Operation manual
Daikin room air conditioner English
Operation manual
Daikin room air conditioner
ATXM20N2V1B
ATXM25N2V1B
ATXM35N2V1B
ATXM50N2V1B
Table of contents
Operation manual
2
ATXM20~50N2V1B
Daikin room air conditioner
3P485919-9K – 2018.09
Table of contents
1 About the documentation 2
1.1 About this document.................................................................. 2
2 About the system 2
2.1 Indoor unit ................................................................................. 2
2.1.1 Indoor unit display....................................................... 3
2.2 About the user interface ............................................................ 3
2.2.1 Components: User interface ....................................... 3
3 Before operation 3
3.1 To insert the batteries................................................................ 3
3.2 To fix the user interface to the wall............................................ 4
3.3 To set the clock ......................................................................... 4
3.4 Brightness of the indoor unit display ......................................... 4
3.4.1 To set the brightness of the indoor unit display .......... 4
3.5 To turn on the power supply...................................................... 4
4 Operation 4
4.1 Operation range ........................................................................ 4
4.2 Operation mode and temperature setpoint................................ 4
4.2.1 To start/stop operation and to set the temperature..... 5
4.3 Airflow rate ................................................................................ 5
4.3.1 To adjust the airflow rate............................................. 5
4.4 Airflow direction ......................................................................... 5
4.4.1 To adjust vertical airflow direction............................... 5
4.4.2 To adjust horizontal airflow direction........................... 5
4.4.3 To use 3-D airflow direction ........................................ 6
4.5 Comfort airflow and Intelligent eye operation ............................ 6
4.5.1 Comfort airflow operation............................................ 6
4.5.2 Intelligent eye operation.............................................. 6
4.5.3 To start/stop Comfort and Intelligent eye operation.... 6
4.6 Powerful operation .................................................................... 6
4.6.1 To start/stop Powerful operation................................. 6
4.7 Econo and Outdoor unit quiet operation.................................... 6
4.7.1 Econo operation.......................................................... 6
4.7.2 Outdoor unit quiet operation ....................................... 6
4.7.3 To start/stop Econo and Outdoor unit quiet operation 7
4.8 Flash streamer air cleaning operation ....................................... 7
4.8.1 To start/stop Flash Streamer operation ...................... 7
4.9 OFF/ON timer operation............................................................ 7
4.9.1 To start/stop OFF timer operation............................... 7
4.9.2 To start/stop ON timer operation................................. 7
4.9.3 To combine OFF timer and ON timer.......................... 8
4.10 Weekly timer operation.............................................................. 8
4.10.1 To set Weekly timer operation .................................... 8
4.10.2 To copy reservations................................................... 9
4.10.3 To confirm reservations .............................................. 9
4.10.4 To deactivate and reactivate Weekly timer operation. 9
4.10.5 To delete reservations ................................................ 9
4.11 Wireless LAN connection .......................................................... 9
4.11.1 Precautions when using the wireless adapter............. 9
4.11.2 To install the Daikin Online Controller application ...... 10
5 Energy saving and optimum operation 10
6 Maintenance and service 10
6.1 Overview: Maintenance and service ......................................... 10
6.2 To clean the indoor unit and user interface ............................... 11
6.3 To clean the front panel............................................................. 11
6.4 To remove the front panel ......................................................... 11
6.5 About the air filters .................................................................... 11
6.6 To clean the air filters ................................................................ 11
6.7 To clean the titanium apatite deodorizing filter .......................... 12
6.8 To replace the titanium apatite deodorizing filter....................... 12
6.9 To re-install the front panel........................................................ 12
6.10 To take following items into account before a long idle period .. 13
7 Troubleshooting 13
8 Disposal 13
1 About the documentation
1.1 About this document
Thank you for purchasing this product. Please:
â–ª Keep the documentation for future reference.
Target audience
Endusers
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
â–ªGeneral safety precautions:
â–ª Safety instructions that you must read before operating your
system
â–ª Format: Paper (in the box of the indoor unit)
â–ªOperation manual:
â–ª Quick guide for basic usage
â–ª Format: Paper (in the box of the indoor unit)
â–ªUser reference guide:
â–ª Detailed step-by-step instructions and background information
for basic and advanced usage
â–ª Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original documentation is written in English. All other languages
are translations.
2 About the system
WARNING: FLAMMABLE MATERIAL
The refrigerant inside this unit is mildly flammable.
2.1 Indoor unit
CAUTION
Do NOT insert fingers, rods or other objects into the air
inlet or outlet. When the fan is rotating at high speed, it will
cause injury.
INFORMATION
The sound pressure level is less than 70dBA.
3 Before operation
Operation manual
3
ATXM20~50N2V1B
Daikin room air conditioner
3P485919-9K – 2018.09
WARNING
â–ª Do not modify, disassemble, remove, reinstall or repair
the unit yourself as incorrect dismantling or installation
may cause an electric shock or fire. Contact your
dealer.
â–ª In case of accidental refrigerant leaks, make sure there
are no naked flames. The refrigerant itself is entirely
safe, non-toxic and mildly flammable, but it will
generate toxic gas when it accidentally leaks into a
room where combustible air from fan heaters, gas
cookers, etc. is present. Always have qualified service
personnel confirm that the point of leakage has been
repaired or corrected before resuming operation.
INFORMATION
The following figures are just examples and may NOT
completely match your system layout.
2.1.1 Indoor unit display
a
b
c
d
e
aSignal receiver for user interface
bOperation lamp
cTimer lamp
dIntelligent eye lamp
eON/OFF button
ON/OFF button
If the user interface is missing, you can use the ON/OFF button on
the indoor unit to start/stop operation. When operation is started
using this button, the following settings are used:
â–ª Operation mode = Automatic
▪ Temperature setting = 25°C
â–ª Airflow rate = Automatic
2.2 About the user interface
â–ª Do NOT expose the user interface to directDirect sunlight.
sunlight.
â–ª Dust on the signal transmitter or receiver will reduceDust.
sensitivity. Wipe off dust with a soft cloth.
â–ª Signal communication might be disabled ifFluorescent lights.
fluorescent lamps are in the room. In that case, contact your
installer.
â–ª If the user interface signals operate otherOther appliances.
appliances, move the other appliances, or contact your installer.
â–ª Make sure that the signal between the unit and the userCurtains.
interface is NOT blocked by curtains or other objects.
NOTICE
â–ª Do NOT drop the user interface.
â–ª Do NOT let the user interface get wet.
2.2.1 Components: User interface
aSignal transmitter
bLCD display
cTemperature adjustment button
dON/OFF button
eVertical swing button
fHorizontal swing button
gComfort airflow and Intelligent eye operation button
hSelect button
iClock button and indoor unit display brightness
jButtons for ON/OFF timer operation
kButtons for Weekly timer operation
lStreamer
mEcono and Outdoor unit quiet operation button
nMode button
oPowerful button
pFan button
3 Before operation
3.1 To insert the batteries
The batteries will last for about 1 year.
1Remove the front cover.
2Insert both batteries at once.
3Put back the front cover.
2
3
1
AAA.LR03
INFORMATION
â–ª Low energy of battery is indicated by flashing of LCD
display.
â–ª ALWAYS replace both batteries at once.
