MONOLITH mk3
Active Sub + Column Array
Item ref: 171.237UK
User Manual
Version 1.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
Monolith mk3 User Manual
Int ction rodu
Thank you for choosing the MONOLITH mk3 active sub + column array with inbuilt media player.
This product is designed to provide medium to high power output for a wide range of sound reinforcement applications.
Please read this manua to a eve optimum performance from your speaker cabinet and avoid damage through misuse. l chi
Package Contents
MONOLITH mk3 active sub cabinet
MONOLITH mk3 column speaker
Adjustable 35mmØ mounting pole
SPK-SPK link lead
IEC power lead
This product contains no user-serviceable parts, so make no attempt to try to fix or modify this item yourself as this will
invalidate the warranty. We recommend you keep the original package and proof of purchase for any possible
replacement or return issues.
Warning
To prevent the risk of fire or electric shock, do not expose any of the components to rain or moisture.
Avoid impact to any of the components.
No user serviceable parts inside - refer servicing to qualified service personnel.
Safety
Please observe the following warning conventions
CAUTION: RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this
unit
This symbol indicates that there are important operating and instructions in the maintenance
literature accompanying this unit.
Ensure that the correct mains lead is used with adequate current rating and mains voltage is as stated on the un . it
Avoid ingress of water or icles into any part of the housing If liquids are spilled on the cabinet, stop using part .
immediately, allow the unit to dry out and have checked by qualified personnel before further use.
Warning: this unit must be earthed
Place nt me
Keep the electronic parts out of direct sunlight and away from heat sources.
Position the cabinet on a stable surface or stand that is adequate to support the weight of the product.
Allow adequate space for cooling and access to controls and connections at the rear of the cabinet.
Keep the cabinet away from damp or dusty environments.
Cleaning
Use a soft dry or slightly damp cloth clean surfaces of the cabinet. to
A soft brush can be used to clear debris from controls and connections without damaging th . em
To avoid damage, do not use solvents to clean any parts of the cabinet.
Monolith mk3 User Manual
Rea panel layout r
Setting up
Position your Monolith mk3 sub cabinet on a stable surface capable of supporting the weight and vibrations
from the cabinet. ert the supplied 35mm pole into the mounting socket on top of the sub cabinet and Ins
mount the column speaker onto the pole at the desired height adjustment.
Connect the speaker output from the Monolith mk3 sub cabinet to the column speaker put using the (10) in
supplied SPK-SPK lead.
Aim the sub and column towards the audience or listeners and not in direct line of sight with any microphones
that are fed into the Monolith mk3 to avoid feedback (howling or squealing caused by the m hearing itself) ic “ ”
Connect the input signal for the Monolith mk3 to either the XLR, 6.3mm jack or L+R RCA sockets on the rear
panel (4, 3, 6). If the input signal is a microphone or at low impedance mic level, use the XLR or 6.3mm jack
and press in the MIC/LINE level switch (11). For standard LINE level put keep this switch the OUT in , at
position.
Th Monolith mk3 has a FLAT/BOOST switch (12) which, when pressed in, engages a gain boost for the lower e
frequencies to enhance the bass output. Set this to BOOST if more prominent bass output is needed. a
connect the supplied IEC power lead to the mains power inlet (16)
If the signal into to the Monolith mk3 cabinet (and the internal media player) to be linked onto a further is
Monolith or other active PA speaker, th signal can be fed from the MIX OUT line output XLR to furthee r
equipmen 5) t (
When all necessary connections are made, set the GAIN and SUBWOOFER LEVEL controls (13, 14) to MIN and
connect the supplied IEC power cable (or equivalent) from the mains power supply to the olith mk3 power Mon
inle , ensuring the correct supply voltage. t (16)
1.
Media player display
2.
Media player controls
3.
Line in 6.3mm jack
4.
Line in XLR socket
5.
MIX OUT line output XLR
6.
Line in L+R RCA sockets
7.
POWER on/off switch
8.
SD card slot
9.
USB port
10.
Column speaker output SPK sock et
11.
MIC/L level switch (for k/XLR) INE Jac
12.
FLAT/BOOST switch
13.
Master GAIN control
14.
SUBWOOFER LEVEL control
15.
Mains fuse holder
16.
IEC power inlet
