Seite 1/23
Version: 01
Date: 2023/09/11
Service Manual - U2724DE
! To ensure the continued reliability of this
product, use only original manufacturerโs
specified parts.
This product is certificated to meet RoHS
Directive and Lead-Free produced definition.
Using approved critical components only is
recommended when the situation to replace
defective parts. Vender assumes no liability
express or implied, arising out of any unauthorized
modification of design or replacing non-RoHS
parts. Service providers assume all liability.
! To ensure following safety repairing behavior, put
the replaced part on the components side of
PWBA, not solder side.
Qualified Repairability:
NOTICE:
Product Announcement:
! To prevent the product away from water or
expose in extremely high humility environment.
! To avoid electrical shocks, the products should be
connected to an authorized power cord, and turn
off the master power switch each time before
removing the AC power cord.
Proper service and repair is important to the safe,
reliable operation of all series products. The
service providers recommended by vender should
be aware of notices listed in this service manual in
order to minimize the risk of personal injury when
perform service procedures. Furthermore, the
possible existed improper repairing method may
damage equipment or products. It is recommended
that service engineers should have repairing
knowledge, experience, as well as appropriate
product training per new model before performing
the service procedures.
! To ensure using a proper screwdriver, follow the
torque and force listed in assembly and
disassembly procedures to unscrew screws.
! Using Lead-Free solder to well mounted the
parts.
! The fusion point of Lead-Free solder requested in
the degree of 220ยฐC.
1. Important Safety Notice
2. Exploded view diagram with list of items
Item Description Q ty Remark๎ ๎ ' ๎ ๎
1๎
LED Board๎
1๎
For EMEA Only not๎ ๎ ,๎ ๎for๎
other regions๎ ๎
2๎
Power Board
1๎
13
4 1๎ ๎
95
6Panel Screws๎11
1 7
8 1๎ ๎
9
10
11๎
Panel๎
1๎
1
Power cable
12
1
13
1
14
See โNOTEโ
See โNOTEโ
See โNOTEโ
USB Board๎
Middle Frame๎๎
DisplayPort 1.8 M cable
Board Screws
Interface BD with TBT board๎ ๎๎
USB-C 1.0 M cable
Thunderbolt 4 cable โข๎
1๎
1๎
See โNOTEโ
NOTE:
For replacement of power cord, connectivity cable and external power supply (if applicable), contact Dell:
1. Go to https://www.dell.com/support.
4. Select the appropriate service or support link based on your need.
5. Choose the method of contacting Dell that is convenient for you.
3. Click Contact Us next to the country dropdown.
2. Verify your country or region in the Choose A Country/Region drop-down menu at the bottom-right corner of the page.
13 4 7 8 14 152 5
613
9 10 11 12
1816 1917
1๎
1๎
15
16
17
18
19
1๎
1๎
1๎
Main Chassis
IO Back Cover
Joystick Board
Joystick
Light Sensor
๎Rear Cover๎
Stand Base
