Seite 1/12
PAGE OF12 1
CONTENTS
2 Introduction
2 Unpacking
2 Installation
2 Electrical installation
2 Anti-tilt bracket
3 Anti-tilt bracket assembly
4 Safety advice
5 Control panel
5 6 Position selector knob
6 Using the oven
7 Solid plates
8 Spiral plates
8 Warming drawer
8 Maintenance
9 Cleaning the oven
9 Replacing the oven lamp
9 Removable oven door
10 Do and Don’t guide
11 Problem check
11 Owners responsibility
11 Service centres
12 Warranty
12 Purchase details
Part Number 067 797
You can rely on Defy. To simplify
Please register your
product at
www.defy.co.za
The Manufacturer
strives for continuous
improvements.
For this reason, the text
and illustrations in this
book are subject to
change without notice.
Kitchenaire
Stove
OWNER’S MANUAL
FOR MODELS:
620 Kitchenaire
Spiral plates
621 Kitchenaire
Solid plates
PAGE OF12 2
Introduction
Congratulations on the purchase of this quality stove.
We trust that you will enjoy many years of trouble free use. Please read these
instructions carefully before using the stove. This manual will provide you with
information on how to operate and care for your stove in order that you gain the maximum
benefit from it.
Unpacking
• Please ensure that packaging material is disposed of in a responsible manner.
• Plastic bags should be cut up to prevent children playing with them and accidentally
suffocating.
• Remove all packing from the oven cavity and position the accessories.
• If the appliance is damaged in any way, do not use it. Report the damage to your dealer,
who will take the necessary corrective action.
Installation
• Levelling feet are provided to assist you in positioning your stove, so that it will stand
firm and level. To adjust the level, turn the relevant foot to either raise or lower the
stove.
• Surfaces immediately adjacent to the oven should be able to withstand temperatures of
up to 100 without delaminating or discolouring.°C
Electrical installation
This appliance must be earthed and the manufacturer and the seller do not accept
responsibility for any damage due to incorrect installation or electrical connection.
This appliance should not be connected through an earth leakage system.
Refer to S.A.N.S. 10142
Connection to the power supply
This appliance has a ‘Y’ type supply cord connection and must be installed by a licensed
electrician, who will ensure that the stove is correctly connected and safely earthed. The
rated current is printed on the serial number label attached to the stove upper back panel.
.
The appliance must be connected to the mains through an All pole isolating switch which
has a minimum clearance between the contacts of 3 mm. in All poles.
A means for disconnection must be provided in the fixed wiring.
Anti-tilt bracket
All stoves can tilt if you or a child sit or lean on an open oven door.
Safety regulations stipulate that the ANTI-TILT brackets supplied with the stove,
must be fitted as shown on page 3.
WARNING
PAGE OF12 3
The Anti-tilt bracket kit assembly comprises of:
A 2 x Anti-tilt brackets (stove)
B 2 x Anti-tilt brackets (wall)
C 6 x Securing bolts (4 short and 2 long)
D 4 x Hilti fasteners
• A is to be fitted at the rear of the stove on the left and right hand side using 2 se-
curing bolts in the threaded holes provided.(2 short bolts per side) C
• B A C is fitted to by the securing bolt (1 long bolt per side)
• Slightly loosen the securing bolt to allow to slide freely over C B A
• Position the stove and slide to touch the wall behind the stove. B
• Mark the two holes in where they touch the wall behind the stove. B
• Remove the stove and unfasten the bracket . B
• Using a 6.0 mm concrete bit, drill two holes at the marked positions.
• Using the Hilti fasteners , firmly secure to the wall. D B
• Slide the stove back in position and carefully engage the brackets so that B
slides over A.
• Securely fasten the two brackets by tightening bolt . (1 long bolt per side)C
• The stove is then secured and will not accidentally tilt if downward pressure is
applied to the open oven door.
Anti-tilt installation top view
Stove
A
AB
CB
C
Wall
Stove
Wall
Anti-tilt installation side view
B
C
A
AB
C
D
Parts
A
C
B
Assembly
