Before the first using your electric storage water heater, carefully read this operation
manual and pay special attention to paragraphs marked with «Attention» symbol.
Dear customer! Congratulations on your purchase of THERMEX electric water heater. We are
convinced that a wide range of our electric water heaters will satisfy any of your needs. Use of modern
technologies and the highest quality materials when manufacturing devices have contributed to gaining
popularity and trust to THERMEX trade mark.
THERMEX electric water heaters are designed and manufactured in strict accordance with domestic
and international standards guaranteeing reliability and safety of operation.
Present operation manual applies to THERMEX models series IBL, volume 10, 15 liters. In all
models Silver Heat heating element can optionally be installed. The full name of your heater model of
is specified in section “Manufacturer’s Guarantee” (sub-section "Note of sale") and in the
identification plate on the casing of the heater.
1. Application
Water heater (hereinafter EWH) is designed to provide with hot water for welfare and industrial
facilities that have cold water supply main with appropriate characteristics.
EWH shall be operated in closed heated spaces and is not designed for continuous flowing mode.
2. Main technical characteristics

Maximum cold water main pressure – 0.7 MPa

Minimum cold water main pressure – 0.05 MPa

Parameters of the power supply - single-phase network with voltage (220 V ± 10%) and +1% 50
Hz + 1%

Power of tube heater is adjustable in steps:
1.5 kW - save heating mode
2.5 kW - full heating mode (TURBO mode)

Thread diameter of hot and cold water connecting pipes - œ”

Heater protection class - IPX4
EN
Model
Volume
(l)
Average heating
time
=450 , Đą ĐĄ
(.5 kW)
Permanent
subsistence
loss (kWh/24
h)
Actual annual energy
consumption * (*Permanent
subsistence loss) (kW/h)
IBL 10O, 10U 10 16 min. 0,56 204,4
IBL 15O, 15U 15 28 min. 0,69 251,8
3. Scope of supply
1. Water heater ..................................................
1 pc.
2. Pressure relief valve GP type ............................ 1 pc.
3. Operation manual ........................................ 1 pc.
4. Packaging ...........................................................................1 pc.
5. Anchors for fastening.......................................................... 2 PCs. for each clamping bar
2
EN
4. Description and principle of operation
EWH consists of the housing, removable flange, safety valve, protective cover and Control Panel.
4.1.
The housing consists of the outer shell, made of plastic, internal tank, thermal insulated with
environmentally friendly polyurethane foam, and two threaded pipes for cold water inlet (blue ring) and
hot water exhaust (red ring).
Internal tank is made of stainless austenitic stainless steel, which ensures high corrosion resistance
and, as a consequence, long operation life.
4.2.
At the removable flange the following is mounted: tubular heater (HEATER), pipe thermostat.
TEH is used to heat water and thermostat provides with possibility to adjust temperature up to +74°
C (± 5° C). Temperature adjustment is made using adjustment knob located on the water heater
control panel (Fig. 1).
The thermal switch is used to prevent overheating and cut off EWH power when water
temperature exceeds +95° C (± 5° c) (fig. 2). EWH housing can heat inthe course of operation.
Two warning lights (button) located on the control panel (fig. 1) of the water heater next to the
temperature adjustment knob indicate operating mode: "POWER" light is on when the save mode
(1.5 kW), and TURBO light - when the full heating mode (2.5 kW). Switching between the modes is
made by pressing TURBO button, when button pressed "TURBO" mode is on, when released – save
mode. EWH power on/off is carried out by POWER button.
4.3.
Safety valve is back-flow valve preventing ingress of water from the water heater to
water main in case of pressure drop in the latter and in case of pressure increase in the tank
when water is heating up, as well as safety valve, relieving excess pressure in tank when water
is heating up. During water heater operation water may leak out of the exhaust outlet pipe of the
safety valve to relieve excessive pressure, which is made for the purpose of water heater
safety. This outlet pipe shall remain open to the atmosphere and be installed constantly down.
and in a non-freezing environment. You shall ensure drainage of water from exhaust pipe safety
valve into the drain, with installation of the corresponding EWH drainage.
It is required regularly (at least once a month) to discharge a small amount of water through the
exhaust pipe of the safety valve into the drain to remove lime deposits and to test the operating
functionality of the valve. Handle is intended to open the valve. It is necessary to control when
operating water heater this handle to be in position closing water draining from the tank.
5. Specifying security measures
5.1.
Electrical safety and corrosion protection of EWH are guaranteed only if there is an effective
earthing in accordance with applicable electric installation rules and regulations.
5.2.
Plumbing pipes and fittings shall conform to parameters of water main and have the required
certificates of quality.
5.3.
When installing and operating EWH the following is not allowed.
3

To power EWH if EWH is not filled with water.
‱ To remove the protective cover when the power is on. EN
‱ Use EWH without grounding or use water pipes as grounding.
‱ To connect EWH to water main with pressure exceeding 0.7 MPa.
‱ To connect EWH to the water supply without safety valve.
‱ To drain water from EWH with power switched on.
‱ To use spare parts not recommended by the manufacturer.
‱ To use water from the EWH for cooking.
‱ To use water containing impurities (sand, small stones), which might lead to EWH and safety
valve breakdown.
‱ To modify design and installation dimensions of EWH brackets.
‱ Ambient temperature, where EWH is operated, shall be within the range from 3° c to 40° C.
Water freezing in EWH at negative temperatures cause its malfunction, which is not a guarantee case.
Attention should be paid to children so that they do not play with EWH. EWH is not intended
for use by persons (including children) with limited physical, sensory or mental capabilities, or
by persons who do not know how to use the EWH, except for cases when this happens under
the supervision or instructions by persons responsible for safety of the EWH.
6. Installation and connection
All installation, plumbing and electrical works must be performed by qualified personnel.
6.1.
Arrangement and
installation
EWH installation shall be performed in accordance with marking on the housing and the following
table:
Model Volume (l) Arrangement
IBL-O 10, 15 Pipes down
IBL-U 10, 15 Pipes up
It is recommended to install EWH as close as possible to the place of hot water using to reduce heat loss in the
pipes.
When drilling (making) holes in the wall, you should consider cables, ducts and pipes in the wall.
When choosing EWH installation place take into account total weight of EWH filled with water. Wall
and floor with low carrying capacity shall be reinforced accordingly.
EWH is suspended with housing bracket on the anchor fixed into the wall. Hooks mounting on the
wall shall exclude spontaneous moving of EWH brackets.
To perform maintenance and servicing of EWH the distance from the protective cover to the nearest
surface in the direction of removable flange axis shall be at least 0.5 m.
In order to avoid damage of the user’s and/or third parties’ property in the event of a faulty hot
water system, it is required to install EWH in spaces with waterproofing and drainage to the
sewers, and in no case to place under items exposed to the water under EWH. When placed
in unprotected areas a protective plate (not supplied) with drainage into sewers shall be
installed under the EWH.
