OPERATION AND MAINTENANCE MANUAL
RONDO’ gas cooker hobs
cod. 7052 142, 7052 642
Foster spa - via M.S. Ottone, 18/20 - 42041 Brescello (RE) Italy - www.fosterspa.com
tel. +39.0522.687425 - tel. Servizio Assistenza +39.0522.684450
fax +39.0522.686019 - fax Servizio Ricambi +39.0522.962166 e-mail: service@fosterspa.com
8
INSTALLATION INSTRUCTIONS
Installation
The purchaser is responsible for installation: the Manufacturer does not offer this service. Any technical assistance
activities carried out by the Manufacturer relating to faulty installation are not covered by the warranty.
The built in hobs are designed for installation on worktops made of any material, provided these are- between 25
mm and 40 mm thick and can withstand temperatures of 100°C. If the hob is installed adjacent to a cabinet on any
one of the two sides, at least 150 mm must divide the hob edge from the cabinet, while the distance between the
rear wall and hob edge must be at least 50 mm. A partition made of insulating material (wood or similar) must be
inserted in the underlying cabinet at least 20 mm from the bottom edge of the hob.
Securing the hob to the cabinet
The hob is secured to the cabinet with the aid of clamps supplied as accessories. The underside of the hob
contains pre drilled holes through which the self tapping plates (A) must be inserted; the relative screws (C) that - -
secure the fixing clamps (B) must then be screwed onto the plates.
TECHNICAL DATA
MODELS
Burners
Automatic
ignition
Safety
valve
Product dimensions
(W x D) in mm
(W x D) in mm
A
SR
R
TC
-
1
1
1
-
-
yes
yes
Ø 520
9
Applying the sealant
Important - the picture below indicates how the sealant must be applied along the entire edge.
This appliance is designed for non professional use in domestic environments.-
Installation room
The use of a gas cooker hob generates heat and humidity in the room in which it is installed. Make sure the room is
well ventilated by keeping any natural ventilation openings open or by installing a cooker hood with flue duct (Fig.
1-2). Intensive and prolonged use of the appliance may require additional ventilation, either by opening a window or
by increasing the efficiency and power of the mechanical ventilation system, if present.
An electric ventilator must be implemented if a cooker hood (Fig. 2) cannot be installed: it must be fitted to the
external wall or window in the room (Fig. 3), provided the room is equipped with air intake vents.
The electric ventilator must guarantee an hourly air exchange rate 3 5 times the volume of the kitchen. The installer -
must comply with the specifications of the UNI CIG 7129 and 7131 standards currently in force.-
Fig. 1
Fig. 2
Fig. 3
min.
min.
Electrical connection
Check the data on the rating plate located on the underside of the appliance and verify that the rated voltage complies
with the mains voltage.
Check the efficiency of the earthing system before carrying out the electrical connection. It is mandatory to earth the
appliance. The Manufacturer shall not be held liable for any harm to persons or damage to objects arising from failure to
comply with this provision.
If the model is not equipped with a plug, install a standardised plug on the cable that is capable of withstanding the power
output indicated on the rating plate. The earth wire is identified by the yellow green jacket. The plug must always be -
accessible.
When carrying out a fixed connection to the mains electricity, an omnipolar cut off device with a contact gap of at least 3 -
mm must be installed between the appliance and the power outlet.
In order to connect the cord to the cooker hob, loosen and remove the terminal board cover to access the contacts
located inside. After making the connection, secure the cord with the fixing system provided and cover the terminal board
immediately.
Whenever the power cord is replaced, make sure that the earth wire (yellow green) is 10 mm longer than the remaining -
wires.
Use an H05RR F type rubber cord comprising wires with 3x1.5 mm cross- -section.
