Digital Watchdog Überwachungskamera MegaPix IVA+ DWC-MV82WIATW

Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Digital Watchdog MegaPix IVA+ DWC-MV82WIATW (2 Seiten) in der Kategorie Überwachungskamera. Dieser Bedienungsanleitung war für 6 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Seite 1/2
MEGApix® IVA+™ models 5MP models 2.1MP models
DWC-MPV85WiATW DWC-MV85WiAT DWC-MV82WiAT
DWC-MPV82WiATW DWC-MV85WiATW DWC-MV82WiATW
DWC-MV82DiVT
Resetting the camera: To reset the
camera, use the tip of a paper clip
or a pencil and press the reset
button. Pressing the button for
five (5) seconds will initiate a
camera-wide reset of all the
settings, including network settings.
Quick Start Guide Quick Start Guide
a
b
c
1. The mounting surface must withstandve times the camera weight.
2. Do not let the cables get caught in improper places or the electric line
cover can be damaged. This may cause a short orre.
3. CAUTION: These servicing instructions are for use by qualified service
personnel only. To reduce the risk of electric shock do not perform any
servicing other than that contained in the operating instructions unless
you are qualified to do so.
4. CAUTION: There is a risk of explosion if the battery is replaced
incorrectly and it should be replaced only with the same battery.
ATTENTION: Il y a risque d’explosion si la batterie est remplae par
une batterie de type incorrect. Mettre au rebut les batteries usages
conformément aux instructions.
5. Used batteries must be disposed of according to local regulations or
the battery manufacturer’s instructions. Disposing of batteries in a re
or in a hot oven, or mechanically crushing and cutting them may cause
an explosion.
6. Leaving the battery in very high temperature or low air pressure
environments may result in an explosion or leak of ammable liquids
or gases.
7. This product is intended to be supplied by a UL Listed Power
Supply Unit marked “Class 2” or “LPS” or PS2 and rated 12
Vdc, 0.62A (DWC-MPV85WiAT and DWC-MV85WiAT), 0.54A
(DWC-MPV82WiAT and DWC-MV82WiAT) and 0.36A
(DWC-MV82DiVT) min.
8. The wired LAN hub providing power over the Ethernet (PoE) in
accordance with IEEE 802-3af shall be a UL Listed device with the
output evaluated as a Limited Power Source as dened in UL60950-1 or
PS2 as dened in UL62368-1.
9. Unit is intended for installation in a Network Environment 0 as defined
in IEC TR 62102. As such, associated
Ethernet wiring shall be limited to inside
the building.
10. For the installation process, remove the
dome cover from the camera module
by loosening the three (3) screws on
the dome. Use the wrench provided
with the camera.
11. Install the moisture packet in the
base of the camera’s lens.
Remove the moisture absorber
from the packaging.
Cut the card and folder along the dotted line.
Place the moisture absorber behind the
camera’s lens module.
12. Remove the protectivelm between
the dome and the camera module.
13. Remove the screw hole caps as shown
in the image below. If you are mounting
the camera using the mounting plate, do
not remove these screws.
14. Using the mounting template sheet or the
camera itself, mark and drill the
necessary holes in the wall or ceiling.
Pass the wires through and make all the necessary connections.
1. NETWORK CONNECTIONS If you are using a PoE Switch, connect
the camera using an Ethernet cable for both data and power.
2. NETWORK CONNECTIONS – If you are using a non-PoE switch,
connect the camera to the switch using an Ethernet cable for data
transmission and use a power adapter to power the camera.
STEP 1 PREPARING TO MOUNT THE CAMERA
STEP 3 INSTALLING THE CAMERA
STEP 2 POWERING THE CAMERA
1. Attach the camera to the mounting surface.
2. For soft installation surfaces, use the included metal mount plate. Fix
the mount plate on the mounting surface using the included screws.
Then, press the bottom case onto the mount plate. The three bezels on
the case will align and snap lock onto the plate.
3. To use the camera’s waterproof wiring:
a. Install the LAN cable into .
b. will be assembled
to with a 1/4 turn.
c. Thread tightly to .
4. Once the installation is complete,
remove the protective film from
the camera’s dome cover.
5. Assemble the dome cover over the
camera body and detach the protectinglm from the dome bubble.
a
a
b
bc
NOTE: To ensure moisture seal, make sure the o-ring is in place
between and . In extreme environments use of an
outdoor rated sealer is recommended.
ab
NOTE: When using the waterproof cap, crimp the RJ45
connector after passing the cable through the
waterproof cap.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours:
9:00 AM 8:00 PM EST, Monday through Friday
digital-watchdog.com
Attention: This document is intended to serve as a quick reference for the
initial setup. It is recommended that the user read the entire instruction manual
for complete and proper installation and usage.
NOTE: Download all your support materials and tools in one place
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the
search bar. Results for applicable Search by Product’
part numbers will populate automatically based on the
part number you enter.
3. Click . All supported materials, including manuals ‘Search’
and quick start guide (QSGs) will appear in the results.
WHAT’S IN THE BOX
Mounting
Bolts and
Nuts
1 set
Mounting
Template for
Metal Plate
Installation
1
Metal
Mounting
Plate
1
Quick Setup
and
Installation
Guides
1 set
Star Wrench 1
Moisture
Absorber
and Absorber
Guide
1 set
Screws and
Plastic
Anchors-
3pcs
1 set
Waterproof
Cap and
Gasket
1 set
Mounting
Template a
Bolt and Nut
Installation
1
Test Video
Cable
DWC-MV85WiAT,
DWC-MV82WiAT
only
1
Protec�on
Film
Mounting Template
Default Login Information: admin | admin
When logging into the camera for the first time, you will be prompted
to set up a new password. You can set the new password using the
DW® IP Finder™ software or directly from the camera’s browser menu.
Models Power requirements Power consumption
DWC-MPV85WiATW
DWC-MV85WiATW
DWC-MV85WiAT
DC 12V, PoE IEEE 802.3af
Class 3.
(Adapter not included)
DC12V: max7.4W
PoE: max8.7W
DWC-MPV82WiATW
DWC-MV82WiATW
DWC-MV82WiAT
DC12V: max 6.5W
PoE: max 8.5W
DWC-MV82DiVT DC12V: max 4.3W
PoE: max 6.2W
Ethernet
Cable
1
Power
Ethernet
Cable
2
Rev: 01/21
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
STEP 3 INSTALLING THE CAMERA (CONT.)
Installation using Mount Bolt and Screws:
1. Using the mounting template, mark and drill the holes on the mounting
surface.
2. Secure the two long mounting screws to the camera’s base.
3. Pass the wires through the mount bracket and make all
necessary connections.
4. Mount the camera to the mounting surface by using the 2 mounting
nuts. Rotate the locking discs over the screws until the camera is held
tightly from the mounting surface.
WARNING DO NOT TOUCH THE SURFACE OF THE
BUBBLE. CleanView Hydrophobic Dome
Coating has been applied to the camera’s dome.
Quick Start Guide
STEP 4 CABLING
STEP 5 MANAGING THE SD CARD
N.C
Activation
Activation
N.O In 1
COM
In 1
COM
In 1
COM
In 1
COM
3Audio In
6Alarm
In
4Audio Out
5Alarm Out
2Network
1Power
The following models include a local SD card slot:
DWC-MV85WiAT, DWC-MV82WiAT
1. To install the camera’s SD Card, locate the SD card
slot in the back of the camera module.
2. Insert a class 10 SD card into the SD card slot by
pressing the SD card slot.
3. To remove the SD Card, press the card inward to
release from the card slot.
DI (+)
DI ( - )
DO ( - )
DO (+)
WHITE
YELLOW
SKY BLUE
GRAY + DOT
STEP 6 D IP FINDER
Thumbnail view
Firmware version
DHCP status
Camera’s uptime
Open IP configuration
settings
Ping camera
Port information
Gateway address
Netmask address
Camera’s MAC address
Filter results
Scan network
Select network to scan
Show/hide thumbnail view
Refresh thumbnail view
Bulk password assignment
Bulk IP assignment
Firmware upgrade
Camera’s name
Camera’s IP address
Part number
Use the DW IP Finder software to scan the network and detect all MEGApicameras, set the camera’s network settings or access the camera’s web client.
Network Setup
1. To install the DW IP Finder, go to
http://www.digital-watchdog.com
2. Enter “DW IP Finder” on the search box at the top of the page.
3. Go to the “Software” tab on the DW IP Finder page to download
the installation file.
4. Follow the installation to install the DW IP Finder. Open the
DW IP Finder and click ‘Scan Devices’. It will scan the selected
network for all supported devices and list the results in the
table. During the scan, the DW® logo will turn gray.
Port forwarding’ has to be set in your
network’s router for external access
to the camera.
Select DHCP to allow the camera to receive its IP address
automatically from the DHCP server.
Select “Static” to manually enter the camera’s IP address, (Sub)
Netmask, Gateway and DNS information.
* The cameras IP must be set to Static if connecting to
Spectrum® IPVMS
Contact your network administrator for more information.
Default TCP/IP information: DHCP
5. When connecting to the camera for the first time, a password
must be set. To set up a password for your new camera:
a. Check the box next to your new camera from the IP Finder’s
search results. You can select multiple cameras.
b. Click “Bulk Password Assign” on the left.
c. In the pop-up window, enter admin/
admin in the current username and
password fields. Enter a new
username and password to the right.
d. Press “change” to apply all changes.
6. Select a camera from the list by
double-clicking on the camera’s image
or clicking on the ‘Click’ button under
the IP Conf. column. The pop-up
window will show the camera’s current
network settings, allowing admin users
to adjust the settings as needed.
7. To access the cameras web page, go
to the IP Config page and click on the
‘View Camera Website’.
8. To save the changes made to the
camera’s setting, input the username
and password of the camera and
click Apply.
The following models include I/O and audio inputs and outputs:
DWC-MPV85WiAT, DWC-MV85WiAT, DWC-MPV82WiAT and
DWC-MV82WiAT
STEP 7 WEB VIEWER
The GUI display may dier by camera models.
NOTE: Some menu options may not be available based on the
camera model. See the full manual for more information.
NOTE: 32bit version of the VLC player must be installed. If you are
using a 64bit system, uninstall the previous 64bit version
and reinstall using the 32bit version.
Once the camera’s network settings have been setup properly, you can
access the camera’s web viewer using the DW IP Finder.
To open the camera’s web viewer:
1. Find the camera using the DW IP Finder.
2. Double-click on the camera’s view in the results table.
3. Press the View Camera Website. The camera’s web viewer will
open up in your default web browser.
4. Enter the cameras username and password you setup in the DW IP
Finder. If you did not setup a new username and password via the
DW IP Finder, you will not be able to view video from the camera.
A message will direct you to setup a new password for the camera
to view video.
5. When accessing the camera for the rst time, install the VLC player
for web les to view video from the camera.


Produktspezifikationen

Marke: Digital Watchdog
Kategorie: Überwachungskamera
Modell: MegaPix IVA+ DWC-MV82WIATW

Brauchst du Hilfe?

Wenn Sie Hilfe mit Digital Watchdog MegaPix IVA+ DWC-MV82WIATW benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten




Bedienungsanleitung Überwachungskamera Digital Watchdog

Bedienungsanleitung Überwachungskamera

Neueste Bedienungsanleitung für -Kategorien-
