ESSENCE IW8
Essence® 8” 2-Way In-Wall Speakers
crestron.com | 800.237.2041
>Ultimate performance 2-way in-wall speakers
>8” woven Kevlar® woofers
>1.1” advanced synthetic polymer dome tweeters
>Precision 4th order crossovers
>Cast aluminum woofer baskets
>Extra large magnets and vented pole pieces
>“Zero-bezel” frameless steel grilles, paintable
>Spring-loaded toggle clamp mounting system
>175 Watts program power handling
>38Hz-20kHz frequency response
>8 Ohms nominal impedance
>Sold in pairs
The product of expert Crestron
® audio engineering, Essence®
speakers deliver the pinnacle of performance for demanding
residential installations. Select esoteric materials, top shelf
components and a refined, high-end appearance underscore the
meticulous design behind each model. The result is a complete line
of in-wall and in-ceiling speakers worthy of a place in every room
of the finest custom home.
The Essence line promises the ultimate in installed audio design,
delivering simply stunning sound quality while minimizing any impact on
your decor thanks to paintable zero-bezel grilles. Streamlined installation
of each speaker is facilitated through a spring-loaded toggle clamp
mounting system.
The Essence IW8 model provides a pair of 2-way in-wall speakers
featuring 8 inch long-throw woven Kevlar® woofers for deep, defined low
end, and large 1.1 inch advanced synthetic polymer dome tweeters for
crisp, fluent highs, articulate midrange, and consistent coverage across a
wider listening area. Cast aluminum woofer baskets assure pure,
uncolored bass response. Precision 4th order crossovers utilizing the
highest quality components ensure a full, rich and detailed response
across the spectrum. Power handling is an impressive 175 Watts
(program), with a wide frequency response from 38 Hz to 20 kHz (±3 dB).
SPECIFICATIONS
Features & Performance
Woofer: 8 inch (203 mm) woven Kevlar® w/rubber surround, vented pole
piece & cast aluminum basket
Tweeter: 1.1 inch (28 mm) advanced synthetic polymer dome, ferrofluid
cooling, damped aperiodic rear chamber
Crossover: 4th order Linkwitz-Riley
Crossover Frequency: 2 kHz
Impedance: 8 Ohms nominal
Frequency Response: 38 Hz to 20 kHz (±3 dB)
Frequency Range: 30 Hz to 20 kHz (-10 dB)
Power Handling: 175 Watts program
Sensitivity: 91.5 dB @ 1W/1m
Connections
Input: (2) spring terminals;
Maximum Wire Size: 10 AWG
Environmental
Temperature: 41° to 104°F (5° to 40°C)
Humidity: 10% to 90% RH (non-condensing)
For indoor use only
Construction
Baffle: ABS plastic, black
Grille: Steel with white textured finish, paintable, magnetically-held “zero-
bezel” frameless design
Mounting: Flush wall mount using 6 integral spring-loaded toggle clamps,
1.35 in (34 mm) maximum surface thickness, 4.33 in (110 mm) minimum
mounting depth, 13.3 in (338 mm) high x 9.8 in (249 mm) wide recom-
mended cutout
Dimensions
Height: 13.91 in (354 mm)
Width: 10.45 in (266 mm)
Depth: 4.50 in (115 mm)
Dimensions shown are per speaker, positioned vertically
Weight
7.54 lb (3.42 kg) per speaker
ESSENCE IW8 Essence
®
8” 2-Way In-Wall Speakers
Crestron Electronics, Inc. 15 Volvo Drive | Rockleigh, NJ 07647
Tel: 800.237.2041 / 201.767.3400 | Fax: 201.767.1903
www.crestron.com
All brand names, product names and trademarks are the property of their respective owners.
©2014 Crestron Electronics, Inc.
Specifications subject to change without notice. Revised 10/30/14
MODELS & ACCESSORIES
Available Models
ESSENCE IW8-W-T: Essence® 8” 2-Way In-Wall Speakers, White
Textured, Pair
Available Accessories
SPKA-NCTP-IW800: New-Construction Speaker Templates
SPKA-GRILLE-IW803: Grilles (for replacement)
ASPIRE IWS82: Aspire® Dual 8” In-Wall Subwoofer
Notes:
Crestron warrants to the original end purchaser that this Crestron Speaker Product, when
purchased directly from Crestron or an authorized Crestron Dealer, will be free from defects in
material and workmanship for the life of the product except for speaker grills and outdoor rated
speakers, which are warranted for five (5) years. Crestron will at its option and expense either
repair the defect or replace the Speaker Product with a new or remanufactured Product or a
reasonable equivalent. In cases where a new model is substituted, a modification to the mounting
surface may be required. If mounting surface modification is required, Crestron assumes no
responsibility or liability for such modifications.
This product may be purchased from an authorized Crestron dealer. To find a dealer, please
contact the Crestron sales representative for your area. A list of sales representatives is available
online at www.crestron.com/salesreps or by calling 800-237-2041.
The specific patents that cover Crestron products are listed online at: .patents.crestron.com
Crestron , the Crestron logo, and Essence are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Kevlar is either a trademark
or registered trademark of E. I. du Pont de Nemours and Company in the United States and/or
other countries. Other trademarks, registered trademarks, and trade names may be used in this
document to refer to either the entities claiming the marks and names or their products. Crestron
disclaims any proprietary interest in the marks and names of others. Specifications are subject
to change without notice. Crestron is not responsible for errors in typography or photography.
©2014 Crestron Electronics, Inc.
