ESX SE-52 Bedienungsanleitung
Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für ESX SE-52 (4 Seiten) in der Kategorie Speaker. Dieser Bedienungsanleitung war für 9 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/4
C O A X S P E A K E R S Y S T E M S
S E 4 2 / S E 5 2 / S E 6 2
C O A X / T R I A X S P E A K E R S Y S T E M S
Q X 4 2 / Q X 5 2 / Q X 6 2 / Q X 6 9 3
C O A X C A R F I T S P E A K E R S Y S T E M S
Q X 3 2 / Q X 4 6 2 / Q X 1 2 0 / Q X 6 8 3
CAUTION
Please ensure the correct polarity (+ or -) for all connections.
Never connect loudspeakers directly with the vehicle’s chassis or power supply.
WIRING DIAGRAM AND CONNECTIONS
SPEAKER CONNECTION:
• Connect the Plus-Terminal (marked red) of the Mid-Bass with the Plus-Terminal of the Amplifier.
• Connect the Minus-Terminal of the Mid-Bass with the Minus-Terminal of the Amplifier.
• Repeat the same procedure for the other channel.
PLUS
MINUS
AMPLIFIER / V
L
SPEAKER OUTPUT L
LAUTSPRECHERAUSGAN G L
ACHTUNG
Bitte achten Sie auf die richtige Polarität (+ oder -) bei allen Verbindungen.
Schließen Sie keine Lautsprecher an die Fahrzeugkarosserie bzw. Batterie an.
VERKABELUNG UND ANSCHLÃœSSE
LAUTSPRECHERANSCHLUSS:
• Verbinden Sie den Plus-Anschluss (rot)des Mitteltöners mit dem Plus-Anschluss des Verstärkers.
• Verbinden Sie den Minus-Anschluss des Mitteltöners mit dem Minus-Anschluss des Verstärkers.
• Wiederholen Sie die Prozedur nochmals für den anderen Kanal.
PLUS
MINUS
VERSTÄRKER
R
SPEAKER OUTPUT R
LAUTSPRECHERAUSGANG R
Produktspezifikationen
| Marke: | ESX |
| Kategorie: | Speaker |
| Modell: | SE-52 |
