KITCHENMASTER
SOLID PLATES STOVE
DSS612
Cooking
Instruction manual
Part number: 073291D
I ntroduction
Dear Customer,
Your new Defy oven was manufactured in a state-of-the-art facility and has passed the strictest quality
control procedures.
Please read this manual carefully before using your oven for the first time and then store it within easy
reach for future reference.
This manual will provide you with information on how to operate and care for your oven to gain the
maximum benefit from it.
We trust you will enjoy years of trouble free use.
EXPLANATION OF SYMBOLS
Important information
Warning—Hazardous situations
Warning—Electric shock
Caution; Warning for fire hazard
Caution; Warning for hot surfaces
Contents
PLEASE REGISTER YOUR PRODUCT AT
www.defy.co.za
DEFY APPLIANCES (PTY) LTD
P.O.BOX 12004
JACOBS
DURBAN
4026
SOUTH AFRICA
1. General Information 2
Unpacking 2
Installation 2
Anti-tilt mechanism 3
Fitting the removable splashback 3
2. Important Safety Instructions 4
General safety 4
Technical specifications 5
3. Operation Instructions 5
Control panel 5
Selector switch 5
Oven operation 6
Ringer timer 6
Cooking times table 6
Solid plates 6
4. Maintenance and Care 7
General cleaning 7
Cleaning the oven cavity 7
Steam assisted cleaning 7
Replacing the oven light 7
Caring for solid plates 7
Troubleshooting 7
Removing the oven door 8
5. Important Notes 9
6. Support 9
7.Branches 10
8. Warranty 11
Page 1
1 2
3
1. General information
Unpacking
Please ensure that packaging material is disposed
of in a responsible manner.
Plastic bags should be cut up to prevent children
playing with them and accidentally suffocating.
Remove all packing from the oven cavity and
position the accessories.
If the appliance is damaged in any way, do not
use it. Report the damage to your dealer, who will
take the necessary corrective action.
Installation
Levelling feet are provided to assist you in
positioning your stove, so that it will stand firm
and level. To adjust the level, turn the relevant
foot to either raise or lower the stove.
Connecting the sprague to the oven
1. Purchase a standard plastic/metal saddle type
bracket, capable of going around the 20 mm
diameter sprague and with a hole pitch of 38
mm (Plastic) 45 mm (Metal), and two 4.2mm x
12mm self-tapping screws from your local
hardware store.
2. Feed the cables through the sprague and
connect to the mains terminal block of the
appliance.
3. Place the plastic/metal saddle around the
sprague and fasten via the 2 self-tapping
screws onto the factory pre-punched holes
adjacent to the mains terminal block of the
appliance.
Electrical installation
The manufacturer and seller do not accept
responsibility for any damage due to incorrect
installation or electrical connection. This
appliance should not be connected through an
earth leakage system. Refer to S.A.N.S. 10142
Connection to the power supply
This appliance has a ‘Y’ type supply cord
connection and must be installed by a licensed
electrician, who will ensure that the stove is
correctly connected and safely earthed.
The rated current is printed on the serial number
label attached to the stove upper back panel.
The appliance must be connected to the mains
through an All pole isolating switch which has a
minimum clearance between the contacts of 3
mm in All poles. A means for disconnection must
be provided in the fixed wiring.
WARNING! ELECTRICAL
CONNECTION MUST ONLY BE
DONE BY A QUALIFIED
ELECTRICIAN!
Page 2
Do not carry the product using the
oven door handle, this may damage
your oven door hinges!
You may lift the product with the
door open by holding the inside of
the oven and the back of the hob.
