SAROS IC6LPT Series
Saros® Low-Profile 6.5” 2-Way In-Ceiling Speaker
crestron.com | 800.237.2041
>High-performance, low-profile 2-way in-ceiling speaker
>Requires only 5-1/8” (130 mm) mounting depth
>6.5” polypropylene woofer with damped cloth
surround for tight, controlled bass and clear midrange
>Optimized dual front ports for enhanced
low-frequency response
>Wide-dispersion, horn-loaded titanium dome
tweeter for crisp, clear high-end and enhanced
pattern control
>Built-in 60 Watt 70/100V multi-tap transformer
>“Zero-bezel” frameless grille for a clean,
contemporary appearance
>Integral metal back can with side-entry cable clamp
>Two-step swiveling dog mounting system for quick and
easy installation
>Includes tile bridge for installation in a drop-tile ceiling
>Meets the requirements of UL® 2043 for installation in an
environmental air-handling space
>50 Watts program power handling at 8 Ohms
>65 Hz - 20 kHz frequency response
>95° nominal coverage pattern
>Easy commissioning using pre-configured channel strip for
Crestron Avia™ DSP
>Available in black or white
>Paintable to blend with surroundings
Saros® speakers by Crestron® deliver professional grade performance and
flexible installation in a range of popular sizes for demanding commercial
applications. Solid construction, easy installation, and high-end components
are hallmarks of the Saros speaker line. Ideal for use in background or
foreground music, paging, and sound reinforcement systems, Saros speakers
are engineered to achieve smooth, even coverage, high output, and clear,
natural sound quality through the employment of horn-loaded titanium
dome tweeters, high-efficiency damped cone woofers, ported enclosures,
and precisely tuned crossovers. Fast and easy commissioning is afforded
using pre-configured channel strips for Crestron Avia
™ DSP.
The Saros IC6LPT series are 2-way in-ceiling speakers that feature a
6-1/2 inch woofer and wide-dispersion, horn-loaded 1 inch dome tweeter.
Their low-profile enclosures allow for installation in constricted ceiling
spaces as shallow as 5-1/8 inches (130 mm). A built-in 60 Watt multi-tap
transformer allows for use with 70 and 100 Volt distributed speaker
systems. Power handling at 8 Ohms is 50 Watts (program), with a
frequency response from 65 Hz to 20 kHz (±3 dB).
Saros IC6LPT series speakers are smartly designed for quick and easy
installation and years of reliable performance. They feature a “zero-bezel”
frameless grille that achieves an unobtrusive and contemporary appearance
well-suited for use in restaurants and night clubs, retail spaces, houses of
worship, convention facilities, universities, and office buildings. Installing
the grille requires no hardware or tools, utilizing powerful magnets to hold
it in place. A safety tether is included to prevent the grille from ever falling
from the ceiling.
Unitized construction of the speaker enclosure simplifies specification and
installation for use in new and existing ceilings. Mounting the speaker is
facilitated using rugged, 2-step swiveling dogs integrated into the enclosure.
The mounting dogs feature two positions to accommodate standard and
extra thick surfaces up to 2.4 inches (61 mm). A tile bridge is included to
provide proper support when installed in a typical drop-tile ceiling. The tile
bridge is adjustable to enable off-center speaker positioning, and can be
folded to fit through the speaker cutout in blind-mount situations. Two
rigging points are also provided on the side of the speaker enclosure for
securing to the building structure using the optional safety tether kit
(SPKA-ST-15 [1]).
An integral metal back can is employed to meet the requirements of
UL® 2043 for installation in an environmental air-handling (plenum) space.
The wiring connection is accessible behind a rear cover panel by removing
a single screw. Wiring enters through a side-mounted cable clamp attached
to the cover panel. Connecting the wiring behind the cover panel is facilitated
using a detachable screw terminal block with provisions for easy parallel
wiring in a multi-speaker application. Setting the 70/100V transformer
tap is performed via a screwdriver-adjustable control located on the front
baffle behind the grille.
Saros IC6LPT speakers are available in white or black, and can be painted
to blend with the ceiling surface. They are priced individually, but must be
ordered in pairs.
SAROS IC6LPT Series Saros
®
Low-Profile 6.5” 2-Way In-Ceiling Speaker
crestron.com | 800.237.2041
SPECIFICATIONS
Features & Performance
Woofer: 6.5 inch (165 mm) polypropylene w/ring mode decoupled cloth
surround & steel basket
Tweeter: 0.98 inch (25 mm) titanium dome, horn loaded
Crossover Frequency: 2.5 kHz
Impedance: 8 Ohms nominal with transformer set to “8Ω”
Transformer Taps: 3.75W/7.5W/15W/30W/60W at 70V;
7.5W/15W/30W/60W at 100V
Frequency Response: 65 Hz to 20 kHz (±3 dB)
Frequency Range: 55 Hz to 20 kHz (-10 dB)
Power Handling: 50 Watts program (8 Ohms)
Sensitivity: 88 dB @ 1W/1m
Coverage: 95° conical (nominal)
Connections
Input: (1) 4-pin 5 mm detachable terminal block with screw-down flanges;
Speaker input with parallel pass-thru;
Maximum Wire Size: 12 AWG (4 mm2)
Controls
Transformer Tap: (1) Recessed screwdriver-adjustable rotary switch
on baffle; Used to select 70/100V tap or 8 Ohms (bypass)
Environmental
Temperature: -2° to 120° F (-19° to 49° C)
Humidity: 5% to 95% RH (non-condensing)
Construction
Enclosure: Zinc-plated steel, plenum-rated, side-entry cable clamp
Baffle: ABS UL 94V-0 plastic
Grille: Steel with white or black textured finish, paintable, magnetically-
held “zero-bezel” frameless design, safety tether included
Mounting: Flush ceiling mount using 4 integral 2-step swiveling dogs,
2.4 in (61 mm) maximum surface thickness, 5.2 in (130 mm) minimum
mounting depth, 9.7 in (245 mm) diameter recommended cutout, tile
bridge included, (2) rigging points for safety tether (SPKA-ST-15 sold
separately)
Dimensions
Diameter: 10.64 in (270 mm) not including mounting dogs
Depth: 5.30 in (135 mm)
Weight
8.2 lb (3.7 kg)
Compliance
UL Listed for US & Canada, CE, FCC Part 15 Class B, UL 1480, UL 1480A,
UL 2043 [2]
MODELS & ACCESSORIES
Available Models
SAROS IC6LPT-B-T-EACH: Saros® Low-Profile 6.5” 2-Way In-Ceiling
Speaker, Black Textured, Single (must be ordered in multiples of 2)
SAROS IC6LPT-W-T-EACH: Saros® Low-Profile 6.5” 2-Way In-Ceiling
Speaker, White Textured, Single (must be ordered in multiples of 2)
Available Accessories
SPKA-ST-15: Safety Tether/Tie Down Kits
SPKA-NCTP-IC610: New-Construction Speaker Templates, Flat
SPKA-NCTP-IC611: New-Construction Speaker Templates, Collared
SPKA-GRILLE-IC610 Series: Round Grilles (for replacement)
SAROS ICS8T Series: Saros® 8” In-Ceiling Subwoofers
DSP Series: Crestron Avia™ Digital Signal Processors
AMP-8000 Series: Crestron Avia™
8-Channel Power Amplifiers, 4/8 Ohm
or 70V, North America & Japan, 100-120V
AMPI-8000 Series: Crestron Avia™
8-Channel Power Amplifiers, 4/8 Ohm
or 100V, International, 220-240V
AMP-150/225/1200/2100 Series: Modular Power Amplifiers, 4/8 Ohm,
70V, or 100V
Notes:
1. Item(s) sold separately.
2. UL 1480 speakers for fire alarm and signaling systems in the United States, in accordance
with the National Electrical Code, NFPA 70, and the National Fire Alarm and Signaling Code,
NFPA 72. In Canada, in accordance with CSA C22.1, Canadian Electrical Code, Part I, Safety
Standard for Electrical Installations; and with CAN/ULC S524, Standard for Installation of Fire
Alarm Systems. UL 2043 in accordance with the Standards for Fire Test for Heat and Visible
Smoke Release for Discrete Products and Accessories Installed in Air-Handling Spaces,
UL 2043 and ULC ORD-C2043.
Crestron warrants to the original end purchaser that this Crestron Speaker Product, when
purchased directly from Crestron or an authorized Crestron Dealer, will be free from defects in
material and workmanship for the life of the product except for speaker grills and outdoor rated
speakers, which are warranted for five (5) years. Crestron will at its option and expense either
repair the defect or replace the Speaker Product with a new or remanufactured Product or a
reasonable equivalent. In cases where a new model is substituted, a modification to the mounting
surface may be required. If mounting surface modification is required, Crestron assumes no
responsibility or liability for such modifications.
This product may be purchased from an authorized Crestron dealer. To find a dealer, please contact
the Crestron sales representative for your area. A list of sales representatives is available online at
https://www.crestron.com/How-To-Buy/Find-a-Representative or by calling 855-263-8754.
The specific patents that cover Crestron products are listed online at
https://www.crestron.com/legal/patents.
Certain Crestron products contain open source software. For specific information, visit
https://www.crestron.com/opensource.
Crestron, the Crestron logo, Crestron Avia, and Saros are either trademarks or registered
trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Dante is
either a trademark or registered trademark of Audinate Pty Ltd. in the United States and/or other
countries. UL is either a trademark or registered trademark of UL LLC in the United States and/or
other countries. Other trademarks, registered trademarks, and trade names may be used in this
document to refer to either the entities claiming the marks and names or their products. Crestron
disclaims any proprietary interest in the marks and names of others. Crestron is not responsible
for errors in typography or photography. Specifications are subject to change without notice.
©2018 Crestron Electronics, Inc.
SAROS IC6LPT Series Saros
®
Low-Profile 6.5” 2-Way In-Ceiling Speaker
Crestron Electronics, Inc. 15 Volvo Drive | Rockleigh, NJ 07647
Tel: 800.237.2041 / 201.767.3400 | Fax: 201.767.1903
www.crestron.com
All brand names, product names and trademarks are the property of their respective owners.
©2018 Crestron Electronics, Inc.
Specifications subject to change without notice. Revised 06/17/18
