STEP 1 – PREPARING TO MOUNT THE CAMERA
STEP 2 – CABLING THE CAMERA TO EXTERNAL DEVICES
1. The mounting surface must withstand five times the camera weight.
2. Do not let the cables get caught in improper places or the electric line cover can be damaged. This may cause a
short or fire.
3. For the installation process, remove the dome cover from the camera module by loosening the three (3) screws on
the dome. Use the wrench provided with the camera.
4. Using the mounting template sheet or the camera itself, mark and drill the necessary holes in the wall or ceiling.
Pass the wires through the mount bracket and make all necessary connections.
1. NETWORK CONNECTIONS - If you are using a PoE switch, connect the camera using an Ethernet cable for both
data and power.
2. NETWORK CONNECTIONS - If you are using a non-PoE switch, connect the camera to the switch using an
Ethernet cable for data transmission and use a power adapter to power the camera.
Models Power requirements Power consumption
DWC-MV72Di4TW, DWC-MV72Di28T DC 12V, PoE IEEE 802.3af
Class2. (Adapter not included)
DC12V: max 3.7W
PoE: max 5.4W
DWC-MV72Wi28TW, DWC-MV72Wi4TW,
DWC-MV72Wi6TW, DWC-MV72Wi28ATW,
DWC-MV72Wi4ATW
DC 12V, PoE IEEE 802.3af
Class2. (Adapter not included)
DC12V: max 3.7W
PoE: max 5.5W
DWC-MV75Wi28TW, DWC-MV75Wi4TW,
DWC-MV75Wi6TW
DC 12V, PoE IEEE 802.3af
Class3. (Adapter not included)
DC12V: max 6W
PoE: max 7.2W
Quick Start Guide Quick Start Guide
WHAT’S IN THE BOX
Quick
Setup and
Installation
Guide
1 set Bolt and
Nuts 2pcs 1 set
Mounting
Templates 1
Screws
and Plastic
Anchors -
2pcs
1 set
Waterproof
Cap 1 set Star
Wrench 1
Resetting the camera: To reset the
camera’s settings, including the network
settings, use the tip of a paper clip or a
pencil. Press the reset button for five
(5) seconds.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours:
9:00 AM – 8:00 PM EST, Monday through Friday
digital-watchdog.com
Attention: This document is intended to serve as a quick reference for the initial
set-up. It is recommended that the user read the entire instruction manual for
complete and proper installation and usage.
NOTE: Download all your support materials and tools in one place
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in the
‘Search by Product’ search bar. Results for applicable
part numbers will populate automatically based on the
part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
a
b
c
3. The camera is equipped with a manual IR activation button.
You can choose to disable the camera’s IR LEDs when the
installation environment requires so.
4. Adjust the camera’s lens position by rotating the
camera on its three-axis gimbal.
5. When assembling the dome back on the camera, align the
screw holes in the dome and the camera’s base.
6. When the installation is complete, remove the dome’s
protective film.
STEP 3 – INSTALLING THE CAMERA
1. Attach the main body to the mount bracket by tightening the
lock screw.
2. To use the camera’s waterproof wiring:
a. Install the LAN cable into .
b. will be assembled
to with a 1/4 turn.
c. Thread tightly to .
a
a
b
bc
NOTE: To ensure moisture seal, make sure the o-ring is in place
between and . In extreme environments use of an
outdoor rated sealer is recommended.
a b
NOTE: When using the waterproof cap, crimp the RJ45 connector
after passing the cable through the waterproof cap.
Default Login Information: admin | admin
When logging into the camera for the first time, you will be prompted
to set up a new password. You can set the new password using the
DW® IP Finder™ software or directly from the camera’s browser menu.
5MP models 2.1MP/1080p models with
microphone built-in 2.1MP/1080p models
DWC-MV75Wi28TW DWC-MV72Wi28ATW DWC-MV72Di4TW
DWC-MV75Wi4TW DWC-MV72Wi4ATW DWC-MV72Di28T
DWC-MV75Wi6TW DWC-MV72Wi28TW
DWC-MV72Wi4TW
DWC-MV72Wi6TW
Mounting Template
Protective
film
LED
on/off
Reset button
Microphone built-in
(DWC-MV72Wi28ATW,
DWC-MV72Wi4ATW models)
Quick Start Guide
Rev Date: 07/20
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
Installation using the mounting bolt and screws
1. Using the mounting template, mark
and drill the necessary holes on the
mounting surface.
2. Secure the two long mounting screws
to the camera’s base.
3. Pass the wires through and make
all the necessary connections.
4. Rotate the locking disks over the
screws until the camera holds tightly
from the mounting surface.
STEP 6 – WEB VIEWER
*
The GUI display may dier by camera models.
STEP 5 – DW® IP FINDER™
Thumbnail view
Firmware version
DHCP status
Camera’s uptime
Open IP configuration
settings
Ping camera
Port information
Gateway address
Netmask address
Camera’s MAC address
Filter results
Scan network
Select network to scan
Show/hide thumbnail view
Refresh thumbnail view
Bulk password assignment
Bulk IP assignment
Firmware upgrade
Camera’s name
Camera’s IP address
Part number
Use the DW® IP Finder™ software to scan the network and detect all MEGApix®
cameras, set the camera’s network settings, or access the camera’s web client.
Network Setup
1. To install the DW IP Finder™, go to ®
http://www.digital-watchdog.com
2. Enter “DW® IP Finder” on the search box at the
top of the page.
3. Go to the “Software” tab on the DW® IP Finder™
page to download the installation file.
4. Follow the installation to install the DW® IP
Finder™. Open the DW IP Finder™ and click ®
‘Scan Devices’. It will scan the selected network
for all supported devices and list the results in
the table. During the scan, the DW® logo will
turn gray.
Select DHCP to allow the camera to receive its IP
address automatically from the DHCP server.
Select “Static” to manually enter the camera’s
IP address, (Sub)Netmask, Gateway and DNS
information.
* The camera’s IP must be set to Static if
connecting to
Spectrum® IPVMS
Contact your network administrator for more
information.
Default TCP/IP information: DHCP
5. When connecting to the camera for the first time,
a password must be set. To set up a password for
your new camera:
a. Check the box next to your new camera from the
IP Finder’s search results. You can select multiple
cameras.
‘Port forwarding’ has to be set in your
network’s router for external access to
the camera.
b. Click “Bulk Password Assign” on
the left.
c. In the pop-up window, enter
admin/ admin in the
current username and password
fields. Enter a new username
and password to the right.
d. Press “change” to apply all
changes.
6. Select a camera from the list by
double-clicking on the camera’s
image or clicking on the ‘Click’
button under the IP Conf. column.
The pop-up window will show
the camera’s current network
settings, allowing admin users to
adjust the settings as needed.
7. To access the camera’s web page,
go to the IP Config page and click
on the ‘View Camera Website’.
8. To save the changes made to
the camera’s setting, input the
username and password of the
camera and click Apply.
NOTE: Some menu options may not be available based on the
camera model. See the full manual for more information.
NOTE: 32bit version of the VLC player must be installed. If you are
using a 64bit system, uninstall the previous 64bit version
and reinstall using the 32bit version.
Once the camera’s network settings have been setup properly, you can
access the camera’s web viewer using the DW IP Finder® ™.
To open the camera’s web viewer:
1. Find the camera using the DW® IP Finder™.
2. Double-click on the camera’s view in the results table.
3. Press the ‘View Camera Website’. The camera’s web viewer will
open up in your default web browser.
4. Enter the camera’s username and password you setup in the DW®
IP Finder™. If you did not setup a new username and password via
the DW® IP Finder™, you will not be able to view video from the
camera. A message will direct you to setup a new password for the
camera to view video.
5. When accessing the camera for the first time, install the VLC player
for web files to view video from the camera.
STEP 4 – MANAGING THE SD CARD
The following models include a local SD card slot:
DWC-MV72Wi28ATW, DWC-MV72Wi4ATW,
DWC-MV72Wi28TW, DWC-MV72Wi4TW,
DWC-MV72Wi6TW, DWC-MV75Wi28TW,
DWC-MV75Wi4TW, DWC-MV75Wi6TW
1. To install the camera’s SD Card, locate the SD
card slot in the back of the camera module.
2. Insert a class 10 SD card into the SD card slot by
pressing the SD card slot.
3. To remove the SD Card, press the card inward to
release from the card slot.
Insert SD Card Remove SD Card
STEP 3 – INSTALLING THE CAMERA (cont.)
