Seite 1/18
1/3” CCD Indoor 3-Axis Dual Voltage
True Day/Night IR Dome Camera
Operation Instructions
Model No. ED335
Please read this manual first for correct installation and operation. This manual should be retained for future
reference. The information in this manual was current when published. The manufacturer reserves the right
to revise and improve its products. All specifications are therefore subject to change without notice.
PRECAUTIONS
1. Do not install the camera near electric or magnetic fields.
Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and audio
speakers since the electromagnetic fields generated from these devices may distort the video image.
2. Never disassemble the camera beyond the recommendations in this manual nor introduce
materials other than those recommended herein.
Improper disassembly or introduction of corrosive materials may result in equipment failure or other
damage.
3. Try and avoid facing the camera toward the sun.
In some circumstances, direct sunlight may cause permanent damage to the sensor and/or internal
circuits.
4. Keep the power cord away from water and other liquids and never touch the power cord with
wet hands.
Touching a wet power cord with the hands or touching the power cord with wet hands may result in
electric shock.
5. Never install the camera in areas exposed to water, oil or gas.
Water, oil or gas may result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning
Use a damp soft cloth to remove any dirt from the camera body. Use lens tissue or a cotton tipped
applicator and ethanol to clean the camera lens. Please do not use complex solvents, corrosive or
abrasive agents for cleaning.
7. Do not operate the camera beyond the specified temperature, humidity or power source ratings.
Use the camera at temperatures within 0 ~ 40 (32℃ ℃ ℉ ℉~104 ) and humidity between 20~80%.
The input power source is 12VDC/24VAC.
1
PRODUCT OVERVIEW
ED335 is a new design IR Dome camera from Everfocus. It incorporates breakthrough DSP technology to
provide brilliant color images in well lit environments. Using a SONY Super HAD CCD image sensor, the
ED335 also delivers excellent true day/night low light performance, and equipped with 34 long lifespan/high
illumination IR LEDs the ED335 is able to deliver bright, detailed monochrome images even in low light or no
light situations out to a range of over 66 feet.
In addition, because the ED335 is easily surface or flush mounted, it can be installed in almost any indoor
environment. The 3-axis gimbal enables installers to easily mount the camera on a wall or ceiling and then
using the built in tilt and dual axis 180° twist, adjust the viewing angle and varifocal lens to frame the desired
field of view. With this unique 3-axis positioning system, installers can capture images from virtually any
angle, without compromising performance.
FEATURES
Designed with advanced digital signal processing circuitry for high image quality
520 TV lines of superior high resolution technology
True Day/night with ICR module
Equipped with 34 IR LEDs for day and night environments
IR distance up to 66 feet (20M; depending on surface reflectivity)
May be attached to wall or ceiling; flush or surface mounted
3-Axis adjustment for almost any viewing angle
Built-in vari-focal type, auto Iris lens
12VDC/24VAC Dual Voltage support
High Output IR LEDs, with a lifespan exceeding 20,000 hours
PACKAGE CONTENTS
ED335 camera, including dome/cover, camera unit and outer (surface mount) base as an assembly.
This user guide.
Accessory pack #1 containing:
4 long mounting screws
4 washers
4 plastic anchors
Hex key for cover screws
4 short screws to attach flush-mounting clips
Rubber plug for side hole in outer base.
Mounting template
2
Power supply pigtail
Video test cable
Accessory pack #2 containing two flush mounting clips
DIMENSIONS
