8 Channel
16 Channel DVR
User Manual SRD-830DC/850DC/870DC/
1610DC/1630DC/1650DC/1670DC
2_ overview
FEATURES
The SRD DVR (Digital Video Recorder) employs H.264 video encoding for 8 or 16 channel inputs and G.723 audio
encoding for 4 or 16 channels while simultaneously supports hard disc recording and playback.
These DVRs also supports network connectivity, providing remote monitoring from a remote PC transferring video
and audio data.
Provides convenient User Interface
8/16 CH Composite Input Connectors
Supports CIF(S)/2CIF(M)/4CIF(L) recording formats
With the network specific codec, network transfer enabled regardless of the recording conditions
De-interlacing processor for better picture quality
HDMI enabling superior picture output quality
Display of HDD information and status by using HDD SMART
4CIF Size (NTSC: 704*480, PAL: 704*576) Recording in 480 (NTSC)/400 (PAL) IPS speed (SRD-870DC/1670DC)
CIF(S) Size (NTSC: 352*240, PAL: 352*288) Recording in 480 (NTSC)/400 (PAL) IPS speed (SRD-850DC/1650DC)
CIF(S) Size (NTSC: 352*240, PAL: 352*288) Recording in 240 (NTSC)/200 (PAL) IPS speed (SRD-1630DC)
CIF(S) Size (NTSC: 352*240, PAL: 352*288) Recording in 120 (NTSC)/100 (PAL) IPS speed
(SRD-830DC/1610DC)
8/16-channel Loop Through Video port connection
Hard Disk overwrite function
Mass storage hard disk backup through high-speed USB 2.0
Mass storage hard disk backup through eSATA (SRD-850DC/870DC/1650DC/1670DC)
Backup function using USB 2.0 flash memory and external CD/DVD writer
Simultaneous Record and Playback of 8/16-channel video data
Various Search Modes (Search by Time, Event, Backup, POS and Motion Detection)
Various Recording Modes (Time Lapse, Event, Scheduled Recording)
Extended Hard Disk Connection (USB 2.0, eSATA) (SRD-850DC/870DC/1650DC/1670DC)
Alarm Interface (Input: 8/16, Output: 4, Reset: 1)
Remote Monitoring function by Windows Network Viewer
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
overview
English _3
OVERVIEW
IMPORTANT SAFETY INSTRUCTIONS
Read these operating instructions carefully before using the unit.
Follow all the safety instructions listed below.
Keep these operating instructions handy for future reference.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings, Install in accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. if the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from
tip-over.
Unplug this apparatus during lightning storms or when unused for long
periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)
6_ overview
overview
CONTENTS
OVERVIEW
2Features
3Important Safety Instructions
4Before Start
8Part Names and Functions (Front)
10 Part Names and Functions (Rear)
13 Remote Control
INSTALLATION

14 Checking the installation environment
15 Rack Installation
15 HDD Addition
CONNECTING WITH OTHER DEVICE

18 Connecting the Video, Audio, and Monitor
18 Connecting the USB
19 Connecting External SATA HDD
19 Connecting POS Device
19 Connecting the Alarm Input/Output
20 Connecting the RS-485 Device
21 Connecting the Network
LIVE

23 Getting Started
25 Live Screen Configuration
29 Live Mode
31 SPOT Out
32 Zoom
32 Audio ON/OFF
32 Freeze
33 Event Monitoring
USING THE DVR

34 System Setup
44 Setting the Device
52 Setting the Recording
55 Setting the Event
58 Backup
59 Network Configuration
66 Controlling a PTZ device
English _7
OVERVIEW
SEARCH & PLAY

68 Search
71 Playback
WEB VIEWER

73 Introducing Web Viewer
74 Connecting Web Viewer
75 Using Live Viewer
81 Using Search Viewer
85 Viewer Setup
95 About
BACKUP VIEWER

96 SEC Backup Viewer
APPENDIX

98 Product Specification (SRD-830DC/1610DC/
1630DC)
101 Product Specification (SRD-850DC/870DC/
1650DC/1670DC)
104 Product Overview
105 Default Setting
108 Troubleshooting
10_ overview
overview
PART NAMES AND FUNCTIONS (REAR)
830DC
1610DC/1630DC
850DC
1650DC
1 32 4 5 6 9 10 12 141311
13
24 5 6 9 10 12 141311
1 32 4 5 6 7 8 9 10 12 141311
1 32 4 5 6 7 8 9 10 12 141311
18_ connecting with other device
The following gures are based on Model SRD-1670DC.
CONNECTING THE VIDEO, AUDIO, AND MONITOR
CONNECTING THE USB
There are two USB ports at the front and one at the back of the product.
You can connect a USB HDD, USB CD/DVD player, USB memory or mouse to the USB port.
If a USB HDD is connected to the system, recognition and settings are available in “ > Menu Setting the Device >
Storage Device”. (Page 46)
This product supports hot-plugging, which connects/removes the USB device during the system operation.
If you use the USB device for Backup purposes, format it with FAT32 on PC if it is not formatted on the DVR.
M
1.
2.
3.
4.
J
connecting with other device
VIDEO IN
AUDIO IN
SPOT AC 100-240V~IN
VIDEO OUT
(VGA)
VIDEO OUT
(composite)
AUDIO OUT
HDMI
VIDEO IN
English _21
CONNECTING WITH OTHER DEVICE
CONNECTING THE NETWORK
Connecting to Internet through Ethernet (10/100/1000BaseT)
Connecting to the Internet using the router
Router
xDSL or Cable
Modem
xDSL or Cable
Modem
External Remote
PC
DDNS Server
(Data Center)
INTERNET
Windows
Network Viewer
Back Bone
Hub/Switcher
Hub/Switcher
RJ-45 Ethernet Cable
(Direct Cable)
INTERNET
