The ULTIMATEASUB10-B-T-EACH active subwoofer made by Origin
Acoustics delivers exceptional low-end frequency extension for
demanding residential installations.
In
In
In
InIn the
the
the
thethe Box
Box
Box
BoxBox
1 ULTIMATEASUB10-B-T-EACH
Additional
Additional
Additional
AdditionalAdditional Items
Items
Items
ItemsItems
6 RCA Cable with 90° Angle Connectors
4 Wall Screws
4 Drywall Anchors
4 Round Rubber Feet
2 Elongated Rubber Feet
1 Wall Mount Plate
Installation
Installation
Installation
InstallationInstallation
Connections
Connections
Connections
ConnectionsConnections
NOTE
NOTE
NOTE
NOTENOTE: Gently pull away the grille from the surface of the subwoofer,
make the connections and then reattach the grille to the front
surface of the subwoofer. Refer to the section Reattach the Grille
for more information.
Mandatory
Mandatory
Mandatory
MandatoryMandatory Connections
Connections
Connections
ConnectionsConnections:
1. Connect the analog unbalanced line level audio connection from the
source to LINE IN RCA connector via RCA cable.
2. Connect the IEC power cable to A/C power.
Optional
Optional
Optional
OptionalOptional Connections
Connections
Connections
ConnectionsConnections:
1. Setthe TRIGGER/AUTO switch to TRIGGER. Then, connect the
TRIGGER input to the +12Vtrigger output of the audio source device.
2. Connect the parallel LINE OUT RCA connector to an additional
subwoofer via RCA cable for an extra bass enhancement.
3. Connect the right-angle USB +5V power connection to the optional
wireless signal extension kit.
ULTIMATE
ULTIMATE
ULTIMATE
ULTIMATEULTIMATEASUB10-B-T-EACH
ASUB10-B-T-EACH
ASUB10-B-T-EACH
ASUB10-B-T-EACHASUB10-B-T-EACH QuickStart
Ultimate
Ultimate
Ultimate
UltimateUltimate 10
10
10
1010 in.
in.
in.
in.in. Active
Active
Active
ActiveActive Subwoofer,
Subwoofer,
Subwoofer,
Subwoofer,Subwoofer, Black
Black
Black
BlackBlack Textured,
Textured,
Textured,
Textured,Textured, Single
Single
Single
SingleSingle
1
1
1
11
Attach
Attach
Attach
AttachAttach the
the
the
thethe Mounting
Mounting
Mounting
MountingMounting Feet
Feet
Feet
FeetFeet
Follow the procedure to attach either set of the included mounting feet
to the subwoofer:
lIf using the elongated, channeled feet for standing the subwoofer up
vertically:
Route the power cable and the RCA cables each through the channels
on their respective feet. Then press the feet onto the bottom edge of
the subwoofer at their respective silkscreen hashmarks to secure
them in place.
lIf using the four rounded feet to lie the subwoofer on its back surface
horizontally:
Screw the four included posts into each of their respective holes at
each corner of the back surface of the subwoofer. Once all four posts
are screwed into place, cover each post with a rubberfoot.
lIf using the four rounded feet to lie the subwoofer on its front
surface:
Remove the grille from the posts that are already installed and then
cover those posts with the rounded feet.
Wall
Wall
Wall
WallWall Mount
Mount
Mount
MountMount
Follow the procedure to mount the subwoofer to a wall:
1. Hold the included mounting bracket against the wall and use a pencil
to lightly mark the position of the screw holes.
2. Drill holes at the marked screw hole locations and install the four
included drywall anchors.
3. Secure the mounting bracket to the wall using the screws.
4. Screw the four included posts into each of their respective holes at
each corner of the back surface of the subwoofer.
5. Hang the subwoofer on the mounting bracket by fitting the posts
into their respective holes in the bracket.
Reattach
Reattach
Reattach
ReattachReattach the
the
the
thethe Grille
Grille
Grille
GrilleGrille
Follow the procedure to reattach the grille to the front surface of the
subwoofer.
1. Place the grille over the front surface of the subwoofer so all the
openings in the columns at each corner of the grille align with their
respective posts.
2. Gently press the grille into place, applying pressure at the corners
over where the posts from the subwoofer will slide into the columns
of the grille. It avoids warping the grille as you push it towards the
subwoofer.
2
2
2
22
ULTIMATE
ULTIMATE
ULTIMATE
ULTIMATEULTIMATEASUB10-B-T-EACH
ASUB10-B-T-EACH
ASUB10-B-T-EACH
ASUB10-B-T-EACHASUB10-B-T-EACH QuickStart
Ultimate
Ultimate
Ultimate
UltimateUltimate 10
10
10
1010 in.
in.
in.
in.in. Active
Active
Active
ActiveActive Subwoofer,
Subwoofer,
Subwoofer,
Subwoofer,Subwoofer, Black
Black
Black
BlackBlack Textured,
Textured,
Textured,
Textured,Textured, Single
Single
Single
SingleSingle
Set
Set
Set
SetSet the
the
the
thethe Switches
Switches
Switches
SwitchesSwitches and
and
and
andand Knobs
Knobs
Knobs
KnobsKnobs
The following section provides information on how to use the switches
and knobs.
lUse the POWER switch to toggle between OFF and ON/STANDBY.
lOn the TRIGGER/AUTO switch,
oTRIGGER/AUTO set to TRIGGER – the unit will turn ON from
STANDBY when the +12V trigger is detected.
or
oTRIGGER/AUTO set to AUTO – the unit will turn ON from
STANDBY when the signal at the LINE IN connection passes the
signal detection threshold.
lUse the POLARITY switch for applications where the subwoofer is
facing in a direction opposite to the other driversin the listening
environment.
oPOLARITY set to 0 degrees – the polarity of the incoming input
signal is maintained at the output of the subwoofer.
or
oPOLARITY set to 180 degrees – the polarity of the incoming input
signal is inverted at the output of the subwoofer.
lUse the LFE/CROSSOVER switch to determine whether the
subwoofer’s internal crossover should be included in the signal chain.
oLFE/CROSSOVER set to LFE – the internal crossover is not
included in the signal chain and the input signal must be filtered
using an external Low Pass processor.
oLFE/CROSSOVER set to CROSSOVER – the internal crossover is
included in the signal chain and whatever frequency is selected on
the CROSSOVER knob will be the center frequency for this Low
Pass.
lUse the CROSSOVER knob to select the rolloff frequency of the low-
pass filter for when the LFE/CROSSOVER switch is set to
CROSSOVER.
Test out various values on this knob (in conjunction with the VOLUME
knob) to achieve the optimal low end response for the acoustic
environment on site.
lUse the VOLUME knob to set the output level of the subwoofer.
Power
Power
Power
PowerPower the
the
the
thethe Unit
Unit
Unit
UnitUnit On
On
On
OnOn
The following section provides information on how to use Power switch.
lThe power switch will put the unit into either an ON/STANDBY or an
OFF state.
lIn ON/STANDBY, the subwoofer will change state depending on the
setting of the TRIGGER/AUTO switch.
On the TRIGGER/AUTO switch,
oTRIGGER/AUTO set to TRIGGER – the unit will turn ON from
STANDBY when the +12V trigger is detected.
or
oTRIGGER/AUTO set to AUTO – the unit will turn ON from
STANDBY when the signal at the LINE IN connection passes the
signal detection threshold.
3
3
3
33
ULTIMATE
ULTIMATE
ULTIMATE
ULTIMATEULTIMATEASUB10-B-T-EACH
ASUB10-B-T-EACH
ASUB10-B-T-EACH
ASUB10-B-T-EACHASUB10-B-T-EACH QuickStart
Ultimate
Ultimate
Ultimate
UltimateUltimate 10
10
10
1010 in.
in.
in.
in.in. Active
Active
Active
ActiveActive Subwoofer,
Subwoofer,
Subwoofer,
Subwoofer,Subwoofer, Black
Black
Black
BlackBlack Textured,
Textured,
Textured,
Textured,Textured, Single
Single
Single
SingleSingle
