What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
Flowline Placid 2 Axis Stabilizing Arm -(FLCM FLN PLA) - -
A s s e m b l y M a n u a l
Tensioner Spring
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
Safety Shock Cord
2
Remove the hook from Flowline support
bar.
Take the cord bundle out from the cup and
pull the whole cord unl a cord lock comes
out.
SetupFlowline Placid
Separate the cord from cord lock and keep
the lock aside for aaching it back
aerwards.
Separate the cord also from the cup and
keep aside for mounng it back later.
Use a tool to unscrew small bolts that hold
the front pulley, from each side.
3
Mount front pulley in between the cord,
and pull the cord so that it goes back inside
the support arm. Again use tools to ghten
the bolts from each side and set the pulley
at its posion.
Turn the Placid Arm upside down. By using
an allen key, loosen the mounng bracket of
Arm. Now the bracket has enough space for
the cord to pass through it.
Insert cord into the mounng bracket. Make
sure that it is going exactly in the centre, up
into the hole of the Placid arm. Then Pull
the cord from boom of Placid arm, near
the spring, while sll holding it upside
down.
To x Placid arm at its appropriate posion,
aach one side of Safety Elasc Cord to a
knob on Placid arm. Then, drag the other
side of elasc cord across Flowline support
arm, and aach to the knob on other side
of Placid arm.
Now you can hold the Placid arm in its
standard posion. The cord is aptly set to
perform its funcon. By using an allen key,
ghten the mounng bracket of Placid Arm
with Flowline support arm.
Pull out the front pulley carefully, so it
doesn t drop into the Flowline support bar ’
and Insert the cord from the boom hole
and tug it out from the top hole.
Produktspezifikationen
| Marke: | Flycam |
| Kategorie: | Statief |
| Modell: | FLCM-FLN-PLA |
