For more product details, please visit GIGABYTE's website.
GIGABYTE will reduce paper use in order to fulîš¿ll the responsibilities of a global citizen.
Also, to reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
Z690 AORUS TACHYON
User's Manual
Rev. 1001
Copyright
© 2023 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the speciîš¿cations and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of
documentations:
îš„For quick set-up of the product, read the Quick Installation Guide included with the product.
îš„For detailed product information, carefully read the User's Manual.
For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before updating
motherboard BIOS, drivers, or when looking for technical information.
Example:
- 3 -
Table of Contents
Chapter 1 Product Introduction .......................................................................................4
1-1 Motherboard Layout ......................................................................................... 4
1-2 Motherboard Block Diagram ............................................................................ 5
Chapter 2 Hardware Installation .....................................................................................6
2-1 Installation Precautions .................................................................................... 6
2-2 Product Speciîš¿cations ...................................................................................... 7
2-3 Installing the CPU and CPU Cooler ............................................................... 11
2-4 Installing the Memory ..................................................................................... 14
2-5 Installing an Expansion Card ......................................................................... 15
2-6 Back Panel Connectors .................................................................................. 16
2-7 Onboard Buttons, Switches, and LEDs .......................................................... 18
2-8 Internal Connectors 21 ........................................................................................
Chapter 3 BIOS Setup ..................................................................................................34
Chapter 4 Installing the Operating System and Drivers ................................................36
4-1 Operating System Installation ........................................................................ 36
4-2 Drivers Installation 37 ..........................................................................................
Chapter 5 Appendix ......................................................................................................38
5-1 Conîš¿guring a RAID Set .................................................................................. 38
5-2 Debug LED Codes ......................................................................................... 39
Regulatory Notices .................................................................................................... 43
Contact Us 46 ................................................................................................................
