Seite 1/56

Tumble Dryer



EDS854J3WB

EDS854N3SB

User Manual



2 www.electrolux.com

CONTENTS

1. SAFETY INFORMATION 4 ................

1.1 Conditions Of Use 4 ............................

1.2 Child Safety 5 ......................................

1.3 Dryer Safety......................................5

1.4 Installation 6 ........................................

1.5 Electrical connection.........................6

1.6 Fire Hazards 7 .....................................

2. PRODUCT DESCRIPTION 8 ..................

2.1 Accessories ......................................9

3. CONTROL PANEL 10 ..............................

3.1 Display ............................................11

4. PROGRAM TABLE .............................12

5. OPTIONS AND SETTINGS 13 ................

5.1 Option Table ...................................13

5.2 Dryness Level 14 .................................

5.3 Time Dry .........................................14

5.4 Dry Temp ........................................15

5.5 Delay Start 15 ......................................

5.6 Extra Anticrease .............................15

5.7 Child Lock Function 15 ........................

5.8 Enabling/Disabling End-Of-Dry

Buzzer 16 .............................................

6. DAILY USE 17 .........................................

6.1 Start a program without delay s tart 17 .

6.2 Starting the program with

delay s tart 17 .......................................

6.3 Change a program..........................17

6.4 Interruption of a program 17 ................

6.5 At the end of the program 18 ...............

6.6 Stand-by function............................18

7. DRYING HINTS 19 ..................................

7.1 Preparing the laundry 19 .....................

7.2 Guide 20 ..............................................

8. CARE AND CLEANING 21 ......................

8.1 Cleaning the lint filter 21 ......................

8.2 Cleaning the drum 21 ..........................

8.3 Cleaning the control panel 22 ..............

8.4 Cleaning The Water Inlet Filter 22 .......

9. TROUBLESHOOTING .......................23

9.1 Troubleshooting ..............................23

9.2 If the drying results are not

satisfactory 24 ......................................

10. TECHNICAL DATA ...........................25

11. INSTALLATION 26 .................................

11.1 Unpacking 26 .....................................

11.2 Positioning 26 ....................................

11.3 Machine Leveling 27 ..........................

11.4 Electrical Connection 28 ....................

11.5 Water Connection 28 .........................

12. ENVIRONMENTAL CONCERNS 29 .....

ENGLISH 3

Adherence to the directions for use in this manual is extremely important for health and

safety. Failure to strictly adhere to the requirements in this manual may result in personal

injury, property damage and affect your ability to make a claim under the Electrolux

manufacturer’s warranty provided with your product. Products must be used, installed and

operated in accordance with this manual. You may not be able to claim on the Electrolux

manufacturer’s warranty in the event that your product fault is due to failure to adhere to

this manual.

- Read the supplied instructions.

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings

with it decades of professional experience and innovation. Ingenious and stylish, it

has been designed with you in mind. So whenever you use it, you can be safe in the

knowledge that you’ll get great results every time. Welcome to Electrolux.

We recommend the use of original spare parts.When contacting Service, ensure that

you have the following data available. The information can be found on the rating plate.

Model, PNC, Serial Number.

Subject to change without notice.

Warning / Caution-Safety information.

General information and tips.

Environmental information.

Get usage advice, brochures, trouble shooter, service information, buy

accessories & spare parts, online product registration :

www.electrolux.com

IMPORTANT INFORMATION THAT MAY IMPACT YOUR

MANUFACTURER’S WARRANTY

WE’RE THINKING OF YOU

CUSTOMER CARE AND SERVICE

Visit our website to:

ENGLISH 5

1.2 Child Safety

• This machine is not intended for use by young

children or infirm persons without supervision.

• Young children should be supervised to ensure that

they do not play with the appliance.

• Keep children and pets away from the appliance

when the door is open. Make sure that children or

pets do not climb into the drum.

• The packaging components (e.g. plastic film,

polystyrene) can be dangerous to children - danger of

suffocation! Keep them out of children’s reach.

• If the appliance has a child safety device, it should be

activated.

• Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.3 Dryer Safety

• Failure to follow these safety

instructions could damage the dryer

or your clothes.

You may then not be covered by

warranty for this damage.

• Only plug this appliance directly into

an AC power supply, which is

properly earthed and has the correct

voltage.

• Connect the mains CAUTION:

plug to the mains socket only at the

end of the installation process. Make

sure that the mains plug is accessible

after installation.

See the serial number sticker

located on the bottom of the

door opening for voltage

information.

For safety reasons we strongly

advise against the use of double

adaptor, extension cords or power

boards.

• If the electrical cord of this appliance

is damaged, it must be replaced by

the Manufacturer, Authorised Service

Agent or similarly qualified person in

order to avoid a hazard.

• These dryers are for drying clothes,

towels and linen at home. Do not use

them for any other purpose.

• Lint must not be allowed to

accumulate around the tumble dryer.

• Do not dry unwashed items in the

tumble dryer.

• Never stop a tumble dryer before the

end of the drying cycle unless all

items are quickly removed and

spread out so that the heat is

dissipated.

6 www.electrolux.com

• The appliance must not be supplied

through an external switching device,

such as a timer, or connected to a

circuit that is regularly switched on

and off by a utility.

• This appliance is for household use

only.

• Do not dry damaged (torn, frayed)

items that contain padding or fillings.

• If laundry has been washed with a

stain remover, carry out an additional

rinse cycle before starting a drying

cycle.

• Dry only fabrics that are suitable to

dry in the appliance. Follow the

cleaning instruction on the item label.

• Do not sit or stand on the open door

of the appliance.

• Do not dry dripping wet clothes in the

appliance.

• Do not exceed the maximum load of

maximum capacity of your dryer

(refer to the “Program chart” chapter).

• CAUTION: Do not run the

appliance without a filter. Clean

the lint filter before or after each

use. (refer to the “Care and

Cleaning” chapter)

1.4 Installation

1.5 Electrical connection

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Follow the installation instructions

supplied with the appliance.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use the appliance

where the temperature can be lower

than 5°C or higher than 35°C.

• The floor area on which the appliance

is to be installed must be flat, stable,

heat resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• Always keep the appliance vertical

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• The appliance must be earthed.

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

WARNING!

Risk of fire and electric shock.

when it is being moved.

• The rear surface of the appliance

must be put against a wall.

• When the appliance is in its

permanent position, check if it is

levelled correctly with the aid of a

spirit level. If it is not, adjust the feet

accordingly.

8 www.electrolux.com

Work top

Lint filter

Control panel

Appliance door

Front feet

Drum lifter

Nozzle

Exhaust grille

Air inlet duct

Outlet cover

Back feet

2. PRODUCT DESCRIPTION

1 1

ENGLISH 11

3.1 Display

Symbol on the display Symbol description

Digital Number; will show:

• Drying cycle time.

• Delay start time.

• The alarm codes. Refer to the chapter

“Troubleshooting” for their description.

Delay start option on.

Indicator: clean filter

The Clean Filter indicator turns on and blinks at

the end of each dry cycle to serve as a reminder

to user to clean lint filter at the end of each load.

Indicator: drying phase

Indicator: cooling phase

After the drying process finish, Cooling process

will operate and switch off heater. The Cooling

indicator blink until finish cooling process. This

process will release heat from the clothes and

crease protection.

Indicator: anticrease phase

The anticrease cycle is designed to help prevent

creases forming in the clothes after program

drying cycle has ended.

The anticrease progress indicator will start

blinking with clean filter during the time anti

crease phase is running. The drum will rotate for

5 seconds every minute and will go for 1 hour.

NOTE

Anticrease phase CANNOT BE DISABLED.

NOTE

Anticrease can be stopped at any time by

opening the door and removing the clothes

or press Start/Pause button.

Extra anticrease on.

12 www.electrolux.com

4. PROGRAM TABLE

Program Load 1) Fabric type

Off -This position to reset program/switching off the

machine.

Cottons Ideal for towels or similar such as cotton and Max.

linen.

Mixed Select this cycle to dry everyday fabrics including Half

cottons, linens and sheets.

Delicates For drying delicate clothing and Synthetics.3.5 kg

Bedding For Bedding clothing.Half

Vapour

Refresh

3-5 pcs (dry

items)

Quickly refresh fabrics that have been in storage

for long time and also smooth out creases.

Energy Saver Cycle to be used to dry cotton with “cotton extra” Max.

dryness level, with maximum energy saving.

Hygienic

Care 2) 4 kg This program appropriate for dry white cotton

cloth or light colored cotton cloth such diaper,

baby clothes that made from cotton fabric to

remove up to 99% of germs.

Denim Leisure clothing such as jeans, sweat-shirts of 4 kg

different material thicknesses (e.g. at the neck,

cuffs, and seams).

Wool Woollen fabrics. Gentle drying for hand-wash-able 1 kg

woolens. Remove items immediately when the

program is completed.

Shirts Easy care fabrics for which a minimum of ironing 3.5 kg

is necessary. The drying results can be different

from one type of fabric to the other. Shake the

items before you put them in the appliance.

When the program is completed, Immediately

remove the items and put them on a hanger.

Synthetics Synthetic and mixed fabrics.3.5 kg

Fast 40 Select this cycle to dry everyday fabrics, cotton or 1 kg

blended fabrics that need to be dried quickly.

1) Maximum capacity depends on the model.

2) Don’t use this program for Synthetic fabric, Sport Fabric, Wool fabric, Colored

fabric, or Other fabric that make from Polyester fiber.

ENGLISH 13

5. OPTIONS AND SETTINGS

5.1 Option Table

1. Program with Dryness Level Option Selected

2. Program with Time Dry Option Selected

1. Select Dryness Level option,

then

2. Select Dry Temp

1. Select Time Dry (mins.) option,

then

2. Select Dry Temp

Program

Dryness Level Dry Temp Delay start

Boost Low Airing

Off

Cottons ■ ■ ■ ■ ■ ■

Mixed ■ ■ ■ ■ ■ ■

Delicates ■ ■ ■ ■ ■

Bedding ■ ■ ■ ■ ■ ■

Vapour Refresh ■ ■

Energy Saver ■ ■ ■

Hygienic Care ■ ■ ■

Denim ■ ■ ■ ■

Wool ■ ■ ■

Shirts ■ ■ ■ ■ ■

Synthetics ■ ■ ■ ■ ■ ■

Fast 40 ■ ■ ■

1 2

14 www.electrolux.com

Level of

dryness

Type of fabric Load

Iron Dry

Suitable

for ironing

Cotton and linen

(sheets,

tablecloths,

shirts, etc.)

up to

Max.1)

1) Maximum capacity depended on

model of Dryer

NOTE

Dryness level settings are based

on the program selected.

5.3 Time Dry

You can set the program duration of 15,

20, 30, 60, 90 and 120 minutes.The

required duration is related to the

quantity of laundry in the appliance.

NOTE

We recommend that you set a

short duration for small quantities

of laundry or for only one item.

5.2 Dryness Level

This function helps to increase dryness

of the laundry.

There are 3 options:

• Extra dry

• Cupboard dry

• Iron dry

Dryness Option Guidelines:

Level of

dryness

Type of fabric Load

Extra Dry

Ideal for

towels or

similar

Cotton and linen

(bathrobes, bath

towels, etc)

up to

Max.1)

Cupboard

Dry

Suitable

for items

to put

away

without

ironing

Cotton and linen

(towels,T-shirts,

underwear, etc)

up to

Max.1)

Synthetics and

mixed fabrics

(jumpers,

blouses,

underwear,

household linen)

up to

3 kg

Program Time Dry (mins.) Dry Temp Delay

start

120 90 60 30 20 15 Boost Low Airing

Off

Cottons ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

Mixed ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

Delicates

Bedding

Vapour Refresh

Energy Saver

Hygienic Care

Denim

Wool

Shirts

Synthetics ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

Fast 40

ENGLISH 15

Dry Time Option Guidelines:

Type of

fabric

Load Suggested

Times

Cotton and

linen

(bathrobes,

bath

towels,

etc.).

5 kg to

Max.1) 120 mins

3 kg to

5 kg

60 mins to

90 mins

1 kg to

3 kg

30 mins to

60 mins

1 pcs to

1 kg

15 mins to

30 mins

Synthetic

or mixed

fabric items

(jumpers,

blouses,

underwear,

household

linen, etc.).

Half 30 mins to

60 mins

1 kg 15 mins to

20 mins

Wool and

hand

washable

wool.

1 kg 15 mins to

30 mins

1) Maximum capacity depended on

model of Dryer

5.4 Dry Temp

This function gives you the option of

selecting different drying levels.

There are 3 levels:

• Boost

For drying most fabrics.

• Low

For drying delicates and synthetics at

lower heat for maximum care of the

fabrics. The Low Heat setting will

cause the heater to cycle on for

shorter time than the Boost setting.

• Airing

This setting does not heat.

ONLY circulate the air in the dryer to

shake out dust and refresh clothes

and only available in Time Dry option.

5.5 Delay Start

This option makes it possible to delay

the start of the program by 30 min, 60

min or 90 min and then by every hour

from 2 to 20 hours. The delay you have

selected is indicated on the display. The

end time will increase in order to show

you the selected delay.

You must select this option after you

have set the program and before you

press the Start/Pause button.

If you wish to add laundry in the

machine during the delay time, press

Start/Pause touchpad to put the

machine in pause mode. Add laundry,

close the door and press Start/Pause

touchpad again.

You can cancel or change the delay

time at any moment, by pressing Start/

Pause touchpad then press “Delay

Start” touchpad once, time will reset to

“0”, now you can change the time or

cancel it, press the Start/Pause

touchpad again to continue operating

the machine.

5.6 Extra Anticrease

This option extends the anti-crease

phase by 2 hours at the end of the

drying cycle. This function reduces

creases. The laundry can be removed

during the anti-crease phase.

The display will shows “ ” when

this option is selected.

5.7 Child Lock Function

This option prevents children playing

with the appliance while a program is

operating. The touch buttons are locked.

• To activate the function, press and

hold “ Extra Anticrease” touchpads

about 2 seconds until the display

shows the icon “ ”.

If you press any touchpad while

Child Lock is activated, the icon

“ ” will flash on display 3 times

along with buzzer sound.

16 www.electrolux.com

5.8 Enabling/Disabling End-Of-

Dry Buzzer

This setting permits you to either enable

or disable the buzzer at the end of the

program. As an example, you might

wish to disable this buzzer when you

start a drying when going to bed, so that

when the cycle finished it will not disturb

you through the night.

Error warning beeps such as

critical faults are not disabled.

• To disable the buzzer sound, press

“Dryness Level” and “Time Dry”

touchpads at the same time for 3

seconds, the display will show “bOF”

with the “BEEP, BEEP” sound.

• To return to default c onfiguration

press these 2 touchpads at the same

time for 3 seconds, the display will

show “bOn” with the “BIP” sound.

20 www.electrolux.com

To help you, here is a list of the average

weights of some common laundry items.

Sheet 700g - 1000g

Tablecloth 400g - 500g

Kitchen towel 70g - 120g

Table napkin 50g - 100g

Towelling hand towel 150g - 250g

Bathrobe 1000g - 1500g

Men’s shirt 200g - 300g

Pillowcase 100g - 200g

Men’s pyjamas 400g - 500g

Ladies nightdress 200g 250g

Bath towel 300g - 400g

7.2 Guide

Always check your labels for the drying

symbol which this international Care

Labelling Code now uses.

Fabric label Description

Laundry is suitable for

tumble drying.

Laundry is suitable for

tumble drying at higher

temperatures.

Laundry is suitable for

tumble drying at low

temperatures only.

Laundry is not suitable

for tumble drying.

• Permanent press and synhetics

- take out as soon as the dryer stops

to reduce wrinkles.

• Woollen articles - not recommended.

Pull them to their original shape, then

dry them flat.

• Woven and loop knit materials

- may shrink, by varying amount,

depending on their quality. Do not use

the “Extra Dry” setting for these

fabrics, Always stretch them out

immediately after drying.

• Fibre or leather materials - always

check the manufacturer’s instructions.

• Baby clothes and night gowns

- acrylic clothing or sleepwear use

only on the “Iron Dry” setting.

• Rubber and plastics - Do not dry any

items made from or containing rubber

or plastics, such as aprons, bibs,

babies’ water proof napkins, curtains,

tablecloths, shower caps, clothes

fitted with foam rubber pads, pillows,

galoshes, or rubber coated tennis

shoes.

• Fibreglass - not recommended, glass

particles left in the dryer could be

picked up by your clothes the next

time you use the dryer and irritate

your skin.

• Fabric softeners or similar products

should not be used in a tumble dryer

to eliminate the effects of static

electricity unless this practise is

specifically recommended by the

manufacturer of the fabric softener or

product.

Note:

We strongly advise against the use

of fabric conditioners of the sheet

type that are added to the clothes in

the drum. These products may lead

to rapid blockage of the lint filter and

inefficient operation of your dryer.

ENGLISH 21

8. CARE AND CLEANING

A clean lint filter reduces drying

times, saves energy and avoids

overheating. Overheating may

also damage your clothes.

What happens If I forget to clean the

lint filter?

If necessary remove fluff from

the filter socket and gasket. You

can use a vacuum cleaner.

Number of usages with

an unclean lint filter

(based on laboratory tests

using a load of new

towels)

tripled

doubled

normal

8.1 Cleaning the lint filter

8.2 Cleaning the drum

WARNING!

Disconnect the appliance before you

clean it.

Use a standard neutral soap detergent

to clean the inner surface of the drum

and drum lifters. Dry the cleaned

surfaces with a soft cloth.

CAUTION!

Do not use abrasive materials or

steel wool to clean the drum.

LINT BUILD-UP IS A FIRE

HAZARD

Cleaning the filter

22 www.electrolux.com

8.3 Cleaning the control panel

Use a standard neutral soap detergent

to clean the control panel.

Use a moist cloth to clean. Dry the

cleaned surfaces with a soft cloth.

CAUTION!

Do not use furniture cleaning agents

or cleaning agents which can cause

corrosion.

8.4 Cleaning The Water Inlet

Filter

If your water is very hard or contains

traces of lime deposit, the water inlet

filter may become clogged.

It is therefore a good idea to clean it

from time to time.

To clean the water inlet filters:

1. Close the water tap.

2. Remove the water inlet hose from

the water tap.

3. Clean the filter in the inlet hose with

a stiff brush.

4. Remove the inlet hose behind the

appliance.

5. Clean the filter in the valve with a

stiff brush or a towel.

6. Re-install the inlet hose. Make sure

that the couplings are tight to

prevent leakages.

7. Open the water tap.

ENGLISH 23

9. TROUBLESHOOTING

Problem Possible solution

You cannot activate the

appliance.

Make sure that the mains plug is connected to

the mains socket.

Check fuse in fuse box (domestic installation).

The program does not start. Press Start/Pause.

Make sure that the appliance door is closed.

The appliance door does not

close.

Make sure that the installation of the filter is

correct.

Make sure that the laundry is not caught

between the appliance door and the rubber seal.

The appliance stops during

operation.

Load is too small, increase the load or use the

Time Drying program.

The cycle time is too long or

unsatisfactory drying result.

Make sure that the weight of the laundry is

suitable for the duration of the program.

Make sure that the filter is clean.

The laundry is too wet. Spin the laundry in the

washing machine again.

Ensure that the room temperature is higher than

+5°C and lower than +35°C. Optimal room

temperature is 19°C to 24°C.

Set the Time Drying or the Extra Dry program. (It

can happen that some area remains humid when

drying big items (e.g. bed sheets ))

The display shows “ ”.

If you want to set a new program, deactivate and

activate the appliance.

Make sure that the options are suitable for the

program.

The display shows Error code.

Alarm Code:

The appliance door is open or not

closed correctly. Please check the

door!

The main supply is unstable. Wait

until the main supply is stable.

No communication between

electronic elements of the appli-

ance. Switch off and switch on

again.

Isolated wet spots on fabrics

after “Vapour Refresh” cycle

completed.

Water pressure too low - please check that the

water pressure is between 200 kPa and 800

kPa.

9.1 Troubleshooting

24 www.electrolux.com

9.2 If the drying results are not

satisfactory

• The set program was incorrect.

• The filter is clogged.

• There was too much laundry in the

appliance.

• The drum is dirty.

• Room temperature is too low or too

high ( optimal room temperature 19°C

to 24°C )

• You have used wet clothes with

“Vapour Refresh” program.

The “Vapour Refresh” program

reduces wrinkle on dry

laundry only. It is not a drying

program.

Problem Possible solution

No water goes out from Nozzle,

when “Vapour Refresh” cycle is

selected.

The water tap is closed, please open the water

tap.

The inlet hose is squashed or kinked, please

check inlet hose connection.

The filter in the inlet hose is blocked, please

clean the inlet hose filter. Refer to relevant

paragraph in “ Care And Cleaning” section.

The Nozzle is clogged, please contact the

Service Centre.

Contact the Service Centre if you are still having

problems.

Clothes are slightly damp after

using “Vapour Refresh” cycle.

This is Normal. Vapour Refresh uses moisture to

reduce the wrinkle on fabrics. It is recommended

to hang clothes after using this cycle.

If your laundry feels wet rather than slightly

damp, then the household water pressure is too

high. You may need to reduce pressure by

installing a pressure reducing valve at mains

water connection to the household. This must be

done by qualified plumber.

Note: High water pressure is harmful to all

appliances in your household that are connected

to the water supply ie: washing machine,

dishwasher... etc.

ENGLISH 25

10. TECHNICAL DATA

Dimensions (Height / Width / Depth) 795 mm x 600 mm x 560 mm

Power Supply (Voltage / Frequency) 220 - 240 V / 50 Hz

Heater Power (Watt) 2100 W

Drum Volume 102 litres

Maximum Capacity Max.1) kg

Type of use Household

Water Pressure 200 kPa - 800 kPa.

Level of protection against ingress of solid

particles and moisture ensured by the protective

cover, except where the low voltage equipment

has no protection against moisture

IPX4

1) Maximum capacity depended on model of Dryer

26 www.electrolux.com

11. INSTALLATION

11.1 Unpacking

1. Use gloves. Cut and remove four

cut out straps as shown.

2. Remove the carton box. Remove

the polystyrene packaging

materials. Remove the plastic bag

which cover the machine.

3. Open the door. Remove all the

items from the drum.

4. Put one of the polystyrene

packaging elements on the floor

behind the appliance. Carefully put

down the appliance with the rear

side on it.

5. Remove the polystyrene base.

6. Pull up the appliance in vertical

position.

11.2 Positioning

You can choose to put your dryer :

• on the floor

• on a work bench upside down or

upright.

• on a wall.

The appliance must not be installed

behind a lockable door, a sliding door or

a door with a hinge on the opposite side

to that of the tumble dryer in such away

that a full opening of the restricted.

The exhaust grille has a range of

positions, which allows you to select the

optimum exhaust air angle. Simply hold

the grille and rotate it until it hits the

built-in stop. Do not install your dryer in a

cupboard or small un-vented laundry

unless you are using a venting kit.

There are 2 venting options

• Front

• Rear - using a included kit

Important: Use only kits approved by

Electrolux with your dryer.

The exhaust duct must not exceed 2

ENGLISH 27

metres in length at 100mm diameter.

If connecting the dryer to a common

ducting system, safety advice should be

requested from the manufacturer.

If you choose to use included kit, the

exhaust grille at the front of the dryer will

need to be replaced with the outlet cover

from the back of the dryer. Gently prise

open the grille, using a thin bladed tool.

Next, remove the cover from the back

and clip it into the grille space at the

front.

The exhaust grille is not required when

using a vent kit.

You can position the vent kit at the back

of the dryer to remove air upwards or

sideways.

Inlet and outlet points need clear airflow

to prevent overheating, so ensure there

is adequate ventilation. (i.e. open

window or external door.)

If a venting kit is used and the exhaust is

discharged out of the room, there must

be adequate ventilation to avoid the

back flow of gases in to the room from

appliances burning other fuels, including

open fires, when operating the tumble

dryer. This is not applicable where a

venting hose is directed to an open

window.

The exhaust air must not be discharged

into a flue which is used for exhausting

fumes from appliances burning gas or

other fuels.

11.3 Machine Leveling

It is important that your Dryer stands

firm and leveled on the floor to ensure

correct operation. The appliance must

not be installed behind a lockable door,

a sliding door or a door with a hinge on

the opposite side to avoid restricting the

Dryer door.

Use a spirit level on the top and side of

the Dryer to check the levels.

If you do not have a spirit level, as a

guide use the edge of a door frame,

cupboard or bench to check that the

Dryer is leveled.

Never place cardboard, wood or similar

materials under the machine to

compensate for any unevenness in the

floor. Install the machine on a flat hard

floor. Make sure that air circulation

around the machine is not impeded by

carpets, rugs etc.

Check that the machine does not touch

the wall or cupboard units.

air flow

28 www.electrolux.com

11.4 Electrical Connection

This machine is designed to operate on

a 220-240 V, single-phase, 50 Hz

supply.

“An incorrect power supply may void

your warranty.”

Check that your domestic electrical

installation can take the maximum load

required, also taking into account any

other appliances in use.

CAUTION!

Connect the machine to an earthed

socket outlet.

CAUTION!

The manufacturer declines any

responsibility for damage or injury

through failure to comply with the

above safety precaution.

CAUTION!

Should the appliance power supply

cable need to be replaced, this shall

be carried out by our Service Centre.

When the appliance is installed, the

power supply cable must be easily

accessible.

11.5 Water Connection

Water tap must be installed within 110cm

of your dryer’s water inlet and the tap

must be 3/4 inch BSP thread for laundry

hose connection. Water pressure must be

between 200kpa to 800kpa.

Use the hose supplied with the dryer. DO

NOT USE OLD HOSES.

To connect the water inlet to dryer:

1. Turn off water supply to washer.

2. Remove inlet hose from water

supply.

3. Turn on water supply for a short

time to run some water into a

bucket or container to clear any

contaminants in the line.

4. Connect the Y-Connector to the

water tap.

water tap

Check

rubber seal,

replace if

worn.

Check

rubber seal

ENGLISH 29

12. ENVIRONMENTAL CONCERNS

Recycle materials with the symbol .

Put the packaging in relevant containers

to recycle it. Help protect the environ-

ment and human health by recycling

waste of electrical and electronic

appliances.

Do not dispose of appliances marked

with the symbol with the household

waste.

Return the product to your local

recycling facility or contact your

municipal office.

5. Connect the inlet hose for the

washer and the dryer to the

Y-Connector and tighten them.

Water Tap

To Washing

Machine

6. Turn on the water tap and check for

leaks at all connection.

30 www.electrolux.com



1.  

 ................................... 32

 ..................... 33

 .............. 33

................................................ 34

 ......................... 34

 ............................ 35

 

 .......................................... 37

 

 ............................................. 39

 

 

 ........................................ 41

....................................... 42

 ................................ 42

 .................................. 43

 ............................... 43

 ......................... 43

 .......................... 43



  ........................... 44

 



  .......................... 45

 ..... 45

 ..................................... 45



  .................................................. 45

 ........................ 46

 ................................ 46

 

 .................................... 47

 ............................................... 48

 

 ......... 49

 ....................... 49

 .............. 50

 .... 50

 

 .......................................... 51



  ............................................. 52

 

 

 .............................. 53

 ...................... 53

 .................. 54

 ....................... 54

 ............................ 55

 

 31





































www.electrolux.co.th









32 www.electrolux.com

1. ้อูล้านควาปลอัย

1.1 เงื�อนไการใ้งาน





• 

• 

• 

• 

• 























 33



• 



• 

• 



• 





• 



• 



• 









• 





• 



















• 







• 







• 

• 



• 







34 www.electrolux.com

• 





• 



• 





• 





• 







• 

• 



• 





• 













• 

• 



• 



• 







• 







• 

• 





• 



• 



• 



• 









• 

 

35

• 



• 



• 



• 



• 







 35













• 





• 











• 







• 

















































• 



















36 www.electrolux.com























2. ส่วนประกอองผลิตัณ์

าษาไย 37

2.1 อุปกรณ์เสริ

ุอุปกรณ์ระายควาร้อนเครื�องอผ้า:

ออกแบบาสาาหับเค่�องอบ้าี�วางิดกับนังด้านนอกโดยง

38 www.electrolux.com

 



























3. แผงควคุการาางาน

1 3 4 5 6

8 7

 39



 



• 

• 

• 

















































40 www.electrolux.com





 1) 

 -

 



 



 

 



 

 



 



  





 



 



  









 

 



1)





42 www.electrolux.com



  





















1)

1)



























• 

• 

• 





  























1)





















1)



















  



     15  

 



 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

















 ■ ■ ■ ■ ■ ■ ■ ■ ■ ■



 43



  













1)







































 



 









 



1)







• 

• 

• 

• 











• 

• 



































































 











44 www.electrolux.com





















• 









• 





 



 





 45







1. 





























2. 



3. 

















4. 













1. 



2. 





3. 













1. 



2. 









1. 





2. 















46 www.electrolux.com







• 

• 

• 

•  

•  

• 





























• 



• 



Produktspezifikationen

Marke:	Electrolux
Kategorie:	Trockner
Modell:	EDS854N3SB

Brauchst du Hilfe?

Wenn Sie Hilfe mit Electrolux EDS854N3SB benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Trockner Electrolux

Electrolux TE1120P Bedienungsanleitung

15 Juni 2024

Electrolux EDV505 Bedienungsanleitung

8 Juni 2024

Electrolux EDC 510E Bedienungsanleitung

8 Juni 2024

Electrolux EDV605S Bedienungsanleitung

8 Juni 2024

Electrolux EDE605A Bedienungsanleitung

8 Juni 2024

Electrolux EDV605 Bedienungsanleitung

8 Juni 2024

Electrolux EDC 67550 Bedienungsanleitung

2 Juni 2024

Electrolux EW8HL92B4 Bedienungsanleitung

24 Mai 2024

Electrolux TWGL3E501 Bedienungsanleitung

17 Mai 2024

Electrolux EW8H259ST Bedienungsanleitung

15 Mai 2024

Bedienungsanleitung Trockner

Neueste Bedienungsanleitung für -Kategorien-

BEKO BM3T3933A Bedienungsanleitung

4 Dezember 2024

BEKO BM3T31023W Bedienungsanleitung

4 Dezember 2024

BEKO B5T68243WSPB Bedienungsanleitung

4 Dezember 2024

BEKO DS8412WPB Bedienungsanleitung

4 Dezember 2024

Hotpoint EU NTDG92 SK IT Bedienungsanleitung

3 Dezember 2024

Hotpoint NT M11 92WK IT Bedienungsanleitung

3 Dezember 2024

Hotpoint NT M11 8X3SKY IT Bedienungsanleitung

3 Dezember 2024

Hotpoint NTS M11 9X3E IT Bedienungsanleitung

3 Dezember 2024

Hotpoint NT M11 82K IT Bedienungsanleitung

3 Dezember 2024

Hotpoint NT M11 9X3SKY IT Bedienungsanleitung

3 Dezember 2024
