GA-Z270X-Gaming 5
User's Manual
Rev. 1001
12ME-Z27GME5-1001R
Copyright
© 2017 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the speciîš¿cations and features in this manual may be made by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or
by any means without GIGABYTE's prior written permission.
îš„For quick set-up of the product, read the Quick Installation Guide included with the product.
îš„In order to assist in the use of this product, carefully read the User's Manual.
îš„For product-related information, check on our website at: http://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means
the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard
BIOS, drivers, or when looking for technical information.
Example:
Motherboard
GA-Z270X-Gaming 5
Oct. 7, 2016
Oct. 7, 2016
Motherboard
GA-Z270X-Gaming 5
- 3 -
Table of Contents
GA-Z270X-Gaming 5 Motherboard Layout 4 ......................................................................
Chapter 1 Hardware Installation 5 .....................................................................................
1-1 Installation Precautions 5 ....................................................................................
1-2 ProductSpecications ...................................................................................... 6
1-3 Installing the CPU 10 ..........................................................................................
1-4 Installing the Memory 10 .....................................................................................
1-5 Installing an Expansion Card ......................................................................... 11
1-6 Setting up AMD CrossFire™/NVIDIA® SLI™Conguration .............................. 11
1-7 Back Panel Connectors 12 ..................................................................................
1-8 Onboard Buttons, Switch, and LEDs 14 ..............................................................
1-9 ChangingtheOperationalAmplier ............................................................... 15
1-10 Internal Connectors 16 ........................................................................................
Chapter 2 BIOS Setup 25 ..................................................................................................
2-1 Startup Screen 25 ...............................................................................................
2-2 M.I.T. .............................................................................................................. 26
2-3 System ........................................................................................................... 32
2-4 BIOS ............................................................................................................... 33
2-5 Peripherals ..................................................................................................... 36
2-6 Chipset ........................................................................................................... 39
2-7 Power ............................................................................................................. 40
2-8 Save & Exit 42 .....................................................................................................
Chapter 3 Appendix 43 ......................................................................................................
3-1 43ConguringaRAIDSet ..................................................................................
3-2 Drivers Installation 45 ..........................................................................................
3-3 Debug LED Codes 46 .........................................................................................
RegulatoryStatements .............................................................................................. 50
Contact Us 52 ................................................................................................................
