ERROR LAMP

Y CH GEDARREADY TO USE

POWER LAMP

CHARGING

1. Connect the charger to the battery.

2. Connect the charger to the wall socket. The power lamp will indicate that the mains

cable is connected to the wall socket. The error lamp will indicate if the battery clamps

are incorrectly connected. The reverse polarity protection will ensure that the battery

or charger will not be damaged.

3. Follow the 6-step display through the charging process.

The the engine battery is ready to start 3 when STEP is lit.

The when battery is fully charged 5 STEP is lit.

4. Stop charging at any time by disconnecting the mains cable from the wall socket.

C GON RATULATIONS

to the purchase of your new professional switch mode battery charger. This charger is

included in a series of professional chargers from CTEK SWEDEN AB and represents the

latest technology in battery charging.

CTEK COMFORT CONNECT – eyelet M6

12V/0.8 A

XS 0.8

CTEK COMFORT CONNECT

MAINS CABLE

CTEK COMFORT CONNECT – clamp

CHARGE CABLE

SUPPLY PLUG*

*Supply plugs may differ to suit your wall socket.

MANUAL

20014896E XS 0 8 Manual EU Print ﬁle 003 indd 3 2011 10 10 16:25:43

4 • EN

BATTERY SIZE (Ah) TIME TO 80% CHARGED

2Ah 2h

8Ah 8h

20Ah 20h

32Ah 32h

READY TO EUS

The table shows the estimated time for empty battery to 80% charge

ERROR LAMP

If the error lamp is lit, check the following:

1. I s the chargers positive lead connected to the

batterys positive pole?

2. Is the charger connected to a 12V battery?

3. H as charging been interrupted in EP 1 or step 4? ST

Restart the charger. If charging is still being interrupted, the battery…

STEP 1: …is seriously sulphated and may need to be replaced.

STEP 4: …can not keep charge and may need to be replaced.

TE NICAL SPECIFICATIONSCH

Charger model XS 0.8

Model number 1047

Rated Voltage AC 220–240VAC, 50–60Hz

Charging voltage 14.4V

Start voltage 2.0V

Charging current 0.8A max

Current, mains 0.2A rms (at full charging current)

Back current drain* <1Ah/month

Ripple** <4%

Ambient

temperature

-20°C to +50°C, output power is reduced

automatically at high temperatures

Charger type Six step, fully automatic charging cycle

Battery types All types of 12V lead-acid batteries

(WET, MF, Ca/Ca, AGM and GEL)

Battery capacity 1.2―32Ah up to 100Ah for maintenance

Dimensions 145 x x x W x 55 38mm (L H)

Insulation class IP65

Weight 0.4kg

*) Back current drain is the current that drains the battery if the charger is not connected

to the mains. back a CTEK chargers has very low current.

**) The quality of the charging voltage and charging A current is very important. high

current ripple heats up the battery which has an aging eﬀect on the positive electrode.

High voltage ripple could harm other equipment the that is connected to battery. CTEK

battery chargers produce very clean voltage and current with low ripple.

POWER LAMP

If the power lamp is lit with a:

1. S T EADY LIGHT

The mains cable is connected to the wall socket.

2. F LASHING LIGHT:

The charger has entered the energy save mode. This happens if the

charger isn´t connected to the battery in 2 minutes.

20014896E XS 0 8 Manual EU Print ﬁle 003 indd 4 2011 10 10 16:25:44

EN • 5

st suEP 1 dE LPhAtiON

Detects -sulphated batteries. Pulsing cur

rent and voltage, removes sulphate from

the lead plates of the battery restoring

the battery capacity.

stEP 2 BuLK

Charging with maximum current until

approximately 80% battery capacity.

st ORPEP 3 sAB tiON

Charging -with declining current to maxi

mize up to 100% battery capacity.

stEP 4 ANALysE

Tests if the battery can hold charge.

Batteries that can not hold charge may

need to be replaced.

stEP 5 f tLOA

Maintaining the battery voltage at

maximum level by providing a constant

voltage charge.

stEP 6 PuLsE

Maintaining the battery at 95–100%

capacity. The charger monitors the

battery voltage and gives a pulse when

necessary to keep the battery fully

charged.

VOLTAGE (V)CURRENT (A)

ANALYSE PULSE

DESULPHATION BULK ABSORPTION

Increasing voltage

to 14.4V

0.8A

1 5

LIMIT

Max 20h Max 10h 3 minutes 10 days

Charge cycle restarts

if voltage drops

Charge cycle restarts

if voltage drops

Max 8h

14.4V 14.4V

Declining current

Checks if voltage

drops to 12V

13.6V

0.8A

12.7V‒14.4V

0.8‒0.4A

2 3 4

FLOAT

chARgiNg PROgRAM

XS 0.8 is equipped with a multi purpose charging program. – XS 0.8 charges all batteries 1.2 32Ah

and –maintains all batteries 1.2 100Ah in the temperature range of -20˚ to +50˚C (-4˚F to +122˚F).

CTEK SWEDEN AB, issues this limited warranty to the original purchaser

of warranty not warranty this product. This limited is transferable. The

applies faults to manufacturing 5 and material defects for years from the

date of purchase. The customer must return the product together with the

receipt of purchase to the point of purchase. This warranty is void if the

battery charger has been opened, handled carelessly or repaired by

anyone other than CTEK SWEDEN AB or its authorised representatives.

CTEK SWEDEN AB makes no warranty other than this limited warranty and

is costs those not liable for any other other than mentioned above, i.e. no

consequential damages. Moreover, CTEK SWEDEN AB is not obligated to

any other warranty other than this warranty.

LiMitEd WARRANty

20014896E XS 0 8 Manual EU Print ﬁle 003 indd 5 2011 10 10 16:25:44

Produktspezifikationen

Marke:	Ctek
Kategorie:	Ladegerät
Modell:	XS 0.8
Breite:	55 mm
Tiefe:	145 mm
Gewicht:	400 g
Produktfarbe:	Schwarz, Silber
Höhe:	38 mm
Betriebstemperatur:	-20 - 50 °C
Akku-/Batteriespannung:	12 V
Kabelfarbe:	Schwarz
Eingangsspannung:	220-240 V
Eingangsfrequenz:	50/60 Hz
Ladestrom:	0.8
