PUB. DIM-1144-000A

HD Camcorder

Instruction Manual

Caméscope HD

Mode d’emploi

Videocámara HD

Manual de Instrucciones

Int roduc t ion

Important Usage Instructions

Water and Moisture - Hazard of electric shock - Do not use this product near water or in rainy/moist situations.

Objects and Liquid Entry - Never push objects of any kind into this product through openings as they may touch dangerous

voltage points or short out parts that could result in a fire or electric shock. Be careful not to spill liquid of any kind onto the

product.

WARNING

TO REDUCE THE RISK OF ELECTRIC SHOCK AND TO REDUCE ANNOYING INTERFERENCE, USE THE RECOMMENDED ACCESSORIES

ONLY.

Unauthorized recording of copyrighted materials may infringe on the rights of copyright owners and be contrary to copyright

laws.

FCC/IC NOTICE

HD Camcorder, XA35 / XA30 systems

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules.

Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should

be made, you could be required to stop operation of the equipment.

Model ID0059/ID0064 (including WLAN Module Model RF400, FCC ID: AZD400)

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device

may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the

device.

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no

proof, however, that these low power wireless devices are absolutely safe. Low power wireless devices emit low levels of radio frequency

energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure of

low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposures have not

found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed

by additional research. This model has been tested and found to comply with FCC/IC radiation exposure limits set forth for an uncontrolled

equipment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules.

Compliance with FCC requirement 15.407(c)

Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and

finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF

transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets

is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or

operational failure.

High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars

could cause interference and/or damage to LE-LAN devices.

Frequecncy Tolerance: 25 ppm

Canon U.S.A., Inc.

One Canon Park, Melville, NY 11747, USA

Tel No. 1-800-OK-CANON (1-800-652-2666)

The Mains plug is used as the disconnect device. The Mains plug shall remain readily operable to disconnect the plug in case of an accident.

1 Read these instructions.

2 Keep these instructions.

3 Heed all warnings.

4 Follow all instructions.

5 Do not use this apparatus near water.

6 Clean only with dry cloth.

7 Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that

produce heat.

8 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your

safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

9 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they

exit from the apparatus.

10 Only use attachments/accessories specified by the manufacturer.

11 Unplug this apparatus during lightning storms or when unused for long periods of time.

12 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has been dropped.

REGIONS OF USE

XA35 / XA30 are in compliance (as of October 2015) with the radio signal regulations of the regions listed below. For details on other

regions where they can be used, make inquiries with the contacts listed on the back side of this instruction manual.

IMPORTANT SAFETY INSTRUCTIONS

CA-570 identification plate is located on the bottom.

CAN ICES-3(B)/NMB-3(B)

REGIONS

Canada, Hong Kong S.A.R., USA, South Korea, Taiwan

Models

ID0059: XA35

ID0064: XA30

mportant

arn

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within

an equilateral triangle, is intended to alert the user

to the presence of uninsulated “dangerous

voltage” within the product’s enclosure, that may

be of sufficient magnitude to constitute a risk of

electric shock to persons.

The exclamation point, within an equilateral

triangle, is intended to alert the user to the

presence of important operating and maintenance

(servicing) instructions in the literature

accompanying the product.

Trademark Acknowledgements

• SD, SDHC and SDXC Logos are trademarks of SD-3C, LLC.

• Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

• App Store, iPad, iPhone, iPod, iTunes and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.

• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the

United States and other countries.

• “AVCHD”, “AVCHD Progressive” and the “AVCHD Progressive” logo are trademarks of Panasonic

Corporation and Sony Corporation.

• Manufactured under license from Dolby Laboratories.

“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

• Google, Android, Google Play, YouTube are trademarks of Google Inc.

• Facebook is a registered trademark of Facebook, Inc.

• IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.

• The Twitter name and marks are trademarks of Twitter, Inc.

• Wi-Fi is a registered trademark of the Wi-Fi Alliance.

• Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of the Wi-Fi Alliance.

• WPS as used on the camcorder’s settings, onscreen displays and in this manual signifies Wi-Fi Protected Setup.

• The Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance.

• JavaScript is a trademark or registered trademark of Oracle Corporation, its affiliates or subsidiaries in the United States and other

countries.

• Other names and products not mentioned above may be trademarks or registered trademarks of their respective companies.

• This device incorporates exFAT technology licensed from Microsoft.

• “Full HD 1080” refers to Canon camcorders compliant with high-definition video composed of 1,080 vertical pixels

(scanning lines).

• This product is licensed under AT&T patents for the MPEG-4 standard and may be used for encoding MPEG-4

compliant video and/or decoding MPEG-4 compliant video that was encoded only (1) for a personal and non-

commercial purpose or (2) by a video provider licensed under the AT&T patents to provide MPEG-4 compliant video. No license is

granted or implied for any other use for MPEG-4 standard.

Highlights of the XA35 / XA30

The Canon XA35 / XA30 HD Camcorder is a high-performance camcorder whose compact size

makes it ideal in a variety of situations. The following are just some of the many functions featured in

the camcorder.

HD Recording

HD CMOS PRO sensor and DIGIC DV 4

image processor

The camcorder is equipped with a

1/2.84-inch CMOS sensor that captures video

at an effective pixel count of approximately

2.91 megapixels (2136x1362). The video is

then processed by the state-of-the-art DIGIC

DV 4 image processor. This allows the

camcorder to excel in low-light situations and

achieve improved image stabilization.

Wide zoom lens

With a focal length at full wide angle of

26.8 mm* (35 mm equivalent), the camcorder

has superb wide-angle shooting capability. The

lens is also capable of 20x optical zoom.

* 28.8 mm when using Dynamic IS.

Shooting video with the look you want

You can adjust many aspects of the picture,

such as the color depth, sharpness and

brightness so that you create a desired "look"

(A77). The camera also comes with preset

looks from which you can choose. The first is

the [Wide DR] look, which applies a gamma

curve with a very wide dynamic range and an

appropriate color matrix. The second is the

[Highlight Priority] look, which creates a natural

gradation in tones and reduces overexposure

in bright areas by not compressing highlights.

When playing back video shot with that look,

you can appreciate the improved detail when

using an external monitor set to brighter

settings.

Operability

Emphasis on versatility

This camcorder has features to make it usable

as a main camera but is also small enough to

be very portable. The advanced image

stabilization (A66) will let you shoot in a

variety of situations in the field. The handle unit

is removable so you can detach it when you

need improved portability and then reattach it

when you need extra functionality.

Manual controls at your fingertips

The focus/zoom ring helps you achieve the

focus you are looking for. You can also easily

change the ring's functionality so that you can

operate the zoom. Furthermore, you can

assign certain frequently used functions to a

customizable button and adjust those

functions with the accompanying dial (A99).

If those were not enough, the camcorder also

features 5 assignable buttons to which you

can assign a variety of functions so that you

can access them with ease (A100).

Face detection

When a subject's face is detected, the

camcorder can track and focus on it (A59).

Furthermore, you can have the camcorder in

manual focus but switch to autofocus only

when a face is detected, ensuring that

important subjects are in focus.

Infrared recording

Record in darkness using infrared recording

(A97). With the built-in infrared light on the

handle unit, you can record nocturnal animals

in their natural environment or other such

scenes.

6AVCHD/MP4 recording and dual

recording

When you record, you can choose between

AVCHD and MP4 formats (A40). You can

also use dual recording (A50) to record the

same scene to both memory cards and even

record on both memory cards using different

formats. Dual recording is convenient, for

example, to create a backup of your recording.

Special recording modes (A 52, 95)

When you make recordings, you can change

the recording frame rate to achieve a fast or

slow motion effect. Alternatively, you can use

pre-recording to record 3 seconds before you

decide to start recording, helping you capture

those hard-to-catch opportunities.

Other Features

Versatile audio connectivity

You can use the built-in microphone, MIC

audio input terminal or the two INPUT

terminals when recording. When using the

INPUT terminals, you can even use

microphones that require phantom power.

Audio scene select

With the audio scene select function (A 84),

you can optimize the audio settings of the

built-in microphone by selecting the audio

scene that matches your surroundings. Your

audience will feel even more immersed in the

scene during playback.

Wi-Fi functions

Because the camcorder is compatible with

Wi-Fi, you have access to a variety of

convenient functions such as using a

smartphone or tablet as a remote control

(A128), using the Web browser on a

smartphone or tablet to view the camcorder's

recordings (A 134), and using an iOS device

to share your videos on the Internet ( 136).A

OLED screen and LCD viewfinder

The OLED screen and LCD viewfinder both

have 100% frame coverage, which will ensure

that you can accurately check that your shots

are framed how you want them. The OLED

screen has incredible clarity, which is

indispensible in checking the details of those

important shots. The viewfinder can be tilted

45 degrees upward, which gives you additional

range and versatility while you shoot.

Touch AE

By simply touching the screen, you can make

dark areas in the picture appear brighter

(A71). This operation is simple yet allows

you to shoot with the desired exposure.

Added and improved functionality

Other functions include relay recording (A50)

and conversion to MP4 (A122).

Enjoying your Recordings on Other Devices

Enjoying Your Recordings Using the Camcorder's Wi-Fi Functions

Connect the camcorder to an

external monitor (A 111).

Copy your recordings to an external

video recorder (A 123).

Save your recordings (A118).

Use your iOS or Android device to remotely control

the camcorder and view the image on its screen

(A 128).

Use the Web browser on your iOS or Android

device to view the recordings on the

camcorder (A 134).

Connect the camcorder to an access point on a

Wi-Fi network. After doing so, you can save your

recordings on a computer (A 139) or play back

your recordings using the camcorder as a media

server (A 138).

Use an iOS device to upload your recordings

to the Internet (A 136).

1 Introduction 11

About this Manual 11

Conventions Used in this Manual 11

Supplied Accessories 13

Names of Parts 14

2 Preparations 21

Attaching the Ferrite Core 21

Charging the Battery Pack 21

Preparing the Camcorder 24

Attaching the Microphone Holder

Unit 24

Attaching the Handle Unit 24

Using the Lens Hood and Lens Cap 25

Using the Viewfinder 25

Adjusting the OLED Screen 26

Grip Belt and Straps 27

Wireless Controller 28

Using a Tripod 29

Basic Operation of the Camcorder 30

Turning the Camcorder On and Off 30

Setting the Shooting Mode 31

Using the Touch Screen 31

Using the FUNC. Button and

Joystick 32

Using the Menus 33

First Time Settings 35

Setting the Date and Time 35

Changing the Language 35

Changing the Time Zone 36

Using a Memory Card 37

Memory Cards Compatible for Use with

the Camcorder 37

Inserting and Removing a Memory

Card 38

Initializing a Memory Card 38

Selecting the Memory Card for

Recordings 39

Selecting the Movie Format (AVCHD/

MP4) 40

3 Recording 41

Recording Movies and Photos 41

Preparing to Record 41

Recording in AUTO Mode 42

Recording in n (Manual) Mode 46

Reviewing the Latest Scene

Recorded 47

Selecting the Recording Mode (Video

Quality) 48

Dual Recording and Relay Recording 50

Selecting the Frame Rate 51

Slow & Fast Motion Recording 52

CINEMA Mode and Cinema-Look

Filters 54

Focus Adjustment 56

Manual Focus 56

Autofocus 58

Face Detection & Tracking 59

Zooming 61

Using the Focus/Zoom Ring 61

Using the Zoom Rockers or Wireless

Controller 62

Using the Touch Screen’s Zoom

Controls 64

Soft Zoom Control 65

Digital Tele-Converter 65

Advanced Image Stabilization 66

Automatic Gain Control (AGC) Limit 67

Automatic Exposure Recording

Programs 68

Exposure Adjustment 70

Using the Manual Exposure Recording

Program 70

Exposure Compensation 71

White Balance 73

Special Scene Recording Programs 75

Looks and Other Image Effects 77

Selecting a Look 77

Adjusting Picture Settings 77

Setting the Time Code 79

Selecting the Running Mode 79

Selecting Drop Frame or Non-Drop

Frame 80

Setting the User Bit 81

User Bit Output 81

Recording Audio 82

Recording Audio to Channel 1 (CH1) 82

Connecting an External Microphone or

External Audio Input Source to the

Camcorder 83

Using the Built-in Microphone or an

External Microphone Connected to the

MIC Terminal 83

Audio Scenes and Other Audio

Settings 84

Audio Recording Level 85

Wind Screen (Built-in Microphone) 86

Table of contents

About this Manual

Introduction

About this Manual

Thank you for purchasing the Canon XA35 / XA30. Please read this manual carefully before you use

the camcorder and retain it for future reference. Should your camcorder fail to operate correctly, refer

to Troubleshooting ( 160).A

Conventions Used in this Manual

• IMPORTANT: Precautions related to the camcorder’s operation.

• NOTES: Additional topics that complement the basic operating procedures.

• POINTS TO CHECK: Restrictions or requirements regarding the function described.

•A: Reference page number within this manual.

• : Used as an abbreviation for the model indicated in the icon. The icon refers to text and

illustrations that apply only to the indicated model.

• The following terms are used in this manual:

“Memory card” refers to an SD, SDHC or SDXC memory card.

“Screen” refers to the OLED screen and the viewfinder screen.

“Scene” refers to one movie unit from the point you press the Y button to start recording

until you press again to pause the recording.

“iOS device” is used in this text to refer to Wi-Fi-enabled iPhones, iPods and iPads while “Android

device” refers to Wi-Fi-enabled Android smartphones and tablets.

• The photos included in this manual are simulated pictures taken with a still camera. Unless indicated

otherwise, illustrations and menu icons refer to the .

• Some screenshots in this manual have been simplified to show only relevant icons.

1Introduction

About this Manual

Focus Adjustment

Autofocus

When autofocus s i activated, the camcorder continuou the focusly adjus sts on the subject in the

center of the screen. The focusing range is 1 cm (0.39 in.; at full wide-angle, mea ured from the front s

of the lens barrel) to G and 60 cm (2 ft.; throughout the zoom range, measured from the front of the

lens barrel) to G. Perform the following procedure to set the autofocus s peed.

1 and modes only: Press .B

2 Open the [AF Mode] screen.

[FUNC.] > [MENU] > p> [AF Mode]

3 Touch the desired option and then touch [X].

• The icon of the selected option appears on the screen.

Operating modes:

Brackets [ ] are used to

refer to control buttons

and menu options you

will select and to other

onscreen messages

and displays.

The three sets of icons indicate the operating

mode and whether a function is available in

that mode.

: Indicates whether the

camcorder is in shooting (CAMERA) or

playback (MEDIA) mode. In this example, the

function is available only in mode. For

details, refer to Turning the Camcorder On

and Off (A30).

: Indicates the movie format. For

details, refer to Selecting the Movie Format

(AVCHD/MP4) (A 40).

: Indicates the shooting

mode. For details, refer to Setting the

Shooting Mode (A31).

The names of physical

buttons and switches on

the camcorder are

indicated within a

“button” frame.

For example B.

The > arrow is used to abbreviate

menu selections. For details on

how to use the menus, refer to

Using the Menus (A 33). For a

summary of available menu options

and settings, refer to the appendix

Menu Options Lists ( 146).A

Supplied Accessories

The following accessories are supplied with the camcorder:

* Use Data Import Utility to transfer your scenes to a computer. Refer to Saving Movies to a Computer

(A118). The CD-ROM includes the instruction manual of the software (on PDF file).

CA-570 Compact Power Adapter

(incl. power cord and ferrite core)

BP-820 Battery Pack Microphone holder unit

(incl. screws)

Handle unit (incl. screws) WL-D89 Wireless Controller

(incl. CR2025 lithium button battery)

HTC-100/S High Speed HDMI Cable

STV-250N Stereo Video Cable IFC-300PCU/S USB Cable Lens hood with lens barrier

Lens cap Data Import Utility CD-ROM*

Names of Parts

1 Built-in speaker (A 104)

2 MIC terminal (A 84)

3 HDMI OUT terminal (A111, 112)

4 REMOTE terminal

For connecting commercially

available remote controllers.

5 HD/SD-SDI terminal (A 112)

6×(headphones) terminal (A 92)

7 USB terminal (A 98)

8 DC IN terminal (A 21)

9 AV OUT terminal (A 111, 113)

10 Grip belt (A27)

t s

e v

Names of Parts

1 Instant AF sensor (A 58, 176)

2 Remote sensor (A 28)

3 Illumination sensor (A154)

4 AF/MF button (A56)/

Assignable button 1 (A100)

5 PRE REC (pre-recording) button

(A 95)/

Assignable button 2 (A100)

6 OLED touch screen (A 26, 31)

7 Focus/Zoom ring switch (A 61)

8 Viewfinder (A 25)

9 Dioptric adjustment lever (A 25)

10 Joystick (A 32)/SET button (A32)

11 Strap mount (A 27)

12 Assignable button 3 (A100)

13 Assignable button 4 (A100)

14 Battery attachment unit (A 21)

15 START/STOP button (A 41)

16 FUNC. button (A 32)

17 Serial number

15141312

ront v

Back view

Names of Parts

1 Built-in stereo microphone

(A 82)

2 Handle attachment unit (A24)

3 Mode switch (A 31)

4 Zoom rocker (A 61)

5 ACCESS indicator (A41)

6 Power switch (A30)

7 POWER / CHG (battery charging)

indicator (A 21)

1 2 3 4 5

op v

Names of Parts

1 Tripod socket (A29)

2 BATTERY RELEASE switch (A22)

3 Eye cup (A 25)

1 2 3

ottom v

Names of Parts

WL-D89 Wireless Controller

1 START/STOP button (A 41)

2G (mode selection) button (A103)

3 MENU button (A34, 147)

4 DISP. (onscreen display) button (A 96)

5 SET button

6Ñ (stop) button (A103)

7 PHOTO button (A41)

8 Zoom buttons (A61)

9 Navigation buttons (Í Î Ï Ð/ / / )

10 103)Ò (play/pause) button (A

Attaching the Ferrite Core

Preparations

Attaching the Ferrite Core

Attach the enclosed ferrite core before you connect the compact power adapter to the camcorder.

Attaching the ferrite core to the compact power adapter cable is necessary to suppress RF

interference.

Attach the ferrite core to the cable about 6 cm (2.4 in.) from the

plug end (the plug to be connected to the camcorder) of the

compact power adapter cable.

Pass the cable through the center of the core and wrap it around the

core (as shown in the illustration), then close the unit until it clicks shut.

Charging the Battery Pack

The camcorder can be powered with a battery pack or directly using the compact power adapter.

For approximate charging times and recording/playback times with a fully charged battery pack, refer

to Charging, Recording and Playback Times (A185).

1 Connect the power cord to the compact power adapter.

2 Plug the power cord into a power outlet.

3 Connect the compact power adapter to the camcorder’s

DC IN terminal.

4 Attach the battery pack to the camcorder.

• Press the battery pack softly into the battery attachment

unit and slide it forward until it clicks in place.

DC IN terminal

2Preparations

Charging the Battery Pack

5 Charging will start when the camcorder is turned off.

• If the camcorder was on, the green POWER/CHG indicator

will go out when you turn off the camcorder. After a

moment, the POWER/CHG indicator will turn on in red

(battery pack charging). The red POWER/CHG indicator will

go out when the battery pack is fully charged.

• If the indicator flashes, refer to Troubleshooting ( 162).A

6 Disconnect the compact power adapter in the order

shown in the illustration.

To remove the battery pack

1 Slide d in the direction of the arrow and

hold it pressed down.

2 Slide the battery pack and then pull it out.

POWER/CHG (battery charging) indicator

햳햲

햵

햴

BATTERY

RELEASE

switch

Charging the Battery Pack

IMPORTANT

• Turn off the camcorder before connecting or disconnecting the compact power adapter. After you

turn off the camcorder, important data is updated on the memory card. Be sure to wait until the

green POWER/CHG indicator goes out.

• When using the AC adapter, do not fix it permanently to one place as this may cause a malfunction.

• Do not connect to the camcorder’s DC IN terminal or to the compact power adapter any electrical

equipment that is not expressly recommended for use with this camcorder.

• To prevent equipment breakdowns and excessive heating, do not connect the supplied compact

power adapter to voltage converters for overseas travels or special power sources such as those on

aircraft and ships, DC-AC inverters, etc.

NOTES

• We recommend charging the battery pack in temperatures between 10 °C and 30 °C (50 °F and

86 °F). If either the ambient temperature or the battery pack’s temperature is outside the range of

approx. 0 °C to 40 °C (32 °F to 104 °F), charging will not start.

• The battery pack will be charged only when the camcorder is off.

• If the power supply was disconnected while charging a battery pack, make sure the POWER/CHG

indicator has gone out before restoring the power supply.

• If remaining battery time is an issue, you can power the camcorder using the compact power

adapter so the battery pack will not be consumed.

• Charged battery packs continue to discharge naturally. Therefore, charge them on the day of use, or

the day before, to ensure a full charge.

• The first time you use a battery pack, fully charge it and then use the camcorder until the battery

pack is completely exhausted. Doing so will ensure that the remaining recording time will be

displayed accurately.

• We recommend that you prepare battery packs to last 2 to 3 times longer than you think you might

need.

•USA and Canada only: The Lithium ion/polymer battery that powers the product is

recyclable. Please call 1-800-8-BATTERY for information on how to recycle this

battery.

Preparing the Camcorder

Using the Lens Hood and Lens Cap

While recording, the supplied lens hood with lens barrier is

effective for reducing stray light that can be the cause of lens

flare and ghost images. Additionally, closing the lens barrier

can help prevent fingerprints and dirt accumulation on the

lens. Use the supplied lens cap when carrying the camcorder

or storing it after use.

* Note that the lens cap and the lens hood with lens barrier cannot

be used simultaneously.

1 Remove the lens cap.

2 Place the lens hood on the front of the lens so that the

groove on the lens hood is aligned with the bottom of

the lens (햲), and then turn the lens hood clockwise

until it stops with a click

(햳).

• Be careful not to deform the lens hood.

• Make sure that the lens hood is aligned with the thread.

• To remove the lens hood, turn it counterclockwise.

Using the Viewfinder

If it is difficult to use the OLED screen, you can use the viewfinder, which can be tilted 45 degrees

upward. You can also use the viewfinder when you rotate the OLED panel 180 degrees to let the

subject watch the recording.

1 Pull out the viewfinder.

2 Use the power switch to turn on the camcorder.

3 Adjust the viewfinder using the dioptric adjustment

lever.

• You can close the OLED panel or rotate it toward the

subject as you prefer.

• You can tilt the viewfinder 45 degrees upward.

Dioptric

adjustment

lever

Preparing the Camcorder

• If you wear glasses, you may find the viewfinder easier to

use if you flip back the outer edge of the eye cup toward

the camcorder body.

NOTES

• Make sure you keep the eye cup attached when using the camcorder.

• For details about how to take care of the viewfinder, refer to Handling Precautions ( 172), A

Cleaning (A 176).

Adjusting the OLED Screen

Open the OLED panel 90 degrees.

• You can rotate the panel 90 degrees downward.

• You can rotate the panel 180 degrees toward the lens. Rotating the OLED panel 180 degrees can

be useful in the following cases:

- To allow the subject to monitor the OLED screen while you use the viewfinder.

- To allow the camcorder to be operated with the wireless controller from the front.

NOTES

• When you rotate the OLED panel, video noise may appear on the screen momentarily. This is not a

malfunction.

• You can adjust the brightness of the OLED screen and viewfinder with the q> [OLED/VF

Brightness] setting or by holding D pressed down for more than 2 seconds. Pressing D will

change the brightness between bright and normal.

• Adjusting the brightness or using the q > [ View Assistance] setting does not affect the

brightness of recordings.

• Using a brighter setting will shorten the effective usage time of the battery pack.

• For details about how to take care of the touch screen, refer to Handling Precautions ( 172), A

Cleaning (A 176).

180°

90° Subject can monitor the OLED screen

(you can use the viewfinder at the same time)

180°

Preparing the Camcorder

•About the OLED and viewfinder screens: The screens are produced using extremely high-

precision manufacturing techniques, with more than 99.99% of the pixels operating to specification.

Less than 0.01% of the pixels may occasionally misfire or appear as black dots. Misfired pixels in

the viewfinder may appear instead as white dots. This has no effect on the recorded image and

does not constitute a malfunction.

Grip Belt and Straps

Fasten the grip belt.

• Adjust the grip belt so that you can reach the zoom rocker

with your index finger, and the Y button with

your thumb.

Attaching an optional wrist strap

Attach the wrist strap to the strap mount on the grip belt,

adjust the length and fasten.

• You can use both for extra convenience and protection.

Preparing the Camcorder

Attaching an optional shoulder strap

Pass the ends of the shoulder strap through the strap mount on the grip belt and adjust the length of

the strap.

Wireless Controller

First, insert the supplied CR2025 lithium button battery into the wireless controller.

1 Press the tab in the direction of the arrow and pull out

the battery holder.

2 Place the lithium button battery with the + side facing

up.

3 Insert the battery holder.

To use the wireless controller

Point the wireless controller at the camcorder’s remote sensor when you press the buttons.

• You can rotate the OLED panel 180 degrees to use the wireless controller from the front of the

camcorder.

Tab

Preparing the Camcorder

NOTES

• When the camcorder cannot be operated with the wireless controller, or when it can only be

operated at very close range, replace the battery.

• The wireless controller may not work properly when the remote sensor is situated under strong light

sources or direct sunlight.

Using a Tripod

You can mount the camcorder on a tripod but do not use tripods

with mounting screws longer than 6.5 mm (0.26 in.) as this may

cause damage to the camcorder.

Basic Operation of the Camcorder

Turning the Camcorder On and Off

You can choose to turn the camcorder on in CAMERA ( ) mode for making recordings or MEDIA

( ) mode for playing back recordings. Select the mode using the power switch.

To turn on the camcorder

Set the power switch to CAMERA for mode (A41) or

MEDIA for mode (A103).

To turn off the camcorder

Set the power switch to OFF.

mode mode

Basic Operation of the Camcorder

Setting the Shooting Mode

In mode, you can change the shooting mode to match your shooting style.

(Auto) mode

Set the mode switch to N. With this mode, the camcorder takes care of all

the settings while you concentrate on recording (A 42). This operating mode is

suitable if you just prefer not to bother with detailed camcorder settings.

(Manual) mode

Set the mode switch to n. With this mode, you can enjoy full access to menus,

settings and advanced functions (A46).

(Cinema) mode

Set the mode switch to E. With this mode, you can give your recordings

a cinematic look and use cinema-look filters to create unique movies (A54).

Using the Touch Screen

The control buttons and menu items that appear on the touch screen change dynamically depending

on the operating mode and the task you are performing. With the intuitive touch screen interface you

have all the controls at your fingertips.

Touch

Press on an element displayed on the touch screen.

Used to start playing back a scene in an index screen, to select

a setting from the menus, etc.

Basic Operation of the Camcorder

Drag

Swipe your finger up and down or left and right across the

screen. Used to scroll menus, to browse through index screen

pages or to adjust slider controls like the volume.

On some screens, you can achieve the same effect by touching

the triangle control buttons.

IMPORTANT

• The camcorder features a capacitive touch screen. In the following cases, you may not be able to

perform touch operations correctly.

- Using your fingernails or hard-tipped objects, such as ballpoint pens.

- Operating the touch screen with wet or gloved hands.

- Applying excessive force or forcefully scratching the touch screen.

- Attaching commercially available screen protectors or adhesive film onto the touch screen’s

surface.

Using the FUNC. Button and Joystick

You can navigate some of the camcorder’s menus and screens using the FUNC. button and joystick

instead of using the touch panel.

Joystick/SET button

When making a menu selection, push the joystick

to move the orange selection frame in the menu.

Then, press the joystick itself (S) to select the

menu item indicated by the orange selection frame.

FUNC. button

Press the button to open the FUNC. panel and then

press again to close the menu after adjusting

desired settings.

Basic Operation of the Camcorder

Using the Menus

Many of the camcorder’s functions can be adjusted from the FUNC. panel and the setup menus. For

details about the available menu options and settings, refer to the appendix Menu Options Lists

(A146).

FUNC. Panel

In mode:

There are three ways to access the FUNC. panel: by touching [FUNC.] on the OLED screen, by

pressing F or by pushing the joystick (Ý Þ/ ) to select [FUNC.] and then pressing S. After

the FUNC. panel is open, select the function you want to use. You may need to scroll up and down the

screen or touch ã ä/ to find the control button of the desired function. In mode, access to

functions is limited.

In mode:

Just like during mode, you can open the FUNC. panel by touching [FUNC.] on the OLED screen,

by pressing F or by pushing the joystick (Ý Þ/ ) to select [FUNC.] and then pressing S.

After the FUNC. panel is open, select the function you want to use.

Operating modes:

Touch the control

button of the

desired function

FUNC. panel in mode

Touch the control

button of the

desired operation

Basic Operation of the Camcorder

Setup Menus

In this manual, navigating the setup menus is explained using the touch panel controls but they can

also be navigated using the joystick and other buttons. The procedure below explains how to use both

methods. If necessary, refer back to this section for details on using the joystick.

To use touch panel controls

1 mode only: Touch [FUNC.].

2 Touch [MENU].

3 Touch the tab of the desired menu.

4 Drag your finger up and down to bring the desired setting

into the orange selection bar.

• You can also touch [Í] and [Î] to scroll up and down.

• Menu items not available appear grayed out.

• You can touch any menu item on the screen to bring it

directly into the selection bar.

5 When the desired menu item is inside the selection bar, touch [æ].

6 Touch the desired option and then touch [X].

• You can touch [X] to close the menu at any time.

To use the joystick

1 mode only: Push the joystick (Ý Þ/ ) to select [FUNC.] and then press S.

• Alternatively, you can press F.

2 Push the joystick (Ý Þ/ ) to select [MENU] and then press S.

3 Push the joystick (Þ) to select the desired tab and then press S.

4 Push the joystick (Ý) to move the selection bar to the desired setting and then press S.

• Menu items not available appear grayed out.

5 Push the joystick (Ý Þ/ ) to select the desired option and then press S.

6 Push the joystick (Ý Þ/ ) to select [X] and then press S.

• You can press F to close the menu at any time.

NOTES

• For brevity's sake, references in the text to settings in the setup menus will include only the tab of

the desired menu and the setting name. For example, "You can adjust the date and time later on

with the q > [Date/Time] setting."

• You can also press M on the wireless controller to open the setup menus.

Operating modes:

First Time Settings

Setting the Date and Time

You will need to set the date and time of the camcorder before

you can start using it. The [Date/Time] screen will appear

automatically when the camcorder’s clock is not set.

1 Use the power switch to turn on the camcorder.

• The [Date/Time] screen will appear.

2 Touch a field you want to change (year, month, day, hours or minutes).

• You can also push the joystick (ÏÐ) to move between the fields.

3 Touch [Í Î] or [ ] to change the field as necessary.

• You can also push the joystick (ÍÎ) to change the field.

4 Set the correct date and time by changing all the fields in the same way.

5 Touch [Y.M.D], [M.D,Y] or [D.M.Y] to select the date format you prefer.

• In some screens, the date will be displayed in short form (numbers instead of month names or

only the day and month), but it will still follow the order you selected.

6 Touch [24H] to use 24-hour clock or leave it unselected to use 12-hour clock (AM/PM).

7 Touch [OK] to start the clock and close the setup screen.

NOTES

• You can adjust the date and time later on with the q > [Date/Time] setting.

• When you do not use the camcorder for about 3 months, the built-in rechargeable lithium battery

may discharge completely and the date and time setting may be lost. In such case, recharge the

built-in lithium battery (A174) and set the time zone, date and time again.

Changing the Language

The default language of the camcorder is English. You can set

it to one of 27 languages.

1 Open the [Language ] screen.

[FUNC.] > [MENU] > q> [Language ]

• Touching [FUNC.] is necessary only when performing the procedure in mode.

Operating modes:

First Time Settings

2 Touch the desired language and then touch [OK].

3 Touch [X] to close the menu.

NOTES

• Some control buttons, such as [ZOOM], [FUNC.] and [MENU], will appear in English regardless of

the language selected.

Changing the Time Zone

Change the time zone to match your location. The default setting is New York. In addition, the

camcorder is able to retain the date and time of an additional location. This is convenient when you

travel so that you can set the camcorder to match the time of your home location or that of your travel

destination.

1 Open the [Time Zone/DST] screen.

[FUNC.] > [MENU] > q> [Time Zone/DST]

• Touching [FUNC.] is necessary only when performing the procedure in mode.

2 Touch [" #] to set the home time zone, or [ ] to set the time zone of your destination

when you are traveling.

3 Touch [Í Î] or [ ] to set the desired time zone. If necessary, touch [$] to adjust for

daylight saving time.

4 Touch [X] to close the menu.

Operating modes:

Using a Memory Card

Inserting and Removing a Memory Card

Make sure to initialize (A38) all memory cards before using them with this camcorder.

1 Turn off the camcorder.

• Make sure the POWER/CHG indicator is off.

2 Open the double memory card slot cover.

3 Insert the memory card straight, with the label facing

the front of the camcorder, all the way into one of the

memory card slots until it clicks.

• You can also use two memory cards, one in each memory

card slot.

4 Close the double memory card slot cover.

• Do not force the cover closed if the memory card is not

correctly inserted.

To remove the memory card

Push the memory card once to release it. When the memory card springs out, pull it all the way out.

IMPORTANT

• Observe the following precautions while the ACCESS indicator is flashing. Failure to do so may

result in permanent data loss.

- Do not disconnect the power source or turn off the camcorder.

- Do not remove the memory card.

• Turn off the camcorder before inserting or removing a memory card. Inserting or removing the

memory card with the camcorder on may result in permanent data loss.

• Memory cards have front and back sides that are not interchangeable. Inserting a memory card

facing the wrong direction can cause a malfunction of the camcorder. Be sure to insert the memory

card as described in step 3.

Initializing a Memory Card

Initialize memory cards when you use them with this camcorder for the first time. You can also initialize

a memory card to permanently delete all the recordings it contains.

1 Power the camcorder using the compact power adapter.

• Do not disconnect the power source or turn off the camcorder until the initialization is completed.

Operating modes:

Using a Memory Card

2 Open the initialization screen for the desired memory card.

[FUNC.] > [MENU] > > > > [Initialize ] [6Mem. Card A] or [7 Mem. Card B]

[Initialize]

• Touching [FUNC.] is necessary only when performing the procedure in mode.

• In the initialization screen, touch [Complete Initialization] to physically erase all the data rather than

just clear the file allocation table of the memory card.

3 Touch [Yes].

• If you selected the [Complete Initialization] option, you can touch [Cancel] to cancel the

initialization while it is in progress. All recordings will be erased and the memory card can be used

without any problem.

4 Touch [OK] and then touch [X].

IMPORTANT

• Initializing a memory card will permanently erase all recordings. Lost original recordings cannot be

recovered. Make sure you save important recordings in advance using an external device (A118).

Selecting the Memory Card for Recordings

Movies and photos are recorded on a memory card. You can select on which memory card your

movies and photos will be recorded.

1 Open the [Recording Media] screen.

[FUNC.] > [MENU] > > [Recording Media]

2 Touch the desired memory card ([6 7 Mem. Card A] or [ Mem. Card B]) for recording

movies ([v Rec Media for Movies]) or for taking photos ([{ Rec Media for Photos]).

3 Touch [X].

• After closing the menu, the icon of the memory card selected for recording movies will appear on

the screen.

Operating modes:

Selecting the Movie Format (AVCHD/MP4)

You can choose to record movies in AVCHD or MP4 format. AVCHD movies are ideal for playback with

fantastic picture quality. MP4 movies are versatile and can easily be played back on smartphones and

tablets or uploaded to the Web.

1 Open the [Movie Format] screen.

[FUNC.] > [MENU] > > [Movie Format]

2 Select the desired movie format.

3 Touch [X].

• The icon of the selected movie format will appear on the screen.

Operating modes:

Recording Movies and Photos

Recording

Recording Movies and Photos

You can select the memory card that will be used to record movies and photos (A39). For details on

recording audio, refer to Recording Audio (A82). Should the camcorder fail to operate correctly, refer

to Troubleshooting ( 160).A

POINTS TO CHECK

•Before you begin recording, make a test recording first to check that the camcorder is operating

correctly.

Preparing to Record

1 Attach a charged battery pack to the camcorder

(A21).

2 Insert a memory card into a memory card slot.

• To use relay recording or dual recording (A 50), insert

memory cards into both memory card slots.

3 Open the lens barrier.

• Set the lens barrier switch to OPEN.

4 If you need to use the viewfinder, pull it out and adjust it,

as necessary.

• You can use the dioptric adjustment lever and tilt the

viewfinder 45 degrees upward.

Lens barrier switch

3Recording

Recording Movies and Photos

Recording in AUTO Mode

When you use mode to shoot video and take photos, the camcorder will automatically adjust

various settings for you.

1 Set the mode switch to N.

2 Set the power switch to CAMERA.

To record video

Press Y to begin recording.

• During recording, Ü will appear on the screen. Additionally, if

the handle unit is attached to the camcorder, the tally lamp will

illuminate.

• The ACCESS indicator will flash from time to time while the

scene is being recorded.

• Press again to pause the recording. Y Ü will

change to Ñ and the scene will be recorded on the memory

card selected for recording movies. The tally lamp will also go

out.

• You can also press Y on the handle unit or wireless

controller.

To take photos

Touch [PHOTO].

• In the lower center of the screen, a green icon (g) will appear. Also, in the upper right of the screen,

{Ð will appear with the icon of the memory card selected for recording photos. The ACCESS

indicator will flash as the photo is being recorded.

• You can record photos simultaneously while recording a movie. In that case, the green icon will not

appear.

• You can also press Z on the wireless controller.

When you have finished recording

1 Set the lens barrier switch to CLOSED to close the lens barrier.

2 Make sure that the ACCESS indicator is off.

3 Set the power switch to OFF.

4 Close the OLED panel and return the viewfinder to its retracted position.

Operating modes:

[PHOTO]

Recording Movies and Photos

Smart AUTO

In mode, the camcorder will automatically detect certain characteristics of the subject,

background, lighting conditions, etc. It will then adjust various settings (focus, exposure, color,

image stabilization, image quality, among others), selecting the best settings for the scene you

want to shoot. The Smart AUTO icon will change to one of the icons in the following table.

Smart AUTO icons

1The icon in parentheses appears under backlight conditions.

2This icon will appear under tele macro conditions. Tele macro is activated automatically when you

zoom toward the telephoto end and close in on the subject. Tele macro allows you to get closer

shots of small subjects and adds a soft focus to the background, so the subject not only looks

larger but also stands out more.

Background (color of the icon) → Bright

(gray)

Blue skies

(light blue)

Vivid colors

(yellow/green/

red)

Sunsets1

(orange)

Subject ↓

People (stationary)

( ) ( ) ( ) —

People (moving)

( ) ( ) ( ) —

Subjects other than people,

such as landscapes ( ) ( ) ( )

Close objects / 2

( / 2)

( / 2)—

Background (color of the icon) → Dark (dark blue)

Subject ↓ Spotlight Night scene

People (stationary) — —

People (moving) — —

Subjects other than people, such as

landscapes

Close objects / 2— —

Recording Movies and Photos

• Under certain conditions, the Smart AUTO icon that appears on the screen may not match the

actual scene. Especially when shooting against orange or blue backgrounds, the sunset or one of

the blue skies icons may appear and the colors may not look natural. In such case, we recommend

recording in mode (A 46).

• Photos are recorded as JPG files. During and modes, the camcorder can take photos

during record standby mode or capture photos from a movie during playback (A 106). The photo

size and number of photos that can be saved on a 1 GB memory card are summarized in the

following table. However, the actual number of photos that can be recorded will vary depending on

the subject and shooting conditions.

• Photos cannot be recorded while the digital zoom is activated or during dual recording.

• You can capture a photo from a scene during playback (A 106).

• When you need to record for a long time with the camcorder set on a tripod, you can close the

OLED panel and use only the viewfinder in order to save power when using a battery pack (A 25).

Movie Format Recording mode Photo size Number of photos

AVCHD Any 1920x1080 660

MP4

35 Mbps, 24 Mbps, 17 Mbps 1920x1080 660

8 Mbps, 4 Mbps 1280x720 1,490

3 Mbps 640x360 5,800

Selecting the Recording Mode (Video Quality)

Recording modes by movie format

Movie format Recording mode Resolution Audio format

AVCHD

28 Mbps LPCM (59.94P)

1920x1080

Linear PCM

28 Mbps (59.94P) Dolby Digital

24 Mbps LPCM Linear PCM

24 Mbps

Dolby Digital17 Mbps

5 Mbps 1440x1080

MP4

35 Mbps (59.94P)

1920x1080

AAC

24 Mbps

17 Mbps

8 Mbps (59.94) 1280x720

4 Mbps

3 Mbps 640x360

Approximate recording times  Default value

For AVCHD movies:

For MP4 movies:

* A single scene can be recorded continuously for 12 hours; at that point, the camcorder will stop.

Recording mode →28 Mbps LPCM

(59.94P) and

28 Mbps

(59.94P)

24 Mbps LPCM

and 24 Mbps 17 Mbps 5 Mbps

Memory card ↓

8 GB Memory card 35 min. 40 min. 1 hr. 3 hr.

16 GB Memory card 1 hr. 15 min. 1 hr. 25 min. 2 hr. 5 min. 6 hr. 5 min.

32 GB Memory card 2 hr. 30 min. 2 hr. 55 min. 4 hr. 10 min. 12 hr. 15 min.*

64 GB Memory card 5 hr. 5 min. 5 hr. 55 min. 8 hr. 20 min. 24 hr. 30 min.*

128 GB Memory card 10 hr. 10 min. 11 hr. 55 min. 16 hr. 45 min.* 49 hr.*

Recording mode →35 Mbps

(59.94P) 24 Mbps 17 Mbps 8 Mbps

(59.94P) 4 Mbps 3 Mbps

Memory card ↓

8 GB Memory card 30 min. 40 min. 1 hr. 2 hr. 10 min. 4 hr. 20 min. 5 hr. 40 min.

16 GB Memory card 1 hr. 1 hr. 25 min. 2 hr. 5 min. 4 hr. 20 min. 8 hr. 40 min. 11 hr.

25 min.

32 GB Memory card 2 hr. 2 hr. 55 min. 4 hr. 10 min. 8 hr. 40 min. 17 hr.

20 min.*

22 hr.

55 min.*

64 GB Memory card 4 hr. 5 hr. 55 min. 8 hr. 20 min. 17 hr.

20 min.*

34 hr.

45 min.*

45 hr.

55 min.*

128 GB Memory card 8 hr. 11 hr.

55 min.

16 hr.

45 min.*

34 hr.

45 min.*

69 hr.

30 min.*

91 hr.

55 min.*

Dual Recording and Relay Recording

When you record, you can use dual recording to record simultaneously on both memory cards so that

you can use one of the movies as a backup.

Alternatively, you can use relay recording so that if the memory card being recorded on becomes full,

the recording will continue uninterrupted on the other memory card.

Activating dual recording

The backup movie is recorded on memory card 3. After you activate dual recording, select the

backup movie's recording mode.

1 Open the [Dual Recording] screen.

[FUNC.] > [MENU] > > [Dual/Relay Recording] > [Dual Recording]

• The screen shows the movie format and recording mode of the movies that will be recorded on

each card.

2 Select the movie format and recording mode for the backup movie that will be recorded

on memory card 3.

• The first option is always the same movie format and recording mode of the movie that will be

recorded on memory card 2. The second two options are always [¸4Mbps] and

[¸3Mbps], which result in small files that are ideal for transferring to a computer.

3 Touch [X].

Activating relay recording

1 Open the [Dual/Relay Recording] screen.

[FUNC.] > [MENU] > > [Dual/Relay Recording]

2 Touch [Relay Recording] and then touch [X].

NOTES

• To use neither function, select [Standard Recording] on the [Dual/Relay Recording] screen.

• When you use relay recording, it does not matter which memory card the recording starts on. The

recording will continue on the other memory card. However, the camcorder will switch to another

memory card only one time.

• With the software Data Import Utility, you can join relay scenes (either AVCHD or MP4 format)

recorded on both memory cards as a single scene and save it on a computer (A 118).

• Dual recording is not available when the recording mode is set to 28 Mbps LPCM (59.94P),

28 Mbps (59.94P), 35 Mbps (59.94P) or 8 Mbps (59.94P).

Operating modes:

Automatic Exposure Recording Programs

With the automatic exposure (AE) recording programs, the camcorder will adjust the shutter speed

and/or aperture value to obtain the optimal exposure. When using the AE recording programs, you can

change functions like the white balance and image effects.

1 Open the screen of the desired recording program.

[FUNC.] > [Rec. Programs] > [‚ Shutter-Pri. AE] or [“ Aperture-Pri. AE]

2 Touch [Ï Ð ‚ “] or [ ] to set the desired shutter speed ( ) or aperture value ( ) and then

touch [X].

• You can also drag your finger along the dial.

• The selected shutter speed or aperture value will appear on the screen next to the recording

program icon.

Options ( Default value)

Available shutter speed settings

Available shutter speed settings when the frame rate is set to 23.98P

Available aperture value settings

ND filter settings will be available when the aperture value is [F4.0].

Operating modes:

[’ Programmed AE]The camcorder automatically adjusts the aperture and shutter speed to obtain

the optimal exposure for the subject.

[‚ Shutter-Pri. AE] Set the shutter speed value. The camcorder automatically sets the appropriate

aperture value.

[“ Aperture-Pri. AE] Set the aperture value. The camcorder automatically sets the appropriate

shutter speed.

[1/8] [1/15] [1/30] [1/60] [1/100]

[1/250] [1/500] [1/1000] [1/2000]

[1/6] [1/12] [1/60][1/24] [1/48]

[1/100] [1/250] [1/500] [1/1000] [1/2000]

[F1.8] [F2.6][F2.0] [F2.2] [F2.4] [F2.8]

[F3.2] [F4.4][F3.4] [F3.7] [F4.0] [F4.8]

[F5.2] [F7.3][F5.6] [F6.2] [F6.7] [F8.0]

Produktspezifikationen

Marke:	Canon
Kategorie:	Camcorder
Modell:	XA30

Brauchst du Hilfe?

Wenn Sie Hilfe mit Canon XA30 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Camcorder Canon

Canon XH G1 Bedienungsanleitung

22 September 2024

Canon Optura 300 Bedienungsanleitung

13 September 2024

Canon ML-105 EF Bedienungsanleitung

28 August 2024

Canon CT-V1 Bedienungsanleitung

27 August 2024

Canon PowerShot SD800 IS Bedienungsanleitung

27 August 2024

Canon PowerShot A85 Bedienungsanleitung

20 August 2024

Canon EOS ELAN II/IIE Bedienungsanleitung

19 August 2024

Canon 310XL Bedienungsanleitung

15 August 2024

Canon Scoopic 16M Bedienungsanleitung

14 August 2024

Canon 8EE Motor Zoom Bedienungsanleitung

13 August 2024

Bedienungsanleitung Camcorder

Neueste Bedienungsanleitung für -Kategorien-

Prixton DV800 Bedienungsanleitung

25 November 2024

Prixton DV670 Bedienungsanleitung

25 November 2024

GoXtreme Stage 2.5K Bedienungsanleitung

24 November 2024

Trust Powerc@m DV-2400V Bedienungsanleitung

12 Oktober 2024

Samsung SMX-F530RN Bedienungsanleitung

12 Oktober 2024

Hitachi DZ-GX20E Bedienungsanleitung

8 Oktober 2024

Sanyo Xacti VPC-CG65 Bedienungsanleitung

7 Oktober 2024

Gembird ACAM-003 Bedienungsanleitung

3 Oktober 2024

Midland XTC260 Bedienungsanleitung

28 September 2024

König CSAC100 Bedienungsanleitung

24 September 2024
