SAROS IC8LPT
Saros® Low-Profile 8” 2-Way In-Ceiling Speaker
crestron.com | 800.237.2041
>High-performance, low-profile 2-way in-ceiling speaker
>Requires only 5-1/8” (130 mm) mounting depth
>8” polypropylene woofer with damped cloth surround
for tight, controlled bass and clear midrange
>Optimized dual front ports for enhanced
low-frequency response
>Wide-dispersion, horn-loaded titanium dome
tweeter for crisp, clear high-end and enhanced
pattern control
>Built-in 60 Watt 70/100V multi-tap transformer
>“Zero-bezel” frameless grille for a clean,
contemporary appearance
>Integral metal back can with side-entry cable clamp
>Two-step swiveling dog mounting system for quick and
easy installation
>Includes tile bridge for installation in a drop-tile ceiling
>Meets the requirements of UL® 2043 for installation in an
environmental air-handling space
>50 Watts program power handling at 8 Ohms
>65 Hz - 20 kHz frequency response
>95° nominal coverage pattern
>Available in black or white
>Paintable to blend with surroundings
Saros® speakers by Crestron® deliver professional grade performance and
flexible installation in a range of popular sizes for demanding commercial
applications. Solid construction, easy installation, and high-end
components are hallmarks of the Saros speaker line. Ideal for use in
background or foreground music, paging, and sound reinforcement
systems, Saros speakers are engineered to achieve smooth, even
coverage, high output, and clear, natural sound quality through the
employment of horn-loaded titanium dome tweeters, high-efficiency
damped cone woofers, ported enclosures, and precisely tuned crossovers.
The Saros IC8LPT model is a 2-way in-ceiling speaker featuring an 8 inch
woofer and wide-dispersion, horn-loaded 1 inch dome tweeter. Its low-
profile enclosure allows for installation in constricted ceiling spaces as
shallow as 5-1/8 inches (130 mm). A built-in 60 Watt multi-tap transformer
allows for use with 70 and 100 Volt distributed speaker systems. Power
handling at 8 Ohms is 50 Watts (program), with a frequency response from
65 Hz to 20 kHz (±3 dB).
The Saros IC8LPT is smartly designed for quick and easy installation and
years of reliable performance. Its “zero-bezel” frameless grille achieves
an unobtrusive and contemporary appearance well-suited for use in
restaurants and night clubs, retail spaces, houses of worship, convention
facilities, universities, and office buildings. Installing the grille requires no
hardware or tools, utilizing powerful magnets to hold it in place. A safety
tether is included to prevent the grille from ever falling from the ceiling.
Unitized construction of the speaker enclosure simplifies specification and
installation for use in new and existing ceilings. Mounting the speaker is
facilitated using rugged, 2-step swiveling dogs integrated into the
enclosure. The mounting dogs feature two positions to accommodate
standard and extra thick surfaces up to 2.4 inches (61 mm). A tile bridge
is included to provide proper support when installed in a typical drop-tile
ceiling. The tile bridge is adjustable to enable off-center speaker
positioning, and can be folded to fit through the speaker cutout in blind-
mount situations. Two rigging points are also provided on the side of the
speaker enclosure for securing to the building structure using the optional
safety tether kit (SPKA-ST-15
[1]).
An integral metal back can is employed to meet the requirements of
UL® 2043 for installation in an environmental air-handling (plenum) space.
The wiring connection is accessible behind a rear cover panel by removing
a single screw. Wiring enters through a side-mounted cable clamp
attached to the cover panel. Connecting the wiring behind the cover panel
is facilitated using a detachable screw terminal block with provisions for
easy parallel wiring in a multi-speaker application. Setting the 70/100V
transformer tap is performed via a screwdriver-adjustable control located
on the front baffle behind the grille.
Saros IC8LPT speakers are available in white or black, and can be painted
to blend with the ceiling surface. They are priced individually, but must be
ordered in pairs.
SAROS IC8LPT Saros
®
Low-Profile 8” 2-Way In-Ceiling Speaker
crestron.com | 800.237.2041
SPECIFICATIONS
Features & Performance
Woofer: 8 inch (203 mm) polypropylene w/ring mode decoupled cloth
surround & steel basket
Tweeter: 0.98 inch (25 mm) titanium dome, horn loaded
Crossover Frequency: 2.5 kHz
Impedance: 8 Ohms nominal with transformer set to “8Ω”
Transformer Taps: 3.75W/7.5W/15W/30W/60W at 70V;
7.5W/15W/30W/60W at 100V
Frequency Response: 65 Hz to 20 kHz (±3 dB)
Frequency Range: 55 Hz to 20 kHz (-10 dB)
Power Handling: 50 Watts program (8 Ohms)
Sensitivity: 90 dB @ 1W/1m
Coverage: 95° conical (nominal)
Connections
Input: (1) 4-pin 5 mm detachable terminal block with screw-down flanges;
Speaker input with parallel pass-thru;
Maximum Wire Size: 12 AWG
Controls
Transformer Tap: (1) Recessed screwdriver-adjustable rotary switch on
baffle;
Used to select 70/100V tap or 8 Ohms (bypass)
Environmental
Temperature: -2° to 120° F (-19° to 49° C)
Humidity: 5% to 95% RH (non-condensing)
Construction
Enclosure: Zinc-plated steel, plenum-rated, side-entry cable clamp
Baffle: ABS UL 94V-0 plastic
Grille: Steel with white or black textured finish, paintable, magnetically-
held “zero-bezel” frameless design, safety tether included
Mounting: Flush ceiling mount using 4 integral 2-step swiveling dogs,
2.4 in (61 mm) maximum surface thickness, 5.2 in (130 mm) minimum
mounting depth, 11.2 in (285 mm) diameter recommended cutout, tile
bridge included, (2) rigging points for safety tether (SPKA-ST-15 sold
separately)
Dimensions
Diameter: 12.13 in (308 mm) not including mounting dogs
Depth: 5.30 in (135 mm)
Weight
11.2 lb (5.0 kg)
Compliance
UL 1480, UL 1480A, UL 2043 [2]
MODELS & ACCESSORIES
Available Models
SAROS IC8LPT-B-T-EACH: Saros® Low-Profile 8” 2-Way In-Ceiling
Speaker, Black Textured, Single (must be ordered in multiples of 2)
SAROS IC8LPT-W-T-EACH: Saros® Low-Profile 8” 2-Way In-Ceiling
Speaker, White Textured, Single (must be ordered in multiples of 2)
Available Accessories
SPKA-ST-15: Safety Tether/Tie Down Kits
SPKA-NCTP-IC810: New-Construction Speaker Templates, Flat
SPKA-NCTP-IC811: New-Construction Speaker Templates, Collared
SPKA-GRILLE-IC810: Round Grilles (for replacement)
SAROS ICS8T: Saros® 8” In-Ceiling Subwoofer
Notes:
1. Item(s) sold separately.
2. UL 1480 speakers for fire alarm and signaling systems in the United States, in accordance
with the National Electrical Code, NFPA 70, and the National Fire Alarm and Signaling Code,
NFPA 72. In Canada, in accordance with CSA C22.1, Canadian Electrical Code, Part I, Safety
Standard for Electrical Installations; and with CAN/ULC S524, Standard for Installation of Fire
Alarm Systems. UL 2043 in accordance with the Standards for Fire Test for Heat and Visible
Smoke Release for Discrete Products and Accessories Installed in Air-Handling Spaces,
UL 2043 and ULC ORD-C2043.
Crestron warrants to the original end purchaser that this Crestron Speaker Product, when
purchased directly from Crestron or an authorized Crestron Dealer, will be free from defects in
material and workmanship for the life of the product except for speaker grills and outdoor rated
speakers, which are warranted for five (5) years. Crestron will at its option and expense either
repair the defect or replace the Speaker Product with a new or remanufactured Product or a
reasonable equivalent. In cases where a new model is substituted, a modification to the mounting
surface may be required. If mounting surface modification is required, Crestron assumes no
responsibility or liability for such modifications.
This product may be purchased from an authorized Crestron dealer. To find a dealer, please
contact the Crestron sales representative for your area. A list of sales representatives is available
online at www.crestron.com/salesreps or by calling 800-237-2041.
The specific patents that cover Crestron products are listed online at: .patents.crestron.com
Certain Crestron products contain open source software. For specific information, please visit
www.crestron.com/opensource.
Crestron, the Crestron logo, and Saros are either trademarks or registered trademarks of Crestron
Electronics, Inc. in the United States and/or other countries. UL is either a trademark or registered
trademark of UL LLC in the United States and/or other countries. Other trademarks, registered
trademarks, and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Crestron disclaims any proprietary interest in the marks
and names of others. Crestron is not responsible for errors in typography or photography.
Specifications are subject to change without notice. ©2017 Crestron Electronics, Inc.
SAROS IC8LPT Saros
®
Low-Profile 8” 2-Way In-Ceiling Speaker
Crestron Electronics, Inc. 15 Volvo Drive | Rockleigh, NJ 07647
Tel: 800.237.2041 / 201.767.3400 | Fax: 201.767.1903
www.crestron.com
All brand names, product names and trademarks are the property of their respective owners.
©2017 Crestron Electronics, Inc.
Specifications subject to change without notice. Revised 11/11/17
