Z690 AORUS PRO
Z690 AORUS PRO DDR4
User's Manual
Rev. 1101
For more product details, please visit GIGABYTE's website.
https://ww w.gigabyte.com/Motherboard/Z690-AORUS-PRO-rev-10?m=ma#kf
https://ww w.gigabyte.com/Motherboard/Z690-AORUS-PRO-DDR4-rev-10?m=ma#kf
GIGABYTE will reduce paper use in order to fulîš¿ll the responsibilities of a global citizen.
Also, to reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
Copyright
© 2023 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the speciîš¿cations and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
îš„For detailed product information, carefully read the User's Manual.
îš„For quick set-up of the product, refer to the Quick Installation Guide on GIGABYTE's
website.
https://download.gigabyte.com/FileList/Manual/mb_manual_quick-guide_am5.pdf?m=sw
For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before updating
motherboard BIOS, drivers, or when looking for technical information.
Example:
- 3 -
Table of Contents
Chapter 1 Product Introduction 4 .......................................................................................
1-1 Motherboard Layout 4 .........................................................................................
1-2 Motherboard Block Diagram 6 ............................................................................
Chapter 2 Hardware Installation 7 .....................................................................................
2-1 Installation Precautions 7 ....................................................................................
2-2 Product Speciîš¿cations ...................................................................................... 8
2-3 Installing the CPU and CPU Cooler 12 ...............................................................
2-4 Installing the Memory 15 .....................................................................................
2-5 Installing an Expansion Card 16 .........................................................................
2-6 Back Panel Connectors 17 ..................................................................................
2-7 Onboard Buttons and LED 19 .............................................................................
2-8 Internal Connectors 20 ........................................................................................
Chapter 3 BIOS Setup 34 ..................................................................................................
Chapter 4 Installing the Operating System and Drivers 36 ................................................
4-1 Operating System Installation 36 ........................................................................
4-2 Drivers Installation 37 ..........................................................................................
Chapter 5 Appendix 38 ......................................................................................................
5-1 Conîš¿guring a RAID Set .................................................................................. 38
5-2 Debug LED Codes 39 .........................................................................................
Regulatory Notices 43 ....................................................................................................
Contact Us 46 ................................................................................................................
