USER GUI D E
NZ AU UK IE E U A E HK SG
ACTIVESMART™ REFRIGERATOR
CONTEMPORARY
FRENCH DOOR REFRIGERATOR FREEZER
RF522A, RF540A & RF610A
BOTTOM MOUNT REFRIGERATOR FREEZER
E372B, E402B, E442B, E522B, RF372B,
RF402B, RF442B, RF522B & RF522W
3
CONTENTS
Registration
To register your product visit our website: fisherpaykel.com/register
Safety and warnings 4
Before you begin 9
Using the control panel 10
Storage features 11
Using your appliance 12
Storage features 22
Wi-Fi connection 24
Cleaning and care 25
Food care 30
User warnings and sounds 31
Troubleshooting 32
Service and warranty 36
European Directive 2012/19/EU on
Waste Electrical and Electronic Equipment (WEEE) 37
4
SAFETY AND WARNINGS
! WARNING!
Electric Shock Hazard
Failure to do so can result in death, electric
shock, fire or injury to persons.
• Read and follow the safety and warnings
outlined in this user guide before operating this
appliance.
! WARNING!
This appliance contains flammable
refrigerant isobutane (R600a).
5
SAFETY AND WARNINGS
READ AND SAVE THIS GUIDE
WARNING!
Read entire manual. Failure to follow all guides and rules could cause personal injury or
property damage. When using this appliance, always exercise basic safety precautions
including thefollowing:
General Use
zThis product has been designed for use in a normal domestic (residential) environment.
zThis refrigerating appliance is not intended to be used as a built-in appliance.
zChildren aged 3 to 8 years may load and unload this appliance under supervision.
zChildren should be supervised to ensure that they do not play with the appliance.
zCleaning and user maintenance shall not be undertaken by children without supervision.
zThis appliance can be used by children aged from 8years and above and persons
withreduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
theappliance in a safe way and understand the hazards involved.
zThe manufacturer’s installation instructions for product and cabinetry ventilation
mustbe followed when installing the appliance.
zTo avoid hazard due to instability of the appliance, it must be fixed in accordance
withinstallation instructions.
zKeep ventilation openings, in the appliance enclosure or the built-in structure,
clearofobstruction.
zDo not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
zDo not damage the refrigerant circuit.
zIn case of damage to the refrigerant circuit, ventilate the area by opening all windows.
zDo not operate electrical equipment or any other equipment that may produce arcs,
sparks or flames in the area. Contact your Fisher & Paykel trained and supported
service technician immediately to arrange for the appliance to be repaired.
zConnect to potable water supply only
zThis refrigerating appliance is intended to be used at ambient temperatures ranging
from 16 °C to 38 °C. The product performance may be compromised when operating
outside of this temperature range.
zIt is hazardous for anyone other than a Fisher & Paykel trained and supported service
technician to service this appliance. In Queensland – the authorized Service Person
MUST hold a Gas Work Authorisation for hydrocarbon refrigerants, to carry out
Servicing or repairs which involve the removal of covers.
Electrical
zThis appliance must be installed in accordance with the installation instructions before
use.
zTo allow disconnection of the appliance from the supply after installation, incorporate a
switch in the fixed wiring in accordance with the wiring rules.
zNever unplug your refrigerator by pulling on the power cord. Always grip the plug
firmly and pull straight out from the outlet.
zDo not plug in any other appliance at the same power point as your refrigerator or use
extension cords or double adapters.
6
SAFETY AND WARNINGS
zRepair or replace immediately all electric service cords that have become frayed or
otherwise damaged. Do not use a cord that shows cracks or abrasion along its length or
at either the plug or appliance end.
zIf the power supply cord is damaged, it must only be replaced by your Fisher & Paykel
trained and supported service technician because special purpose tools are required.
zWhen moving your appliance away from the wall, be careful not to roll over or damage
the power cord.
zWARNING: Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
zWhen positioning the appliance, ensure the power cord is not trapped or damaged.
zDo not locate multiple portable socket-outlets or portable power supplies at the rear
of the appliance.
Food safety
zRegularly clean accessible draining systems and surfaces that come in
contact with food.
zEnsure any raw meat or fish is stored in sealed containers to prevent
cross-contamination.
zImmediately clean any drips or spills on surfaces.
zIf the appliance will be left empty for long periods, switch off, defrost, clean, dry, and
leave the door open to prevent mould developing within the appliance.
zOpening the door for long periods can cause a significant increase of the temperature
in the compartments of the appliance.
Storing food and drinks/wine
zDo not store explosive substances such as aerosol cans with a flammable propellant
inthis appliance.
zNever store volatile or flammable materials in your appliance as they may explode.
zNever freeze liquids in glass containers. Liquid expands during freezing, which may
cause the container to explode.
zNever freeze carbonated drinks. They may explode.
Servicing
zYour refrigerator is designed to operate for many years without the need for service
checks. However, if your refrigerator is malfunctioning, have it attended to by your
Fisher & Paykel trained and supported service technician as soon as possible. All
electrical repairs must be carried out by an adequately trained service technician or
qualified electrician.
zThe LED light cannot be serviced by the user. Contact your Fisher & Paykel Dealer or
Fisher & Paykel trained and supported service technician.
zIf you suspect that the product is not getting cold — items such as ice cream are
melting— remove all perishable food and store in another appliance or cooler to prevent
spoilage. Immediately call for a service technician.
Cleaning
zUse mild dish-washing liquid with warm water and a lint-free cloth to clean the product.
zAvoid using anti-bacterial cleaning products on either the interior or exterior
of the cabinet as they may cause rusting of metal components and cracking of
plasticcomponents.
7
SAFETY AND WARNINGS
Disposal
zExtreme care must be taken when disposing of your old appliance to avoid hazards:
zThe flammable refrigerant gas must be safely removed by a qualified servicetechnician.
zThe thermal insulation foam in this appliance may contain flammable insulationblowing
gases, any exposed foam may be highly flammable andmustbe carefully treated
during disposal.
zWARNING: Risk of child entrapment. Before you throw away your old refrigerator or
freezer, the doors and panels should be removed and the racks left in place so that
children may not easily climb inside.
zConsult your local energy authority or local codes as to the best way to dispose
ofyour old appliance.
Water connection
zThe water connection to your Ice & water refrigerator must be installed by an
authorised plumber or Fisher & Paykel trained and supported service technician.
zInstallation and use MUST comply with all state and local plumbing codes. Check
with your local public works department for plumbing codes. You must follow their
guidelines as you install the water filtration system.
zIf the water tank has not been used for an extended period of time, or has developed
an unpleasant taste or odour, flush the water system. If the problem persists, replace
the water filter cartridge and refer to the flushing instructions detailed in section
‘Flushing through the water dispenser.
zTo avoid serious illness or death, only connect your water filter to safe drinking water.
zThe water filter cartridge needs to be changed when the replacement indicator icon
illuminates. This will happen every six months.
zIf the water filtration system has been allowed to freeze, replace filter cartridge.
Failure to replace the disposable filter at recommended intervals may lead to reduced
filter performance and failure of the filter, causing property damage from water
leakage or flooding.
zIn cases of excessively reduced filter life — we recommend that you consult a local
plumber or your water supplier for advice on suitable filtration requirements for the
water supplied to your home.
zFilter replacement is the consumer’s responsibility and will not be covered by the
warranty except in the case of faulty parts or materials within the filter cartridge.
zIf the water has not created ice for some time or ice has an unpleasant taste or odour
dispose of ice and refer to ‘Automatic ice’ for flushing instructions. If unpleasant taste
or odour persists, you may wish to fit a new filter cartridge.
zUse new tubing supplied with the refrigerator. DO NOT reuse old tubing from old water
and ice connections.
zYour water filtration system can withstand up to 827kPa of water pressure.
zEnsure the supplied pressure limiting valve is installed before installing the water
filtration system. DO NOT install if water pressure exceeds 827kPa.
To reduce the risk associated with property damage due to water leakage or flooding:
zDO NOT install systems in areas where ambient temperatures may go above 38°C or
drop below 0°C.
zDO NOT install on hot water supply lines. The maximum operating water temperature of
this filter system is 38°C.
zDO NOT install where water hammer conditions may occur. If water hammer conditions
exist, you must install a water hammer arrester.
8
WARNING!
To reduce the risk associated with choking:
zDO NOT allow children under 3 years of age to have access to small parts during the
installation of the water filter.
Ice making
zAvoid contact with the moving parts of the ice maker ejector mechanism, and do
not place your fingers on the automatic ice- making mechanism while the appliance
is inoperation.
zAt first use or after water filter has been replaced, there may be discolouration in the
first bin of ice cubes. Discard the discoloured ice cubes. If discolouration continues in
succeeding bins, contact your Fisher & Paykel trained and supported service technician.
Power failure
zIn the event of a power interruption, the appliance will automatically save the current
temperature settings. When power is recovered, the appliance will revert to the current
temperature settings only.
zMost power failures are corrected within a short period of time. 1 – 2 hours loss of
power will not affect the appliance’s temperatures.
zTo avoid sudden change of temperature while the power is off, you should avoid
opening the door. A refrigerator will keep food safe for up to 4 hours during a power
outage. Keep the door closed as much as possible. Discard refrigerated perishable food
such as meat, poultry, fish, eggs, and leftovers after 4 hours without power.
Light source information
zThis product contains light sources of energy efficiency class F. The light sources used
in this appliance are not suitable for room illumination.
SAFETY AND WARNINGS
9
Note: Automatic Ice and non-Ice & Water models do not have an external water dispenser.
RF522A, RF540A & RF610A E372B, E402B, E442B,
E522B, RF372B, RF402B,
RF442B & RF522B
RF522W
E372B, E402B, E442B, E522B, RF372B, RF402B, RF442B & RF522B models have three
handle options as shown below.
Pocket handlesDesigner handles
BEFORE YOU BEGIN
zEnsure the installer has completed the final checklist in the installation guide.
zRead this guide, taking special note of the safety and warnings section.
zRemove all packaging and dispose of it responsibly. Recycle items that you can.
Recessed handles
10
USING THE CONTROL PANEL
1Wi-Fi illuminates when functionality is activated.*
Illuminates to indicate that the keys on the control panel are locked. Allows you
to disable the buttons on the control panel.
Illuminates when the water filter needs replacing.
IIluminates to indicate that Sabbath mode is activated.
Illuminates to indicate key press sounds are deactivated.
2Allows you to select the compartment to adjust the temperature.
zUpper light to indicate the refrigerator compartment is selected.
zLower light to indicate the freezer compartment is selected.
3Alarm mute deactivates the door alarm for 20minutes.
4Allows you to adjust the temperature of the selected compartment.
5Allows you to select features:
FAST FREEZE BOTTLE CHILL
ICE ON/OFF ICE BOOST
* Not available in E372B & RF372B models.
The control panel enables you to view and modify all the features and options of
yourrefrigerator. Extra features available on selected models.
1
2
4
5
3
Ice & Water models Non-Ice & Water models
11
STORAGE FEATURES
REFRIGERATOR
Fruit and vegetable bins/Slim bin
with humidity control lids
Separate fruits and vegetables to prevent the ethylene-sensitive
produce from ripening too quickly-helps to extend their storage
life.
Also used for storing deli items and beverages, or fordefrosting
foods.
Slim bin (where fitted) The slim bins at the bottom of the refrigerator compartment
provide storage space for items that you may want to keep
separate from the rest of the refrigerator..
These slim storage bins can be used for deli item storage,
beverages or for defrosting foods.
Cantilever glass shelving Heat-treated safety glass
Can be removed and positioned at heights to suit your storage
requirements.
Dairy shelf and door shelves The top door shelf is a dairy compartment for storing butter and
cheeses.
The middle shelves are designed for general items, condiments
and drinks.
The bottom shelves are designed to store large drinks or those
drinks you require frequent access to.
Clear windows give ultimate visibility to what is being stored in
the door shelves.
Adjustable door shelves with dividers.
Single bottle holders (where fitted) The bottle holders can be used to store a variety of bottles.
Bottles are best stored with the neck of the beverage facing the
front of the refrigerator.
Unused bottle holders can be stacked up on top of one another
so they do not take up unnecessary shelf space.
FREEZER
Ice maker* Removable ice container.
Hygienic ice scoop.
Freezer bins Allow for easy storage of frozen food items.
* Ice & Water and Automatic Ice models only.
13
USING YOUR APPLIANCE
1
Key mute
To activate/deactivate , press KEY MUTE
for fourseconds.
Once KEY MUTE is activated the icon on
the internal control panel illuminates, all key
sounds are silenced.
Door alarms and the BOTTLE CHILL alarm are
still operational.
Door alarms
If the refrigerator compartment door is left open, the alarm will beep after 90seconds, if
the freezer door is left open the alarm will beep after 60seconds. If either of the doors
remains open, subsequent beeps will sound every 30 seconds for fiveminutes.
Alarm mute
To activate/deactivate ALARM MUTE,
press once. The light above the
button will illuminate to indicate the
refrigerator is muted.
ALARM MUTE will automatically deactivate
after 20minutes or when the door is closed.
1
Key lock
KEY LOCK allows you to disable the buttons on the internal control panel. This is useful
when cleaning your refrigerator.
To activate/deactivate , press and KEY LOCK
together for fourseconds.
When KEY LOCK is activated the icon on
the internal control panel will illuminate.
Pressing any of the buttons will sound several
beeps to tell you that they are disabled.
1
14
Sabbath mode
In SABBATH MODE, alarms, lights and displays are deactivated for 80 hours.
Once in Sabbath mode:
zThe interior light will not turn on when you open the refrigerator.
zThe door alarms will not operate.
zThe display will not illuminate, except the Sabbath mode icon.
zThe internal and external control panels will not operate.
zSabbath mode automatically deactivates after 80 hours.
To activate/deactivate SABBATH MODE, press
, and together for fourseconds. The
icon on the internal control panel will
illuminate when SABBATH MODE is activated.
1
If you turn off your refrigerator while in SABBATH MODE it will resume automatically once
the refrigerator is switched on again.
USING YOUR APPLIANCE
15
For best results, activate the function before it is required. Alternatively, activate it
whenplacing food into the freezer.
2
To activate, press on the internal display.
The FAST FREEZE light will illuminate.
To deactivate before the 24hours has
elapsed, press again.
When FAST FREEZE is deactivated
the light is off.
1
Features
FAST FREEZE boosts freezing speed by dropping to its coldest temperature for 24 hours,
helping retain freshness, texture and taste during the freezing process.
USING YOUR APPLIANCE
Fast Freeze*
* Available in Ice & Water and Automatic Ice models only.
16
An alarm will sound after 15minutes to
remind you to remove your beverage.
For non water-dispensing models
Open the refrigerator compartment door
and press anybutton on the control panel to
silence the alarm.
2
4
To deactivate before 15minutes, BOTTLE CHILL
press the button on the control panel.
When BOTTLE CHILL is deactivated, the
light will not illuminate and the icon is
not visible on the external display (Ice &
Water model only).
For water-dispensing models
The icon will flash on the external
display. Press on the external display to
silence the alarm.
3
USING YOUR APPLIANCE
1
BOTTLE CHILL rapidly chills your beverages in the freezer for a set time of 15 minutes.
Depending on bottle size, you may need to return it to the freezer and reset.
Bottle Chill*
To activate, press on the control panel.
The BOTTLE CHILL light will illuminate.
The icon will illuminate on the external
display (Ice & Water models only).
* Available in Ice & Water and Automatic Ice models only.
17
USING YOUR APPLIANCE
2
Ice Boost*
When you first turn your ice maker on,
ICE BOOST is off.
To activate, press . The light above the
button will illuminate.
ICE BOOST will pause once your ice bin is full.
To manually deactivate press again.
The light will not illuminate.
Activating ICE BOOST will automatically
turn on ice making.
Deactivating ice making automatically
deactivates ICE BOOST.
1
ICE BOOST increases ice production by up to 30% and will automatically deactivate
after 24 hours.
IceOn/Off*
ICE ON/OFF activates automatic ice - this is only available in the lower compartment.
Your ice maker is designed to automatically dispense ice into the ice storage bin below
until it detects the bin is full. The more ice you use, the more it makes. Before first use the
automatic ice systems needs to be flushed.
To activate/deactive, press .
When the ice maker is activated the light
will illuminate.
1
* Available in Ice & Water and Automatic Ice models only.
18
Information about your manual ice system
To make ice, take the ice tray and lid from the top of the ice storage bin. Remove the lid
from the ice tray and fill the tray with water. Place the lid back on the ice tray and carefully
position it back onto the ice storage bin.
Once the ice is solid, take the ice tray and lid off the ice storage bin, remove the lid from
the tray and twist the ice tray at each end in opposite directions. Turn the ice tray over the
ice storage bin to dislodge the cubes into the bin.
Fill the ice tray with clean water and repeat to fill the ice storage bin.
Attached to the ice storage bin is the ice scoop which provides hygienic access to ice.
To access ice cubes, take the ice tray and lid from the top of the ice storage bin and place
onto a flat surface. Take the scoop from the front of the bin, scoop cubes into vessel and
then replace the scoop, tray and lid back to the top of the bin.
For maximum ice storage, level the stored cubes around the bin with the ice scoop.
If ice is not used often, old cubes will become cloudy, taste stale, will shrink and may stick
together. Empty the ice storage bin periodically and wash in lukewarm water.
Dry thoroughly and place back in the correct position.
USING YOUR APPLIANCE
Manual ice system (selected models only)
An ice storage bin which sits inside the upper top freezer bin provides storage for and gives
you access to clean, clear ice cubes.
Upper left freezer bin, ice storage bin, ice
tray, lid and scoop in correct position
Accessing your ice
19
USING YOUR APPLIANCE
To dispense water, gently press the dispensing pad with a
glass or container.
To stop the flow of water, simply pull your glass or container
away from the dispensing pad.
Pressing hard against the dispensing pad will not increase the
flow or dispense more water.
Dispensing
Your water dispenser is designed for one-handed operation.
Water-dispensing models only
3 2 1
4
1Dispenser lock button
and LED light
Locks/unlocks the water dispenser. The LED above the lock
button will illuminate when dispenser is locked.
2Bottle Chill indicator Icon will illuminate when BOTTLE CHILL isactivated and
flashes when the beverage is ready.
3Filter change indicator Icon will illuminate when water filter requires changing.
4Drip tray The drip tray is designed to fit into the bottom of the water
dispenser panel to capture any odd drips of water that may
fall after dispensing.
20
USING YOUR APPLIANCE
Dispenser lock
The DISPENSER LOCK is located on the external display and can be activated to prevent
water from being dispensed. Thisisuseful when you are cleaning the external display or
when there are small children around.
To activate/deactivate DISPENSER LOCK, press
for fourseconds.
When activated the light above the button
will illuminate.
When the dispenser pad is pressed, several
beeps will sound to alert the user that water
cannot be dispensed.
1
Water filter
The water supplied to your refrigerator is filtered to remove impurities through a filter
located internally at the top right corner of the refrigerator. Replace your filter cartridge
every 6months.
zThere is a replacement indicator icon on the internal control panel and external
display which will appear when the filter needs replacing. The icon will flash, as a
reminder, when water isdispensed.
zReplacement filter cartridges are available from your Fisher & Paykel dealer, online or
from a Fisher & Paykel service technician. The details of the replacement filter cartridge
are labelled on the cartridge.
To reset the filter indicator:
Press and together for 4seconds.
The on the control panel will turn
off when reset.
Changing the water filter cartridge
Guidance of how to replace your water filter can be found at fisherpaykel.com/water-filter.
21
USING YOUR APPLIANCE
Press the water dispenser pad to
dispense 4L of water.
Wait for 4 minutes before dispensing again.
Dispense another 4L of water. Your water
dispenser is now ready for use.
Water will continue to drip from the dispenser
for a few more days after installation
as the remaining trapped air is released
from the system.
NOTE: There may be carbon residue dispensed
together with water. This is not harmful, and
normal during flushing process.
To flush through the water dispenser
To flush through the automatic icemaker
1
2
Press and hold , and together for
4seconds then close the door(s). The ice
tray will flip twice and empty the water into
the bin below. The ice tray will flip only after
the doors are closed.
Repeat the cycle to help remove any
dust in the ice tray collected during
manufacture and transport.
Empty the water in the bin and return the bin
correctly. Ensure that the scoop is located in
front of the bin.
Once your ice maker is turned on, discard the
first 3harvests of ice (8cubes per harvest).
This will flush away any impurities in the water
line and ensure the best ice quality.
Do the above steps after a holiday/vacation or
extended periods of not using ice.
Flushing the water filter
Before you start using the Ice & Water function, complete the flushing steps to ensure
optimum performance of your water filter.
22
Humidity control system
Humidity control lids
The control lids are fitted to the fruit and vegetable bins of your refrigerator.
zThese lids seal the bins and provide a humid microclimate to extend the storage timesof
fruit and vegetables.
zThe lids have specially designed grooves that retain moisture to prevent condensation
from dripping onto the fruits and vegetables at times of high humidity.
Humidity slide
STORAGE FEATURES
Each bin has an adjustable humidity slide that enables you to choose a fruit or vegetable
setting depending on your storage needs.
zIf there is too much water in the bins (due to high humidity), the control can be
adjustedtowards the fruit setting to reduce drips of water and/or wipe the
waterdry (if required).
zBe aware that a small amount of water in the bins is beneficial for fruit and
vegetablestorage.
zUse the vegetable setting when you store ethylene-sensitive vegetables such
aslettuce, spinach, broccoli, cabbage, carrots.
zUse the fruit setting when you store high-ethylene fruits such ascitrus fruits,
stonefruits and some tropical fruits.
zWe recommend adjusting the humidity slide to the center when you store both
fruitsandvegetables.
zWe recommend storing all fruit and vegetables without external packaging and
inseparate bins.
zSeparating the fruit and vegetables prevent ethylene-sensitive produce fromripening too
quickly, and help extend their storage life.
Humidity control graphic
23
STORAGE FEATURES
Slim storage drawer (where fitted)
Glass shelves
The slim bins at the bottom of the refrigerator
compartment provide storage space for items
that you may want to keep separate from the
rest of the refrigerator.
These slim storage bins can be used for deli
item storage, beverages or for defrosting foods.
Glass shelves can be repositioned in the
cabinet as desired.
Remove shelves by lifting up the back of the
shelf and then pulling the shelf forward.
Slim storage drawer
Bottle holder (where fitted)
The bottle holders can be used to store
a variety of bottles.
To position the bottle holder in your refrigerator,
simply slot the back edge of the bottle
holder onto the back trim of any shelf in the
refrigerator compartment.
If you are not using all or some of the bottle
holders, the unused bottle holders can be
stacked up on top of one another so they do
not take up unnecessary shelf space.
Bottles are best stored with the neck of the
beverage facing the front of the refrigerator.
Bottle holder
24
Your appliance may be connected to your home wireless network and operated remotely
using the app.
Getting started
zEnsure your home Wi-Fi network is turned on.
zYou will be given step by step guidance on your mobile device.
zIt may take up to 10 minutes to connect your appliance.
On your mobile device:
1 Download the app from www.fisherpaykel.com/connect
2 Register and create an account.
3 Add your appliance and set up the Wi-Fi connection.
Not available in E372B & RF372B models.
WI-FI CONNECTION
25
CLEANING AND CARE
Exterior
Clean all surfaces with liquid dishwashing detergent dissolved in warm water andasoft
cloth. Rinse with clean water and dry with a clean, lint-free cloth.
Do not use any abrasive stainless steel cleaners, glass cleaners, solvents or scourer pads as
these will damage the door surface.
Door gasket
Clean the magnetic door gasket every three months with a toothbrush, and liquid detergent
dissolved in warm water.
Bottle holder (where fitted)
Clean with warm water and detergent. The use of abrasive cleaners and solvents
may cause damage.
Cabinet surround
To maximise operating efficiency regularly
vacuum the flooring around your appliance.
Cleaning behind the appliance is required once
or twice a year. More frequent cleaning may
be necessary for dusty homes or those with
pets shedding hair.
To do this wind up the feet and carefully ease the
refrigerator out of its position. Switch off andunplug.
Vacuum the flooring behind your appliance and the
rear compartment cover (where fitted) to remove
dust accumulation. Use a dry lint-free cloth to clean
the appliance walls and surrounding cabinetry.
After cleaning, plug in and switch on. Push the appliance into position and wind feet down.
Cleaning the rear compartment cover
26
CLEANING AND CARE
Drip tray (Water-dispensing models only)
1
2
Remove the drip tray from the
dispenser panel.
Pull the two halves of the tray apart.
Clean with liquid detergent dissolved in water
and a soft lint-free cloth.
Rinse with clean water and dry with a clean,
lint-free cloth.
Securely clip the two halves together.
Re-insert the drip tray back into the
dispenser panel, rounded sides first.
External display and water dispenser (Water-dispensing models only)
Activate the DISPENSER LOCK to prevent
water from dispensing when cleaning, refer
‘Dipenser lock’ section for details.
Clean the pad and external display with a
damp, soft lint-free cloth.
27
CLEANING AND CARE
Interior
It is important to keep the interior of the refrigerator and freezer clean to help prevent food
from becoming contaminated during storage.
The amount and types of food stored determines how often cleaning should be carried out
in the refrigerator (ideally once every 1 to 2 weeks).
Remove the shelves from cabinet and door. Wash shelves and storage bins in warm water
and detergent; rinse in clean water and dry before replacing.
Wipe over the interior surfaces with warm water and liquid dishwashing detergent.
Alternatively you can use 1tsp baking soda dissolved in 500ml of warm water. Rinse
with cleanwater.
To help remove “old stale refrigerator” smells add a few drops of vanilla essence or vinegar
to the water before cleaning.
Clean interior surfaces with warm water and liquid dishwashing detergent. Use a toothbrush
for the magnetic door gasket.
Do not use harsh, abrasive cloths on any part of the refrigerator or freezer.
Glass shelves
Clean with warm water and detergent.
Bottle holder (where fitted)
Clean with warm water and detergent. The use of abrasive cleaners and solvents
may cause damage.
Automatic ice dispenser (Ice & Water and Automatic Ice models only)
We do not recommend you clean the ice maker componentry, but it is important to clean
the bins occasionally. The storage bin should be cleaned regularly and the old ice in the
bottom of the bin discarded. Wash bin in lukewarm water. Dry thoroughly and replace.
When replacing the bin ensure that the scoop is on the right hand side or at the front of the
bin (model dependent).
Many commercially available cleaning products contain solvents that may attack the
plastic components of your refrigerator and cause them to crack. It is important to use
only warm water and a small amount of liquid dishwashing detergent on any components
inside and outside your refrigerator. Avoid using anti-bacterial cleaning products on either
the interior or exterior of the cabinet as they may cause rusting of metal components and
cracking of plastic components.
Produktspezifikationen
Marke: | Fisher & Paykel |
Kategorie: | Kühlschrank |
Modell: | RF540ADUB7 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Fisher & Paykel RF540ADUB7 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Kühlschrank Fisher & Paykel
19 September 2024
18 September 2024
15 September 2024
6 September 2024
6 September 2024
4 September 2024
4 September 2024
4 September 2024
4 September 2024
4 September 2024
Bedienungsanleitung Kühlschrank
- Kühlschrank Samsung
- Kühlschrank Infiniton
- Kühlschrank Domo
- Kühlschrank Emerio
- Kühlschrank G3 Ferrari
- Kühlschrank Tristar
- Kühlschrank Sanyo
- Kühlschrank Manta
- Kühlschrank Medion
- Kühlschrank SilverCrest
- Kühlschrank Hanseatic
- Kühlschrank Panasonic
- Kühlschrank Quigg
- Kühlschrank LG
- Kühlschrank Adler
- Kühlschrank Camry
- Kühlschrank Guzzanti
- Kühlschrank Princess
- Kühlschrank Royal Catering
- Kühlschrank Trisa
- Kühlschrank Bosch
- Kühlschrank AEG
- Kühlschrank Ardes
- Kühlschrank Asko
- Kühlschrank Siemens
- Kühlschrank ATAG
- Kühlschrank Bauknecht
- Kühlschrank Bifinett
- Kühlschrank Caso
- Kühlschrank Concept
- Kühlschrank Electrolux
- Kühlschrank Fagor
- Kühlschrank Gaggenau
- Kühlschrank Gorenje
- Kühlschrank Klarstein
- Kühlschrank Koenic
- Kühlschrank Küppersbusch
- Kühlschrank Miele
- Kühlschrank Proficook
- Kühlschrank Severin
- Kühlschrank Teka
- Kühlschrank Unold
- Kühlschrank Whirlpool
- Kühlschrank Bomann
- Kühlschrank CombiSteel
- Kühlschrank Essentiel B
- Kühlschrank H.Koenig
- Kühlschrank Listo
- Kühlschrank Melissa
- Kühlschrank OK
- Kühlschrank Russell Hobbs
- Kühlschrank Vox
- Kühlschrank Yamaha
- Kühlschrank IKEA
- Kühlschrank Denver
- Kühlschrank ECG
- Kühlschrank Bush
- Kühlschrank Telefunken
- Kühlschrank Thomson
- Kühlschrank Mestic
- Kühlschrank Amica
- Kühlschrank BEKO
- Kühlschrank Blaupunkt
- Kühlschrank Boretti
- Kühlschrank Cuisinart
- Kühlschrank Eta
- Kühlschrank Grundig
- Kühlschrank Heinner
- Kühlschrank Hotpoint
- Kühlschrank Inventum
- Kühlschrank Kenwood
- Kühlschrank KitchenAid
- Kühlschrank Micromaxx
- Kühlschrank Moulinex
- Kühlschrank Primo
- Kühlschrank Schneider
- Kühlschrank Sharp
- Kühlschrank Smeg
- Kühlschrank Polar
- Kühlschrank Tomado
- Kühlschrank Dometic
- Kühlschrank Rocktrail
- Kühlschrank AEG-Electrolux
- Kühlschrank Ardo
- Kühlschrank Aspes
- Kühlschrank Balay
- Kühlschrank Blomberg
- Kühlschrank Scandomestic
- Kühlschrank Bompani
- Kühlschrank Brandt
- Kühlschrank Candy
- Kühlschrank Castor
- Kühlschrank Comfee
- Kühlschrank Constructa
- Kühlschrank Corberó
- Kühlschrank Curtiss
- Kühlschrank Daewoo
- Kühlschrank Edesa
- Kühlschrank Elektra Bregenz
- Kühlschrank ELIN
- Kühlschrank Eudora
- Kühlschrank Eurotech
- Kühlschrank Worx
- Kühlschrank Everglades
- Kühlschrank Exquisit
- Kühlschrank Pyle
- Kühlschrank Mitsubishi
- Kühlschrank Finlux
- Kühlschrank GE
- Kühlschrank Haier
- Kühlschrank High One
- Kühlschrank Hisense
- Kühlschrank Hoover
- Kühlschrank Arthur Martin
- Kühlschrank Hotpoint-Ariston
- Kühlschrank Iberna
- Kühlschrank Ignis
- Kühlschrank Bartscher
- Kühlschrank Indesit
- Kühlschrank Juno
- Kühlschrank Juno-Electrolux
- Kühlschrank Baumatic
- Kühlschrank Kelvinator
- Kühlschrank Bertazzoni
- Kühlschrank Luxor
- Kühlschrank Lynx
- Kühlschrank Maytag
- Kühlschrank Brandy Best
- Kühlschrank Midea
- Kühlschrank Caple
- Kühlschrank NABO
- Kühlschrank Neff
- Kühlschrank Nordmende
- Kühlschrank EAS Electric
- Kühlschrank PKM
- Kühlschrank Privileg
- Kühlschrank Progress
- Kühlschrank Rex
- Kühlschrank Rommer
- Kühlschrank Salora
- Kühlschrank ETNA
- Kühlschrank Scholtès
- Kühlschrank Frigidaire
- Kühlschrank SIBIR
- Kühlschrank Smart Brand
- Kühlschrank Svan
- Kühlschrank Techwood
- Kühlschrank Thor
- Kühlschrank V-ZUG
- Kühlschrank Vestel
- Kühlschrank Vestfrost
- Kühlschrank Junker
- Kühlschrank Zanker
- Kühlschrank Zanussi
- Kühlschrank Zerowatt
- Kühlschrank Leonard
- Kühlschrank M-System
- Kühlschrank Monogram
- Kühlschrank Oranier
- Kühlschrank Pelgrim
- Kühlschrank Philco
- Kühlschrank Respekta
- Kühlschrank Rosières
- Kühlschrank Schaub Lorenz
- Kühlschrank Thermador
- Kühlschrank Valberg
- Kühlschrank Viva
- Kühlschrank Zoppas
- Kühlschrank Akai
- Kühlschrank Arçelik
- Kühlschrank Changhong
- Kühlschrank Chiq
- Kühlschrank Continental Edison
- Kühlschrank Hitachi
- Kühlschrank Hyundai
- Kühlschrank Kernau
- Kühlschrank Orava
- Kühlschrank TCL
- Kühlschrank Toshiba
- Kühlschrank Livoo
- Kühlschrank DCG
- Kühlschrank Liebherr
- Kühlschrank Elica
- Kühlschrank DeLonghi
- Kühlschrank Element
- Kühlschrank Franke
- Kühlschrank Kalorik
- Kühlschrank Optimum
- Kühlschrank Saro
- Kühlschrank Waeco
- Kühlschrank Costway
- Kühlschrank Cecotec
- Kühlschrank Husqvarna
- Kühlschrank Wolkenstein
- Kühlschrank Avintage
- Kühlschrank Climadiff
- Kühlschrank Frilec
- Kühlschrank Sub-Zero
- Kühlschrank Honeywell
- Kühlschrank Foster
- Kühlschrank Moa
- Kühlschrank Silverline
- Kühlschrank Osprey
- Kühlschrank Novy
- Kühlschrank Airlux
- Kühlschrank Cata
- Kühlschrank Cobal
- Kühlschrank Cylinda
- Kühlschrank De Dietrich
- Kühlschrank Elba
- Kühlschrank Faure
- Kühlschrank Freggia
- Kühlschrank Hansa
- Kühlschrank Leisure
- Kühlschrank MPM
- Kühlschrank Nodor
- Kühlschrank Stoves
- Kühlschrank UPO
- Kühlschrank Friac
- Kühlschrank CaterCool
- Kühlschrank White Knight
- Kühlschrank Logik
- Kühlschrank GYS
- Kühlschrank Veripart
- Kühlschrank Thetford
- Kühlschrank Dacor
- Kühlschrank GOTIE
- Kühlschrank Mobicool
- Kühlschrank Americana
- Kühlschrank Bluesky
- Kühlschrank Heller
- Kühlschrank Orima
- Kühlschrank Proline
- Kühlschrank Dimplex
- Kühlschrank Thorens
- Kühlschrank Mora
- Kühlschrank Westinghouse
- Kühlschrank Paulmann
- Kühlschrank Amana
- Kühlschrank Arthur Martin-Electrolux
- Kühlschrank Carrefour Home
- Kühlschrank Electrolux-Rex
- Kühlschrank Euromaid
- Kühlschrank Galanz
- Kühlschrank Gram
- Kühlschrank Whiteline
- Kühlschrank Vivax
- Kühlschrank Profilo
- Kühlschrank Sauber
- Kühlschrank Lamona
- Kühlschrank Limit
- Kühlschrank Meireles
- Kühlschrank Tricity Bendix
- Kühlschrank Kogan
- Kühlschrank United
- Kühlschrank Nordland
- Kühlschrank Jocca
- Kühlschrank Benavent
- Kühlschrank Edy
- Kühlschrank Milectric
- Kühlschrank New Pol
- Kühlschrank Qilive
- Kühlschrank Waltham
- Kühlschrank Zenith
- Kühlschrank True
- Kühlschrank Insignia
- Kühlschrank Cosmo
- Kühlschrank Crosley
- Kühlschrank Rhino
- Kühlschrank Carpigiani
- Kühlschrank Danby
- Kühlschrank Viking
- Kühlschrank Vedette
- Kühlschrank Sogo
- Kühlschrank Ariston Thermo
- Kühlschrank Gourmetmaxx
- Kühlschrank Signature
- Kühlschrank RCA
- Kühlschrank Bellini
- Kühlschrank Daikin
- Kühlschrank Swan
- Kühlschrank AYA
- Kühlschrank Esatto
- Kühlschrank Orbegozo
- Kühlschrank Napoleon
- Kühlschrank Ilve
- Kühlschrank Furrion
- Kühlschrank Gibson
- Kühlschrank CDA
- Kühlschrank General Electric
- Kühlschrank Flavel
- Kühlschrank Fridgemaster
- Kühlschrank Seiki
- Kühlschrank Aldi
- Kühlschrank Defy
- Kühlschrank Dunavox
- Kühlschrank Edgestar
- Kühlschrank Electra
- Kühlschrank Engel
- Kühlschrank EvaKool
- Kühlschrank Fisher Paykel
- Kühlschrank Gardenline
- Kühlschrank Gastro-Cool
- Kühlschrank Gecko
- Kühlschrank Igloo
- Kühlschrank Jocel
- Kühlschrank Kenmore
- Kühlschrank La Germania
- Kühlschrank La Sommeliere
- Kühlschrank Lavorwash
- Kühlschrank Magic Chef
- Kühlschrank Marynen
- Kühlschrank Mercury
- Kühlschrank Newpol
- Kühlschrank Novamatic
- Kühlschrank ONYX
- Kühlschrank POLARIS
- Kühlschrank Rangemaster
- Kühlschrank Salton
- Kühlschrank Scancool
- Kühlschrank SPT
- Kühlschrank Stirling
- Kühlschrank Sunny
- Kühlschrank Tecnolux
- Kühlschrank Teco
- Kühlschrank Temptech
- Kühlschrank Vinata
- Kühlschrank Vintec
- Kühlschrank Whynter
- Kühlschrank WLA
- Kühlschrank Parmco
- Kühlschrank Turbo Air
- Kühlschrank Hatco
- Kühlschrank Zephyr
- Kühlschrank Avanti
- Kühlschrank Kunft
- Kühlschrank Kucht
- Kühlschrank Becken
- Kühlschrank Avantco
- Kühlschrank Wells
- Kühlschrank Nevir
- Kühlschrank JennAir
- Kühlschrank Winia
- Kühlschrank BlueStar
- Kühlschrank Romo
- Kühlschrank Norlake
- Kühlschrank Chefman
- Kühlschrank Blaze
- Kühlschrank Ravanson
- Kühlschrank Wine Klima
- Kühlschrank Lec Medical
- Kühlschrank Fulgor Milano
- Kühlschrank Delfield
- Kühlschrank Hoshizaki
- Kühlschrank Godrej
- Kühlschrank NewAir
- Kühlschrank Snaigė
- Kühlschrank Kolpak
- Kühlschrank Beverage-Air
- Kühlschrank Airflo
- Kühlschrank Arctic Air
- Kühlschrank Arktic
- Kühlschrank BeefEater
- Kühlschrank Artusi
- Kühlschrank Glem Gas
- Kühlschrank Nemco
- Kühlschrank Traulsen
- Kühlschrank Husky
- Kühlschrank Sôlt
- Kühlschrank Federal
- Kühlschrank APW Wyott
- Kühlschrank Le Chai
- Kühlschrank Marvel
- Kühlschrank BSK
- Kühlschrank Equator
- Kühlschrank Orien
- Kühlschrank Khind
- Kühlschrank Hestan
- Kühlschrank Azure
- Kühlschrank Alto-Shaam
- Kühlschrank Hiberg
- Kühlschrank Sam Cook
- Kühlschrank U-Line
- Kühlschrank Coldtainer
- Kühlschrank Techfrost
- Kühlschrank Icecool
- Kühlschrank Gasmate
- Kühlschrank Bromic
- Kühlschrank Silhouette
- Kühlschrank Cool Head
- Kühlschrank LERAN
- Kühlschrank Belling
- Kühlschrank Cookology
- Kühlschrank Summit
- Kühlschrank Structural Concepts
- Kühlschrank IFB
- Kühlschrank Brastemp
- Kühlschrank FrigeluX
- Kühlschrank Consul
- Kühlschrank Haeger
- Kühlschrank Kuhla
- Kühlschrank Linarie
- Kühlschrank Irinox
- Kühlschrank Haden
- Kühlschrank Mabe
- Kühlschrank Perlick
- Kühlschrank Sedona
- Kühlschrank Coyote
- Kühlschrank Atosa
- Kühlschrank Enofrigo
- Kühlschrank MBM
- Kühlschrank NEO Tools
- Kühlschrank Accucold
- Kühlschrank Gamko
- Kühlschrank Merax
- Kühlschrank Adventure Kings
- Kühlschrank Hydra Kool
- Kühlschrank DCS
- Kühlschrank Palsonic
- Kühlschrank Euro Appliances
- Kühlschrank Lemair
- Kühlschrank Magic Cool
- Kühlschrank Schmick
- Kühlschrank Fhiaba
- Kühlschrank InAlto
- Kühlschrank Create
- Kühlschrank LeCavist
- Kühlschrank Electroline
- Kühlschrank Koolatron
- Kühlschrank XO
- Kühlschrank Emperor's Select
- Kühlschrank Maxx Cold
- Kühlschrank Vinotemp
- Kühlschrank Norpole
- Kühlschrank Wisberg
- Kühlschrank Brass Monkey
- Kühlschrank Cooluli
- Kühlschrank Café
- Kühlschrank John Lewis
- Kühlschrank Kubo
- Kühlschrank Jenn-Air
- Kühlschrank New World
- Kühlschrank AVEA
- Kühlschrank Lec
- Kühlschrank Tisira
- Kühlschrank Unic Line
- Kühlschrank Blucher
- Kühlschrank ColdTech
- Kühlschrank IOMABE
- Kühlschrank Les Petits Champs
- Kühlschrank Master-Bilt
- Kühlschrank Simfer
- Kühlschrank Marbor
- Kühlschrank Adora
- Kühlschrank Gladiator
- Kühlschrank Triomph
- Kühlschrank Dellware
- Kühlschrank HABAU
- Kühlschrank Tuscany
- Kühlschrank TESLA Electronics
- Kühlschrank Premium Levella
- Kühlschrank DAYA
- Kühlschrank Sangiorgio
- Kühlschrank Kalamazoo
- Kühlschrank Yolco
- Kühlschrank Aconatic
- Kühlschrank Kluge
- Kühlschrank Hoover-Grepa
- Kühlschrank Coca-Cola
- Kühlschrank Acros
- Kühlschrank HomeCraft
- Kühlschrank Koldfront
- Kühlschrank Eqtemp
Neueste Bedienungsanleitung für -Kategorien-
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
