Operation manual
R32 Split series English
Operation manual
R32 Split series
FTXP20M5V1B
FTXP25M5V1B
FTXP35M5V1B
FTXP20M5V1B9
FTXP25M5V1B9
FTXP35M5V1B9
Table of contents
Operation manual
2
FTXP20~35M5V1B/B9
R32 Split series
3P520336-6T – 2021.12
Table of contents
1 About the documentation 2
1.1 About this document.................................................................. 2
2 User safety instructions 2
2.1 Instructions for safe operation ................................................... 2
3 About the system 4
3.1 Indoor unit ................................................................................. 4
3.1.1 Indoor unit display....................................................... 4
3.2 About the user interface ............................................................ 4
3.2.1 Components: Wireless remote control........................ 5
3.2.2 Status: Wireless remote control LCD.......................... 5
3.2.3 To operate the wireless remote control....................... 5
4 Before operation 5
4.1 To mount the wireless remote control holder ............................ 5
4.2 To insert the batteries................................................................ 6
4.3 To switch between Fahrenheit and Celsius............................... 6
4.4 To turn on the power supply...................................................... 6
5 Operation 6
5.1 Operation range ........................................................................ 6
5.2 When to use which feature ........................................................ 6
5.3 Operation mode and temperature setpoint................................ 6
5.3.1 To start/stop operation mode and to set the
temperature................................................................. 7
5.3.2 Airflow rate.................................................................. 7
5.3.3 Airflow direction........................................................... 7
5.3.4 Comfort airflow operation............................................ 8
5.3.5 Powerful operation...................................................... 8
5.3.6 Econo operation.......................................................... 9
5.3.7 OFF/ON timer operation ............................................. 9
6 Energy saving and optimum operation 10
7 Maintenance and service 10
7.1 Overview: Maintenance and service ......................................... 10
7.2 To clean the indoor unit and wireless remote control................ 11
7.3 To clean the front panel............................................................. 11
7.4 To clean the air filters ................................................................ 11
7.5 To clean the titanium apatite deodorising filter and the silver
particle filter (Ag-ion filter) ......................................................... 11
7.6 To replace the titanium apatite deodorising filter and the silver
particle filter (Ag-ion filter) ......................................................... 12
7.7 To close the front panel............................................................. 12
7.8 To take following items into account before a long idle period .. 12
8 Troubleshooting 12
8.1 Symptoms that are NOT system malfunctions .......................... 12
8.1.1 Symptom: A sound like water flowing is heard ........... 12
8.1.2 Symptom: A blowing sound is heard........................... 12
8.1.3 Symptom: A ticking sound is heard............................. 13
8.1.4 Symptom: A whistling sound is heard......................... 13
8.1.5 Symptom: A clicking sound during operation or idle
time is heard ............................................................... 13
8.1.6 Symptom: A clapping sound is heard ......................... 13
8.1.7 Symptom: White mist comes out of a unit (Indoor
unit) ............................................................................. 13
8.1.8 Symptom: The units can give off odours..................... 13
8.1.9 Symptom: The outdoor fan rotates while the air
conditioner is not in operation ..................................... 13
8.2 Solving problems based on error codes .................................... 13
9 Disposal 13
1 About the documentation
1.1 About this document
Thank you for purchasing this product. Please:
â–ª Keep the documentation for future reference.
Target audience
Endusers
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
â–ªGeneral safety precautions:
â–ª Safety instructions that you must read before operating your
system
â–ª Format: Paper (in the box of the indoor unit)
â–ªOperation manual:
â–ª Quick guide for basic usage
â–ª Format: Paper (in the box of the indoor unit)
â–ªUser reference guide:
â–ª Detailed step-by-step instructions and background information
for basic and advanced usage
â–ª Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original documentation is written in English. All other languages
are translations.
2 User safety instructions
Always observe the following safety instructions and regulations.
2.1 Instructions for safe operation
WARNING: MILDLY FLAMMABLE
MATERIAL
The refrigerant inside this unit is mildly
flammable.
CAUTION
Do NOT insert fingers, rods or other
objects into the air inlet or outlet. When
the fan is rotating at high speed, it will
cause injury.
2 User safety instructions
Operation manual
3
FTXP20~35M5V1B/B9
R32 Split series
3P520336-6T – 2021.12
WARNING
â–ª Do NOT modify, disassemble,
remove, reinstall or repair the unit
yourself as incorrect dismantling or
installation may cause an electrical
shock or fire. Contact your dealer.
â–ª In case of accidental refrigerant
leaks, make sure there are no naked
flames. The refrigerant itself is
entirely safe, non-toxic and mildly
flammable, but it will generate toxic
gas when it accidentally leaks into a
room where combustible air from fan
heaters, gas cookers, etc. is present.
Always have qualified service
personnel confirm that the point of
leakage has been repaired or
corrected before resuming operation.
CAUTION
ALWAYS use the wireless remote
control or other user interface (if
applicable) to adjust the position of the
flaps and louvers. When the flaps and
louvers are swinging and you move
them forcibly by hand, the mechanism
will break.
CAUTION
NEVER expose little children, plants or
animals directly to the airflow.
WARNING
Do NOT place a flammable spray
bottle near the air conditioner and do
NOT use sprays near the unit. Doing
so may result in a fire.
CAUTION
Do NOT operate the system when
using a room fumigation-type
insecticide. Chemicals could collect in
the unit, and endanger the health of
people who are hypersensitive to
chemicals.
WARNING
â–ª The refrigerant inside the unit is
mildly flammable, but normally does
NOT leak. If the refrigerant leaks in
the room and comes in contact with
fire from a burner, a heater, or a
cooker, this may result in fire, or the
formation of a harmful gas.
â–ª Turn OFF any combustible heating
devices, ventilate the room, and
contact the dealer where you
purchased the unit.
â–ª Do NOT use the unit until a service
person confirms that the part from
which the refrigerant leaked has been
repaired.
WARNING
â–ª Do NOT pierce or burn refrigerant
cycle parts.
â–ª Do NOT use cleaning materials or
means to accelerate the defrosting
process other than those
recommended by the manufacturer.
â–ª Be aware that the refrigerant inside
the system is odourless.
WARNING
The appliance shall be stored so as to
prevent mechanical damage and in a
well-ventilated room without
continuously operating ignition sources
(e.g. open flames, an operating gas
appliance, or an operating electric
heater). The room size shall be as
specified in the General safety
precaution.
DANGER: RISK OF
ELECTROCUTION
To clean the air conditioner or air filter,
be sure to stop operation and turn all
power supplies OFF. Otherwise, an
electrical shock and injury may result.
CAUTION
After a long use, check the unit stand
and fitting for damage. If damaged, the
unit may fall and result in injury.
