Gigabyte B550M DS3H AC Bedienungsanleitung
Gigabyte
Hauptplatine
B550M DS3H AC
Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Gigabyte B550M DS3H AC (43 Seiten) in der Kategorie Hauptplatine. Dieser Bedienungsanleitung war für 7 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/43
GIGABYTE will reduce paper use in order to fulîš¿ll the responsibilities of a global citizen. Also, to
reduce the impacts on global warming, the packaging materials of this product are recyclable and
reusable. GIGABYTE works with you to protect the environment.
For more product details, please visit GIGABYTE's website.
B550M DS3H AC(-Y1) B550M DS3H
B550M DS3H AC
B550M DS3H AC-Y1
B550M DS3H
User's Manual
Rev. 1301
Copyright
© 2022 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the speciîš¿cations and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
îš„In order to assist in the use of this product, carefully read the User's Manual.
îš„For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before updating
motherboard BIOS, drivers, or when looking for technical information.
Example:
- 3 -
Table of Contents
B550M DS3H AC(-Y1)/B550M DS3H Motherboard Layout .............................................4
Chapter 1 Hardware Installation .....................................................................................5
1-1 Installation Precautions .................................................................................... 5
1-2 Product Speciîš¿cations ...................................................................................... 6
1-3 Installing the CPU ............................................................................................ 9
1-4 Installing the Memory ....................................................................................... 9
1-5 Installing an Expansion Card ......................................................................... 10
1-6 Back Panel Connectors .................................................................................. 10
1-7 Internal Connectors ........................................................................................ 12
Chapter 2 BIOS Setup ..................................................................................................20
2-1 Startup Screen ............................................................................................... 20
2-2 The Main Menu .............................................................................................. 21
2-3 Favorites (F11) ............................................................................................... 22
2-4 Tweaker .......................................................................................................... 23
2-5 Settings .......................................................................................................... 26
2-6 System Info. ................................................................................................... 32
2-7 Boot ................................................................................................................ 33
2-8 Save & Exit ..................................................................................................... 36
Chapter 3 Appendix ......................................................................................................37
3-1 Conîš¿guring a RAID Set .................................................................................. 37
3-2 Drivers Installation .......................................................................................... 39
Regulatory Notices .................................................................................................... 40
Contact Us ................................................................................................................ 43
