Ultra Series | N88BR5V
People Counng
The camera uses complex real-me people counng algorithms to
deliver accurate ow stascs from two disnct people counng
funcons, Line Crossing and Regional. The line crossing funcon counts
the number of people crossing a dened line, and the regional funcon
counts the number of people in a disnct, user-dened area. People
counng is ideal for measuring the number of customers entering or
exing a locaon and to monitor groups of people in a disnct locaon.
Dewarping Mode
Fisheye dewarping solves the problem of distoron in the circular
panoramic view. The camera oers mulple dewarping modes for
dierent installaons and conguraons, either with a Dahua XVR, NVR,
via the Web interface. Each dewarping mode oers opons to adjust
each scene.
Cybersecurity
Dahua network cameras are equipped with a series of key cybersecurity
technologies including: security authencaon and authorizaon, access
control, trusted protecon, encrypted transmission, and encrypted
storage. These technologies improve the camera’s ability to prevent
malicious access and to protect data.
Protecon
The camera allows for ±25% input voltage tolerance, suitable for
the most unstable condions for outdoor applicaons. Subjected
and cered to rigorous dust and immersion tests (IP67) and impact
tests (IK10), the camera is the choice for installaon in even the most
unforgiving environments.
us.dahuasecurity.com
•1/1.7-in. 8MP Progressive-scan CMOS Sensor
•8MP (3280 x 2480) at 30 fps Maximum Resolution
•Immervision Panomorph Lens RPL: B9VVT
•Triple Stream Encoding
•Smart H.265+ and Smart H.264+ Dual Codecs
•Analytics+ Functions — People Counting and Perimeter Protection
•Multiple Dewarp Modes
•Built-in Microphone and Speaker
•Day/Night (ICR), 3DNR, AWB, AGC, BLC
•Maximum IR Distance 10 m (32.81 ft)
•IP67 Ingress Protection and IK10 Vandal Resistance
•Five-year Warranty*
8 MP Network Fisheye Camera
360° Panoramic IR Fisheye Camera
System Overview
Dahua Fisheye Cameras provide detailed anoramic views in a compact, p
low-prole design. The CMOS sensor combined with a sheye lens
provide a high-quality 360° panoramic view without blind spots, making
the camera the ideal solution or wide and en eas. The camera f op ar
offers multiple dewarp modes for different installations and
configurations that enhance the video for a specific scene. The IP67
environmental protection rating and the IK10 vandal resistance ensure
the camera operates in the harshest environments.
Funcons
Panomorph Technology
The sheye camera incorporates Panomorph Technology from
Immervision, an industry leader in 360° soluons and applicaons.
Panomorph technology is comprised of patented panomorph opcs and
viewing funconality for opmal 360° image quality. The panomorph
opc includes magnied zones of interest based on an innovave
distoron control concept. The viewing funconality removes all added
distoron and enables 360° immersive navigaon within live or recorded
360° video. Immervision is the only universally-accepted 360° dewarping
standard; all major VMS plaorms and camera vendors support this
technology.
Perimeter Protecon
Dahua Analycs+ includes Tripwire and Intrusion funcons that oer
custom tripwires based on object type for automaon in limited access
areas. Perimeter Protecon requires less pixels to detect an object to
deliver improved accuracy and decreased false alarms due to lights,
weather, trees, or animals.
*Warranty applies to products sold through an authorized Dahua Dealer.
WizMind Series devices oer advanced Dahua Analycs+ funcons for
comprehensive, human-oriented analyc soluons. WizMind Series
products deliver perimeter protecon and advanced people counng with
heat map funconality. WizMind is ideal for complex applicaons with
demanding requirements that need advanced analyc capabilies.
us.dahuasecurity.com
Ultra Series | N88BR5V
Technical Specicaon
Camera
Image Sensor 1/1.7-in. 8MP CMOS
Total Sensor Pixels 3280(H) x 2480(V)
RAM/ROM 4 GB / 2 GB
Scanning System Progressive
Electronic Shutter Speed Auto, Manual, 1/3 s to 1/100,000 s
Minimum Illumination
Color: 0.01 lux at F2.0 (30 IRE)
B/W: 0.001 lux at F2.0 (30 IRE)
0 lux at F2.0 with IR on
S/N Ratio More than 56 dB
IR Distance Up to 10.0 m (32.81 ft)
IR On/Off Control Auto, Manual
IR LEDs Three (3)
Lens
Lens Type Immervision Panomoprh Lens – RPL: B9VVT
Fixed
Mount Type M12
Focal Length 1.29 mm
Maximum Aperture F2.0
Angle of View Horizontal: 360°
Focus Control Fixed
Close Focus Distance 0.20 m (0.66 ft)
DORI Distance¹
Detect (8 ppf) (19 ppf) (38 ppf) (76 ppf)Observe Recognize Identify
27.90 m (91.54 ft) 11.20 m (36.75 ft) 5.60 m (18.37 ft) 2.80 m (9.19 ft)
Video
Compression Smart H.265+, H.265, Smart H.264+, H.264, H.264H,
MJPEG (substream only)
Streaming Capability Three (3) Streams
Resolution 8MP (3280 x 2480), 2880 x 2160, 3MP (2048 x 1536),
1.3MP (1280 x 960), D1 (704 x 576), CIF (352 x 288)
Effective Maximum Resolution, based on Dewarping Mode
Dewarping Mode Mount Location Resolution (H x V)
1 Original All Locations 3280 x 2480
1 Panoramic
Ceiling/Ground 4096 x 1024
Wall
2 Panoramic Ceiling/Ground 2432 x 2432
1 Region All Locations 1216 x 1216
2 Regions All Locations 2432 x 2432
4 Regions All Locations 2432 x 2432
1 Original + 3 Regions All Locations 2432 x 2432
1. The DORI distance is a measure of the general proximity for a specic classicaon to help pinpoint the
right camera for your needs. The DORI distance is calculated based on sensor specicaons and lab test
results according to EN 62676-4, the standard that denes the criteria for the Detect, Observe, Recognize and
Idenfy classicaons.
Frame Rate
Main Stream 8MP at 30 fps
Stream 1 D1 at 30 fps
Stream 2 1.3MP at 30 fps
Bit Rate Control CBR, VBR
Bit Rate H.265: 3 Kbps to 13891 Kbps
H.264: 8 Kbps to 16384 Kbps
Day/Night Auto (ICR), Color, B/W
BLC Mode BLC, HLC, DWDR
White Balance Auto, Natural, Street Lamp, Outdoor, Manual
Gain Control Auto, Gain Priority, Shutter Priority, Manual
Noise Reduction 3D DNR
Motion Detection Off, On (4 Zone, Rectangle)
Region of Interest Off, On (4 Zone)
Advanced Features Defog
Privacy Masking Off, On (4 Area, Rectangle)
Audio
Compression PCM, G.711a, G.711Mu, G.726, G.723
Network
Ethernet RJ-45 (100/1000 Base-T)
Protocol
HTTP, HTTPs, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP,
DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP,
Bonjour, 802.1x, Multicast, ICMP, IGMP, SNMP
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; P2P
Streaming Method Mulitcast
Maximum User Access 20 Users
Edge Storage
Network Attached Storage (NAS)
FTP, SFTP
Micro SD Card, maximum 256 GB
Web Viewer IE, Firefox, Safari
Management Software DSS, DMSS
Mobile Operating System iOS, Android
Cybersecurity
Video Encryption, Firmware Encryption, Configuration
Encryption, Digest, WSSE, Account Lockout, Security
Logs, IP/MAC Filtering, Generating and Importing
X.509 Certification, Syslog, HTTPS, 802.1x, Trusted
Boot, Trusted Execution, Trusted Upgrade
Cercaons
Safety UL62368-1, CAN/CSA C22.2 No. 62368-1-14
EN62368-1
Electromagnetic
Compatibility (EMC)
47 CFR FCC Part 15, Subpart B
Electromagnetic Compatibility Directive 2014/30/EU
Radio Equipment Directive 2014/53/EU
Interface
Audio Input: One (1) Channel, RCA + Built-in Microphone
Output: One (1) Channel, RCA + Built-in Speaker
Alarm Input: Two (2) Channels (5 VDC, 5 mA)
Output: Two (2) Channels (30 VDC, 1 A; 50 VAC, 0.5 A)
Electrical
Power Supply 12 VDC or PoE+ (IEEE802.3at, Class 4)
Power
Consumption
Basic 12 VDC: 6.5 W
PoE: 6.1 W
Maximum 12 VDC: 13 W
PoE: 13.9 W
Ultra Series | N88BR5V
Ordering Informaon
Type Part Number Description
8MP Fisheye N88BR5V 8MP Panoramic Network IR Fisheye Camera,
Accessories,
optional
PFA100 Mount Adapter
DH-PFA132-E Junction Box
PFA150 Pole Mount
(use with PFB302S or DH-PFA132-E)
PFA151 Corner Mount
(use with PFB302S or DH-PFA132-E)
PFA152-E Pole Mount
(use with PFB302S or DH-PFA132-E
PFB300C Ceiling Mount
(use with PFA100)
PFB302S Wall Mount
(use with PFA100)
us.dahuasecurity.com
Environmental
Operating Conditions –40 °C to +55 °C (–40 °F to +131 °F)
Less than 95% RH
Storage Conditions –30 °C to +70 °C (-22 °F to +158 °F)
Ingress Protection IP67
Vandal Resistance IK10
Construcon
Casing Metal
Dimensions ø149.80 mm x 59.80 mm (ø5.90 in. x 2.35 in.)
Net Weight 0.79 kg (1.74 lb)
Gross Weight 1.21 k g (2.67 lb)
Recommended Installaon Height
Indoor
Ceiling 3.0 m to 4.0 m (9.84 ft to 13.12 ft)
Wall 2.0 m to 3.0 m (6.56 ft to 9.84 ft)
Outdoor
Ceiling 6.0 m to 8.0 m (19.69 ft to 26.25 ft)
Wall Depends on height of pole
Accessories
Dimensions (mm/inch)
Rev 001.003 © 2021 Dahua Technology USA. All rights reserved. Design and specifications are subject to change without notice.
Oponal:
PFB300C
Ceiling Mount
PFA150
Pole Mount
PFA100
Mount Adapter
DH-PFA132-E
Junction Box
PFA152-E
Pole Mount
PFA151
Corner Mount
Analycs+ Funcons²
Perimeter Protection
• Detects human violations using the following
methods:
Tripwire: a target crosses a defined line.
Intrusion: a target enters or exits a defined
perimeter.
• Monitors a combination of detection methods.
People Counting
• Delivers accurate flow statistics from the following
methods:
Line Crossing: counts a person as they cross a
threshold in a defined direction.
Region: counts the number of people in a defined
area.
• Counts people simultaneously from four (4) threshold
lines and four (4) defined regions.
Intelligent Video System Funcons
IVS triggers an alarm and takes a defined action for the following events:
Standard Features
• Tampering with the camera.
• Error writing to an onboard Micro SD card.
• Error sending or receiving data over the network.
• Unauthorized access to the camera.
• IP Address Conflict
Advanced Feature
Heat Map Generates a visual representation of data.
2. People Counng and Heat Map can be used concurrently, but the other IVS funcons cannot be used
together with People Counng or Heat Map.
3. People Counng a can be congured in the camera's Web interface as well as via a Dahua NVR.
DH-PFM321D-US
12 VDC, 1 A Power Adapter
PFB302S
Wall Mount
0[TIZOUT(U^ 6URK)UXTKX3U[TZ)GSKXG
Came
6,'+
)KOROTM3U[TZ'JGVZKX =GRR3U[TZ
6,'
6,(9
6,()
6,'
*.6,'+
6,' 6,' 6,'
Mounng Diagram

Produktspezifikationen

Marke: Dahua Technology
Kategorie: Überwachungskamera
Modell: N88BR5V

Brauchst du Hilfe?

Wenn Sie Hilfe mit Dahua Technology N88BR5V benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Überwachungskamera Dahua Technology

Dahua Technology

Dahua Technology Ultra IPC-HF7842F Bedienungsanleitung

8 Oktober 2024
Dahua Technology

Dahua Technology Lite IPC-HDW1320S Bedienungsanleitung

4 Oktober 2024
Dahua Technology

Dahua Technology Ultra IPC-HF7442F-FR Bedienungsanleitung

4 Oktober 2024
Dahua Technology

Dahua Technology SD49225T-HN-W Bedienungsanleitung

23 September 2024
Dahua Technology

Dahua Technology DH-HAC-HDW1230T-Z Bedienungsanleitung

22 September 2024
Dahua Technology

Dahua Technology Pro HAC-HFW2221SP-0280B Bedienungsanleitung

17 September 2024
Dahua Technology

Dahua Technology SD5A825GA-HNR Bedienungsanleitung

15 September 2024
Dahua Technology

Dahua Technology SDT5X425-4Z4-QA-2812 Bedienungsanleitung

13 September 2024
Dahua Technology

Dahua Technology Pro PTZ12240-LR8-N Bedienungsanleitung

11 September 2024
Dahua Technology

Dahua Technology Pro HAC-HFW2231BP-0360B Bedienungsanleitung

10 September 2024

Bedienungsanleitung Überwachungskamera

Neueste Bedienungsanleitung für -Kategorien-

Trebs

Trebs CCD-401C Bedienungsanleitung

15 Oktober 2024
D-Link

D-Link DCS-7510 Bedienungsanleitung

15 Oktober 2024
Foscam

Foscam FI9900EP Bedienungsanleitung

14 Oktober 2024
Alecto

Alecto DVC-215IP Bedienungsanleitung

14 Oktober 2024
Hikvision

Hikvision DS-2CD2326G2-IU Bedienungsanleitung

13 Oktober 2024
Hikvision

Hikvision DS-2TD2166-15/V1 Bedienungsanleitung

13 Oktober 2024
Hikvision

Hikvision DS-2DE7A245IX-AE/S1 Bedienungsanleitung

13 Oktober 2024
Hikvision

Hikvision DS-2CD7A26G0-IZ(H)SY Bedienungsanleitung

11 Oktober 2024
Hikvision

Hikvision DS-2CE79DF8T-AZE Bedienungsanleitung

11 Oktober 2024
Hikvision

Hikvision DS-2XM6726G0-I(D)(S)(M)(/ND) Bedienungsanleitung

11 Oktober 2024
