Product Announcement:
This product is certificated to meet RoHS
Directive and Lead-Free produced definition.
Using approved critical components only is
recommended when the situation to replace
defective parts. Vender assumes no liability
express or implied, arising out of any unauthorized
modification of design or replacing non-RoHS
parts. Service providers assume all liability.
Qualified Repairability:
Proper service and repair is important to the safe,
reliable operation of all series products. The
service providers recommended by vender should
be aware of notices listed in this service manual in
order to minimize the risk of personal injury when
perform service procedures. Furthermore, the
possible existed improper repairing method may
damage equipment or products. It is recommended
that service engineers should have repairing
knowledge, experience, as well as appropriate
product training per new model before performing
the service procedures.
NOTICE:
! To avoid electrical shocks, the products should be
connected to an authorized power cord, and turn
off the master power switch each time before
removing the AC power cord.
! To prevent the product away from water or
expose in extremely high humility environment.
! To ensure the continued reliability of this
product, use only original manufacturer’s
specified parts.
! To ensure following safety repairing behavior, put
the replaced part on the components side of
PWBA, not solder side.
! To ensure using a proper screwdriver, follow the
torque and force listed in assembly and
disassembly procedures to unscrew screws.
! Using Lead-Free solder to well mounted the
parts.
! The fusion point of Lead-Free solder requested in
the degree of 220°C.
1. Important Safety Notice
2. Exploded view diagram with list of items
3. Wiring Connectivity Diagram
Audio Line out
USB
Down-Stream
Port
LG LM315QU1-SSA1
8Kx4K PANEL
AC Power socket
USB
Down-Stream
Port
V by ONE 1
KEYPAD & PWR
LED Board
USB Up-Stream
Port
DP1.3 Port 2DP1.3 Port 1
T-CON VCC 10V V by ONE 2
POWER BOARD
USB
Down-Stream
Port
USB
Down-Stream
Port
STAND
LED Board
FAN 1
FAN 2
INTERFACE BOARD
