OPERATION MANUAL
FFQ25B9V1B
FFQ35B9V1B
FFQ50B9V1B
FFQ60B9V1B
Split system air conditioners
6
3
5
4
2
1
2
3
4
4
7
8 3 92
6
5
1
1
1 1
A
B
12
3
4
5
6
FFQ25~60B9V1B
Split system air conditioners
4PW70943-1 – 08.2011
Operation manual
1
CONTENTS Page
What to do before operation ..............................................................1
Important information regarding the refrigerant used ........................ 1
Safety considerations ........................................................................1
Names and functions of parts............................................................ 1
Operation range.................................................................................2
Installation site...................................................................................2
Name and function of each switch and display
on the remote controller.....................................................................2
Operation procedure..........................................................................2
Optimum operation ............................................................................2
Not a malfunction of the air conditioner.............................................3
Troubleshooting .................................................................................4
Maintenance......................................................................................4
The original instructions are written in English. All other languages
are translations of the original instructions.
W HAT TO DO BEFORE OPERATION (See figure 1)
This operation manual is for the following systems with standard
control. Before initiating operation, contact your Daikin dealer for the
operation manual that corresponds to your system.
If your installation has a customized control system, ask your Daikin
dealer for the operation that corresponds to your system.
■Heat pump type
This system provides cooling, heating, automatic, and fan
operation modes.
■Straight cooling type
This system provides cooling, and fan operation modes.
I MPORTANT INFORMATION REGARDING THE
REFRIGERANT USED
This product contains fluorinated greenhouse gases covered by the
Kyoto Protocol.
Refrigerant type: R410A
GWP(1) value: 1975
(1) GWP = global warming potential
Periodical inspections for refrigerant leaks may be required
depending on European or local legislation. Please contact your local
dealer for more information.
S AFETY CONSIDERATIONS
N AMES AND FUNCTIONS OF PARTS (See figure 2)
FFQ25B9V1B
FFQ35B9V1B
FFQ50B9V1B
FFQ60B9V1B
Split system air conditioners Operation manual
THANK YOU FOR PURCHASING THIS DAIKIN AIR
CONDITIONER. CAREFULLY READ THIS OPERATION
MANUAL BEFORE USING THE AIR CONDITIONER. IT
WILL TELL YOU HOW TO USE THE UNIT PROPERLY
AND HELP YOU IF ANY TROUBLE OCCURS. AFTER
READING THE MANUAL, FILE IT AWAY FOR FUTURE
REFERENCE.
NOTE These units can be controlled by a remote controller.
Refer to the manual of the remote controller for more
information.
APair system
BMulti system
1Unit with remote controller
■Never let the indoor unit and the remote controller get
wet.
It may cause an electric shock or a fire.
■Never use flammable spray such as hair spray,
lacquer or paint near the unit.
It may cause a fire.
■Never replace a fuse with that of a wrong ampere
rating or other wires when the fuse blows out.
Use of wire or copper wire may cause the unit to
break down or cause a fire.
■This appliance is not intended for use by persons,
including children, with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
■Never touch the air outlet or the horizontal blades
while the swing flap is in operation.
Fingers may become caught or the unit may break down.
■Never insert objects such as sticks into the air inlet or
outlet. It is dangerous for an object to touch the fan
when it is turning at high speed.
■Never remove the fan guard of the outdoor unit.
The rotating fan at high speed without the guard is
very dangerous.
■Never inspect or service the unit by yourself.
Ask a qualified service person to perform this work.
1Indoor unit
2Discharged air
3Inlet air
4Remote controller
5Connection electric wire
6Refrigerant piping
7Drain pipe
8Outdoor unit
9Ground wire
Wire to ground outdoor unit to prevent electrical shocks.
