Seite 1/18
- 1 -
Table of Contents
Conguring a RAID Set (Intel® Z270/H270 Series) .........................................................2
1-1 Conîš¿guring SATA Controllers ............................................................................. 2
1-2 Installing the SATA RAID/AHCI Driver and Operating System.......................... 16
- 2 -
Conguring a RAID Set (Intel® Z270/H270 Series)
To create a RAID set, follow the steps below:
A. Install SATA hard drive(s) in your computer.
B. Conîš¿gure SATA controller mode in BIOS Setup.
C. Conîš¿gure a RAID array in RAID BIOS. (Note 1)
D. Install the SATA RAID/AHCI driver and operating system.
Before you begin, please prepare the following items:
•At least two SATA hard drives or SSDs (Note 2) (to ensure optimal performance, it is recommended that you
use two hard drives with identical model and capacity). (Note 3)
•A Windows setup disk.
•Motherboard driver disk.
•A USB thumb drive.
RAID Levels
1-1 Conguring SATA Controllers
A. Installing hard drives
Install the hard drives/SSDs in the Intel® Chipset controlled connectors on the motherboard. Then connect
the power connectors from your power supply to the hard drives.
RAID RAID RAID RAID 0 1 5 10
Minimum
Number of Hard
Drives
≥2 ≥32 4
Array Capacity Number of hard
drives * Size of the
smallest drive
Size of the smallest
drive
(Number of hard
drives -1) * Size of
the smallest drive
(Number of hard
drives/2) * Size of the
smallest drive
Fault Tolerance No Yes Yes Yes
(Note 1) Skip this step if you do not want to create RAID array on the SATA controller.
(Note 2) An M.2 PCIe SSD or an U.2 SSD cannot be used to set up a RAID set either with an M.2 SATA SSD
or a SATA hard drive.
(Note 3) Refer to Chapter 1, "Internal Connectors," for the installation notices for the U.2, M.2, and SATA
connectors.
- 3 -
The BIOS Setup menus described in this section may differ from the exact settings for your motherboard.
The actual BIOS Setup menu options you will see shall depend on the motherboard you have and
the BIOS version.
B. Conguring SATA controller mode in BIOS Setup
Make sure to conîš¿gure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test). Go to
Peripherals\SATA And RST Conguration SATA Controller(s), make sure is enabled. To create RAID, set
SATA Mode Selection Intel RST Premium With Intel Optane System Acceleration to (Figure 1).
Step 2:
To use the EZ RAID feature, follow the steps in "C-1." To conîš¿gure UEFI RAID, follow the steps in "C-2." To
enter the legacy RAID ROM, refer to "C-3" for more information. Finally, save the settings and exit BIOS Setup.
Figure 1
