GA-B85M-HD3 R4
User's Manual
Rev. 1001
12ME-85MHD3R-1001R
Motherboard
GA-B85M-HD3 R4
Feb. 17, 2015
Feb. 17, 2015
Motherboard
GA-B85M-HD3 R 4
Copyright
© 2015 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the speciîš¿cations and features in this manual may be made by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by
any means without GIGABYTE's prior written permission.
îš„In order to assist in the use of this product, carefully read the User's Manual.
îš„For product-related information, check on our website at: http://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means the
revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard BIOS,
drivers, or when looking for technical information.
Example:
- 3 -
Table of Contents
GA-B85M-HD3 R4 Motherboard Layout 4 ..........................................................................
GA-B85M-HD3 R4 Motherboard Block Diagram 5 .............................................................
Chapter 1 Hardware Installation 6 .....................................................................................
1-1 Installation Precautions 6 ....................................................................................
1-2 Product Speciîš¿cations ...................................................................................... 7
1-3 Installing the CPU 9 ............................................................................................
1-4 Installing the Memory 10 .....................................................................................
1-5 Installing an Expansion Card 10 .........................................................................
1-6 Back Panel Connectors 10 ..................................................................................
1-7 Internal Connectors 12 ........................................................................................
Chapter 2 BIOS Setup 18 ..................................................................................................
2-1 Startup Screen 18 ...............................................................................................
2-2 M.I.T. .............................................................................................................. 19
2-3 System Information 24 ........................................................................................
2-4 BIOS Features 25 ...............................................................................................
2-5 Peripherals ..................................................................................................... 28
2-6 Power Management 30 .......................................................................................
2-7 Save & Exit 32 .....................................................................................................
Chapter 3 Appendix 33 ......................................................................................................
Drivers Installation 33 .....................................................................................................
Regulatory Statements 34 ..............................................................................................
Contact Us 36 ................................................................................................................
