that has not been recommended, the production functions/
performance may not be guaranteed.
Install the product by referring to “Installation & connection” in the user manual.
21. Installing or using the product in water can cause serious damage to the product.
warninG
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE
VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.
Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
To prevent injury, this apparatus must be securely attached to the Wall/ceiling in accordance
with the installation instructions.
caution
caution
riSK of eLectric SHocK.
Do not open
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
eXpLanation of GrapHicaL SymBoLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in
the literature accompanying the product.
overview
overview
4_ overview
Class construction
An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a
protective earthing connection.
Battery
Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
Disconnection Device
Disconnect the main plug from the apparatus, if it’s defected. And please call a repair man in
your location.
When used outside of the U.S., it may be used HAR code with fittings of an approved
agency is employed.
CAUTION
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock do not perform any servicing other than that contained in
the operating instructions unless you are qualified to do so.
The CVBS out terminal of the product is provided for easier installation, and is not
recommended for monitoring purposes.
Please use the input power with just one camera and other devices must not be connected.
The ITE is to be connected only to PoE networks without routing to the outside plant.
Please read the following recommended safety precautions carefully.
yDo not place this apparatus on an uneven surface.
yDo not install on a surface where it is exposed to direct sunlight, near heating equipment or
heavy cold area.
yDo not place this apparatus near conductive material.
yDo not attempt to service this apparatus yourself.
yDo not place a glass of water on the product.
yDo not install near any magnetic sources.
yDo not block any ventilation openings.
yDo not place heavy items on the product.
yPlease wear protective gloves when installing/removing the camera.
The high temperature of the product surface may cause a burn.
User’s Manual is a guidance book for how to use the products.
The meaning of the symbols are shown below.
yReference : In case of providing information for helping of product’s usages
yNotice : If there’s any possibility to occur any damages for the goods and human caused by
not following the instruction
Please read this manual for the safety before using of goods and keep it in the safe place.
English _5
●●overview
contentS
overview
3
3 Important Safety Instructions
6 Product Features
6 Recommended PC Specifications
6 Recommended Micro SD/SDHC/SDXC
Memory Card Specifications
6 NAS recommended specs
7 What’s Included
8 At a Glance
installation & connection
10
10 Installation
12 Inserting/Removing a Micro SD Memory
Card
13 Memory Card Information (Not Included)
14 Connecting with other Device
network connection and
setup
18
18 Connecting the Camera Directly to Local
Area Networking
18 Connecting the Camera Directly to a DHCP
Based DSL/Cable Modem
19 Connecting the Camera Directly to a
PPPoE Modem
19 Connecting the Camera to a Broadband
Router with the PPPoE/Cable Modem
20 Buttons used in IP Installer
20 Static IP Setup
22 Dynamic IP Setup
22 Port Range Forward (Port Mapping) Setup
23 Connecting to the Camera from a Shared
Local PC
23 Connecting to the Camera from a Remote
PC via the Internet
web viewer
24
24 Connecting to the Camera
25 Password setting
25 Login
25 Plug-in support specifications for each
browser
26 Installing WebViewer Plugin
26 Using a Plug-in Free Webviewer
26 Using the Live Screen
29 Playing the recorded video
setup screen
31
31 Setup
31 Basic Setup
35 PTZ setup
38 Video & Audio setup
44 Network Setup
48 Event Setup
50 NAS (Network Attached Storage) guide
53 Configure analysis settings
57 System Setup
59 Open Platform Setup
appendix
60
60 Specification
62 Product Overview
63 Troubleshooting
64 Open Source Announcement
overview
6_ overview
PRODUCT FEATURES
•Dustproof/Waterproof (IP66)
The dustproof and waterproof design makes you feel at ease when installing the product outdoors or exposing
it to rain.
•Full HD video support
•Multi-Streaming
This network camera can display videos in different resolutions and qualities simultaneously using different
CODECs.
•Web Browser-based Monitoring
Using the Internet web browser to display the image in a local network environment.
•Alarm
When an event occurs, video is either sent to the email address registered by the user, sent to the FTP server,
saved in a Micro SD card or NAS, or a signal is sent to the alert output terminal.
•Tampering Detection
Detects tempering attempts on video monitoring.
•Motion Detection
Detects motion from the camera’s video input.
•Audio Detection
Detects sound louder than a certain level specified by user.
•Smart Codec
Adaptively applies codecs for a portion of the camera’s field of view to improve the quality of such area specified
by user.
•Auto Detection of Disconnected Network
Detects network disconnection before triggering an event.
•Fog detection
Detects fog that is heavier than the detection level.
•Face Detection
Detects faces in the specified area from the camera’s video input.
•IVA (Intelligent Video Analysis) function
Detects a motion or situation that meets the configured event rules.
•Sound source classification
Detects a sound source specified by the user.
•ONVIF Compliance
This product supports ONVIF Profile S&G.
For more information, refer to www.onvif.org.
RECOMMENDED PC SPECIFICATIONS
•CPU : Intel(R) Core(TM) i7 3.4 GHz or higher
•RAM : 8G or higher
•Supported OS : Windows 7, 8, 10, Mac OS X 10.10, 10.11, 10.12
•Plug-in free web viewer
Supported web browsers : Google Chrome, MS Edge, Mozilla Firefox, Apple Safari 10 (Mac OS X only)
•Plug-in Webviewer
Supported web browsers : MS Explore 11, Apple Safari 10 (Mac OS X only)
RECOMMENDED MICRO SD/SDHC/SDXC MEMORY CARD
SPECIFICATIONS
•Recommended capacity : 16GB to 256GB (MLC type)
•The following types of memory cards from the following manufacturers are recommended for this camera.
- Manufacturer : SanDisk, Transcend
- Product family : High endurance
NAS RECOMMENDED SPECS
•Recommended capacity : 200GB or higher is recommended.
•Simultaneous access : One unit of NAS can accept a maximum of sixteen camera accesses.
•For this camera, you are recommended to use a NAS with the following manufacturer’s specs.
Recommended products Available sizes
QNAP NAS A maximum of 16 cameras can access simultaneously.
Synology NAS A maximum of 16 cameras can access simultaneously.
J
`If you use NAS equipment for purposes other than video saving, the number of accessible cameras may be reduced.
English _7
●● overview
wHat’S incLuDeD
Please check if your camera and accessories are all included in the product package.
(As for each sales country, accessories are not the same.)
Appearance DescriptionItem Name Quantity
Camera
1
Instruction book,
Installer S/W CD
1
Quick Guide
(Optional)
1
Warranty card
(Optional)
1
Cable for the testing monitor
1
Used to test the camera connection to a portable
display device
Template
1
Product installation guide
Power Terminal Block
1
Plugged in the power plug
L Wrench
1
Used to remove and replace the dome cover
Appearance DescriptionItem Name Quantity
CAUTION: Be w are of the Rated Voltage and Po larit yof the power connec tion.
Power Cable
1
Used to plug into the power port
Audio/RS-485/Alarm cable
1
Used for audio, RS-485 and Alarm connection
Cable bush
1
Used to connect the LAN cable with a diameter of
Ø7~8.5.
Tapping Screw 3 Used for installation on the wall or ceiling
Machine Screws
3
Used for assembling the dome case when
installing the product on the pipe, wall mount, etc.
or blocking a hole.
Card-type moisture absorbent
2
Attached when installed.
overview
8_ overview
AT A GLANCE
Appearance
Item Description
a
Dome cover Case cover used to protect the lens and the main unit.
b
Camera Case Housing part that covers the camera body.
Components
a
b
DC12V
VIDEO
USB
AUDIO / ALM / RS485
RESET
2
1
a
f e
c
d
b
ACT LINK
NETWORK
VIDEO
AUDIO / ALM / RS485
USB
21
POWER
NETWORK
AUDIO
ALM
RS485
gh
English _9
●● overview
Item Description
a
Lens Lens for the camera.
b
MICRO USB port
Port to connect the WiFi dongle.
You can check the installation video through the applications installed in the smartphone.
Refer to “Connect to WiFi dongle” on page 14.
`WiFi dongle and OTG adapter are sold separately.
c
Test Monitor Out Output port for test monitoring the video output. Use the test monitor cable to connect to a
mobile display and check the test video.
d
Audio/RS-485/Alarm
connector This is a terminal to connect audio, RS-485 and alarm cables.
e
Reset Button
The button restores all camera settings to the factory default.
Press and hold for about 5 seconds to reboot the system.
J If you reset the camera, the network settings will be adjusted so that DHCP can be
enabled. If there is no DHCP server in the network, you must run the IP Installer
program to change the basic network settings such as IP address, Subnet mask,
Gateway, etc., before you can connect to the network.
f
Power Port Port for power terminal block.
g
Network Port Used to connect the PoE or Ethernet cable for network connection.
h
Micro SD Memory Card
Compartment Compartment for the Micro SD memory card.
10_ installation & connection
installation & connection
INSTALLATION
J
`This camera is waterproof and in compliance with the spec, but the jack connected to the external cable is not. You are IP66
recommended to install this product below the edge of eaves to prevent the cable from being externally exposed.
Precautions before installation
Ensure you read out the following instructions before installing the camera:
• It must be installed on the area (ceiling or wall) that can withstand 5 times the weight of the camera
including the installation bracket.
• Stuck-in or peeled-off cables can cause damage to the product or a fire.
• For safety purposes, keep anyone else away from the installation site.
And put aside personal belongings from the site, just in case.
• If you use excessive force when installing the product, the camera may be damaged and malfunction.
If you forcibly install the product using non-compliant tools, the product may be damaged.
Disassembling
1. Using the L wrench provided, turn the 3 fastening
bolts on the dome cover counter clockwise to remove
the cover.
2. Remove the tape attached to the inner cover.
3. Remove the sponge for protecting the lens.
Installation
1. Use the supplied template to drill holes for installation
screws (with diameter of 6mm and minimum depth of
55mm).
2. After aligning the holes for mounting the camera, use the
tapping screws to secure the camera.
`Make sure that the < > mark printed on the side of the FRONT
camera is facing the direction the camera will be facing for
surveillance.
3. Connect the required cable to the terminal inside the
camera.
J
`Connect the cable to the PTZ rotary unit so that the cable to be rotated is not damaged or caught.
4. Close the dome cover.
`Assemble so that the logo on the dome cover is on same direction as the < > of the camera.FRONT
`Securely fasten the fastening bolt using an L wrench to prevent water from leaking.
J
`Do not install the camera vertically on a wall.
This will cause Tilt step-out.
Connecting waterproof power cable and LAN cable
1. Remove the dome cover and the case.
2. Pull out the long projected part of the rubber plug on the bottom and
remove it as shown in the figure.
J
`Use an appropriate cable bush for the LAN cable to be connected.
- Basic camera : Use the cable with a diameter of Ø5~6.5.
- Components provided : Use the cable with a diameter of Ø7~8.5.
`Connect after checking the cable bushing connection.
DC12V
FRONT
VIDEO
USB
AUDIO / ALM / RS485
RESRT
2
1
DC12V
FRONT
VIDEO
USB
AUDIO / ALM / RS485
RESRT
2
1
FRONT
Dome cover logo
Marked FRONT
ACT LINK
NETWORK
VIDEO
AUDIO / ALM / RS485
USB
21
POWER
NETWORK
AUDIO
ALM
RS485
ACT LINK
NETWORK
VIDEO
AUDIO / ALM / RS485
USB
21
POWER
NETWORK
AUDIO
ALM
RS485
AUDIO
ALM
RS485
POWER
NETWORK
POWER/NETWORK
AUDIO/ALM/
RS485
DC12V
FRONT
VIDEO
USB
AUDIO / ALM / RS485
RESRT
2
1
Bolts
Dome cover
Camera Case
Camera Body
English _11
●● INSTALLATION & CONNECTION
3. Insert the power cable into the small hole made by removing the projected
part of the rubber plug in step 2 above, and lay the cable along the long
groove.
4. Connect the power cable with the power terminal block.
5. Insert the LAN cable into the large hole made by removing the projected
part of the rubber plug in step 2 above.
6. Remove the sheath with a cable cutter, and align the cables.
7. Connect the LAN cable with a LAN connector, and insert it into the LAN
tool.
8. Connect the finished cable to the Ethernet port.
Connecting Audio/RS-485/Alarm cable
1. Remove the dome cover and the case.
2. Pull out the rubber plug on the bottom as shown in the figure.
3. Insert the Audio/RS-485/Alarm cable through the hole formed by removing
the rubber plug in step 2, and connect it to the alarm terminal of the PCB.
4. Align the cable so that it should not be damaged or jammed when installing
the camera.
5. Insert the rubber stopper on the Audio/RS-485/Alarm cable into the hole.
6. Attach the dome cover.
Attaching to the unbundled adapter
Choose and purchase a necessary one of the following options (unbundled) that is suitable to the installation
site or for your convenience.
1. Remove the dome cover from the case by referring to the “ ” section. (page Disassembling
10
)
2. Secure the camera case to the optional adapter with the optional machine screws supplied.
3. Connect and arrange the necessary cables lest that they should be damaged or twisted while installing the
camera.
4. Install the camera body in the reverse order of “ ”.Disassembling
5. Close the dome cover.
`Securely fasten the fastening bolt using an L wrench to prevent water from leaking.
Outdoor installation
When you install it outside of the building, please waterproof it with waterproof butyl rubber tape (can be
purchased in stores) so that water does not leak from the gap of the cable connected to the outside.
1. Connect the power, I/O, and LAN cables.
2. Wrap the black cable jacket (Area A) and the cable connection area
with waterproof (butyl rubber) tape so that more than half of the
butyl rubber tape is overlapped.
J
`If the cable jacket is not waterproofed properly, then it can directly cause
leakage. Make sure to protect the cable with a dense layer of taping.
`Waterproof butyl tape is made of butyl rubber that can be stretched to twice
its normal length.
Ca erm a
Ca erm a
Ca erm a
S temys
S temys
S temys
AA
CAUTION: B e ware of th e Rated Volta ge and Pola rity
of the pow er con necti on.
CAUTION: B e ware of th e Rated Volta ge and Pola rity
of the pow er con necti on.
CAUTION: B e ware of th e Rated Volta ge and Pola rity
of the pow er con necti on.
DC12V
VIDEO
USB
AUDIO / ALM / RS485
RESET
2
1
CAUTION: B e ware of th e Rated Volta ge and Pola rity
of the pow er con necti on.
CAUTION: B e ware of th e Rated Volta ge and Pola rity
of the pow er con necti on.
CAUTION: B e ware of th e Rated Volta ge and Pola rity
of the pow er con necti on.
ACT LINK
NETWORK
VIDEO
AUDIO / ALM / RS485
USB
21
POWER
NETWORK
AUDIO
ALM
RS485
ACT LINK
NETWORK
VIDEO
AUDIO / ALM / RS485
USB
21
POWER
NETWORK
AUDIO
ALM
RS485
DC12V
VIDEO
USB
AUDIO / ALM / RS485
RESET
2
1
installation & connection
12_ installation & connection
Optional Accessories for Installation
For your easier installation, you can purchase appropriate optional accessories available.
1. WALL MOUNT ADAPTOR(SBP-300WM or SBP-300WM1)/
HANGING MOUNT(SBP-301HM2)
This adaptor is used when installing the dome camera onto a
wall.
2. CEILING MOUNT ADAPTOR(SBP-300CM)/HANGING MOUNT(SBP-
301HM2)
This adaptor is used when installing the dome camera on a concrete
ceiling.
3. The POLE MOUNT ADAPTOR(SBP-300PM) is the adapter to be used
when installing the WALL MOUNT ADAPTOR (SBP-300WM or SBP-
300WM1) on an 80mm or larger column.
4. CORNER MOUNT ADAPTOR (SBP-300KM)
This is an adaptor for WALL MOUNT ADAPTOR (SBP-300WM or
SBP-300WM1) installation on the corner of wall joint.
5. VANDAL BACK BOX (SBV-136B)
Adapter used for the installation of a vandal camera on the ceiling.
INSERTING/REMOVING A MICRO SD MEMORY CARD
J
`Disconnect the power cable from the camera before inserting the Micro SD memory card.
`Do not insert the Micro SD memory card while it’s upside down by force.
Otherwise, it may damage the Micro SD memory card.
`When it rains or the humidity is high, insertion or ejection of a Micro SD card is not recommended.
`Disassembly of the product cover should be finished within 5 minutes, or there will be the risk of internal dew condensati
Inserting a Micro SD Memory Card
1. Separate the Dome cover of the camera.
2. Insert a Micro SD card in the arrow direction shown in the figure.
ACT LINK
NETWORK
VIDEO
AUDIO / ALM / RS485
USB
21
POWER
NETWORK
AUDIO
ALM
RS485
VIDEO
21
English _13
●● INSTALLATION & CONNECTION
Removing a Micro SD Memory Card
Gently press down on the exposed end of the memory card as shown in the diagram to eject the memory
card from the slot.
J
`Pressing hard and releasing the Micro SD memory card when removing it may cause the Micro SD memory card to pop out
suddenly or damage the slot.
`Before removing the Micro SD memory card, in < >, set the device to < > and press the [ ] button and turn Storage Off Apply
the camera off. (Page 48)
`If you turn off the camera or remove the Micro SD memory card that contains data from the product, the data may be lost or
damaged.
MEMORY CARD INFORMATION (NOT INCLUDED)
What is a memory card?
The memory card is an external data storage device that has been developed to offer an entirely new way to
record and share video, audio, and text data using digital devices.
Selecting a memory card that’s suitable for you
Your camera supports Micro SD/SDHC/SDXC memory cards.
You may, however, experience compatibility issues depending on the model and make of the memory card.
The following types of memory cards from the following manufacturers are recommended for this camera.
- Manufacturer : SanDisk, Transcend
- Product family : High endurance
It is recommended to use a 16GB to 256GB (MLC type) memory card for this camera.
Playback performance can be affected depending on the speed of memory card.
Memory Card Components
Micro SD/SDHC/SDXC
Contacts
ACT LINK
NETWORK
VIDEO
AUDIO / ALM / RS485
USB
21
POWER
NETWORK
AUDIO
ALM
RS485
VIDEO
21
installation & connection
14_ installation & connection
CONNECTING WITH OTHER DEVICE
J
`The CVBS out terminal of the product is provided for easier installation, and is not recommended for monitoring purposes.
`The Micro USB out terminal of the product is provided for easier installation, and is not recommended for monitoring
purposes.
Ethernet Connection
Connect the Ethernet cable to the local network or to the Internet.
Connecting WiFi
Camera Setup
1. Connect OTG adapter (5-pin) and WiFi dongle to the micro USB terminal.
Smartphone Setup
1. Install the Wisenet Installation application.
2. Select the camera SSID after turning on the WiFi.
3. Run the Wisenet Installation application.
4. When you log in to the camera, the video will be connected. (initial password: 4321)
`The video will be played without being logged in during the initial connection.
5. You can adjust angle of view while watching the video through smartphone.
Recommended dongle manufacturer
Manufacturer Model
NETIS WF2123 n300
EDIMAX EW-7811Un
IP Time N100mini
TP-LINK TL-WN823N V1
ASUS USB-N13
NETGEAR WNA3100M
CAUTION: Be wa re of the
Rated Vol tage a nd Po larity
of the p ower c onnec tion.
CAUTION: Be wa re of the
Rated Vol tage a nd Po larity
of the p ower c onnec tion.
CAUTION: Be wa re of the
Rated Vol tage a nd Po larity
of the p ower c onnec tion.
ACT LINK
NETWORK
VIDEO
AUDIO / ALM / RS485
USB
21
SOFT
AP
POWER
NETWORK
AUDIO
ALM
RS485
Ethernet
Power
WiFi dongle
Monitor to install
English _15
●●INSTALLATION & CONNECTION
Power Supply
Use the screwdriver to connect each line (+, –) of the power cable to the corresponding power port of the
camera.
J
`If DC 12V and PoE power are supplied at the same time, the unit will operate with the external power (DC 12V).
- You can also use a router featuring PoE to supply power to the camera.
- Use PoE that is compliant with the IEEE 802.3af protocols.
- It is recommended to use either PoE or DC 12V alone rather than in combination.
`Be careful not to reverse the polarity when you connect the power cable.
`If you want to connect an external device, you must turn off the external device before proceeding.
`Connect the set and the adapter power line first, and then connect the power cable to the outlet on the wall.
Power Cable Specification for Each Model
Input power Wire Type (AWG) Cable Length (Max.)
DC 12V #18 19m
#16 30m
AC 24V #20 26m
#18 40m
Network Cable Specification
Item Contents Remark
Connector RJ45
Ethernet 10/100BASE-T 10/100 Mbps
Cable UTP Category 5e
Max Distance 100M
PoE Support IEEE 802.3af
Connecting to Audio Input/Output
1. Connect the AUDIO IN port of the camera with the microphone or LINE OUT port of the amplifier that the
microphone is connected to.
2. Connect the AUDIO OUT port of the camera with the speaker or LINE IN port of the amplifier that the
speaker is connected to.
3. Check the specifications for audio input.
• Audio Codec
- Audio In : G.711 PCM (Bit Rate: 64kbps / Sampling Frequency: 8kHz), G.726 ADPCM (Bit Rate:
16Kbps, 24Kbps, 32Kbps, 40Kbps / Sampling Frequency: 8kHz), AAC (Bit Rate: 48Kbps / Sampling
Frequency: 16kHz)
- Audio Out : G.711 PCM (Bit Rate: 64kbps / Sampling Frequency: 8kHz)
• Full duplex Audio
• Audio in : Selectable (microphone/Line-in), Supported voltage: 2.5VDC (4mA), Input impedance: 2K Ohm
• Audio out : Line-out (3.5mm mono jack), Maximum output: 1Vms
• Line out impedance : 600Ω
Network
Microphone
Microphone
Microphone
Amp Amp
Speaker
Speaker
Speaker
PC
installation & connection
16_ installation & connection
Connecting to the I/O port box
Connect the Alarm I/O cable to the corresponding port of the port box.
• ALARM-IN : Used to connect the alarm input sensor or external day/night sensor.
• ALARM-OUT : Used to connect the alarm output signal.
• GND : Common port for alarm in/output signal.
J
`If devices (e.g., flashing light and siren) that exceed the voltage and current specifications are connected by using the open
collector method, it may cause malfunction.
Refer to the “ ” when connecting devices that exceed the voltage and current specifications. (page Alarm Out Wiring Diagram
To connect the external sensor
Connect one strand of each signal line (2-strand) of the sensors to the [ ] port, and connect the ALARM IN
other strand to the [ ] port.GND
RS-485 communication
• Control signal connection diagram
RS-485+
RS-485-
TXD+
TXD-
Camera Controller
Communication cable
An RS-485 communication line is needed for communication between the camera and the controller.
J
`It is recommended that the cable length be less than 30M.
`The communication cable is not included.
`Refer to “ ” for the terminal setting method. (Pages 37~38)RS-485
DC12V
VIDEO
USB
AUDIO / ALM / RS485
RESET
2
1
Sensor Alarm
(Warning lamp)
English _17
●●INSTALLATION & CONNECTION
Alarm In Wiring Diagram
Alarm Out Wiring Diagram
Sensor
GND
RESISTORALARM IN (5mA SINK)
RESISTOR RESISTOR
VCC_3.3V
DIODE
GND
MLCC TRANSISTOR
External
connection
Inside of the camera
Warning lamp /
Siren power
Warning lamp /
Siren
(
-
) (
+
)
ALARM OUT (12VDC 20mA MAX)
RESISTOR 10K ohm
DIODE
RELAY
DC 5V or 3.3V
TRANSISTOR
GND
GND
TRANSISTOR
External connection Inside of the camera
GND
RESISTOR
18_ network connection and setup
network connection and setup
You can set up the network settings according to your network configurations.
CONNECTING THE CAMERA DIRECTLY TO LOCAL AREA NETWORKING
Connecting to the camera from a local PC in the LAN
1. Launch an Internet browser on the local PC.
2. Enter the IP address of the camera in the address bar of the browser.
M
`A remote PC in an external Internet out of the LAN network may not be able to connect to the camera installed in the intranet
if the port-forwarding is not properly set or a firewall is set.
In this case, to resolve the problem, contact your network administrator.
`In the IP installer, you can use the initial password, “ ” to set IP Address, Subnet Mask, Gateway, HTTP Port, VNP Port, IP 4321
type. After changing the network interface, for better security, access the web viewer and change the password.
`By factory default, the IP address will be assigned from the DHCP server automatically.
If there is no DHCP server available, the IP address will be set to 192.168.1.100.
To change the IP address, use the IP Installer.
For further details on IP Installer use, refer to “ ”. (Page Static IP Setup 20)
CONNECTING THE CAMERA DIRECTLY TO A DHCP BASED DSL/CABLE
MODEM
1. Connect the user PC directly with the network camera.
2. Run the IP Installer and change the IP address of the camera so that you can use the web browser on
your desktop to connect to the Internet.
3. Use the Internet browser to connect to the web viewer.
4. SetupMove to [ ] page.
5. Network DDNSMove to [ ] – [ ] and configure the DDNS settings.
6. Basic IP & Port DHCPMove to [ ] – [ ], and set the IP type to [ ].
7. Connect the camera, which was removed from your PC, directly to the modem.
8. Restart the camera.
M
`For configuring the DDNS settings, refer to “ ”. (page DDNS 45)
`For registering the DDNS settings, refer to “ ”. (page Registering with DDNS 45)
`Refer to “IP & Port” for how to setup IP. (page 34)
<Local Network>
Camera
Camera
Local PC
INTERNET
External Remote PC
DDNS Server
(Data Center, KOREA)
Camera External Remote PC
DDNS Server
(Data Center, KOREA)
DSL/Cable Modem
INTERNET
English _19
●●NETWORK CONNECTION AND SETUP
CONNECTING THE CAMERA DIRECTLY TO A PPPoE MODEM
1. Connect the user PC directly with the network camera.
2. Run the IP Installer and change the IP address of the camera so that you can use the web browser on
your desktop to connect to the Internet.
3. Use the Internet browser to connect to the web viewer.
4. SetupMove to [ ] page.
5. Network DDNSMove to [ ] – [ ] and configure the DDNS settings.
6. Basic IP & Port PPPoEMove to [ ] – [ ] Setup Page, set the IP type to [ ], and enter the network service’s ID
and password.
7. Connect the camera, which was removed from your PC, directly to the modem.
8. Restart the camera.
M
`For configuring the DDNS settings, refer to “ ”. (page DDNS 45)
`For registering the DDNS settings, refer to “ ”. (page Registering with DDNS 45)
`Refer to “IP & Port” for how to setup IP. (page 34)
CONNECTING THE CAMERA TO A BROADBAND ROUTER WITH THE
PPPoE/CABLE MODEM
This is for a small network environment such as homes, SOHO and ordinary shops.
Configuring the network settings of the local PC connected to a Broadband Router
Configuring the network settings of the local PC connected to a Broadband Router, follow the instructions
below.
•Select : < > Network < > Properties < > Local Area Connection < > General < > Properties
< > Internet Protocol (TCP/IP) < > Properties < > or <Obtain an IP address automatically Use the
following IP address>.
•Follow the instructions below if you select < >:Use the following IP address
ex1) If the address (LAN IP) of the Broadband Router is 192.168.1.1
IP address : 192.168.1.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.1.1
ex2) If the address (LAN IP) of the Broadband Router is 192.168.0.1
IP address : 192.168.0.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.0.1
ex3) If the address (LAN IP) of the Broadband Router is 192.168.xxx.1
IP address : 192.168.xxx.100
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.xxx.1
M
`For the address of the Broadband Router, refer to the product’s documentation.
`For more information about port forwarding of the broadband router, refer to “Port Range Forward (Port Mapping) Setup”.
(Page 22)
Camera
Camera
Local PC
Broadband
Router
PPPoE or
Cable Modem
PPPoE or
Cable Modem External Remote PC
DDNS Server
(Data Center, KOREA)
INTERNET
Camera External Remote PC
DDNS Server
(Data Center, KOREA)
PPPoE Modem
INTERNET
network connection and setup
20_ network connection and setup
BUTTONS USED IN IP INSTALLER
Item Description
a
Device Name
Model name of the connected camera.
Click the column to sort the list by model name.
However, search will be stopped if clicked during the search.
b
Alias This function is not currently implemented.
c
Mode Displays either < > or < > for the current network connection Static>, <Dynamic PPPoE
status.
d
MAC(Ethernet) Address
Ethernet address for the connected camera.
Click the column to sort the list by Ethernet address.
However, search will be stopped if clicked during the search.
e
IP Address
IP address.
Click the column to sort the list by IP address.
However, search will be stopped if clicked during the search.
f
Protocol
Network setting for the camera.
The factory default is “IPv4”.
Cameras with the IPv6 setting will be displayed “IPv6”.
g
URL
DDNS URL address enabling access from the external Internet.
However, this will be replaced with the < > of the camera if DDNS registration IP Address
has failed.
h
IPv4 Scans for cameras with the IPv4 setting.
Item Description
i
IPv6 Scans for cameras with the IPv6 setting.
Activated in an IPv6 compliant environment only.
j
Search Scans for cameras that are currently connected to the network.
However, this button will be grayed out if neither IPv4 nor IPv6 is checked.
k
Auto Set The IP Installer automatically configures the network settings.
l
Manual Set You should configure the network settings manually.
m
Exit Exits the IP Installer program.
M
`
For the IP installer, use only the installer version provided in the installation CD or use the latest one if available. You can dow
the latest version from the Hanwha Techwin web site.
`If the supporting OS is Windows 8.1, it is recommended that you use the Wisenet Device Manager instead of the IP Wisen
The Wisenet Device Manager Program can be downloaded by visiting the Hanwha Techwin website (http://www.hanwha
security.com) under the menu < > - <Customer Support Technical Guides> - <Online Tool>.
STATIC IP SETUP
Manual Network Setup
Run < > to display the camera search list. IP Installer_v2.XX.exe
At the initial startup, both [ ] and [ ] will be grayed out.Auto Set Manual Set
M
`For cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not support this function.
1. Select a camera in the search list.
Check the MAC address of the camera on the camera’s label.
Both the [ ] and [ ] buttons will be Auto Set Manual Set
activated.
2. Manual SetClick [ ].
The Manual Setting dialog appears.
< >, < >, < >, <IP Address Subnet Mask Gateway HTTP
Port VNP Port>, and < > of the camera are displayed in the
preset values.
3. AddressIn the < > pane, provide the necessary information.
• MAC (Ethernet) Address : The MAC address imprinted on
the camera label is automatically displayed and requires no
user setting.
M
`IP related parameters can be set only when DHCP is not checked.
a b c d e f g
h i j k l m
English _21
●● NETWORK CONNECTION AND SETUP
If not using a Broadband Router
For setting < >, < >, and < >, contact your network administrator.IP Address Subnet Mask Gateway
4. PortIn the < > pane, provide necessary information.
•HTTP Port : Used to access the camera using the Internet
browser, defaulted to 80.
•VNP Port : Used to control the video signal transfer,
defaulted to 4520.
5. Enter the password.
Enter the password of “ ” account, which was used to admin
access the camera.
J
`For the security purposes, you are recommended to use a combination of numbers, alphabets uppercase and lowercase and
special characters for your password.
`If you want to change the password, refer to “ ” of the user setup. (page Administrator password change 33)
6. OKClick [ ].
Manual network setup will be completed.
If using a Broadband Router
•IP Address : Enter an address falling in the IP range provided
by the Broadband Router.
ex) 192.168.1.2~254, 192.168.0.2~254,
192.168.XXX.2~254
•Subnet Mask : The < > of the Broadband Router Subnet Mask
will be the < > of the camera.Subnet Mask
•Gateway : The < > of the Broadband Router Local IP Address
will be the < > of the camera.Gateway
M
`The settings may differ depending on the connected Broadband
Router model.
For more information, refer to the user manual of the applicable router.
`For more information about port forwarding of the broadband router, refer to “Port Range Forward (Port Mapping) Setup”.
(Page 22)
If the Broadband Router has more than one camera connected
Configure the IP related settings and the Port related settings distinctly with each other.
ex)
Category Camera #1 Camera #2
IP related settings
IP Address
Subnet Mask
Gateway
192.168.1.100
255.255.255.0
192.168.1.1
192.168.1.101
255.255.255.0
192.168.1.1
Port related settings HTTP Port
VNP Port
8080
4520
8081
4521
M
`If the < > is set other than 80, you must provide the < > number in the address bar of the Internet browser HTTP Port Port
before you can access the camera.
ex) http://IP address : HTTP Port
http://192.168.1.100:8080
Auto Network Setup
Run < > to display the camera search list. IP Installer_v2.XX.exe
At the initial startup, both [ ] and [ ] will be grayed out.Auto Set Manual Set
M
`For cameras found with the IPv6 setting, these buttons will be grayed out as the cameras do not support this function.
1. Select a camera in the search list.
Check the MAC address of the camera on the camera’s label.
Both the [ ] and [ ] buttons will be Auto Set Manual Set
activated.
2. Auto SetClick [ ].
The Auto Setting dialog appears.
The < >, < >, and < > will IP Address Subnet Mask Gateway
be set automatically.
3. Enter the password.
Enter the password of “ ” account, which was used to admin
access the camera.
J
`For the security purposes, you are recommended to use a
combination of numbers, alphabets uppercase and lowercase and
special characters for your password.
`If you want to change the password, refer to “Administrator
password change” of the user setup. (page 33)
4. OKClick [ ].
Auto network setup will be completed.
network connection and setup
22_ network connection and setup
DYNAMIC IP SETUP
Dynamic IP Environment Setup
•Example of the Dynamic IP environment
- If a Broadband Router, with cameras connected, is assigned an IP address by the DHCP server
- If connecting the camera directly to modem using the DHCP protocols
- If IPs are assigned by the internal DHCP server via the LAN
Checking the Dynamic IP
1. Run the IP Installer on the user’s local computer.
Cameras allocated with < > address are shown in Dynamic IP
the list.
2. Select a camera from the search result.
3. Manual SetClick the [ ] button and check the camera’s
< > address. Dynamic IP
If you uncheck < >, you can change IP to < >.DHCP Static
PORT RANGE FORWARD (PORT MAPPING) SETUP
If you have installed a Broadband Router with a camera connected, you must set the port range forwarding on the
Broadband Router so that a remote PC can access the camera in it.
Manual Port Range Forwarding
1. From the Setup menu of the Broadband Router, select
< > - < >. Applications & Gaming Port Range Forward
For setting the port range forward for a third-party Broadband
Router, refer to the user guide of that Broadband Router.
2. TCP UDP PortSelect < > and < > for each connected camera
to the Broadband Router.
The number of each port to be configured to the IP router
should be set according to the port number designated
in < > - < > - < > on the camera web Setup Basic IP & Port
viewer.
3. Save SettingsWhen done, click [ ].
Your settings will be saved.
M
`Above sample instructions are based on the CISCO’s Broadband Router.
`The settings may differ depending on the connected Broadband Router model.
For more information, refer to the user manual of the applicable router.
Setting up Port Range Forward for several network cameras
•You can set a rule of Port Forwarding on the Broadband Router device through its configuration web page.
•A user can change each port using the camera setting screen.
When Camera1 and Camera2 are connected to a router :
M
`Port forwarding can be done without additional router setup if the router supports the UPnP (Universal Plug and Play) function.
After connecting the network camera, select the checkbox from the menu < > in < > in Quick connect Wisenet DDNS
“Settings -> -> Network DDNS”.
User Internet
Broadband Router
Start End Protocol IP Address
3000 3000 TCP/UDP 192.168.1.100
3001 3001 TCP/UDP 192.168.1.101
4520 4520 TCP/UDP 192.168.1.100
4521 4521 TCP/UDP 192.168.1.101
8080 8080 TCP/UDP 192.168.1.100
8081 8081 TCP/UDP 192.168.1.101
Camera1 (192.168.1.100)
HTTP port 8080
Device port 4520
RTSP port 3000
Camera2 (192.168.1.101)
HTTP port 8081
Device port 4521
RTSP port 3001
English _23
●●networK connection anD Setup
connectinG to tHe camera from a SHareD LocaL pc
1. Run the IP Installer.
It will scan for connected cameras and display them as a list.
2. Double-click a camera to access.
The Internet browser starts and connects to the camera.
M
`Access to the camera can also be gained by typing the camera’s IP
address in the address bar of the Internet browser.
connectinG to tHe camera from a remote pc via tHe
internet
Since using the IP Installer on a remote computer that is not in the Broadband Router’s network cluster is not
allowed, users can access cameras within a Broadband Router’s network by using the camera’s DDNS URL.
1. Before you can access a camera in the Broadband Router network, you should have set the port range
forward for the Broadband Router.
2. From the remote PC, launch the Internet browser and type the DDNS URL address of the camera, or the
IP address of the Broadband Router in the address bar.
ex) http://ddns.hanwha-security.com/ID
M
`For registering the DDNS settings, refer to “ ”. (page Registering with DDNS 45)
24_ web viewer
web viewer
CONNECTING TO THE CAMERA
Normally, you would
1. Launch the Internet browser.
2. Type the IP address of the camera in the address bar.
ex) • IP address (IPv4) : 192.168.1.100
http://192.168.1.100
- the Login dialog should appear.
• IP address (IPv6) : 2001:230:abcd: ffff:0000:0000:ffff:1111
http://[2001:230:abcd:ffff:0000:0000:ffff:1111] - the Login
dialog should appear.
If the HTTP port is other than 80
1. Launch the Internet browser.
2. Type the IP address and HTTP port number of the camera in the address bar.
ex) IP address : 192.168.1.100:HTTP Port number(8080)
http://192.168.1.100:8080 - the Login dialog should appear.
Using URL
1. Launch the Internet browser.
2. Type the DDNS URL of the camera in the address bar.
ex) URL address : http://ddns.hanwha-security.com/ID
- the Login dialog should appear.
J
`Network connection is disabled in the LAN only environment.
Connecting via UPnP
1. Run the client or operating system in support of the UPnP protocol.
2. Click the camera name for search.
In the Windows operating system, click the camera name searched from the network menu.
- The login window is displayed.
Connecting via Bonjour
1. Run the client or operating system in support of the Bonjour protocol.
2. Click the camera name for search.
In the Mac operating system, click the camera name searched from the Bonjour tab of Safari.
- The login window is displayed.
To check the DDNS address
If the camera is connected directly to the DHCP cable modem, DSL modem, or PPPoE modem, the IP
address of your network will be changed each time you try to connect to the ISP (Internet Service Provider)
server.
If this is the case, you will not be informed of the IP address changed by DDNS.
Once you register a dynamic IP-based device with the DDNS server, you can easily check the changed IP
when you try to access the device.
To register your device to the < > server, visit http://ddns.hanwha-security.com and register your device DDNS
first, and then set the Web Viewer’s < > - < > to < >, as well as providing Network DDNS Wisenet DDNS
< > that had been used for DDNS registration.Product ID
English _25
●●WEB VIEWER
PASSWORD SETTING
When you access the product for the first time, you must register the
login password.
When the “ ” window appears, enter the new Password change
password.
J
`For a new password with 8 to 9 digits, you must use at least 3 of
the following: uppercase/lowercase letters, numbers and special
characters. For a password with 10 to 15 digits, you must use at
least 2 types of those mentioned.
-Special characters that are allowed. : ~`!@#$%^*()_-+=|{}[].?/
`For higher security, you are not recommended to repeat the same characters or consecutive keyboard inputs for your
passwords.
`If you lost your password, you can press the [ ] button to initialize the product. So, don’t lose your password by using a RESET
memo pad or memorizing it.
LOGIN
Whenever you access the camera, the login window appears.
Enter the User ID and password to access the camera.
1. admin User nameEnter “ ” in the < > input box.
The administrator ID, “ ”, is fixed and can not be admin
changed.
2. PasswordEnter the password in the < > input field.
3. OKClick [ ].
If you have logged in successfully, you will the Live Viewer
screen.
J
`When you access the camera web viewer, pay special attention to the
security by checking whether the image data is encrypted.
M
`If you check the “ ” option when your input is done, in future you will be logged in automatically Remember my credentials
without being prompted to enter the login information.
`You will experience the best video quality if the screen size is 100%. Reducing the ratio may cut the image on the borders.
PLUG-IN SUPPORT SPECIFICATIONS FOR EACH BROWSER
The existing plug-in web viewer and a new plug-in free web view is embedded together.
This allows you to use the web viewer in newer browser environments that do not support plug-ins, such as
Chrome, EDGE and FireFox (Windows 64-bit only). For browsers that allow the installation of plug-ins, such as IE
and Safari, installing the plug-in is recommended.
According to the browser environment, the following differences may be observed.
•Chrome, FireFox(Windows 64bit only), EDGE browser : Although they don’t support plug-ins, you can
use a web viewer as a plug-in free web viewer is embedded.
J
`As the plug-in free webviewer has lower performance than the plug-in webviewer, it has a limit on the monitoring of high
quality profiles and playback of saved videos.
To monitor high quality profiles and play saved videos, use either a plug-in webviewer or SmartViewer.
-Plugin-free webviewer creation conditions: The selected profile exceeds MJPEG Full HD 10fps H.264 (Chrome : full screen
resolution supported / Edge, Firefox, Safari : Full HD 30 fps or higher) H.265 FullHD 10fps 2Mbps or higher
-Plugin-free playback conditions: MJPEG/H.264 full screen resolution, H.265 HD or below
`The plug-in free feature has been optimized for the Chrome browser.
`Supports Adaptive Streaming
-This is the feature that automatically lowers the profile if there is a delay of more than 5 seconds. It was made to prevent
issues such as increased latency and no response from the browser when playing the video on a system with lower hardware
specifications than recommended.
The video profile is reduced in the following sequence: 1920X1080(20fps) -> 1280X720(20fps) -> 640X480(20fps).
•IE, Safari browser : You can use a web viewer even if you don’t install the existing plug-in web viewer.
J
`To monitor/play saved video seamlessly, you are required to install a plug-in.
English _27
●●WEB VIEWER
Item Description
o
Alarm output Activate the Alarm Out port.
p
Audio control Activates audio and adjusts the volume.
J
`Some functions may not work on a specific browser or codec.
To capture the snapshot
1. Capture ( )Click [ ] on the scene to capture.
2. When a captured video is saved, a notification message appears.
The captured image is saved in the designated folder for each browser.
M
`If the screen is not captured by IE browser in Windows 7 or higher, run the IE Browser with the Admin privilege.
To save
1. Record ( )Click the [ ] icon.
2. To end the recording, press [Record ( )] again.
M
`You can save the recorded file on the PC in an avi file format. Designate a path and save the video.
To fit the full screen
1. Full Screen ( )Click the [ ] icon.
2. This will fit the Viewer to the full screen.
3. To leave full screen mode, click the [Full Screen ( ) Esc] button again or press the [ ] key on the
keyboard.
To Use Audio
1. Audio ( )Click [ ] icon to activate audio communication.
2. Use [ ] bar to control the volume.
M
`If there is no sound from pulling in and out the audio jack while it is in operation, click the [ ] icon to enable it Audio ( )
again.
`To use audio, you need to set < ” to < > (page Audio in> in “Video Profile Enable 31).
Item Description
g
Profile type
You can select a profile type in < > under the < > setup menu.Video profile Basic
`Click the icon to display the name of the current profile.
J
`
Afterimages can be displayed on the screen under the following conditions if the video is
played in the monitoring page:
-The resolution is changed due to a profile change.
-Incoming data is being slowed due to a network delay when the profile is changed.
-The web browser window size and location is changed.
h
PTZ
Controls pan/tilt/zoom operation of the camera.
Zoom In ( )
Zoom in on the screen by raising the bar on the right side of the UI or
by pressing the [ ] button.
The farther the position of the bar from the center, the faster the
zoom-in speed.
Zoom Out ( )
Reduce the scale of the screen by lowering the bar on the right side
of the UI or by pressing the [ ] button.
The farther the position of the bar from the center, the faster the
zoom-out speed.
Close-range focus ( ) It focuses on objects at close range.
Long-range focus ( ) It focuses on objects at long range.
Automatic tracking ( ) When the icon is clicked and changes to ON, objects/people are
tracked automatically.
Auto focus ( ) It automatically adjusts the focus of the screen.
i
Profile access information You can read the profile information.
j
Switch View Mode
Full Screen ( ) Double click on the video screen, and the current video will be
played in the full screen of the monitor.
Fit to screen ( ) A view mode in which the size of the camera video automatically fits
to the web browser size.
Size of the original file
( ) View mode in which the video is played in the actual resolution.
Maintain Aspect Ratio
( ) View mode that adjusts the aspect ratio to best fit the resolution.
k
Capture Saves the current image as an image file.
l
Record The user can save the video on the PC.
m
Pixel Counter Checks the number of pixels in the selected area on the video screen.
n
Microphone control Activates the microphone.
web viewer
28_ web viewer
To Use Microphone
Click [ ] icon to activate the microphone.Mic ( )
M
`If you are using IE or the Safari browser, you will need to install plug-in.
To count the number of pixels
1. Pixel count ( )Click the [ ] icon to activate it.
2. Drag the mouse on the video to select an area.
3. The number of pixels in the selected area is displayed on the screen.
To control the PTZ
1. Click the [ ] icon.
2. Move the jog dial [ ] on the scroll pad to move the camera direction, or move the bar on the right side
of the UI up or down to adjust the zoom.
3. Select [ ] in the screen focus to adjust the focus.
To run a sequence
• Preset : Executes the saved preset.
For detailed preset settings, refer to “To configure the detailed settings for the preset”. (page 35)
- Home : Launches the saved home position.
- Set : Specifies the preset.
• Swing : Run a saved swing.
Refer to “To configure the swing settings” for details of swing setting. (page 36)
• Group : Run a saved group.
Refer to “To set a group” for details of group setting. (page 36)
• Tour : Run a saved tour.
Refer to “To configure the tour settings” for details of tour setting. (page 36)
• Trace : Run a saved trace.
Refer to “To set the tracing function” for details of trace setting. (page 37)
To enable the Area Zoom mode
• : For zoom movement, click and drag to the location on the screen that you want to move to.
• : Change the current zoom factor to x1.
• : Return to the previous area and settings.
• : If navigated with Prev, it is switched to area and setting before navigation.
To use the Lock-On function
Right-click on a video, and select the object of auto tracing manually.
To check the profile status
You can check the profile information.
1. Status ( Click the [ )] icon.
2. The profile access information screen is updated whenever the screen is enabled.
•Profile access : Show the information of the newly added profile.
- Profile : Show the information of the newly added codec.
- Bitrate(kbps) : Show both the actual bit rate and the set bit rate.
- Framerate(fps) : Show both the actual frame rate and the set frame rate.
- ATC(%) : Show the ATC status.
- Concurrent users count : Show the number of concurrent users who access the profile.
•Current users : Shows information on users accessing web viewer and displaying monitoring video.
- Profile : Show the name of the profile accessed by the user.
- Bitrate(kbps) : Show the current bit rate.
- Network connection status : It shows whether the network is working fine.
- IP address : Show the IP address of the current user.
web viewer
30_ web viewer
To play after searching by time
1. Click the [ ] icon.
2. On the calendar, set the search date, start time and end time.
The event searched is displayed on the time bar.
3. Play ( Click the [ )] button.
The video at the selected time will be played.
4. When a video is played, the recording time of the video currently being played is displayed.
5. Search the video forward and backward and adjust the playback speed.
- How to Move Playback Interval
When the [ , ] button is selected, it moves forward by 1 frame/moves backward by i frame.
- How to Control Playback Speed
Click the [ ] button and you can select a speed of either 1x, 2x, 4x and 8x or -1x, -2x, -4x and -8x,
and you can set the playback speed as desired.
6. Time Bar ( Move the position of the [ )] to play the video at a desired time.
To back up the searched video
1. BackupDuring playback, click [ ] on the scene to back up.
The data in the applicable section will be backed up.
2. ApplyClick [ ] button.
The Save As window appears.
3. SaveConfirm the save path and click [ ] button.
The screenshot will be backed up to the specified path.
To play the backup video
The backed up images are saved in an .avi format. Installing the media player that supports the format for the
user PC is recommended.
M
`If playback does not run smoothly due to the user environment, optimizing by installing the latest codec and other methods
are required.
To Play an AVI File
(1) Micro SD memory card
1. Separate the Micro SD memory card from the camera.
J
`Before separating the Micro SD memory card, set the < > to < > in the “Device Off Setup
Event Storage” menu.
2. Insert the Micro SD memory card into the PC.
3. Play the AVI file in the “ RecordingData YYYY_mm_DD
AVI” directory, using a media player.
M
`A filename starts with the format “001_YYYYMMDD_HHMMSS.avi”
and the file number is incremented by one.
YYYYMMDD_HHMMSS indicates the start time of data saving.
`“001_YYYYMMDD_HHMMSS.smi” file is a caption file, and you can
view it if it exists in the same directory as its related AVI file.
`Once corrupted, the data in the Micro SD memory card cannot be
replayed in the Web Viewer’s [Playback].
(2) NAS (Network-Attached Storage)
1. In Windows browser, use \\<ip address>\ to access.
ex) 192.168.13.250 defaultfolder 2017_01_13 AVI
2. ComputerGo to < > < > Network drive connection
Enter 1.
3. Connected to the NAS.
The directory structure is same as the directory structure for a
Micro SD memory card.
M
`A filename starts with the format “001_YYYYMMDD_HHMMSS.avi”
and the file number is incremented by one.
YYYYMMDD_HHMMSS indicates the start time of data saving.
`“001_YYYYMMDD_HHMMSS.smi” file is a caption file, and you can
view it if it exists in the same directory as its related AVI file.
`If you change or damage the saved data on your own, it will not play
back or save properly.
English _31
●● SETUP SCREEN
setup screen
SETUP
You can configure the basic camera information, PTZ, video and audio, network, event, analyze, system and open
platform settings.
1. Setup ( On the live screen, click the [ )] button.
2. The Setup screen appears.
BASIC SETUP
Video profile
1. Basic ( )From the Setup menu, select the < > tab.
2. Video profileClick < >.
3. Video profile connection policySet the < >.
• Keep connection when profile setting is changed : Output
uses the same settings even when the settings of the
active profile are changed.
If not selected, changing a profile used by an existing
connection resets such connection.
4. Select each profile properties.
For more details, refer to “To Add/Change the Video
Profile”. (Page 32)
5. Click the input box of each item and enter / select a desired
value.
`The context menu may differ depending on the selected codec type.
• Default profile : If no profile is selected when using the Web Viewer, the default video profile is applied.
• E-mail/FTP profile : Video profile to be transferred to the specified email or FTP site.
`Only the MJPEG codec can be set as the E-mail/FTP profile.
• Record profile : This is the profile that is applied to video recording.
6. Select whether or not to input audio in the video.
Select the < > check box and you can input audio in the video.Audio In
7. According to your situation, set ATC (Auto Transmit Control) mode.
• ATC mode : It adjusts the video properties according to the
variance in the network bandwidth, controlling the bit rate.
Adjusting the bit rate depends on the ATC mode.
- Control framerate : Reduce the frame rate if the network
bandwidth drops down.
- Control compression : Control the compression rate if the network bandwidth drops down.
Compression adjustment can cause deterioration of the image quality.
- Event(MD) : Activated when the motion detection (MD) event is set. Frame rate is adjusted when an
event occurs.
If no motion is detected in the surrounding area, the minimum amount of frames is output to save the
bandwidth use.
`If < > is set to < >, the encoding priority according to the ATC mode will be fixed as below:Bitrate control CBR
Bitrate control / ATC mode Control framerate Control compression Event(MD)
CBR Compression Framerate Framerate
• Sensitivity : Affect the transfer rate according to the variance in the network bandwidth.
The transfer rate will be adjusted to the fastest if the bandwidth is <Very high>, and adjusted to the
latest if the bandwidth is <Very low>.
• Limit : If the quality or frame rate is adjusted, the property will be changed to the applied value (%)
against the previous setting value (100%).
Note that if you reduce the property value too much, you may encounter flickering on the screen. So it
is advisable to adjust the value within the threshold.
J
`It is recommended to apply ATC control only for cameras supporting ATC.
`Set the ATC sensitivity to <Very low> in a network environment with high variance in the network bandwidth.
`If the network connection is unstable, you may encounter flickering on the screen.
8. ApplyWhen done, click [ ].
setup screen
32_ setup screen
To Add/Change the Video Profile
The profile setup can be added or modified to accommodate various profiles depending on the recording
conditions.
1. Video profile AddIn < >, click the < > button.
2. Provide the name and select a codec.
3. Specify the conditions under which the codec will be applied.
4. Specify the details of the selected codec including resolution and frame rate.
•Resolution : Set the video size of the H.264/H.265 and MJPEG files.
•Framerate : Set the max number of video frames per sec.
M
`The Sensor mode setup in Camera Setup changes the maximum configurable framerate.
Sensor 25 fps 30 fps 50 fps 60 fps
Framerate 1~25 fps 1~30 fps 1~50 fps 1~60 fps
•Maximum bitrate : Set the max bit rate of video when the bit rate control is set to VBR.
J
`As the bit rate can be adjusted limitedly according to the resolution, frame rate and screen complexity, the actual bit rate
can be greater than the maximum bit rate. So you must consider the use conditions when setting the value.
•Target bitrate : Set the target bit rate when the bit rate control is set to CBR.
•Bitrate control : You can select one from constant bit rate and variable bit rate for compression. Fixed
bitrate means that the network transmission bitrate is fixed while varying the video quality or frame rate,
variable bitrate means that a higher priority is placed on the video quality while varying the bitrate.
J
`After setting the fixed bit rate for bit control, if you select the video quality priority mode, depending on the complexity of
the screen, the actual transmitted frame rate may differ from the frame rate setup in order to guarantee the optimal video
quality for the given bit rate.
•Encoding priority : You can set the priority of video transmission to frame rate or compression.
•GOV length : It specifies the distance (in terms of number of frames) between two consecutive I-Frames
in a video sequence when H.264/H.265 codec was selected. (One I-Frame + 0~Several P-Frames)
•Profile : You can select the profile of the H.264 codec.
•Entropy coding : Reduce the possible compression loss due to encoding.
•Smart codec : Specify the use of Smart codec.
M
`You can use this when the bit rate control value is CBR. Detailed settings are configured in the Smart Codec on the
Audio & Video tab. (Page 44)
•Dynamic GOV : When the bit rate control is VBR in H.264/H.265 codec, it makes the GOV length
automatically change to the set value of the maximum dynamic GOV.
•Dynamic FPS : Set the FPS value to automatically change the setting of the FPS value to the maximum
dynamic value when the bit rate control is VBR between H.264/H.265 codec.
•Multicast(RTSP) : Specify the use of the RTSP protocol.
- IP address : Enter an IPv4 address with which you can connect to the IPv4 network.
- Port : Specify the video communication port.
- TTL : You can set the TTL for the RTP packet.
J
`If you set the Multicast address to 224.0.0.0~224.0.0.255, multicast may not work properly in all environments. In that
case, we recommend you change the multicast address.
What is GOV length?
GOV(Group of Video object planes) is a set of video frames for H.264/H.265 compression, indicating a
collection of frames from the initial I-Frame to the next I-Frame. GOV consists of 2 kinds of frames: I-Frame
and P-Frame.
I-Frame is the basis frame of compression, and contains data for a completed single image. P-Frame
contains only the data that has changed from the preceding I-Frame.
For H.264/H.265 codec, you can determine the GOV length.
If you set a recording profile with H.264/H.265 codec, the GOV length will be framerate/2.
What is dynamic GOV?
Dynamic GOV is a function that enables the GOV to automatically change in a range from the set value of the
minimum GOV length to the maximum dynamic GOV set value according to the situation of the video.
In a video with almost no motion, GOV operates with the dynamic GOV settings, which makes the bit rate of
the entire video reduced. The I-frame is output right after a motion is detected and GOV operates with the
GOV length settings until the motion disappears.
If you use this function, the GOV of a video operates with the minimum GOV length settings.
English _33
●●SETUP SCREEN
User
1. Basic ( )From the Setup menu, select the < > tab.
2. UserClick < >.
3. Provide the necessary user information.
•Administrator password change : Change the password
for the administrator.
J
`For the security purposes, you are recommended to use a
combination of numbers, alphabets uppercase and lowercase
and special characters for your password.
`It is recommended to change your password once every three
months.
`The password length and limits are shown as follows.
-A combination of at least three types of upper case, lower case, numeric, and special characters: 8 to 9 characters.
-A combination of at least two types of upper case, lower case, numeric, and special characters: 10 to 15 characters.
-Should be different from the ID.
-Don’t use 4 or more characters consecutive together. (examples : 1234, abcd)
-Don’t use 4 or more characters repeated. (examples : !!!!, 1111, aaaa)
-Special characters that are allowed. : ~`!@#$%^*()_-+=|{}[].?/
-After the factory setting, the admin and user passwords are initialized. You need to reset the password.
-When you access the camera web page for the first time or access it after the initialization, you will be moved to the
admin password setting menu.
-In this menu, you need to login again with the new password before using the camera web page menus.
-If the existing password is not matched, when you change the admin password, you cannot change the password.
-After changing your password, if there is a camera connected to a CMS or NVR client, then you need to re-register it
with the newly changed password. If the camera is still connected with the same password, then the account may be
locked because a client uses the previous password.
`If you try to login with the registered account, 5 or more consecutive password authentication has failed, and then the
account may be locked for thirty seconds.
`When the password is changed while multiple connections are active from a PC, the browser may malfunction. In that
case, reconnect to the server.
•Guest setup : If you select < >, the guest account can access the Web viewer Enable guest access
screen but can only view the live Viewer screen.
`The ID/password for the guest account is < >, which cannot be changed.guest/guest
•Authentication setup : If you select < >, you can Enable RTSP connection without authentication
access RTSP without logging in and view the video.
•Current users : If you select < >, you can set or change the user permissions.Use
`The administrator may set up audio input, audio output, alarm output and PTZ authority.
`Audio In / Audio Out / Alarm Out / PTZ : You can set whether the current user account can use live Audio In / Audio Out / Alarm
Out / PTZ control.
`Profile : If you select < >, you can only see the default profile video; if selecting < >, you can see the full profile Default All
videos.
J
`ONVIF functions available to a registered user allowed to use ONVIF functions are limited to those of granted with permission.
4. ApplyWhen done, click [ ].
Date & Time
1. Basic ( )From the Setup menu, select the < > tab.
2. Date & TimeClick < >.
3. Specify the time and date that will be applied to the camera.
•Current system time : Displays the current time settings of
your system.
•Timezone : Specify the local time zone based on the GMT.
•Daylight saving time : If checked, the time will be set one
hour before the local time zone for the specified time
period.
This option will be displayed only in areas where DST is applied.
•System time setup : Specify the time and date that will be applied to your system.
- Manual : Sets the current time of the camera manually.
When you select the < > check box, the time of the webviewer is set to Synchronize with PC viewer
the time displayed on the PC that runs the webviewer.
- Synchronize with NTP server : Sync with the time of the specified server address.
4. ApplyWhen done, click [ ].
J
`If you select the < >, the standard timezone should be set the same as the current timezone in Synchronize with PC viewer
PC.
English _35
●●SETUP SCREEN
PTZ SETUP
PTZ setup
You can change the direction of lens and activate the zoom.
1. PTZ ( From the Setup menu, select the < )> tab.
2. PTZ setupClick < >.
To set the preset
1. PresetClick the < > tab.
2. Click the cursor [ ] on the screen moving pad to control
movement of the screen.
•Move screen: Scroll the cursor in the direction desired.
•Control screen movement rate: The further away the cursor
is from the center, the faster it moves on the screen.
3. Control zoom movement.
•Zoom In: Move up the bar in the right of the UI, or press the [ ] button.
The farther the bar is from the center, the faster the screen expands.
•Zoom Out: Move down the bar in the right of the UI, or press the [ ] button.
The farther the bar is from the center, the faster the screen reduces in size.
4. Adjust the focus.
•Manual focus ( / ) : Adjusts the focus of the screen for short distance or long distance.
•Auto focus ( ) : The system sets the focus automatically.
J
`When performing the sequence action at a high or low temperature, the system may respond slower than the set rate for
accurate sequence action.
`Auto and Motion Detection/IVA function addition must be set in the Follow-up action mode of Preset Edit.
5. ApplyWhen done, click [ ].
To add the home position
1. Move to a desired start screen point and press [ ]. Set home
The point will be set to the home position.
2. Go homeClick [ ] in the home position. You will move to the predetermined home position.
3. When the camera is rebooted after setting, the screen is located at the home position. (If the camera was
on another sequence operation, the sequence is performed.)
To add a preset
1. Set presetClick on the [ ] button.
2. Select the preset number to be added.
3. OKSet the preset name and click on the [ ] button.
To delete a preset
1. Select the preset number to delete.
2. RemovePress the [ ] button.
To move to a desired preset
1. Click preset number you want to move in the preset settings.
To configure the detailed settings for the preset
1. Select the number of preset that you want to configure.
•Follow-up action : In < > mode, you can enable or disable the autorun/tracking/video Follow-up action
analysis operation after activating the preset. (This setting does not apply in the swing function.)
- Auto run : The sequence setting for auto execution is performed. If you turn off the function or if there
is no auto-executing operation, the preset operation status is maintained. (This setting is not applied
if preset is run with a group or tour function.)
- Auto : Performs AutoTracking operation for the period of time set in the tracking time.
- Video analysis : Motion detection/IVA operation is executed.
•Camera setup : You can change the camera setting to the environment of the selected preset.
Refer to “ ” for how to set the camera. (page 39) Camera setup
•Motion detection : You can set the event signal to be generated when a motion detection event is
detected in the preset.
For more information, see “ ”. (Page 53)Motion Detection
•IVA : You can set the system to generate an event signal when a movement is detected in the preset, or
an intelligent video analysis event is detected.
For more details, refer to “ ”. (Page 54)IVA
2. ApplyWhen done, click [ ].
J
`Be sure to execute sequence setting or preset after saving preset setting.
If the corresponding operation is not performed, a malfunction such as an unexpected preset setting change may occur.
`While setting preset edit, you cannot use the functions, such as preset setting, home position setting and move to the home
position.
To set the last location
1. Set whether or not to use the last position and time.
When using the last position, if the time is set between 1 and 600 seconds, the current position value will
be saved after the set time.
2. After setting, reboot the camera and the screen will be in the last position.
English _39
●● SETUP SCREEN
7. DeleteIf you want to delete a name in the list, select it and click [ ].
8. To change the pattern of the configure privacy area, select the pattern from the pattern list and click the
[Apply ] button.
M
`For the privacy area, the privacy setting is enabled only under x zoom without using the DIS feature.4.3
`In the privacy area where the zoom display limit function is applied, [ ] will be displayed after the set name. ZOOM
Audio setup
You can configure the I/O settings of the audio source from the camera.
1. Video & Audio ( From the Setup menu, select the < )>
tab.
2. Audio setupClick < >.
3. Set the audio input value.
• Source : Sets the audio input.
- Line : Connect the cable to the audio device.
- External microphone : Uses an external microphone.
• Apply power to Ext. Mic. : Select this check box when the external microphone is not powered, and the
power will be supplied from the camera to the microphone. You can configure settings when selecting
< >.External microphone
• Codec : Specify the audio codec.
- G.711 : A audio codec standard, it uses 64 Kbps PCM (Pulse Code Modulation) encoding.
ITU standard audio codec that is adequate for digital voice transfer in PSTN network or through a
PBX.
- G.726 : ITU standard audio codec applying ADPCM (Adaptive Differential Pulse Code Modulation) for
variable bit rates of 40/32/24/16 Kbps to 64 Kbps PCM encoding.
- AAC : Acronym of Advanced Audio Coding, which is an international standard designed to be the
successor of the MP3 format. You can use audio at a higher sampling rate than when you use the
existing G.711 or G.726 codec.
• Sampling rate : Refers to the number of times of sampling when digitalizing an analog soundtrack. The
higher this value is, the better the sound quality is.
• Bitrate : Set the bit rate to differentiate compression ratio if using G.726 codec.
• Gain : Specify the audio input amplification.
J
`Sound quality deterioration or howling may occur if the loudness of the sound source or gain value were set excessively.
4. Set the audio output level.
• Enable : Sets whether to use audio output.
• Gain : Specify the audio output amplification.
5. ApplyWhen done, click [ ].
Camera setup
You can change the camera settings according to the environment where the camera is located.
1. Video & Audio ( From the Setup menu, select the < )>
tab.
2. Camera setupClick < >.
3.
Configure the settings as necessary of :
Image preset mode,
Sensor, SSDR, White balance, Back light, Exposure, Day/
Night, Special, OSD, Focus
4. ApplyWhen done, click [ ].
`
If a certain time (timeout: 240s) is elapsed
with your not pressing the
[ ]Apply
button after changing the settings, your changes will not be
applied.
If you want to set an image preset
Users can set presets easily.
The selected image preset mode will be in operation during the configured period, but at other times the
values configured in the user preset mode are reflected.
1. Select a desired mode from the image presets.
• High definition : This is the factory setting for your camera.
Select it for video recording, focusing on reproducibility.
• Motion : Record a moving object clearly. If there are many
moving objects, such as on a road or in a crowded place
like a museum, select this option.
J
`Noise level can increase in a low illumination environment, and sensitivity can go down.
• Noise reduction : Select this when you need a video with low noise in the low illumination environment.
• Bright video : This makes the dark area in a full video brighter.
J
`Video contracts effects are reduced.
• Motion & Noise reduction : Use this when there are many moving objects, such as on a road or
in a crowded place like a museum, or when you need a video with low noise in a low illumination
environment.
• Motion & Bright video : Use it when there are many moving objects, such as on a road or in a crowded
place like a museum, or when you need to make a dark area in full video brighter.
• Vivid video : Makes the entire video displayed in vivid colors.
J
`The contrast of the video reduces and the color reproducibility becomes low.
• User preset : Select it if you want to display video with settings chosen by you.
J
`When selecting a mode other than the preset mode, you can’t set the shutter speed, AGC, SSDR, SSNR and color.
2. Set the camera item for each image preset mode.
3. ApplyWhen done, click [ ].
English _41
●● SETUP SCREEN
To Set BLC
You can specify a desired area on the video manually and set the area to be displayed more clearly.
1. BacklightSelect < >.
2. Mode BLCSet < > to < >.
If you select BLC, the Box adjustment screen and the BLC
box step are displayed on the PTZ Control screen.
3. Select each item and set it properly.
•BLC level : You can change the level to adjust the brightness of the monitoring area.
•Box adjustment : Use the arrow buttons to adjust the size and position of the BLC Box.
•Box Step : Specify the pixel unit for movement. You can use the arrow buttons of < > Box adjustment
to add or reduce the pixels.
HLC (Highlight Compensation) Setup
If a strong light like a streetlamp or vehicle headlight points toward the camera, the area can be set to be cut
off to prevent a saturated area on the monitor.
1. BacklightSelect < >.
2. Mode HLCSet < > to < >.
•HLC level : This adjusts the brightness level to cut off the
highlighted area.
•Mask
- Off : Does not block an area with a brightness that is a
certain level or higher.
- On : Always blocks an area with a brightness that is a certain level or higher.
- Night only : No blocked area is generated if the surrounding environment becomes dark to a certain
level.
- All day : No blocked area is generated if the surrounding environment becomes dark or bright to a
certain level.
•Mask color : You can select the color of the blocked area.
•Mask tone : You can adjust the brightness of the color in the blocked area.
•Dimming : Detects an area on the screen with strong light, and adjusts the brightness and reduces the
saturated area.
J
`When setting HLC, a green box is displayed on the screen for 15 seconds.
`To prevent malfunction at the time of HLC setup, the vertical space of the HLC area should be over 40 and below 60 while
the horizontal space over 30 and below 60.
M
`At night operation, this function will be activated only if the incoming highlight exceeds a certain area in a low contrast
environment.
`At night operation, HLC will not function in too a bright or too a dark scene.
`During daytime operation, HLC will not work in dark condition.
To Set WDR
It displays a sharp image of the objects in a scene where both bright and dark areas exist.
1. BacklightSelect < >.
2. Mode WDRSet < > to < >.
3. Select each item and set it properly.
•WDR level : Adjusts the intensity of backlight
compensation.
•Auto : Detects the surrounding environment and automatically uses backlight compensation.
•Turn off in low light : Does not use automatic backlight compensation when detecting a dark
environment.
•Turn off in B/W : Does not use backlight compensation when switching to B/W mode.
J
`It is recommended to use WDR in the indoor environment.
`Noise may exist between the dark area and the bright area in the WDR mode.
`With WDR mode On or Off, the minimum, maximum and user-preferred shutter value will be reset.
`If you use the P aperture lens manually or a shaking preventive shutter, the WDR performance is partially limited.
`In WDR mode, noise may occur in the motion area.
To Set Exposure
You can adjust the exposure level of the camera.
1. ExposureSelect < >.
2. Select each item and set it properly.
•Brightness : Adjust the screen brightness.
•Minimum shutter : The limit of the longest exposure time.
`Shutter is the mode to set up the range of the sensor exposure time
which will specify the upper and lower limits for the electronic shutter
movement.
`The framerate may be reduced in the dark condition if Shutter has a
lower value than specified in the Sensor mode.
•Maximum shutter : The limit of the shortest exposure time.
•Prefer shutter : Sets an appropriate exposure duration that is preferentially applied within the exposure
duration range.
•Anti flicker : It prevents screen flickering incurring from the dissonance between the surrounding lighting
and the frequency.
•SSNR
- On : Noise of the video is removed.
- Wise NR : Automatically adjusts the nose reduction level when there is a moving object in the video
to increase the identifiability.
setup screen
44_ setup screen
Smart codec
Set a desired area of the video incoming from the camera as ROI area and specify the detection sensitivity for
the area.
1. Video & Audio ( From the Setup menu, select the < )>
tab.
2. Smart codecClick < >.
3. Adjust the PTZ.
4. Set the image quality.
The ROI area will be displayed in the specified quality.
5. Specify an area of interest to monitor manually.
6. Select a desired area with the mouse pointer, and drag it as
much as you want.
`You can specify up to 5 distinct areas.
7. To cancel all the settings for the area, click the [ ] button.Clear
8. ApplyWhen done, click [ ].
J
`The Smart codec will not be active if it is set to < > in < >. (page Off Video profile 31)
WiseStream
This is the feature that optimizes the size of the video data by reducing the bit rate through increasing the
compression of the parts where there is no movement after detecting the complexity in the image.
1. Video & Audio ( From the Setup menu, select the < )>
tab.
2. WiseStreamClick < >.
3. Select wise stream mode.
- Off : Wise Stream function will be disabled.
- Low ~ High : use the wise stream to select the bit rate
reduction level.
4. ApplyWhen done, click [ ].
J
`In the following cases, the WiseStream function may malfunction.
- Sudden screen switch may cause distortion of the video.
- It is not appropriate to use in an environment with too much movement and motion on the screen.
NETWORK SETUP
DDNS
DDNS is an abbreviation of Dynamic Domain Name Service that converts the IP address of a camera into a
general Host Name so that the user can easily remember it.
J
`You can use the DDNS service only if the internet is connected.
1. Network ( From the Setup menu, select the < )> tab.
2. DDNSClick < >.
3. DDNSSelect the < > connection type.
4. Type in the DDNS items according to the selected type.
• Wisenet DDNS : Select this if you use the DDNS server
provided by Hanwha Techwin.
- Product ID : Enter the product ID that is registered with
the Wisenet DDNS service.
- Quick connect : It sets port forwarding automatically when used with a UPnP (Universal Plug and
Play) supporting router.
M
`If you want to use the DDNS service without using a hub that supports the UPnP function, click Quick connect, th
go to the hub menu and activate port forwarding for your hub.
For more on how to set port forwarding for your hub, refer to “ ”. (page Port Range Forward (Port Mapping) Setup
22)
• Public DDNS : Select one of provided public DDNS servers when you use a public DDNS server.
- Server : Select desired public DDNS service server.
- Host name : Enter the name of the host that is registered with the DDNS server.
- User name : Enter the user name for the DDNS service.
- Password : Enter the password for the DDNS service.
5. ApplyWhen done, click [ ].
J
`If selected < >, be sure to select Wisenet DDNS service.Quick connect
Produktspezifikationen
Marke: | Hanwha |
Kategorie: | Überwachungskamera |
Modell: | XNP-6040H |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Hanwha XNP-6040H benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Überwachungskamera Hanwha
31 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
30 August 2024
Bedienungsanleitung Überwachungskamera
- Überwachungskamera Samsung
- Überwachungskamera Approx
- Überwachungskamera Belkin
- Überwachungskamera Sanyo
- Überwachungskamera Exibel
- Überwachungskamera Gembird
- Überwachungskamera Genius
- Überwachungskamera Hama
- Überwachungskamera LogiLink
- Überwachungskamera Logitech
- Überwachungskamera Manhattan
- Überwachungskamera Nedis
- Überwachungskamera Niceboy
- Überwachungskamera Philips
- Überwachungskamera Sony
- Überwachungskamera Trust
- Überwachungskamera Panasonic
- Überwachungskamera Clas Ohlson
- Überwachungskamera Profile
- Überwachungskamera ZyXEL
- Überwachungskamera Bosch
- Überwachungskamera Laserliner
- Überwachungskamera Buffalo
- Überwachungskamera Canon
- Überwachungskamera Velleman
- Überwachungskamera Powerfix
- Überwachungskamera Eminent
- Überwachungskamera Linksys
- Überwachungskamera Maginon
- Überwachungskamera Netgear
- Überwachungskamera Technaxx
- Überwachungskamera Alecto
- Überwachungskamera Denver
- Überwachungskamera EMOS
- Überwachungskamera Gira
- Überwachungskamera König
- Überwachungskamera MarQuant
- Überwachungskamera Renkforce
- Überwachungskamera Thomson
- Überwachungskamera Trevi
- Überwachungskamera Blaupunkt
- Überwachungskamera Schneider
- Überwachungskamera Trebs
- Überwachungskamera Pyle
- Überwachungskamera Topcom
- Überwachungskamera Pioneer
- Überwachungskamera JVC
- Überwachungskamera Motorola
- Überwachungskamera Xiaomi
- Überwachungskamera Abus
- Überwachungskamera Avidsen
- Überwachungskamera Elro
- Überwachungskamera EZVIZ
- Überwachungskamera Imou
- Überwachungskamera INSTAR
- Überwachungskamera Megasat
- Überwachungskamera Olympia
- Überwachungskamera Smartwares
- Überwachungskamera Switel
- Überwachungskamera Yale
- Überwachungskamera Ferguson
- Überwachungskamera Orion
- Überwachungskamera Gigaset
- Überwachungskamera Strong
- Überwachungskamera Toshiba
- Überwachungskamera Garmin
- Überwachungskamera Perel
- Überwachungskamera Netis
- Überwachungskamera Lindy
- Überwachungskamera Fenton
- Überwachungskamera Waeco
- Überwachungskamera Acme
- Überwachungskamera Burg Wächter
- Überwachungskamera Marmitek
- Überwachungskamera Marshall
- Überwachungskamera Honeywell
- Überwachungskamera B/R/K
- Überwachungskamera Marshall Electronics
- Überwachungskamera TRENDnet
- Überwachungskamera Targa
- Überwachungskamera First Alert
- Überwachungskamera AVerMedia
- Überwachungskamera Zebra
- Überwachungskamera TP-Link
- Überwachungskamera Flamingo
- Überwachungskamera Kodak
- Überwachungskamera Rollei
- Überwachungskamera IGet
- Überwachungskamera Adj
- Überwachungskamera Netatmo
- Überwachungskamera Duramaxx
- Überwachungskamera Ebode
- Überwachungskamera Xavax
- Überwachungskamera InFocus
- Überwachungskamera Overmax
- Überwachungskamera Monoprice
- Überwachungskamera Monacor
- Überwachungskamera JUNG
- Überwachungskamera Ednet
- Überwachungskamera AG Neovo
- Überwachungskamera Nest
- Überwachungskamera Edimax
- Überwachungskamera V-TAC
- Überwachungskamera Aritech
- Überwachungskamera Uniden
- Überwachungskamera Kogan
- Überwachungskamera Genie
- Überwachungskamera M-e
- Überwachungskamera Elmo
- Überwachungskamera Lumens
- Überwachungskamera Jablocom
- Überwachungskamera Conceptronic
- Überwachungskamera D-Link
- Überwachungskamera Eufy
- Überwachungskamera Stabo
- Überwachungskamera Friedland
- Überwachungskamera EVOLVEO
- Überwachungskamera SPC
- Überwachungskamera August
- Überwachungskamera Ring
- Überwachungskamera Digitus
- Überwachungskamera SereneLife
- Überwachungskamera Swann
- Überwachungskamera Vitek
- Überwachungskamera DataVideo
- Überwachungskamera LevelOne
- Überwachungskamera Aida
- Überwachungskamera APC
- Überwachungskamera Beafon
- Überwachungskamera Chuango
- Überwachungskamera Cisco
- Überwachungskamera Grandstream
- Überwachungskamera Delta Dore
- Überwachungskamera EVE
- Überwachungskamera Defender
- Überwachungskamera Tenda
- Überwachungskamera Swisstone
- Überwachungskamera Foscam
- Überwachungskamera Ubiquiti Networks
- Überwachungskamera Kramer
- Überwachungskamera Vaddio
- Überwachungskamera Intellinet
- Überwachungskamera Reolink
- Überwachungskamera Swan
- Überwachungskamera Hikvision
- Überwachungskamera FLIR
- Überwachungskamera Furrion
- Überwachungskamera Arlo
- Überwachungskamera Nexxt
- Überwachungskamera Planet
- Überwachungskamera EnGenius
- Überwachungskamera Dörr
- Überwachungskamera Lorex
- Überwachungskamera Ikan
- Überwachungskamera Comtrend
- Überwachungskamera Somfy
- Überwachungskamera Dahua
- Überwachungskamera Dedicated Micros
- Überwachungskamera DIO
- Überwachungskamera EasyN
- Überwachungskamera Escam
- Überwachungskamera EverFocus
- Überwachungskamera Ganz
- Überwachungskamera GeoVision
- Überwachungskamera Hombli
- Überwachungskamera Home Protector
- Überwachungskamera Iiquu
- Überwachungskamera Indexa
- Überwachungskamera Interlogix
- Überwachungskamera KlikaanKlikuit
- Überwachungskamera Kompernass
- Überwachungskamera Mr Safe
- Überwachungskamera Naxa
- Überwachungskamera Nordval
- Überwachungskamera Notifier
- Überwachungskamera Oplink
- Überwachungskamera Provision ISR
- Überwachungskamera Quantum
- Überwachungskamera Raymarine
- Überwachungskamera Revo
- Überwachungskamera SAB
- Überwachungskamera Satel
- Überwachungskamera SecurityMan
- Überwachungskamera Sinji
- Überwachungskamera SMC
- Überwachungskamera Sonic Alert
- Überwachungskamera Sricam
- Überwachungskamera Steren
- Überwachungskamera Storage Options
- Überwachungskamera Tenvis
- Überwachungskamera Hive
- Überwachungskamera Ubiquiti
- Überwachungskamera Vivotek
- Überwachungskamera Woonveilig
- Überwachungskamera Y-cam
- Überwachungskamera ACTi
- Überwachungskamera AVer
- Überwachungskamera Epcom
- Überwachungskamera ZKTeco
- Überwachungskamera AirLive
- Überwachungskamera Mobotix
- Überwachungskamera Dahua Technology
- Überwachungskamera Speco Technologies
- Überwachungskamera 3xLOGIC
- Überwachungskamera Atlantis Land
- Überwachungskamera CRUX
- Überwachungskamera Pentatech
- Überwachungskamera Summer Infant
- Überwachungskamera Illustra
- Überwachungskamera Surveon
- Überwachungskamera Avigilon
- Überwachungskamera Brilliant
- Überwachungskamera Lanberg
- Überwachungskamera Verint
- Überwachungskamera Axis
- Überwachungskamera EtiamPro
- Überwachungskamera MEE Audio
- Überwachungskamera Advantech
- Überwachungskamera Chacon
- Überwachungskamera Alula
- Überwachungskamera EKO
- Überwachungskamera IOIO
- Überwachungskamera KJB Security Products
- Überwachungskamera BZBGear
- Überwachungskamera Adesso
- Überwachungskamera Brickcom
- Überwachungskamera Insteon
- Überwachungskamera Aigis
- Überwachungskamera Pelco
- Überwachungskamera ORNO
- Überwachungskamera Atlona
- Überwachungskamera Linear PRO Access
- Überwachungskamera Laxihub
- Überwachungskamera Valueline
- Überwachungskamera Aqara
- Überwachungskamera Tecno
- Überwachungskamera Lutec
- Überwachungskamera Brinno
- Überwachungskamera Night Owl
- Überwachungskamera WyreStorm
- Überwachungskamera Exacq
- Überwachungskamera Equip
- Überwachungskamera AVMATRIX
- Überwachungskamera UniView
- Überwachungskamera Alfatron
- Überwachungskamera Syscom
- Überwachungskamera BLOW
- Überwachungskamera Videotec
- Überwachungskamera DSC
- Überwachungskamera AViPAS
- Überwachungskamera Milestone Systems
- Überwachungskamera Inkovideo
- Überwachungskamera Hamlet
- Überwachungskamera Mobi
- Überwachungskamera Infortrend
- Überwachungskamera VideoComm
- Überwachungskamera Kguard
- Überwachungskamera Boyo
- Überwachungskamera HiLook
- Überwachungskamera Mach Power
- Überwachungskamera Canyon
- Überwachungskamera Digital Watchdog
- Überwachungskamera Ernitec
- Überwachungskamera Ikegami
- Überwachungskamera Gewiss
- Überwachungskamera Weldex
- Überwachungskamera Costar
- Überwachungskamera Sentry360
- Überwachungskamera ALC
- Überwachungskamera Spyclops
- Überwachungskamera Compro
- Überwachungskamera IDIS
- Überwachungskamera I3International
- Überwachungskamera B & S Technology
- Überwachungskamera Qian
- Überwachungskamera Accsoon
- Überwachungskamera Control4
- Überwachungskamera Petcube
- Überwachungskamera Apeman
- Überwachungskamera ATN
- Überwachungskamera IC Intracom
- Überwachungskamera POSline
- Überwachungskamera Watec
- Überwachungskamera ETiger
- Überwachungskamera Videcon
- Überwachungskamera BirdDog
- Überwachungskamera Topica
- Überwachungskamera Rostra
- Überwachungskamera Caddx
- Überwachungskamera Whistler
- Überwachungskamera ClearView
- Überwachungskamera Beseye
- Überwachungskamera IMILAB
- Überwachungskamera CNB Technology
- Überwachungskamera Tapo
- Überwachungskamera Securetech
- Überwachungskamera NetMedia
- Überwachungskamera Nivian
- Überwachungskamera Guardzilla
- Überwachungskamera Blink
- Überwachungskamera Zavio
- Überwachungskamera Campark
- Überwachungskamera IPX
- Überwachungskamera Annke
- Überwachungskamera AVTech
- Überwachungskamera Vimtag
- Überwachungskamera Security Labs
- Überwachungskamera Seneca
- Überwachungskamera Vosker
- Überwachungskamera Owltron
- Überwachungskamera Enabot
- Überwachungskamera Luis Energy
- Überwachungskamera Sir Gawain
- Überwachungskamera VisorTech
- Überwachungskamera Milesight
- Überwachungskamera GVI Security
- Überwachungskamera Conbrov
- Überwachungskamera HuddleCamHD
- Überwachungskamera Setti+
- Überwachungskamera BIRDFY
- Überwachungskamera I-PRO
- Überwachungskamera DVDO
- Überwachungskamera TCP
Neueste Bedienungsanleitung für -Kategorien-
15 Oktober 2024
15 Oktober 2024
14 Oktober 2024
14 Oktober 2024
13 Oktober 2024
13 Oktober 2024
13 Oktober 2024
11 Oktober 2024
11 Oktober 2024
11 Oktober 2024
