EVERFOCUS
1/3” Color 3-Axis Dome Camera
Operation Instructions
Model No. ECD360AV
Please read this manual first for correct installation and operation. This manual should be retained
for future reference. The information in this manual was current when published. The
manufacturer reserves the right to revise and improve its products. All specifications are therefore
subject to change without notice.
PRECAUTIONS
1. Do not install the camera near electric or magnetic fields.
Install the camera away from TV/radio transmitters, magnets, electric motors, transformers
and audio speakers since the electromagnetic fields generated from these devices may distort
the video image or otherwise interfere with camera operation.
2. Never disassemble the camera beyond the recommendations in this manual nor
introduce materials other than those recommended herein. Improper disassembly or
introduction of corrosive materials may result in equipment failure or other damage.
3. Try to avoid facing the camera toward the sun.
In some circumstances, direct sunlight may cause permanent damage to the sensor and/or
internal circuits, as well as creating unbalanced illumination beyond the capability of the
camera to compensate.
4. Keep the power cord away from water and other liquids and never touch the power
cord with wet hands. Touching a wet power cord with your hands or touching the power
cord with wet hands may result in electric shock.
1
5. Never install the camera in areas exposed to oil, gas or solvents.
Oil, gas or solvents may result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning
For cameras with interchangeable lenses, do not touch the surface of the sensor directly with
the hands. Use lens tissue or a cotton tipped applicator and ethanol to clean the sensor and
the camera lens. Use a damp soft cloth to remove any dirt from the camera body. Please do
not use complex solvents, corrosive or abrasive agents for cleaning of any part of the camera.
7. Do not operate the camera beyond the specified temperature, humidity or power source
ratings. This camera is suitable for indoor operation only. Use the camera at temperatures
within -10ºC ~ +50 ºC (14 ~122 ) and humidity between 20% and 80%. This device is
not rated as submersible. The input power source is 12VDC.
8. Mounting
Use care in selecting a solid mounting surface which will support the weight of the camera
plus any wind, snow, ice or other loading, and securely attach the camera to the mounting
surface using screws and anchors which will properly support the camera. If necessary (e.g.
when mounting to drop ceilings) use a safety wire to provide additional support for the
camera.
Table of Contents
Product Overview………………………………………………………………..1
Main Features……………………………..……………..…….…………………1
Content List……………………………………………………………………… 2
Specifications………………………………………………………….………… 3
Dimensions………………………………………………………………………. 3
Installation……………………………………………………….……………… .4
Product Overview
The EverFocus ECD360AV is an indoor color camera with plastic housing, clear
dome to pass the maximum amount of light, and integral dome liner to conceal the
viewing direction. The 3-axis positioning system allows convenient wall or ceiling
mounting without the need for brackets, and permits the lens to be aligned in
virtually any viewing direction. Equipped with a Sony 1/3” Super HAD high
resolution 540 line sensor and 3.5~8mm varifocal DC iris lens, the field of view can
be readily adjusted to suit the application while the auto iris function adapts to a
wide range of lighting conditions. The camera draws only 150mA from a 12VDC
2
supply; to use this camera with a 24VDC supply system, accessory 24VDC/12VDC
converters are available. With its excellent low light sensitivity of only .12 lux, 3
axis positioning and varifocal lens, the ECD360AV suits a wide variety of indoor
surveillance applications.
FEATURES
Indoor 3-axis color dome camera
SONY 1/3’’ Super HAD CCD sensor
Integral dome liner conceals viewing direction
3-Axis bracket for easy installation.
Built-in Vari-focal DC-drive 3.5~8.5mm auto iris lens
Excellent low light sensitivity of only .12 lux minimum illumination
Employs Digital Signal Processor (DSP) chip-set for image control.
High resolution 540 TV lines
High sensitivity, low smear, high anti-blooming and high S/N ratio.
Built-in functions: Auto Electronic Shutter (AES), Auto Gain Control (AGC), Auto White
Balance (AWB).
Box Contents
Camera
This User Guide
Mounting Screws (4) and hollow wall adapters
Power adapter pigtail
Mounting Template
