INSTALLATION GUIDE
Accessory door panels
DOOR PANEL INSTALLATION
431057A 10.22 NZ AU HK SG TW UK IE EU CN
Remove both side pins with
pliers and carefully pull the panel
bracket down and out slightly.
1
SAFETY & WARNINGS
Ensure a 2mm minimum ventilation gap below the
door is maintained.
Ensure all packaging is removed and disposed
o bly.f responsi
Ensure the Knock-To-Pause module is oriented
correctly before attaching.
2
3
4
Unplug knock-to-pause module
from the controller and remove
the earth wire from the bracket.
Remove the Knock-to-Pause
module from the back of
the bracket.
Install the handle to the panel
following the installation
guidance available for your
handle kit.
Reconnect the Knock-to-Pause
module to the UI 1 slot on the
wash controller as shown.
6
7
8
9
Reconnect the Earth wire to the
panel bracket.
Warning: Failure to reconnect the
Earth wire may result in electrical
shock or death.
Carefully fit the panels onto the
product. Re-insert both side pins
to secure panels in place.
Insert a crosshead driver into
the hole above each side pin
and rotate to adjust the panel
alignment. There is a maximum
travel distance of Ā± 1/16ā(2mm).
Repeat for both sides if required.
For more information, visit www.fisherpaykel.com
! WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electrical shock or death.
ā¢ Read and follow the safety and warnings before
operating this appliance.
Double models
Repeat each step on both drawers.
Ensure a 8mm minimum ventilation gap below the door
is maintained.
COMPONENTS REQUIRED
Crosshead driver Pliers
5Attach the Knock-to-Pause
module to the panel as shown.
Ensure the module is correctly
oriented and is not in contact
with the brackets before securing.
! WARNING!
Cut Hazard
Failure to use caution could result in injury.
ā¢ Take care: some edges may be sharp.
SERIES 11 models
SERIES 7 & 9 models
