IMSS E3265
-
1
-
E3265
REV P 6/8/20
IMSS60, IMSS84, IMSS120, EIMSS60 & EIMSS84
MODELS
INSTALLATION & OPERATIONS MANUAL
KEEP THIS MANUAL FOR FUTURE REFERENCE
Engineering and technical data are subject to change without notice.
FEDERAL INDUSTRIES 215 Federal Ave. Belleville, WI 53508
Toll Free 1(800) 356-4206 WI Phone (608) 424-3331 Fax: (608) 424-3234
IMSS E3265
-
2
-
CONTENTS
INTRODUCTION ....................................................................................................................................... 3
WARNING LABELS & SAFETY INSTRUCTIONS ............................................................................. 4
PRE-INSTALLATION PROCEDURES .................................................................................................. 5
INSPECTION FOR SHIPPING DAMAGE ............................................................................... 5
INSTALLATION INSTRUCTIONS...................................................................................................... 5-8
LOCATING THE DISPLAY CASE .......................................................................................... 5
ELECTRICAL CONNECTION .............................................................................................. 5-6
PERMANENT CONNECTED .................................................................................................. 5
STANDARD BASE ELECTRICAL CONNECTION .......................................................... 5-6
TOP ELECTRICAL CONNECTION ....................................................................................... 6
CORD CONNECTED ................................................................................................................ 6
REMOVING CASE FROM SHIPPING SKID .......................................................................... 7
REMOVING PACKAGING MATERIAL ................................................................................. 7
LEVELING THE CASE ............................................................................................................. 7
SEALING THE UNIT TO THE FLOOR ................................................................................... 7
BASE PANELS REMOVAL IMSS60 & IMSS84 ..................................................................... 8
BASE PANELS REMOVAL IMSS120 ..................................................................................... 9
BASE COMPONENT LAYOUT ........................................................................................ 10-13
CONDENSATE EVAPORATOR ............................................................................................ 14
CONDENSATE PAN SHIPPED LOOSE ................................................................................ 14
CONDENSATE PUMP ........................................................................................................... 15
SHELVES ............................................................................................................................ 16-17
OPERATING INSTRUCTIONS ........................................................................................................ 18-21
USER CONTROLS .................................................................................................................. 18
POWER SWITCH ................................................................................................................... 18
LIGHT SWITCH ..................................................................................................................... 18
ELECTRONIC CONTROL ................................................................................................ 18-21
INITIAL START UP ................................................................................................................ 21
PLACING PRODUCT IN CASE ............................................................................................. 21
CLEANING INSTRUCTIONS ........................................................................................................... 21-24
ACRYLIC AIR DEFLECTOR ................................................................................................. 21
DAILY CLEANING ................................................................................................................ 22
WEEKLY CLEANING ....................................................................................................... 22-23
MAINTENANCE ................................................................................................................... 24
CLEANING CONDENSER COIL .......................................................................................... 24
SERVICE INFORMATION .................................................................................................................... 25
PRE-SERVICE CHECKLIST .................................................................................................. 26
SPECIAL SERVICE SITUATIONS ........................................................................................ 27
SALE & DISPOSAL ................................................................................................................................. 27
ELECTRICAL DATA .............................................................................................................................. 28
CONTROL OPERATION ....................................................................................................................... 29
ELECTRONIC CONTROL ..................................................................................................... 29
OPERATION ........................................................................................................................... 29
DEFROST CYCLE .................................................................................................................. 29
MAXIMUM RUN TIMER ....................................................................................................... 29
CONTROL PARAMETERS ............................................................................................... 30-32
REFRIGERATION OPERATION .................................................................................................... 33-35
SELF CONTAINED OPERATION ........................................................................................ 33
REMOTE OPERATION ...................................................................................................... 33-34
ELECTRONIC EXPANSION VALVE (EEV)……………………………………………….35
REPLACEMENT PARTS - ................................................................................................................ 36-37
WIRING DRAWING .......................................................................................................................... 38-68
IMSS E3265
-
3
-
INTRODUCTION
Thank you for purchasing a Federal Industries Merchandiser. This manual contains important
instructions for installing and servicing the RSSM, Refrigerated Self-Service Merchandisers. A
repair parts list is also included in the manual. Read all of these documents carefully before
installing or servicing your case.
NOTICE
Read this manual before installing your case. Keep this manual and refer to it before
doing any service on the equipment. Failure to do so could result in personal injury or
damage to the case.
NOTICE
Installation and service of the electrical components in the case must be performed by a
licensed electrician.
The portions of this manual covering components contain technical instructions intended only
for persons qualified to perform electrical work.
DANGER
Improper or faulty hookup of electrical components in the case can result in severe
injury or death.
All electrical wiring hookups must be done in accordance with all applicable local,
regional, or national standards.
NOTE: UNIT MUST BE GROUNDED
REGISTRATION & SERIAL NUMBER
It’s important to keep a record of the model and serial number of your merchandiser for warranty
and part identification. Please write them here for your quick reference.
Register your product online! Visit our website at and register www.federalindustries.com
your product today.
Case Model__________________________ Serial Number______________________
We’re here to provide you with the best possible experience with your new product, however, we
cannot cover everything about your merchandiser in this manual, so if you have any additional
questions or issues, please see the SERVICE INFORMATION PAGE to find who you should
contact.
