To reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
For more product details, please visit GIGABYTE's website.
B560M DS3HB560M DS3H AC
B560M DS3H AC
B560M DS3H
User's Manual
Rev. 1001
Copyright
© 2021 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the speciîš¿cations and features in this manual may be made by GIGABYTE without prior
notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in
any form or by any means without GIGABYTE's prior written permission.
îš„In order to assist in the use of this product, carefully read the User's Manual.
îš„For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before updating
motherboard BIOS, drivers, or when looking for technical information.
Example:
- 3 -
Table of Contents
B560M DS3H AC/B560M DS3H Motherboard Layout 4 .....................................................
Chapter 1 Hardware Installation 5 .....................................................................................
1-1 Installation Precautions 5 ....................................................................................
1-2 ProductSpecications ...................................................................................... 6
1-3 Installing the CPU 10 ..........................................................................................
1-4 Installing the Memory 10 .....................................................................................
1-5 Installing an Expansion Card ......................................................................... 11
1-6 Back Panel Connectors .................................................................................. 11
1-7 Internal Connectors 14 ........................................................................................
Chapter 2 BIOS Setup 22 ..................................................................................................
2-1 Startup Screen 22 ...............................................................................................
2-2 The Main Menu 23 ..............................................................................................
2-3 Smart Fan 6 24 ..................................................................................................
2-4 Favorites (F11) 25 ...............................................................................................
2-5 Tweaker .......................................................................................................... 26
2-6 Settings .......................................................................................................... 31
2-7 System Info. 36 ...................................................................................................
2-8 Boot ................................................................................................................ 37
2-9 Save & Exit 40 .....................................................................................................
Chapter 3 Appendix 41 ......................................................................................................
3-1 Installing Intel® Optane™ Memory and Storage Management 41 ........................
3-2 Drivers Installation 42 ..........................................................................................
Regulatory Notices 43 ....................................................................................................
Contact Us 46 ................................................................................................................
