HD Camcorder
Instruction Manual
&
%
2
Int r od uct ion
Important Usage Instructions
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
COPYRIGHT WARNING:
Unauthorized recording of copyrighted materials may infringe on the rights of copyright
owners and be contrary to copyright laws.
The Mains plug is used as the disconnect device. The Mains plug shall remain readily operable
to disconnect the plug in case of an accident.
CAUTION:
• Danger of explosion if the wrong type of batteries are attached. Use only the same type of batteries.
• Do not expose batteries or product to excessive heat such as the inside of a car under
direct sunlight, fire, etc.
While using the compact power adapter, do not wrap it or cover it with a piece of cloth,
and do not place it in confined narrow spaces.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point, within an equilateral triangle, is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
the product.
3
FCC/IC NOTICE
HD Camcorder, VIXIA HF R32 / VIXIA HF R30 / VIXIA HF R300 systems
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condition
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and use in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the manual.
If such changes or modifications should be made, you could be required to stop operation of the
equipment.
Model ID0002 (including WLAN Module Model WM217)
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to th
following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
The available scientific evidence does not show that any health problems are associated with using
low-power wireless devices. There is no proof, however, that these low power wireless devices are
absolutely safe. Low-power wireless devices emit low levels of radio frequency energy (RF) in the
microwave range while being used. Whereas high levels of RF can produce health effects (by heating
tissue), exposure to low-level RF that does not produce heating effects causes no known adverse
health effects. Many studies of low-level RF exposures have not found any biological effects. Some
studies have suggested that some biological effects might occur, but such findings have not been
confirmed by additional research. This model has been tested and found to comply with FCC/IC
radiation exposure limits set forth for an uncontrolled equipment and meets the FCC radio frequency
(RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF)
Exposure rules.
Canon U.S.A., Inc.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
Tel No. (516)328-5600
This Class B digital apparatus complies with Canadian ICES-003.
4
In these safety instructions the word “apparatus” refers to the Canon HD Camcorder
VIXIA HF R32 / VIXIA HF R30 / VIXIA HF R300 and all its accessories.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
8 Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
9 Only use attachments/accessories specified by the manufacturer.
10 Unplug this apparatus during lightning storms or when unused for long periods of time.
11 Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
REGIONS OF USE
VIXIA HF R32 and VIXIA HF R30 are in compliance (as of January 2012) with the radio signa
regulations of the regions listed below. For details on other regions where they can be used,
make inquiries with the contacts listed on the back side of this instruction manual.
IMPORTANT SAFETY INSTRUCTIONS
CA-110 identification plate is located on the bottom.
REGIONS
Canada, Hong Kong S.A.R., USA, South Korea
Model
ID0002: VIXIA HF R30 / VIXIA HF R32
5
Trademark Acknowledgements
• SD, SDHC and SDXC Logos are trademarks of SD-3C, LLC.
• Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the United State
and/or other countries.
• App Store, iPhone, iTunes, Mac OS and Macintosh are trademarks of Apple Inc., registered in the U.S. and
other countries.
• “x.v.Color” and the “x.v.Color” logo are trademarks.
• HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
• “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation
and Sony Corporation.
• Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
• YouTube is a trademark of Google Inc.
• Facebook is a registered trademark of Facebook, Inc.
• Wi-Fi is a registered trademark of the Wi-Fi Alliance.
• Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of the Wi-Fi Alliance.
• WPS as used on the camcorder’s settings, onscreen displays and in this manual signifies Wi-Fi Protected
Setup.
• DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the
Living Network Alliance.
• Other names and products not mentioned above may be trademarks or registered trademarks of their
respective companies.
• This device incorporates exFAT technology licensed from Microsoft.
• “Full HD 1080” refers to Canon camcorders compliant with high-definition video
composed of 1,080 vertical pixels (scanning lines).
• ANY USE OF THIS PRODUCT OTHER THAN CONSUMER PERSONAL USE IN ANY MANNER
THAT COMPLIES WITH THE MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR P
IS EXPRESSLY PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG
PORTFOLIO, WHICH LICENSE IS AVAILABLE FROM MPEG LA, L.L.C., 250 STEELE STREET, SUIT
COLORADO 80206.
• This product is licensed under AT&T patents for the MPEG-4 standard and may be used for encoding MPEG
compliant video and/or decoding MPEG-4 compliant video that was encoded only (1) for a personal and non
commercial purpose or (2) by a video provider licensed under the AT&T patents to provide MPEG-4 complia
video. No license is granted or implied for any other use for MPEG-4 standard.
6
Exciting Features and New Functions
& %/
Wi-Fi Functions
(A 149)
Story Creator (A 67)
Enjoy the freedom of Wi-Fi
functions by making your
camcorder an active part of your
Wi-Fi home network or by
conveniently accessing Wi-Fi
hotspots to upload your videos
wherever you may be.
• You can save your recordings
wirelessly to a computer in your
home network using the sup-
plied software Network Utility
(A 156). You can also send
your recordings wirelessly to an
FTP server (A 156), for exam-
ple to send your videos from
your vacation spot to a network-
attached storage drive back
home.
• You can upload your recordings
wirelessly, directly from your
camcorder to YouTube and
Facebook (A 160).
• You can play back the record-
ings in your camcorder from
DLNA-compatible TV sets and
other DLNA media players con-
nected to your home network
(A 164).
Transform your movies into
compelling video stories just by
recording video following simple
pre-scripted suggestions,
optimized for various scenarios.
Cinema-Look Filters
(A 70)
Use professional cinema-look
filters to create unique movies
with distinctive looks.
AVCHD and MP4
Recording (A 31)
Record movies in AVCHD and play
them back on an HDTV in all their
splendor. Alternatively, record
movies in MP4 for uploading to the
Web and transferring to mobile
devices.
7
Smart AUTO (A 46)
Smart AUTO automatically selects the best
scene mode for the scene you want to
shoot. You get spectacular recordings
every time without worrying about settings.
Video Snapshot
(A 72)
Face Detection
(A 99)
Shoot or capture short scenes
and arrange them into a video
clip set to your favorite
background music.
The camcorder automatically
detects people’s faces and
adjusts the focus and other
settings accordingly for beautiful
results.
& %/
Memory Save (A 136) Image Stabilization
Easily save the whole content of
the built-in memory or a memory
card onto an external hard drive
connected directly to the
camcorder. With no need for a
computer, this is a very
convenient way to save backup
copies of your recordings.
Dynamic IS (A 97)
compensates for camcorder
shake when you shoot video
while walking. Powered IS
(A 98) will produce stable shots
when you zoom in on distant
subjects (full telephoto).
Intelligent IS (A 48) selects the
type of image stabilization for the
recording situation.
8
Enjoying Your Recordings on Other Devices
MPEG-2AVCHD
MP4
Eye-Fi
Connect the camcorder
to an HDTV (A 127) Use an Eye-Fi card
(A 146) to wirelessly
upload recordings to
your computer or a video
sharing Web site.
Upload MP4 movies to
your computer (A 133). Save your recordings.
You can also create discs
from your recordings.*
Standard Definition
Upload AVCHD movies to your computer (A 131).
& %/ You can also choose to convert your AVCHD
movies to standard definition files (A 142) before uploading.
High Definition
Use the supplied PIXELA’s
software (A 131).
Upload your AVCHD
movies* (A 142) or
MP4 movies
(A 148) to the Web.
* /& % only.
9
& %/
Enjoying Your Recordings Using the Camcorder's Wi-Fi Functions
LAN cable
Play video wirelessly directly from the memory on
AVCHD- and DLNA-compatible HDTVs and other
devices connected to the network (A 164).
Join a Wi-Fi
network by first
connecting to an
access point
(A 151).
Transfer your recordings
wirelessly from the
camcorder to a computer or
FTP server (A 156).
Wirelessly connect to a Wi-Fi-enabled iOS
device like an iPhone to upload your
recordings (A 161). Because you do not
need to be near your home network, you can
even upload videos while traveling!
Upload your recordings wirelessly
to YouTube and Facebook
(A 160) to share your videos
with friends and family.
10
Table of contents
Introduction
6 Exciting Features and New Functions
14 About this Manual
16 Getting to Know the Camcorder
16 Supplied Accessories and CD-ROMs
18 Names of Parts
Preparations
20 Getting Started
20 Charging the Battery Pack
23 Using the Grip Belt
24 Opening the Lens Cover and Adjusting the LCD Screen
26 Basic Operation of the Camcorder
26 Using the Touch Screen
27 Using the Menus
31 Operating Modes
34 First Time Settings
34 Setting the Date and Time
35 Changing the Language
36 Changing the Time Zone
37 Using a Memory Card
37 Memory Cards Compatible for Use with the Camcorder
39 Inserting and Removing a Memory Card
40 & %/ Selecting the Memory (Built-in Memory/
Memory Card) for the Recordings
41 & %/ Relay Recording
42 Initializing the Memory
Table of contents
Table of contents 11
AUTO Mode
44 Basic Recording
44 Shooting Video and Taking Photos in AUTO Mode
46 About the Smart AUTO function
48 Intelligent IS
49 Zooming
51 Quick Start
Video
53 Basic Playback
53 Playing Back Video
57 3D Flip View
58 The [Index Selection] Screen: Selecting the Content to
Play Back
60 Deleting Scenes and Stories
64 Selecting the Playback Starting Point
66 Onscreen Displays and Data Code
67 Video Stories and Cinema Style
67 Using Story Creator to Create Compelling Stories
70 Cinema Mode and Cinema-Look Filters
72 Video Snapshot
73 Decoration: Adding a Personal Touch
79 Playing Back Stories from the Gallery
81 Rating Scenes
82 Playback with Background Music
85 Copying and Moving Scenes Within/Between Stories
86 Selecting a Story’s Thumbnail Image
87 Changing a Story’s Title
89 Advanced Functions
89 Recording in Manual Mode
91 Selecting the Video Quality (Recording Mode)
94 Selecting the Frame Rate
95 Special Scene Recording Programs and Programmed AE
97 Advanced Image Stabilization
98 Powered IS
98 Pre-Recording
99 Face Detection
12
Table of contents
101 Touch & Track
102 Faders
103 Manual Exposure Adjustment
104 Manual Focus Adjustment
106 Tele Macro
107 White Balance
108 Self Timer
109 Audio Recording Level
111 Using Headphones
112 Using an External Microphone
113 Audio Mix
114 Capturing Video Snapshot Scenes and Photos from a
Movie
116 Dividing Scenes
Photos
118 Viewing Photos
120 Deleting Photos
122 Slideshow
External Connections
123 Terminals on the Camcorder
124 Connection Diagrams
127 Playback on a TV Screen
128 Saving and Sharing Your Recordings
128 & %/ Copying Movies and Photos to a Memory
Card
131 Saving Recordings on a Computer
136 & %/ Memory Save: Saving an Entire Memory
onto an External Hard Drive
140 Copying Recordings to an External Video Recorder
142 & %/ Uploading AVCHD Movies to the Web
148 Uploading MP4 Movies and Photos to the Web
Table of contents 13
& %/ Wi-Fi Functions
149 Introduction to Wi-Fi
151 Connecting to a Wi-Fi Network
156 Transferring Files to a Computer or FTP Server
160 Uploading Recordings to YouTube and Facebook
161 Uploading Videos Using an iOS Device
164 Wireless Playback on a DLNA-Compatible Device
Additional Information
168 Appendix: Menu Options Lists
168 [Main Functions] Panel
172 [Other Settings] Menus
182 Appendix: Onscreen Icons and Displays
187 Trouble?
187 Troubleshooting
194 List of Messages
205 Do’s and Don’ts
205 Handling Precautions
209 Maintenance/Others
210 Using the Camcorder Abroad
211 General Information
211 Accessories
212 Optional Accessories
216 Specifications
220 Index
14
Introduction
About this Manual
Thank you for purchasing the Canon VIXIA HF R32 / VIXIA HF R30 /
VIXIA HF R300. Please read this manual carefully before you use the
camcorder and retain it for future reference. Should your camcorder fail
to operate correctly, refer to Troubleshooting (A187).
Conventions Used in this Manual
• IMPORTANT: Precautions related to the camcorder’s operation.
• NOTES: Additional topics that complement the basic operating
procedures.
• POINTS TO CHECK: Restrictions or requirements regarding the
function described.
•A: Reference page number within this manual.
•& : Text that applies only to the models shown in the icon.
• The following terms are used in this manual:
When not specified as “memory card” or “built-in memory”, the term
“memory” by itself refers to both.
“Scene” refers to one movie unit from the point you press the
Y button to start recording until you press again to pause
the recording.
• The photos included in this manual are simulated pictures taken with
a still camera. Unless indicated otherwise, illustrations and menu
icons refer to the &.
Introduction 15
Self Timer
Operating modes:
* For movies only.
1 Press .
2 Activate the self timer.
•< will appear on the screen.
• Repeat, selecting [jOff], to turn off the self timer.
Movies: In record pause mode, press Y.
The camcorder starts recording after a 10-second countdown. The
countdown appears on the screen.
*
[ Other Settings] > > r [Self Timer] >
[ ]iOn <] > [X
Brackets [ ] are used to refer to
control buttons and menu options
you will touch on the screen and to
other onscreen messages and
displays.
indicates that a function is available in the
operating mode indicated and indicates
that the function is not available. The operating
mode icons are divided into three groups: the
first three icons represent the camera mode,
the second three icons represent the recording
standard, and the last two represent playback
modes. For a detailed explanation refer to
Operating Modes ( 31).A
The names of physical buttons
and switches on the
camcorder are indicated within
a “button” frame.
For example Y.
The >
>
>
>> arrow is used to abbreviate menu selections.
For a detailed explanation on how to use the menus,
refer to Using the Menus (A27). For a concise
summary of all available menu options and settings,
refer to the appendix Menu Options Lists ( 168).A
16
Introduction
Getti ng to Kn ow the C amco rder
Supplied Accessories and CD-ROMs
The following accessories are supplied with the camcorder:
* CA-110E including power cord, in Asia.
** & %/ only.
XCA-110 Compact Power Adapter*
BP-709 Battery PackW
XIFC-300PCU/S USB Cable
HTC-100/S HDMI CableW
XQuick Guide
XWi-Fi Basic Setup Guide**
Stylus PenW
Introduction 17
The following CD-ROMs and software are supplied with the camcorder:
•PIXELA CD-ROM
- /& % You can use VideoBrowser for managing, editing, and
playing back AVCHD movies, and Network Utility when transferring
recordings wirelessly to a computer.
-' Use Transfer Utility for saving and transferring AVCHD
movies and music files you can use as background music.
- A printed Startup Guide for PIXELA's software is also supplied. Refer
to this Startup Guide for details about the supplied software.
•Canon VIXIA CD-ROM. Contains the following components.
- Instruction Manual - The full-version instruction manual of the
camcorder (this PDF file).
- ImageBrowser EX - This CD-ROM contains an automatic installer for
the supplied software ImageBrowser EX, which allows you to save
and manage MP4 movies and photos; and upload MP4 movies to
CANON iMAGE GATEWAY**, YouTube and Facebook. An Internet
connection is required for installation.
- Music data - Music files that can be used as background music during
playback. These music files are for exclusive use with the supplied
PIXELA’s software. The disc cannot be played back on CD players.
- Image mix data - Image files that can be used with the image mix
function (image mix frames).
*The CD-ROM includes the instruction manual of the software (on PDF file).
**CANON iMAGE GATEWAY is an online service that allows you to share mov-
ies and photos, create video podcasts, make photo albums, and more. This
service may not be available in all countries/regions.
18
Introduction
Names of Parts
1U A (camera/play) button ( 33)
2HOME button (A27)
3VIDEO SNAP (video snapshot) button
(A72)
4ACCESS indicator (A44)
5Memory card slot cover
6MIC terminal (A112)
7AV OUT terminal (A123, 125)/
× (headphones) terminal (A111)
8HDMI OUT terminal (A123, 124)
9USB terminal (A123, 125, 136, 140)
Aq Memory card slot (A39)
Aa START/STOP button (A44)
As DC IN terminal (A20)
Ad Grip belt (A23)
Af Wi-Fi antenna (& %/ only)
Ag Lens cover switch (A24)
Ah Stereo microphone (A109, 113)
Ah
Left side view
1
6 78 9
Aq
23 4 5
Aa
As
Ag
Ad Af
Right side view
Front view
Introduction 19
Aj Speaker (A55)
Ak Zoom lever (A49)
Al LCD touch screen (A24, 26)
Sq POWER button
Sa ON/OFF (CHG) (charge) indicator:
Green – On
Orange – Standby (A51)
Red – Charging (A20)
Ss Battery attachment unit (A20)
Sd Serial number
Sf Tripod socket (A206)
Sg BATTERY RELEASE switch (A21)
Al
Top view
AkAj
LCD panel
Sa
Ss
Sq
Sd Sf Sg
Bottom view
Back view
20
Preparations
Preparations
This chapter describes basic operations, such as using the
touch panel, navigating the menus, and first time settings to
help you learn more about your camcorder.
Getting Started
Charging the Battery Pack
The camcorder can be powered with a battery pack or directly using
the compact power adapter.
For approximate charging times and recording/playback times with a
fully charged battery pack, refer to Charging, Recording and Playback
Times (A213).
1 Plug the power cord into a
power outlet.
For Asia only: Connect the power
cord to the compact power
adapter before plugging the
power cord into the power outlet.
2 Connect the compact power
adapter to the camcorder’s DC
IN terminal.
3 Attach the battery pack to the
camcorder.
Press the battery pack softly into
the battery attachment unit and
slide it up until it clicks in place.
DC IN terminal
For Asia only:
Preparations 21
4 Charging will start when the
camcorder is turned off.
• If the camcorder was on, the
green ON/OFF (CHG) indicator
will go out when you turn off the
camcorder. After a moment,
the ON/OFF (CHG) indicator
will turn on in red (battery pack
charging). The red ON/OFF
(CHG) indicator will go out
when the battery pack is fully
charged.
• If the indicator flashes, refer to
Troubleshooting (A190).
To remove the battery pack
1 Slide d in the
direction of the arrow and hold it
pressed down.
2 Slide the battery pack and
then pull it out.
IMPORTANT
• Turn off the camcorder before connecting or disconnecting the com-
pact power adapter. After pressing P to turn off the camcorder,
important data is updated in the memory. Be sure to wait until the green
ON/OFF (CHG) indicator goes out.
• Do not connect to the camcorder’s DC IN terminal or to the compact
power adapter any electrical equipment that is not expressly recom-
mended for use with this camcorder.
ON/OFF (CHG) (charge) indicator
BATTERY RELEASE switch
22
Preparations
• To prevent equipment breakdowns and excessive heating, do not con-
nect the supplied compact power adapter to voltage converters for
overseas travels or special power sources such as those on aircraft and
ships, DC-AC inverters, etc.
NOTES
• We recommend charging the battery pack in temperatures between
10 °C and 30 °C (50 °F and 86 °F). If either the ambient temperature or
the battery pack’s temperature is outside the range of approx. 0 °C to
40 °C (32 °F to 104 °F), charging will not start.
• If the ambient temperature or the battery pack's temperature is low,
charging may take longer than usual.
• The battery pack will be charged only when the camcorder is off.
• If the power supply was disconnected while charging a battery pack,
make sure the ON/OFF (CHG) indicator has gone out before restoring
the power supply.
• If remaining battery time is an issue, you can power the camcorder
using the compact power adapter so the battery pack will not be con-
sumed.
• Charged battery packs continue to discharge naturally. Therefore,
charge them on the day of use, or the day before, to ensure a full
charge.
• Optional battery packs for this camcorder can display the remaining
battery time. The first time you use an optional battery pack, fully charge
it and then use the camcorder until the battery pack is completely
exhausted. Doing so will ensure that the remaining recording time will be
displayed accurately.
• We recommend that you prepare battery packs to last 2 to 3 times
longer than you think you might need.
•USA and Canada only: The Lithium ion/polymer battery that
powers the product is recyclable. Please call
1-800-8-BATTERY for information on how to recycle this
battery.
Preparations 23
Using the Grip Belt
Fasten the grip belt.
Adjust the grip belt so that you can
reach the zoom lever with your
index finger, and the Y
button with your thumb.
You can attach the supplied stylus
pen to the grip belt.
To remove the grip belt
1 Lift the padded handgrip’s flap and detach the strap from the Velcro
pad.
2 Pull the strap to remove it first from the front bracket on the
camcorder, then to unthread it from the handgrip and finally to
remove it from the rear bracket on the camcorder.
24
Preparations
Opening the Lens Cover and Adjusting the LCD Screen
Before you start recording, open
the lens cover.
Move the lens cover switch down
to to open the lens cover.
Rotating the LCD Panel
Open the LCD panel 90 degrees.
• You can rotate the panel 90 degrees downward.
• You can rotate the panel 180 degrees toward the lens. Rotating the
LCD panel 180 degrees can be useful to allow the camcorder to include
yourself in the picture when recording with the self timer.
180°
90° Subject can monitor the LCD screen
180°
Preparations 25
NOTES
•About the LCD screen: The screen is produced using extremely high-pre-
cision manufacturing techniques, with more than 99.99% of the pixels
operating to specification. Less than 0.01% of the pixels may occasion-
ally misfire or appear as black, red, blue or green dots. This has no
effect on the recorded image and does not constitute a malfunction.
• For details about how to take care of the touch screen, refer to Handling
Precautions (A205), Cleaning (A209).
• You can adjust the screen's brightness using the q > [LCD Bright-
ness] and [LCD Backlight] settings. When the compact power adapter
is connected, [LCD Backlight] will automatically change to [H Bright].
26
Preparations
Basic Operation of the Camcorder
Using the Touch Screen
The control buttons and menu items that appear on the touch screen
change dynamically depending on the operating mode and the task
you are performing. With the intuitive touch screen interface you have
all the controls at your fingertips. You can also use the supplied stylus
pen for a more precise operation.
Touch
Press firmly on an element displayed on the
touch screen.
Used to start playing back a scene in an
index screen, to select a setting from the
menus, to select the subject whom the cam-
corder will recognize as the main subject of
the scene, etc.
Drag
While applying pressure, swipe your finger
up and down or left and right across the
screen.
Used to scroll menus, to browse through
index screen pages or to adjust slider
controls like the volume.
IMPORTANT
• The camcorder uses a pressure-sensitive touch screen. Press
firmly when using touch operations.
• In the following cases, you may not be able to perform touch operations
correctly.
- Using your fingernails or hard-tipped objects other than the supplied
stylus pen, such as ballpoint pens.
- Operating the touch screen with wet or gloved hands.
- Applying excessive force or forcefully scratching the touch screen.
- Attaching commercially available screen protectors or adhesive film
onto the touch screen’s surface.
Preparations 27
Using the Menus
Many of the camcorder's functions can be adjusted from the [ Main
Functions] panel and [ Other Settings] menus in the HOME menu.
For details about the available menu options and settings, refer to the
appendix Menu Options Lists (A168).
HOME Menu
Operating modes:
The HOME menu is the gateway to
most of the camcorder's functions
and settings. After you press
, the HOME menu will
appear and you can select from
the following control buttons. The
available control buttons depend
on whether the camcorder is in
recording or playback mode.
•[ Main Functions] - This contains functions commonly used while
shooting, such as focus and exposure. Available only in recording
mode.
•[ Other Settings] - Selecting this control button will open up the
[ Other Settings] menus, which gives you access to settings such as
the video quality (recording mode) and LCD brightness.
In recording mode
In playback mode
for & %/
28
Preparations
•[ Camera Mode] - From the [ Camera Mode] menu, you will be
able to change whether you record movies in mode (camcorder
automatically takes care of many settings), mode (you can manu-
ally change settings), or mode (using the cinema-look filters, you
can make movies with a cinematic feel). Available only in recording
mode. For details on how to set the camera mode, refer to Recording
(A31).
•[ Recording Standard] - This camcorder can record movies in either
the AVCHD or MP4 recording standard. Use this menu to select the
standard that best suits your needs. You can also use Story Creator
mode (A67) when choosing to record in AVCHD. Available only in
recording mode. For details on how to set the recording standard, refer
to Recording (A31).
•[ Wi-Fi] - & %/ Allows you to access the various Wi-Fi func-
tions this camcorder has to offer. Available only in playback mode. For
more details on Wi-Fi functions, refer to Wi-Fi Functions (A149).
•[G Index Selection] - Use this to switch between the various index
screens in playback mode (A58).
[Main Functions] Panel
Operating modes:
* In mode, access to functions is limited.
The [ Main Functions] panel contains frequently used shooting func-
tions. Press to open the HOME menu and then touch [ Main
Functions] to open the panel. Alternatively, you can touch F in the
upper-left portion of the recording screen. Next, touch the function you
want to set or adjust.
*
Preparations 29
You may need to drag your finger up and down along the scroll bar or
touch [ ] and [ ] to find the control button of the desired function.
[Edit] Panel
Operating modes:
Touch [Edit] to display a panel showing available operations (copying,
deleting, etc.), and then touch the operation you want to perform.
Touch the control
button of the
desired function
Drag your finger up
and down along the
scroll bar to display
the rest of the panel
In mode
Touch to scroll up
or down
In mode
for & %/
Touch the control
button of the
desired operation
30
Preparations
[Other Settings] Menus
Operating modes:
* In mode, access to functions is limited.
1 Press to open the HOME
menu.
2 Touch [ Other Settings] to open
the [ Other Settings] menus.
3 Touch the tab of the desired
menu.
4 Drag your finger up and down to
bring the setting you want to
change into the orange selection bar.
• You can also use the [ ] and [ ] icons for scrolling.
• Menu items not available appear grayed out.
• You can touch any menu item on the screen to bring it directly into
the selection bar.
5 When the desired menu item is inside the selection bar, touch
[ ].
6 Touch the desired option and touch [X].
You can touch [X] to close the menu at any time.
*
Preparations 31
Operating Modes
Recording
When recording, the camcorder's operating mode is determined by the
[ Camera Mode] and [ Recording Standard] menus in the HOME
menu. First, set the camera mode.
1 Press to open the
HOME menu.
2 Touch [ Camera Mode] and
then touch the desired camera
mode.
3 Touch [OK].
Next, set the recording standard. The recording standard determines
the type of data the movie is recorded as — namely, AVCHD or MP4.
1 Press to open the HOME menu.
2 Touch [ Recording Standard] and then touch the desired
recording standard.
3 Touch [OK].
Camera mode Operation
(AUTO mode)
Let the camcorder take care of most of the settings while you
concentrate on recording (A 44). Great for beginners or if you just
prefer not to bother with detailed camcorder settings.
(Manual mode) Enjoy full access to menus, settings and advanced functions (A 89).
(Cinema mode)
Give your recordings a cinematic look and use cinema-look filters to
create unique movies (A 70).
32
Preparations
NOTES
• You can adjust the video quality using the r > [Recording Mode]
setting.
• Some portable devices may not be able to play back MP4 movies
recorded with this camcorder.
Recording
standard
Control
button Operation
v
Movies are recorded in AVCHD, which is designed for
playback on HDTVs. Select this recording standard if you
plan to show off your movies and you want to impress your
audience with fantastic picture quality.
é
Movies are recorded in AVCHD using Story Creator
(A 67), which allows you to create compelling video
stories. Because Story Creator mode records in AVCHD,
your movies will look amazing when played back on an
HDTV.
By recording movies in MP4, your movies are smaller in
size but retain high quality. This is especially useful for
playback on portable devices or sharing on the Web.
Preparations 33
Playback
Press the camera/play button
T to switch the camcorder
between camera (recording) mode
and playback mode. You can press
T when the camcorder is off
to turn it on directly in playback
mode.
NOTES
• /& % When switching to a playback mode, the memory
selected for playback will be the same currently used for recording.
Playback mode Operation
Playing back movies (A 53).
Viewing photos (A 118).
34
Preparations
First Time Settings
Setting the Date and Time
You will need to set the date and time of
the camcorder before you can start
using it. The [Date/Time] screen will
appear automatically when the cam-
corder’s clock is not set.
When the [Date/Time] screen appears,
the year will be selected.
1 Touch a field you want to change (year, month, day, hours or
minutes).
2 Touch [Í Î] or [ ] to change the field as necessary.
3 Set the correct date and time by changing all the fields in the
same way.
4 Touch [Y.M.D], [M.D,Y] or [D.M.Y] to select the date format you
prefer.
In some screens, the date will be displayed in short form (numbers
instead of month names), but it will still follow the order you selected.
5 Touch [24H] to use 24-hour clock or leave it unselected to use
12-hour clock (AM/PM).
6 Touch [OK] to start the clock and close the setup screen.
NOTES
• You can adjust the date and time later on with the q > [Date/Time]
setting.
• When you do not use the camcorder for about 3 months, the built-in
rechargeable lithium battery may discharge completely and the date
and time setting may be lost. In such case, recharge the built-in lithium
battery (A 208) and set the time zone, date and time again.
Preparations 35
Changing the Language
The default language of the camcorder
is English. You can set it to one of 27
languages.
Operating modes:
1 Press .
2 Select the desired language.
NOTES
• Some control buttons, such as [ZOOM] or [PHOTO], will appear in
English regardless of the language selected.
[ Other Settings] > > q [Language !] >
Desired language > [OK] > [X]
36
Preparations
Changing the Time Zone
Change the time zone to match your location. The default setting is
New York.
Operating modes:
1 Press .
2 Open the [Time Zone/DST] screen.
3 Touch [" #] to set the home time zone, or [ ] to set the time zone
of your destination when you are traveling.
4 Touch [Í Î] or [ ] to set the desired time zone. If necessary, touch
[$] to adjust for daylight saving time.
5 Touch [X] to close the menu.
[ Other Settings] > > q [Time Zone/DST]
Preparations 37
Using a Memory Card
Memory Cards Compatible for Use with the Camcorder
You can use the following types of commercially available Secure Digi-
tal (SD) cards with this camcorder.
As of December 2011, the movie recording function has been tested
using SD/SDHC/SDXC memory cards made by Panasonic, Toshiba
and SanDisk. For the latest information on cards that can be used, visit
your local Canon Web site.
* When using an SD memory card without a speed class rating, you may not be able
to record movies, depending on the memory card used.
**SD memory cards with a capacity of 64 MB or smaller cannot be used to record
movies.
NOTES
• About the Speed Class: Speed Class is a standard that indicates the mini-
mum guaranteed data transfer speed of memory cards. When you buy
a new memory card, look for the Speed Class logo on the package.
We recommend using memory cards rated SD Speed Class 4, 6 or 10.
Memory card type: . SD memory card, / SDHC memory card,
0 SDXC memory card
SD Speed Class*:
Capacity: 128 MB or larger**.
38
Preparations
SDXC Memory Cards
You can use SDXC memory cards with this camcorder. When using
memory cards with other devices, such as digital recorders, computers
and card readers, make sure that the external device is compatible
with SDXC cards. The table below summarizes compatibility by com-
puter operating system, as of December 2011. For the latest informa-
tion, however, contact the computer, operating system or memory card
manufacturer.
Compatible operating systems for SDXC memory cards
IMPORTANT
• If you use an SDXC memory card with a computer OS that is not SDXC-
compatible, you may be prompted to format the memory card. In such
case, cancel the operation to prevent data loss.
• After repeatedly recording, deleting and editing scenes (fragmented
memory), it will take longer to write data on the memory and recording
may stop. Save your recordings and initialize the memory.
Eye-Fi Cards
This product is not guaranteed to support Eye-Fi card functions
(including wireless transfer). In case of an issue with an Eye-Fi card,
please check with the card manufacturer.
Also note that an approval is required to use Eye-Fi cards in many
countries or regions. Without approval, use of the card is not permit-
ted. If it is unclear whether the card has been approved for use in the
area, please check with the card manufacturer.
Operating system Compatibility
Windows 7 Compatible
Windows Vista Compatible (requires Service Pack 1 or later)
Windows XP Compatible (requires Service Pack 3 and KB955704 update)
Mac OS X Compatible (requires version 10.6.5 or later)
Preparations 39
Inserting and Removing a Memory Card
Make sure to initialize (A 42) all memory cards before using them with
this camcorder.
1 Turn off the camcorder.
Make sure the ON/OFF (CHG)
indicator is off.
2 Open the memory card slot
cover.
3 Insert the memory card at a
slight angle, with the label
facing toward the lens, all the
way into the memory card slot
until it clicks.
• The memory card slot is at a
slight angle toward the lens so
be careful not to damage the
memory card when inserting
it.
• Be sure you understand the
information provided in Eye-Fi
Cards (A 38) before using an
Eye-Fi card.
4 Close the memory card slot
cover and press until it clicks.
Do not force the cover closed if
the memory card is not correctly
inserted.
To remove the memory card
Push the memory card once to release it. When the memory card
springs out, pull it all the way out.
Memory card
Lens
Top view
40
Preparations
IMPORTANT
• Memory cards have front and back sides that are not interchangeable.
Inserting a memory card facing the wrong direction can cause a mal-
function of the camcorder. Be sure to insert the memory card as
described in step 3.
& %/ Selecting the Memory (Built-in Memory/Memory
Card) for the Recordings
You can select to record your movies and photos in the built-in mem-
ory or on a memory card. The default memory for recording both is the
built-in memory.
Operating modes:
POINTS TO CHECK
• Be sure you understand the information provided in Eye-Fi Cards
(A 38) before using an Eye-Fi card.
1 Press .
2 Select the desired memory.
* When selecting the memory, you can check the approximate available recording
time/number of photos, based on currently used settings.
[ Other Settings] >
>
>
> > r>
>
>
>> [Rec Media for Movies]
or [Rec Media for Photos] >
>
>
>> [&] (built-in memory) or
[ ]*] (memory card)* >
>
>
>> [X
Preparations 41
& %/ Relay Recording
You can activate the relay recording so if the built-in memory becomes
full while recording movies, the recording will continue uninterrupted
on the memory card.
Operating modes:
1 Insert a memory card that contains no video recordings into the
memory card slot.
2 Press .
3 Activate the relay recording.
* The approximate available recording time will now reflect the combined space in
the memories used for relay recording.
NOTES
• There will be a momentary stop in the scene at the point where the
camcorder switches from one memory to another.
• Any of the following actions will deactivate the relay recording function:
- Turning off the camcorder.
- Opening the memory card slot cover.
- Changing the camcorder’s operating mode.
- Changing the memory used for recording movies.
[
Other Settings]
>
>
>
>>
r
>
>
>
>>
[Rec Media for Movies]
>
>
>
>>
[
&
]
>
>
>
>>
[Relay Recording]
>
>
>
>>
[
%
]*
>
>
>
>>
[
X
]
42
Preparations
Initializing the Memory
Initialize memory cards when you use them with this camcorder for the
first time. You can also initialize a memory card or the built-in memory
( /& % only) to permanently delete all the recordings it contains.
& %/ At the time of purchase, the built-in memory comes pre-
initialized and contains music files for use as background music and
images for use with the image mix function (image mix frames).
Operating modes:
1 Power the camcorder using the compact power adapter.
Do not disconnect the power source or turn off the camcorder until the
initialization is completed.
2 Press .
3 Initialize the memory.
& %/
'
1Touch this option if you want to physically erase all the data rather than just clear
the file allocation table of the memory.
2If you selected the [Complete Initialization] option, you can touch [Cancel] to cancel
the initialization while it is in progress. All recordings will be erased and the memory
can be used without any problem.
[ Other Settings] >
>
>
>> / q >
>
>
>> [Initialize & *] >
>
>
>>
[& Built-in Mem.] or [* Mem. Card] >
>
>
>> [Initialize] >
>
>
>>
[Complete Initialization] 1 >
>
>
>> [Yes] 2 ]
>
>
>
>> [OK] >
>
>
>> [X
[ Other Settings] >
>
>
>> q >
>
>
>> [Initialize *] >
>
>
>>
[Initialize] >
>
>
>> [Complete Initialization] 1 >
>
>
>> [Yes] 2
>
>
>
>> [OK] >
>
>
>>
[ ]X
Preparations 43
IMPORTANT
• Initializing the memory will permanently erase all recordings. Lost origi-
nal recordings cannot be recovered. Make sure you save important
recordings in advance using an external device (A 128).
• Initializing a memory card will permanently erase any music files and
images you may have transferred to the card. (& %/ The music
files and image mix frames that come pre-installed in the built-in mem-
ory will be restored after it is initialized.) To transfer music files from the
supplied VIXIA CD-ROM to the memory card:
- Windows users: Use the supplied software VideoBrowser (&/
% only) or Transfer Utility (' only). For details, refer to the
Software Guide (PDF file) of the supplied PIXELA’s software.
- Mac OS users: Use Finder to transfer music files from the [MUSIC]
folder on the supplied VIXIA CD-ROM to the memory card. Refer to
About the music files (A 219) for the folder structure of the memory
card.
• At the time of purchase, Eye-Fi cards contain the necessary network
configuration software. Be sure to install the software and complete the
required configuration setup before you initialize the Eye-Fi card prior to
using it with this camcorder.
44
AUTO Mode
AUTO Mode
This chapter covers how to easily record video and photos in
mode, and how to use basic shooting functions like zoom
and Quick Start. To enjoy full access to menus and more
advanced functions, refer to Recording in Manual Mode
(A89).
Basic Recording
Shooting Video and Taking Photos in AUTO Mode
With mode, you can take great-looking videos and photos by let-
ting the camcorder automatically adjust settings based on the record-
ing situation.
Operating modes:
POINTS TO CHECK
• Before you begin recording, make a test recording first to check that
the camcorder is operating correctly.
AUTO Mode 45
1 Press P to turn on the
camcorder.
•& %/ By default,
movies and photos are
recorded in the built-in
memory. You can select the
memory that will be used to
record movies and photos
(A40).
• Please read the
IMPORTANT section
(A48) before using an
Eye-Fi card.
2 Open the lens cover switch.
3 Press .
To change the recording
standard, refer to Recording
(A31).
4 Set the camcorder to mode.
To record video
Press Y to begin recording.
• Press Y again to pause the recording.
• The ACCESS indicator will flash from time to time while the scene is
being recorded.
• You can turn on the scene rating option in recording mode with the
r > [Rate Scenes (Recording)] setting.
[ Camera Mode] >
>
>
>> [N] > [OK]
AUTO Mode 47
Smart AUTO icons
* The icon in parentheses appears under backlight conditions.
Background →
(color of the icon) Bright*
(gray)
Blue skies*
(light blue)
Vivid colors*
(green/red)
Sunsets
(orange)
Subject ↓
People (stationary) ( ) ( ) ( ) —
People (moving) ( ) ( ) ( ) —
Subjects other than people,
such as landscapes
( ) ( ) ( )
Close objects /
( / )
/
( / )
/
( / ) —
Background →
(color of the icon)
Dark
(dark blue)
Subject ↓Spotlight Night scene
People (stationary) — —
People (moving) — —
Subjects other than people,
such as landscapes
Close objects / — —
48
AUTO Mode
IMPORTANT
• To protect the lens, keep the lens cover closed when you are not
recording movies and when you are not using the camcorder.
• Observe the following precautions while the ACCESS indicator is on or
flashing. Failing to do so may result in permanent data loss or damage
to the memory.
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
• Be sure to save your recordings regularly (A128), especially after
making important recordings. Canon shall not be liable for any loss or
corruption of data.
• Recordings on an Eye-Fi card will be uploaded automatically after set-
ting the camcorder to playback mode, if you are within the range of a
configured network. Always verify that Eye-Fi cards have been
approved in the country/region of use. See also Using an Eye-Fi card
(A146).
NOTES
• About the power saving mode: If q> [Power Saving Mode] > [Auto
Power Off] is set to [iOn], the camcorder will shut off automatically
to save power when it is powered by a battery pack and is left without
any operation for 5 minutes. Press P to turn on the camcorder.
Intelligent IS
Intelligent IS allows the camcorder to select the best image stabilization option
based on your shooting method. The Intelligent IS icon will change to one of the
following icons. In and modes, you can set the image stabilization
manually (A97).
* You can turn off Powered IS through the [ Main Functions] panel (A 98).
Shooting method Icon
Most general situations; Zooming out (zooming toward
T
); Following subjects at a distance moving left or right
Ä (Dynamic IS)
Zooming in (zooming toward S)È (Powered IS)*
Close-up of a subject (Macro IS)
Remaining stationary, such as when using a tripod (Tripod mode)
AUTO Mode 49
• When recording in bright places, it may be difficult to use the LCD
screen. In such cases, you can adjust the LCD backlight with the q
> [LCD Backlight] setting or adjust the brightness of the LCD screen
with the q > [LCD Brightness] setting.
• Under certain conditions, the Smart AUTO icon that appears on the
screen may not match the actual scene. Especially when shooting
against orange or blue backgrounds, the Sunset or one of the Blue
Skies icons may appear and the colors may not look natural. In such
case, we recommend recording in mode (A 89).
• Photos are recorded as JPG files. The photo size (1920x1080) and
quality cannot be changed. At this size, a 1 GB memory card can hold
approximately 670 photos. However, the actual number of photos that
can be recorded will vary depending on the subject and shooting condi-
tions.
Zooming
There are two ways you can zoom in and out: using the zoom lever on
the camcorder or using the zoom controls on the touch screen. You
can also select the zoom type (optical, advanced or digital).
Operating modes:
Using the Zoom Lever
Move the zoom lever toward T
(wide angle) to zoom out. Move it
toward S (telephoto) to zoom in.
By default, the zoom lever operates
at a variable speed – press gently
for a slow zoom; press harder for
faster zooms.
T Zoom out S Zoom in
50
AUTO Mode
Using the Touch Screen’s Zoom Controls
1 Display the zoom controls on the touch screen.
• The zoom controls appear on the left side of the screen.
2 Touch the zoom controls to operate
the zoom.
Touch anywhere within the T area to
zoom out or anywhere within the S area
to zoom in. Touch closer to the center for
a slow zoom; touch closer to the V U/
icons for faster zooms.
3 Touch [X] to hide the zoom controls.
Selecting the Zoom Type
The camcorder offers three types of zoom - optical, advanced and
digital.
Operating modes:
* In mode, [Zoom Type] will be set to [ Optical].
[FUNC.] > [ZOOM]
*
[FUNC.] >
>
>
>> [Zoom Type] >
>
>
>> Desired zoom type
AUTO Mode 51
Options
NOTES
• Keep at least 1 m (3.3 ft.) away from the subject. At full wide angle, you
can focus on a subject as close as 1 cm (0.39 in.). Using tele macro
(A 106), you can focus on a subject as close as 50 cm (1.6 ft.) at full
telephoto.
• In or mode, you can also set p > [Zoom Speed] to
one of three constant speeds (3 is the fastest, 1 the slowest). When
[Zoom Speed] is set to [Y Variable], the zoom speed will be faster in
record pause mode than when actually recording, except when pre-
recording (A 98) is activated.
Quick Start
When you close the LCD panel with the camcorder on, the camcorder
enters the standby mode. In standby mode the camcorder consumes
only about 1/3 the power used when recording, saving energy when
you are using a battery pack. Additionally, when you open the LCD
panel, the camcorder is ready to start recording in approximately
1 second*, allowing you to record the subject right away.
* The actual time required varies depending on the shooting conditions.
Operating modes:
[ Optical] For optical zoom, the camcorder uses the optical
magnification ratio of the lens.
[ Advanced] For advanced zoom, the camcorder processes
the image beyond the range of the optical zoom to obtain a
larger zoom without any deterioration in image quality. At full wide
angle, the angle of view with advanced zoom is wider than the
angle of view with optical zoom.
[ Digital] For digital zoom (light blue area on the zoom bar),
the image is processed digitally so image quality will deteriorate
the more you zoom in. When you are using digital zoom (zoom
position is within the light blue area on the zoom bar), photos
cannot be taken.
52
AUTO Mode
1 With the camcorder on and in a recording mode, close the LCD
panel.
A beep will sound and the green ON/OFF (CHG) indicator will change
to orange to indicate the camcorder entered standby mode.
2 When you wish to resume recording, open the LCD panel.
The ON/OFF (CHG) indicator turns back green and the camcorder is
ready to record.
IMPORTANT
• Do not disconnect the power source during standby mode (while the
ON/OFF (CHG) indicator is lit in orange).
NOTES
• The camcorder will not enter standby mode if the LCD panel is closed
while the ACCESS indicator is on or flashing or while the HOME menu
or menus contained therein (not including the [ Main Functions]
panel) are being displayed. The camcorder may also not enter standby
mode when the battery charge is too low. Check that the ON/OFF
(CHG) indicator changes to orange.
• About standby mode and auto power off:
- The camcorder will power off automatically if left in standby mode for
10 minutes. Press P to turn on the camcorder.
- You can select the length of time until shut-off or turn off the Quick
Start function altogether with the q> [Power Saving Mode] >
[Quick Start (Standby)] setting.
- The usual 5-minute auto power off setting of [Power Saving Mode] is
not applicable while the camcorder is in standby mode.
Video 53
Video
This chapter covers functions related to movies, including play-
back, advanced shooting, using Story Creator and other
advanced functions. For details about basic video shooting,
refer to AUTO Mode (A 44).
Basic Playback
Playing Back Video
You can use the s > [Data Code] setting to choose whether to
display the recording date (and other information, for AVCHD movies)
when you play back videos (A 66).
Operating modes:
1 Press T.
2 Open the [ Movies] or
[ Movies] index screen, if
it is not displayed.
[G] > [ Movies] or [ Movies]
54
Video
3 Look for the scene you want to play back.
Move the zoom lever toward T to show 15 scenes per page; move it
toward S to show 6 scenes per page.
4 Touch the desired scene to play it back.
• For AVCHD movies, the camcorder will play back the scene selected
and continue until the end of the last scene in the index screen. For
MP4 movies, the camcorder will play back only one scene.
• Touch the screen to display the playback controls. During playback,
the playback controls will disappear automatically after a few
seconds without operation. In playback pause, touch the screen
again to hide the playback controls.
! Open the index selection screen.
" Memory being read.
# Recording date**.
$ Division line between recording dates.
% Drag your finger left/right for the next/previous index
page*.
& Display the next/previous index page.
' Scene's timeline (A 64)**.
( A3D Flip View ( 57)**.
* While browsing through index pages, a larger scroll bar will appear
at the bottom of the screen for a few seconds. When you have a
large number of scenes it may be more convenient to drag your fin-
ger along the scroll bar.
**Not available for MP4 movies.
Video 55
During playback:
Adjusting the volume for AVCHD movies
1 During playback, touch the screen to display the playback controls.
2 Touch [Ý], drag your finger along the [Speaker Volume]* bar to
adjust the volume and touch [K].
* When q > [AV/Headphones] is set to [ Headphones], adjust the [Head-Ó
phone Volume] bar instead.
! Jump to the beginning of the scene. Double-tap to jump
to the previous scene*.
" Jump to the beginning of the next scene*.
# Pause the playback.
$ Fast playback** backward/forward.
% Display the volume (A 55) and background music mix
balance (A 82) controls.
& Stop the playback.
' Decoration (A 73).
( Volume.
) Recording date. Use the s > [Data Code] setting to
turn this on and off.
* Not available for MP4 movies.
**Touch several times to increase the playback speed to approxi-
mately 5x → 15x → 60x (for AVCHD movies) or 5x → 15x (for MP4
movies) normal speed.
AVCHD movies MP4 movies
56
Video
Adjusting the volume for MP4 movies
1 During playback, touch the screen to display the playback controls.
2 Drag your finger across the volume bar to adjust the volume.
During playback pause:
IMPORTANT
• Observe the following precautions while the ACCESS indicator is on or
flashing. Failing to do so may result in permanent data loss.
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
• You may not be able to play back with this camcorder movies recorded
on a memory card using another device.
NOTES
• Depending on the recording conditions, you may notice brief stops in
video or sound playback between scenes.
• During fast/slow playback, you may notice some anomalies (blocky
video artifacts, banding, etc.) in the playback picture.
• The speed indicated on the screen is approximate.
• Slow reverse playback will look the same as continuous frame reverse.
! Resume playback.
" Slow playback* backward/forward.
# Capture the displayed frame as a photo (A 115)**.
$ Decoration (A 73)**.
* Touch several times to increase the playback speed 1/8 → 1/4 the
normal speed.
**Not available for MP4 movies.
Video 57
3D Flip View
Operating modes:
Touch [ ] in the [ Movies] index screen to switch to 3D Flip View.
This fun way of displaying scenes grouped by recording date in a 3D
layout can be useful to flip through a large number of recordings.
! Recording date.
" Drag your finger left to go to the next date with record-
ings.
# Drag your finger up and down to browse through the
scenes recorded in the displayed date.
$ Drag your finger right to go to the previous date with
recordings.
% Return to the [ Movies] index screen.
& Current scene / Total number of scenes recorded on the
selected date.
' Touch the scene in the front to play it back.
58
Video
The [Index Selection] Screen: Selecting the Content to Play Back
From the [G Index Selection] screen you can select the content you
want to play back (original scenes by date or by story, or photos, for
example). & %/ You can also select the memory from which
you want to play back your recordings.
Operating modes:
In any index screen:
Touch [G].
During single photo view, touch the screen once to display the controls
then touch [f] to open the [ Photos] index screen.
! & %/ Touch the tab of the desired memory:
built-in memory or memory card.
" Touch a control button to select the content you want to
play back.
Video 59
Options
NOTES
•& %/ Fast/slow playback modes are not available for scenes
converted to standard definition. Scenes in the [SD Movies] index
screen can only be played back at normal speed.
• You cannot jump to the previous or next scene with MP4 movies.
[y
y
y
yy Movies] Scenes recorded in AVCHD organized by
recording date.
[ê
ê
ê
êê Gallery] Scenes recorded in AVCHD organized by story
(A79).
[ Movies] Scenes recorded in MP4.
[ Photos] Photos’ index screen.
[z
z
z
zz SD Movies] (& %/ only when a memory card is
selected) Scenes that were converted to standard definition to
upload them to the Web (A142).
Two playback modes for AVCHD movies: the [ Movies]
index screen vs. the gallery
In the [ Movies] index screen you can find all the AVCHD mov-
ies you have recorded, conveniently organized by recording date.
When you play back scenes from the [ Movies] index screen
they will be played back in chronological order.
In the gallery, you can find your scenes grouped as video stories. If
you record movies using the Story Creator function (A67), your
scenes will appear in the story you created; scenes recorded with-
out using this function will appear in the [Unsorted] story (or [Video
Snapshot] story, in the case of video snapshot scenes). When you
play back a story from the gallery, scenes will be played back in the
order of the story’s outline, regardless of their recording date.
60
Video
Deleting Scenes and Stories
You can delete those scenes and stories that you are not interested in
keeping. Deleting scenes allows you also to free up space on the mem-
ory.
Deleting a Single Scene
Operating modes:
1 Play back the scene you wish to delete.
When playing back a scene in the gallery, pause the scene you wish to
delete and then continue to step 2.
2 Touch the screen to display the playback controls.
3 Delete the scene.
Deleting Scenes from the [ Movies] or [ Movies] Index Screen
Operating modes:
1 Open the [ Movies] or [ Movies] index screen.
For AVCHD movies, to delete all the scenes recorded on a specific
date, drag your finger left/right until the desired date appears in the title
bar.
2 Delete the scenes.
* When you select [Select], perform the following procedure to select the individ-
ual scenes you want to delete before touching [Yes].
** Touch [Stop] to interrupt the operation while it is in progress. Some scenes may
be deleted nevertheless.
[Ý] > [Edit] > [Delete] > [Yes] > [OK]
[Edit] > [Delete] > Desired option* > [Yes]** > [OK]
Video 61
To select individual scenes
1 Touch on the individual scenes you want to delete.
• A checkmark ! will appear on the scenes you touch. The total
number of selected scenes will appear next to the " icon.
• Touch a selected scene to remove the checkmark. To remove all
checkmarks at once, touch [Remove All] > [Yes].
2 After selecting all the desired scenes, touch [OK].
Options
Deleting a Single Scene from a Story
Operating modes:
1 Open the list of scenes of the story that contains the scene you
want to delete.
2 In the [Scene List] screen, drag your finger up/down to select the
scene you want to delete.
3 Touch the orange [ ] icon on the left to open the [Edit Scene]
screen.
4 Delete the scene.
[date]Delete all the scenes recorded on the date shown in the
control button. For AVCHD movies only.
[Select] Select individual scenes to delete.
[All Scenes] Delete all the scenes.
[G] > [ Gallery] > Bring the desired story to the
front > [Scene List]
[ ] > [Yes] > [OK] > [K]
Video 63
Deleting Stories
Operating modes:
Deleting a story permanently deletes all the scenes it contains. The two
preexisting stories, [Unsorted] and [Video Snapshot], cannot be
deleted.
1 Open the gallery.
2 Select the story you want to delete.
Drag your finger right/left to bring the desired story to the front.
3 Delete the story.
* Touch [Stop] to interrupt the operation while it is in progress. Some scenes may
be deleted nevertheless.
IMPORTANT
• Be careful when deleting recordings. Once deleted, scenes cannot be
recovered.
• Deleting a story permanently deletes all the scenes it contains.
• When deleting scenes, scenes will be removed from the [ Movies]
or [ Movies] index screen and from any stories in the gallery they
may have belonged to, regardless of the method used to delete them.
• Save copies of important scenes before deleting them (A131).
• Observe the following precautions while the ACCESS indicator is on or
flashing (while scenes are being deleted).
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
[G] > [ Gallery]
[Story Details] > [Edit Story] > [Delete Story] > [Yes]*
> [OK]
Video 65
To change the interval between frames
!Touch twice to return to the index screen.
"Previous/next scene.
#Drag your finger left along the ruler to display the next 5 frames.
$Scene’s recording mode and length.
%Recording date and time.
&Drag your finger right along the ruler to display the previous
5 frames.
'Current scene / Total number of scenes.
(Currently selected interval between frames.
[6 sec] > Desired interval > [K]
66
Video
Onscreen Displays and Data Code
With every scene or photo recorded, the camcorder keeps a data
code. For AVCHD movies, the data code includes date/time of record-
ing, information about the camera setup, etc. For MP4 movies, the
data code is the date of recording. You can choose the information to
be displayed.
Operating modes:
1 Press .
2 Select the information to be displayed.
NOTES
• The data code will appear when the screen is touched, regardless of the
selected option.
[ Other Settings] > [y] or [ ] > [Data Code] >
Desired option > [X]
Video 67
Video Stories and Cinema Style
Using Story Creator to Create Compelling Stories
Story Creator is a helpful function that offers suggestions for typical
scenes in a number of situations. With Story Creator, creating interest-
ing video stories is as easy as selecting one of the story themes, such
as [Travel], [Party] or [Kids & Pets], and following the suggested cate-
gories to record video. During playback, select your story from the gal-
lery to play back the scenes you recorded as a single, compelling video
story (A79).
Operating modes:
Creating a New Story
1 Press .
2 Start Story Creator mode.
3 Touch [Create New Story] and select the desired theme.
Drag your finger left/right to bring the desired story theme to the front.
4 Touch [Create Story] and then select the story scene (category).
Initially, the current date will be used as the story’s title, but you can
change it by touching [ì] (A87).
5 Touch [To Recording Screen].
A confirmation screen will appear that shows the selected theme, story
scene (category), shooting advice and the recommended shooting
length.
[ Recording Standard] > [é] > [OK]
[ë] (including the story scene title) > Desired story
scene > Orange [ ] icon on the left
68
Video
6 Touch [OK].
• A new story will be created and the camcorder will enter record
pause mode. The selected story scene category will appear at the
bottom of the screen.
• If you touch [?], a screen showing the selected theme, story scene
(category), shooting advice and the recommended shooting length
will appear.
Recording a Scene within a Story
Press Y to record movies within the selected story scene
(category).
• Use the displayed recommended length as a reference when recording
scenes.
• Scenes will be recorded under the story and story scene currently
selected.
• You can also record video snapshot scenes (A72).
To select a different story scene (category)
1 Touch [ë] (including the story scene title) at the bottom of the
screen.
2 Drag your finger up/down to select another category and touch the
orange [ ] icon on the left.
!Shooting tip for the current category.
"Recommended length of scenes in this category.
#Currently selected story scene (category). You can
touch here to return to the list of story scenes.
70
Video
Cinema Mode and Cinema-Look Filters
In (cinema) mode, the camcorder will adjust the frame rate and
several other picture-related settings to give your recordings a cine-
matic look. In this mode you can also use a variety of professional cin-
ema-look filters to create unique movies with a distinctive appearance.
Operating modes:
1 Press .
2 Set the camera mode to .
3 Select the desired cinema-look filter.
• The selected cinema-look filter will be applied and its number will
appear on the control button.
[ Camera Mode] > [ ] > [OK]
[FILTER 1] > Desired cinema-look filter > [OK]
Video 71
Options (
Default value)
The camcorder offers 7 cinema-
look filters. Select the desired filter
while previewing the effect on the
screen.
NOTES
• Photos cannot be recorded while the camcorder is set to mode.
[1: Cinema Standard]
[2: Vivid]
[3: Cool]
[4: Nostalgic]
[5: Sepia]
[6: Old Movies]
[7: Dramatic B&W]
! Filter number (will appear on
the control button)
" Filter name
# Preview the effect on the
screen
$ Brief description (onscreen
guidance)
72
Video
Video Snapshot
Record a series of short scenes. Then, play back your video snapshot
scenes set to your favorite music (A 82) to create your own fun music
video. You will be surprised how by changing the background music,
you can give your scenes an entirely new feel.
The default length of a video snapshot scene is 4 seconds but you can
change it to 2 or 8 seconds, or to the length recommended for the
selected story scene (category) in Story Creator, with the r >
[Video Snapshot Length] setting.
Operating modes:
1 Press V.
• A blue border appears on the
screen.
• Press V again to
return to normal video
recording mode.
2 Press Y.
• The camcorder records for a
few seconds (the blue frame
serves as a visual progress bar)
and then automatically returns
to record pause mode.
• When the camcorder stops recording, the screen will momentarily
turn black as if a camera shutter had released.
NOTES
• Changing the camcorder to playback mode will deactivate the video
snapshot mode.
Video 73
Decoration: Adding a Personal Touch
Add a new level of enjoyment to
your scenes by decorating
them. You can add animated
graphics, stamps and even your
own freehand drawings. The
supplied stylus pen will be espe-
cially useful for decorating
scenes.
You can decorate scenes as
they are being recorded, during
playback or just before convert-
ing them to standard definition
( /& % only; A 142).
Decorating Scenes while Recording
Operating modes:
1 Open the decoration screen.
• The decoration screen will open automatically also when you stow
the LCD panel with the touch screen facing out.
2 Use a tool from the toolbar as explained in the following
procedures.
3 Press Y to record movies with your decorations.
You can add decorations even while recording a scene.
4 Touch [X] to exit the decoration screen.
[FUNC.] > [Ò Decoration]
74
Video
! Canvas - The area where you will draw and see your decorations
in action.
" Toolbar.
# [Ó Pens and Stamps] Select the type of pen or stamp and its
color. You can also save a canvas or load a previously saved
canvas.
$ [× Animated Stamps] Select animated stamps to add to your
decoration.
% [ Ø Captions] Add the date, date and time, story title* or story
theme* as a caption that will be included in the recording.
& [Ü]** (Image Mix) Choose one of 27 different frames to add
onto the canvas. Image mix can be used in combination with the
pens, stamps and animated stamps.
' [Ý]** In recording mode: pause the live video. Touch [Ý] again to
restore the live video. You can add decorations to and record the
frozen image.
In playback mode: pause the playback. Touch [Ð] to resume
playing back the scene.
( [ß] Minimize the toolbar to the top of the screen to view almost
all of the canvas. Touch [à] to restore the toolbar.
* Not available in mode.
**Not available in mode and for MP4 movies.
Video 75
To use [Pens and Stamps]
1 Touch [Ó].
The [Pens and Stamps] screen will appear.
2 Select the desired pen or stamp from [Tools].
3 Select white or black from [Colors].
Alternatively, you can touch [Ö] and select a color from the color
palette.
4 Draw freely on the canvas.
Touch [Ó] > [Clear] > [Yes] to clear the canvas and start again.
5 When you finish drawing, save the canvas.
* The freehand drawings and stamps will be saved in the built-in memory (&/
% ' only) or on a memory card ( only).
To load a previously saved canvas
In the decoration screen:
* The camcorder will apply the last freehand drawings and stamps that were saved
in the built-in memory (& %/ only) or on a memory card (' only).
To use [Animated Stamps]
1 Touch [×].
The [Animated Stamps] screen will appear.
2 Touch one of the control buttons.
3 Touch anywhere on the canvas to place the selected animated
stamp. You can also drag some animated stamps to a different
location.
[Ó] > [&Save]* or [* Save]* > [Yes] > [K]
[Ó] > [&Load]* or [* Load]* > [Yes] > [K]
76
Video
To use [Captions]
1 Touch [Ø].
The [Captions] screen will appear.
2 Touch [Date] or [Time].
When recording a scene using Story Creator, you can also select [Title]
(the story’s title) or [Story Scene] (the story scene category).
3 Select the desired text settings and touch [K].
• Touch [ ] (white text on dark background), [ ] (white text) or [ ]
(black text).
4 Touch the caption and drag it to the desired location.
To use image mix
Operating modes:
1 Touch [Ü] to open the [Select Image] screen.
2 Touch [+] or [-] to select a different image mix frame.
& %/ You can touch one of the memory icons at the bottom of
the screen to read image mix frames saved on a different memory (only
when recording on or playing back scenes from a memory card).
3 Touch [K] to mix the selected frame with the live video.
Video 77
To use the Chroma Key function
1 Open the [Select Image] screen of the image mix function (A 76).
2 Touch [+] or [-] to select the image you created.
3 Touch [Ð] to open the [Chroma Key] screen.
4 Touch [Green] or [Blue] depending on the characteristics of the
image you want to use and touch [Ï] or [Ð] or drag your finger
along the bottom bar to adjust the chroma key setting as necessary.
5 Touch [Ð] at the top of the screen to open the [Transparency]
screen.
6 Touch [Ï Ð] or [ ] or drag your finger along the bottom bar to adjust
the overall transparency of the image as necessary.
7 Touch [K] to mix your image with live video.
Mixing Your Own Images with Live Video
You can use images you make on your computer for the image mix
(Chroma Key) function. Make sure that the image you want to use
has a blue or green area, which will be replaced by the live video
using Chroma Key mixing. Refer to About the image files for the
Image Mix function (A 219) for details about the types of image
files that can be used and where to transfer them.
Blue/Green area that will be replaced
by the live video
Example of an image used for Chroma Key
78
Video
Decorating Scenes during Playback
Operating modes:
1 From the [ Movies] index screen or gallery, play back the
scene you want to decorate.
2 Touch the screen to display the playback controls.
3 Touch [Ò] to open the decoration screen.
4 Decorate the scene using the tools from the toolbar as explained
in the previous section.
In playback mode, the decorations will not be saved with the original
recording.
NOTES
• Initializing a memory will erase any [Pens and Stamps] drawing canvas
and image files you may have saved. (& %/ The image mix
frames that come pre-installed in the built-in memory will be restored
after it is initialized.)
• When q i > [Autostart Decoration] is set to [ On], the decora-
tion screen will open automatically when you stow the LCD panel with
the LCD screen facing out.
• Animated stamps and captions cannot be used at the same time.
• & %/ When r > [Rec Media for Movies] is set to [&] (the
built-in memory), you will not be able to select image mix frames saved
on a memory card.
• Image mix cannot be selected during playback or while converting a
scene to standard definition (A142; & %/ only). Select the
image mix during playback pause or before starting the conversion.
• For AVCHD movies, decorations will appear in the thumbnails of scenes
in the [ Movies] index screen and gallery. For MP4 movies, decora-
tions will not appear in thumbnails.
Video 79
Playing Back Stories from the Gallery
You can play back recordings made using Story Creator to play them
back as a single compelling video story following the order of the
story’s script. Regular scenes and video snapshot scenes recorded
without using Story Creator, will appear in the gallery under the
[Unsorted] or [Video Snapshot] stories. When playing back stories from
the gallery, you can choose to play back only scenes with a certain rat-
ing.
Operating modes:
1 Open the gallery.
! Open the [G Index Selection] screen (A 58).
" Drag your finger right or left to select a story.
# Story’s theme.
$ Selected story (large thumbnail in the front).
% Story’s title (A 87).
& Details about the story (number of scenes, total playback time)
and editing options.
' List of scenes recorded in the selected story.
2 Select the story you want to play back.
Drag your finger right/left to bring the desired story to the front.
[G] > [ Gallery]
80
Video
3 Select the rating of the scenes you want to play back.
4 Touch the story’s thumbnail to start the playback.
• The complete story will be played back from the first scene to the
last. When playback ends, the camcorder will return to the gallery.
• During the playback of a story other than [Unsorted] or [Video
Snapshot], touch the screen and then touch [ë] to display the
scene’s category during playback. Touch the screen and then touch
[ë] again to turn the story scene display off.
• Playback controls are the same as when playing back scenes from
the [ Movies] or [ Movies] index screen (A 55).
IMPORTANT
• Observe the following precautions while the ACCESS indicator is on or
flashing. Failing to do so may result in permanent data loss.
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
NOTES
• If playback of a scene in the gallery is interrupted, you cannot resume
playback at the point it stopped. The story will start over from the begin-
ning the next time you play it back.
[Story Details] > [Select by Rating] > Desired rating >
[ ]K] > [K
82
Video
2 Open the list of scenes of the story that contains the scenes you
want to rate.
3 In the [Scene List] screen, drag your finger up/down to select the
scene you want to rate.
4 Touch the orange [ ] icon on the left to open the [Edit Scene]
screen.
5 Touch the control button of the desired rating and touch [K]
twice to return to the gallery.
Rating Scenes During Playback
Operating modes:
1 Play back from the gallery the story that contains the scenes you
want to rate.
2 During playback of a scene you want to rate, pause the playback
and rate the scene.
3 Touch [Ð] to resume the playback and rate other scenes in the
same way or touch [Ñ] to return to the gallery.
Playback with Background Music
You can play back movies (or a photo slideshow) using one of the sup-
plied music tracks as background music.
Operating modes:
[G] > [ Gallery] > Bring the desired story to the
front > [Scene List]
Touch the screen > [Ý] > [Edit] > [Rating] > Desired
rating >
>
>
>> [X]
Video 83
The supplied VIXIA CD-ROM contains 3 music tracks you can use as
background music. & %/ : The music files come pre-installed in
the built-in memory.
You can mix the original audio and the background music and adjust
the background music mix balance to your preference.
POINTS TO CHECK
• To play back scenes or a slideshow of photos recorded on the memory
card, you will need to transfer the music tracks to the memory card in
advance. See the NOTES section (A 85).
1 Press .
2 Open the gallery or [ Movies] index screen.
3 Press .
4 Select the music track.
[G] > [ Gallery] or [ Movies]
[ Other Settings]
>
s
>
[Select Music]
>
[
i
On]
>
[Í] or [Î] to select the desired music track
! Select the desired music track.
" Adjust the background music balance.
# Play back the original sound (no background music).
$ Delete the music track selected.
% Listen to the music track selected. Touch again (Ñ) to
stop the playback.
84
Video
5 Adjust the mix balance between the original sound and the
background music.
Touch [y] (more of the original sound) or [Û] (more of the background
music) or drag your finger along the [Music Balance] bar to adjust the
background music balance as desired.
6 Touch [X] and then touch a story or scene to start the playback
with the selected background music.
To adjust the background music balance during playback
1 During playback, touch the screen to display the playback controls.
2 Touch [Ý], drag your finger along the [Music Balance] bar to adjust
the background music balance as desired and touch [K].
To delete a music track
In the [Select Music] screen, touch [Í] or [Î] to select the track you
want to delete.
IMPORTANT
• If you use copyrighted songs and music tracks in your video creations,
remember that music under copyright may not be used without permis-
sion from the copyright holder, except for cases permitted under appli-
cable laws, such as for personal use. Make sure to follow applicable
laws when using music files.
[ ] > [Yes]
Video 85
NOTES
• Initializing a memory card will permanently erase any music files you
may have transferred to the card. (& %/ The music files that
come pre-installed in the built-in memory will be restored after it is initial-
ized.) To transfer music files from the supplied VIXIA CD-ROM to the
memory card:
- Windows users: Use the supplied software VideoBrowser (&/
% only) or Transfer Utility (' only). For details, refer to the
Software Guide (PDF file) of the supplied PIXELA’s software.
- Mac OS users: Use Finder to transfer music files from the [MUSIC]
folder on the supplied VIXIA CD-ROM to the memory card. Refer to
About the music files (A 219) for the folder structure of the memory
card.
• Transfer music files to the memory card that contains the recordings
you want to play back with background music.
Copying and Moving Scenes Within/Between Stories
You can copy and move scenes in the gallery within the same story
scene (category), between story scenes in the same story, and
between stories recorded in the same memory.
Operating modes:
1 Open the list of scenes of the story that contains the scene you
want to copy or move.
2 In the [Scene List] screen, drag your finger up/down to select the
scene you want to copy/move.
3 Touch the orange [ ] icon on the left to open the [Edit Scene]
screen and touch [Copy] or [Move].
[G] > [ Gallery] > Bring the desired story to the
front > [Scene List]
86
Video
4 Select the destination.
Drag your finger right/left to select the desired story and touch its
thumbnail. Then, drag your finger up/down to select the desired
category and touch the orange [ ] icon on the left. And last, drag your
finger up/down to move the orange bar within the category to select
the position of the scene.
5 Copy or move the scene.
1This step is not necessary when copying/moving a scene into a story scene
category that contains no other scenes.
2When copying a scene, you can touch [Stop] to interrupt the operation while it
is in progress.
3This step is not necessary when moving a scene.
NOTES
• You cannot copy or move scenes to the two preexisting stories,
[Unsorted] and [Video Snapshot].
Selecting a Story’s Thumbnail Image
Initially, the image used as the story’s thumbnail is the first frame of the
first scene in the story. You can set your favorite scene as the thumb-
nail that will represent the story in the gallery.
Operating modes:
1 Open the gallery.
2 Select the story whose thumbnail you want to change.
Drag your finger right/left to bring the desired story to the front.
[Set]1 > [Yes] 2 > [OK] 3 ]> [K
[G] > [ Gallery]
Video 87
3 Open the [Story Thumbnail] screen.
4 Locate the frame you want to use as the story’s thumbnail.
Playback controls will appear on the screen (A55). Use any special
playback modes (fast/slow playback, frame reverse/advance) as
necessary to locate the desired image.
5 Touch [Set] to change the story’s thumbnail.
6 Touch [K] to return to the gallery.
Changing a Story’s Title
When you first create a story, the current date will be used as the
story’s title but you can change the title later on. The title can be up to
14 characters long (available characters are limited). The title of the two
preexisting stories, [Unsorted] and [Video Snapshot] cannot be
changed.
Operating modes:
1 Open the gallery.
2 Select the story whose title you want to change.
Drag your finger right/left to bring the desired story to the front.
3 Open the [Edit Title] screen.
4 Use the virtual keyboard to change the title.
5 Touch [OK] > [ [K] >K] to return to the gallery.
[Story Details] > [Edit Story] > [Story Thumbnail]
[G] > [ Gallery]
[Story Details] >
>
>
>> [Edit Story] > [Edit Title]
88
Video
NOTES
• We recommend using the supplied stylus pen to enter characters.
• /& % When you import files with the supplied software
VideoBrowser using the option to join and import music and video files
from the gallery, some special characters in the story's title (/, \, <, >, :,
*, ", |, ?) will be changed to an underscore (_) in the file name.
!Switch between letters and numbers/special characters.
"Change the position of the cursor.
#Delete the character to the cursor’s left (backspace).
$Caps Lock. When the numerical keyboard is displayed,
[#%?] switches between set 1 and set 2 of special char-
acters.
Video 89
Advanced Functions
Recording in Manual Mode
When the camcorder is set to mode, you can enjoy full access to
the menus and manually adjust the exposure, focus, white balance and
many more of the camcorder’s settings to your preference. Even in this
mode, though, the camcorder can help you with the settings. For
example, by using Special Scene recording programs (A95).
Operating modes:
1 Press P to turn on the
camcorder.
• /& % By default,
movies and photos are
recorded in the built-in
memory. You can select the
memory that will be used to
record movies and photos
(A40).
• Please read the IMPORTANT
section (A48) before using
an Eye-Fi card.
2 Open the lens cover switch.
3 Press .
To change the recording
standard, refer to Recording
(A31).
4 Set the camcorder to mode.
5 Record movies and photos.
The procedure is the same as in mode (A44).
[ Camera Mode] >
>
>
>> [n] > [OK]
90
Video
IMPORTANT
• To protect the lens, keep the lens cover closed when you are not
recording movies and when you are not using the camcorder.
• Observe the following precautions while the ACCESS indicator is on or
flashing. Failing to do so may result in permanent data loss or damage
to the memory.
- Do not open the memory card slot cover.
- Do not disconnect the power source or turn off the camcorder.
- Do not change the camcorder’s operating mode.
• Be sure to save your recordings regularly (A128), especially after
making important recordings. Canon shall not be liable for any loss or
corruption of data.
• Recordings on an Eye-Fi card will be uploaded automatically after set-
ting the camcorder to playback mode, if you are within the range of a
configured network. Always verify that Eye-Fi cards have been
approved in the country/region of use. See also Using an Eye-Fi card
(A146).
NOTES
• The zoom, Quick Start function, power saving modes, etc. operate the
same way in mode as in mode. For details, refer to AUTO
Mode (A44).
• Photos cannot be recorded while the digital zoom is activated (light blue
area on the zoom bar) or while fading in or fading out a scene.
Reviewing the Latest Scene Recorded
You can review the last 4 seconds of the last scene recorded with the
camcorder without switching to playback mode. While reviewing the
latest scene, the picture will be played back without sound.
Operating modes:
[FUNC.] > [v Review Recording]
Video 91
NOTES
• For MP4 movies, you cannot review the last movie recorded if, after you
recorded the movie, you performed another operation such as opening
a menu.
Selecting the Video Quality (Recording Mode)
The camcorder offers 5 recording modes for recording AVCHD movies
and 2 for MP4 movies. Changing the recording mode will change the
recording time available on the memory. For AVCHD movies, select
MXP or FXP mode for better movie quality; select LP mode for longer
recording times.
For MP4 movies, you can choose one of two bit rates. Bit rate indi-
cates how much information is recorded in 1 second of video. Select
4 Mbps for smaller file sizes and faster uploads.
The following table gives approximate recording times.
Operating modes:
1 Press .
2 Select the recording mode.
For MP4 movies, a single scene can be
recorded continuously for 30 minutes. The
icon in the upper left is a reminder of
this. If the file size reaches 4 GB even before
30 minutes has elapsed, however, recording
will stop.
[ Other Settings] > > r [Recording Mode] >
Desired recording mode > [X]
Video 93
Approximate recording times Default value
AVCHD movies in MXP mode are recorded in 1,920 x 1,080 resolution. AVCHD
movies recorded using other recording modes are recorded in 1,440 x 1,080
resolution. MP4 movies are recorded in 1,280 x 720 resolution.
For AVCHD movies:
For MP4 movies:
1& %/ At the time of purchase, the built-in memory contains about 70
MB of music files (background music), 5 MB of image files (image mix frames)
and about 2 MB of file management data.
2A single scene can be recorded continuously for 12 hours; at that point, the
camcorder will stop for about 3 seconds before resuming recording.
Recording mode → MXP FXP XP+ SP
LP
Memory ↓
4 GB Memory card 20 min. 1 hr. 30 min. 40 min.
10 min.
1 hr.
30 min.
8 GB Memory card/
% Built-in memory 1
40 min. 1 hr. 1 hr.
25 min.
2 hr.
20 min.
3 hr.
16 GB Memory card 1 hr.
25 min.
2 hr.
5 min.
2 hr.
50 min.
4 hr.
45 min.
6 hr.
5 min.
32 GB Memory card/
& Built-in memory 1
2 hr.
55 min.
4 hr.
10 min.
5 hr.
45 min.
9 hr.
35 min.
12 hr.
15 min.
2
Recording mode → 9 Mbps 4 Mbps
Memory ↓
4 GB Memory card 55 min. 2 hr. 5 min.
8 GB Memory card/
% Built-in memory 1
1 hr. 50 min. 4 hr. 10 min.
16 GB Memory card 3 hr. 50 min. 8 hr. 25 min.
32 GB Memory card/
& Built-in memory 1
7 hr. 40 min. 16 hr. 55 min.
94
Video
Selecting the Frame Rate
You can change the frame rate (the number of frames recorded per
second) to change the look of your movies.
Operating modes:
1 Press .
2 Select the frame rate.
Options for AVCHD movies ( Default value)
Options for MP4 movies ( Default value)
NOTES
• The frame rate can be set independently for and modes.
[´ 60i (Standard)] 60 fields per second, interlaced. Standard
frame rate of NTSC analog TV signals.
[· PF30] Shooting at 30 frames per second, progressive*. Use
this frame rate to easily edit your recordings, for example, to post
them on the Web.
[¹ PF24]** Shooting at 24 frames per second, progressive*.
Using this frame rate will give your recordings a cinematic look.
Recording in mode will further enhance the effect.
* Recorded as 60i.
**Default option for mode.
[ 30P]30 frames per second, progressive.
[» 24P] 24 frames per second, progressive.
[ Other Settings] >
>
>
>> r >
>
>
>> [Frame Rate] >
>
>
>>
Desired frame rate >
>
>
>> [X]
Video 95
Special Scene Recording Programs and Programmed AE
Recording in a very bright ski resort or capturing the full colors of a
sunset or a fireworks display becomes as easy as selecting a Special
Scene recording program.
On the other hand, you can select the Programmed AE (AE: auto expo-
sure) recording program. With this recording program, the camcorder
automatically adjusts the shutter speed and aperture while you are able
to adjust the other settings.
Operating modes:
* To set the Programmed AE recording program, select [’ Programmed AE]
instead and then touch [ ]. The rest of the procedure is not necessary.X
Options ( Default value)
[úSCN: Portrait] The camcorder uses a large
aperture, to achieve a sharp focus on the sub-
ject while blurring the background.
[ûSCN: Sports] To record sports scenes such
as tennis or golf.
[ü SCN: Night Scene] To record nightscapes
with lower noise.
[ýSCN: Snow] To record in bright ski resorts
without the subject being underexposed.
[FUNC.] >
>
>
>> [Rec. Programs] >
>
>
>> [úSCN: Portait]* >
>
>
>>
Desired recording program >
>
>
>> [X]
96
Video
NOTES
• [ú ûSCN: Portrait]/[ SCN: Sports]/[ý SCN: Snow]/[þ SCN:
Beach]: The picture may not appear smooth during playback.
• [ú SCN: Portrait]: The blur effect of the background increases the
more you zoom in (S).
• [ý þSCN: Snow]/[ SCN: Beach]: The subject may become overex-
posed on cloudy days or in shaded places. Check the image on the
screen.
• [Œ SCN: Low Light]:
- Moving subjects may leave a trailing afterimage.
- Picture quality may not be as good as in other modes.
- White points may appear on the screen.
- Autofocus may not work as well as in other modes. In such case,
adjust the focus manually.
[þSCN: Beach] To record on a sunny beach
without the subject being underexposed.
[ÿ SCN: Sunset] To record sunsets in vibrant
colors.
[ŒSCN: Low Light] To record in low-light situa-
tions.
[œ SCN: Spotlight] To record spotlit scenes.
[Š SCN: Fireworks] To record fireworks.
98
Video
NOTES
• If the degree of camcorder shake is too high, the image stabilizer may
not be able to fully compensate.
• [ Dynamic] is available only when [Zoom Type] is set to
[ Optical].
• For surveying and following shots, when you pan the camcorder from
side to side or tilt it up and down, we recommend setting the IS mode
to [ Dynamic] or [ Standard].
Pre-Recording
The camcorder will start recording 3 seconds before you press
Y, ensuring you do not miss important shooting opportuni-
ties. This is especially useful when it is difficult to predict when to start
recording.
Operating modes:
1 Activate the pre-recording function.
• z will appear on the screen.
• Repeat, selecting [OFF], to turn off pre-recording.
Powered IS
You can use Powered IS to make the image stabilization even more
powerful. Powered IS is most effective when you are stationary and
zooming in on far subjects using high zoom ratios (the more you
approach the telephoto end). Holding the LCD panel with your left
hand will add to the stability of the shot.
• By default, the custom control button (A 180) is set to
[È Powered IS].
[FUNC.] > [È Powered IS] > [ON] > [X]
[FUNC.] > [ [z Pre REC] > [ON] >X]
Video 99
2 Press Y.
The scene recorded in the memory will start 3 seconds before
Y was pressed.
NOTES
• The camcorder will not record the full 3 seconds prior to pressing
Y if the button was pressed within 3 seconds of having
turned on pre-recording or having finished the previous recording.
• Any of the following actions will deactivate the pre-recording function.
- Leaving the camcorder without any operation for 5 minutes.
- Changing the operating mode.
- Pressing V.
- Opening the decoration screen.
- Closing the LCD panel to set the camcorder to standby mode.
- Touching any of the following control buttons in the [Main Functions]
panel: [Rec. Programs], [White Balance], [Faders], [Decoration] or
[Review Recording].
- Opening the [Other Settings] menus.
Face Detection
The camcorder automatically detects people’s faces and uses this
information to select the optimal settings for beautiful videos and pho-
tos.
Operating modes:
* Face detection is always activated in mode.
POINTS TO CHECK
• Select a recording program other than [ü SCN: Night Scene],
[Œ SCN: Low Light] or [Š SCN: Fireworks].
By default, face detection is activated. If the function was turned off, per-
form the following procedure to turn it on.
1 Press .
*
100
Video
2 Activate face detection.
To select the main subject
If there is more than one person in the picture, the camcorder will auto-
matically select one person it determines is the main subject. The main
subject is indicated by a white face detection frame and the camcorder
will optimize the settings for that person. Other faces will have gray
frames.
Touch a different face on the
touch screen to optimize the
camcorder’s settings for that
person using the Touch &
Track function.
NOTES
• The camcorder may mistakenly detect the faces of non-human sub-
jects. In such case, turn face detection off.
• In certain cases, faces may not be detected correctly. Typical examples
include:
- Faces extremely small, large, dark or bright in relation to the overall
picture.
- Faces turned to the side, at a diagonal or partially hidden.
• Face detection cannot be used when the shutter speed used is slower
than 1/30 (1/24 if the frame rate is set to [¹ PF24] or [» 24P]) or
when the digital zoom is activated at more than 144x zoom.
• When face detection is activated, the slowest shutter speed used by the
camcorder is 1/30 (1/24 if the frame rate is set to [¹ PF24] or [»
24P]).
[ Other Settings] > > p [Face Detection &
Tracking] > [i On }] > [X]
Main subject
102
Video
Faders
The camcorder offers two professional looking transition effects to
fade-in or fade-out scenes. You have the option to activate the fader
only one time or every time you start or stop recording.
Operating modes:
* You can preview the transition effect on the screen.
• The icon of the selected fader appears in green.
To fade in/out
Press Y in record pause mode (Û) to start recording with
a fade in. Press Y while recording (Ü) to fade out and pause
the recording.
NOTES
• When you apply a fader, not only the picture but also the sound will fade
in or out.
• Faders cannot be used in the following cases:
- While using the [Old Movies] cinema-look filter in mode.
- When recording scenes with decorations.
- When recording video snapshot scenes.
- While pre-recording is activated.
• You can select whether to fade to/from a black screen or a white screen
with the p > [Fader Setting] setting.
[FUNC.] > [ [R Faders] > Desired fader* >X]
Video 103
Manual Exposure Adjustment
At times, backlit subjects may appear too dark (underexposed) or sub-
jects under very strong lights may appear too bright or glaring (overex-
posed). To correct this, you can adjust the exposure manually or use
the Touch AE function to automatically set the optimal exposure for the
subject you select. This is convenient when the brightness of the sub-
ject you want to shoot is noticeably brighter/darker than the general
brightness of the image.
Operating modes:
POINTS TO CHECK
• Select a recording program other than [Š SCN: Fireworks].
1 Open the exposure adjustment screen.
2 Touch a subject that appears inside the y frame.
• The Touch AE mark (I) will flash and the exposure will be adjusted
automatically so the area you touched will be correctly exposed. You
have the option to further adjust the exposure manually as
necessary.
• You can touch [n] instead to adjust the exposure manually without
activating the Touch AE function.
• The manual adjustment dial appears and the adjustment value is set
at ±0.
• Touch [n] again to return the camcorder to automatic exposure.
3 Touch [Ï Ð] or [ ] or drag your finger along the dial to set the
exposure adjustment value.
The adjustment range may vary depending on the initial brightness of
the image, and some values may be grayed out.
4 Touch [X] to lock the exposure at the selected value.
During exposure lock, y and the selected exposure adjustment value
will appear on the screen.
[FUNC.] > [y Exposure]
104
Video
NOTES
• If the recording program is changed during exposure lock, the cam-
corder will return to automatic exposure.
• When shooting subjects with a strong light source behind them, the
camcorder automatically corrects for the backlight*. You can turn off the
automatic backlight correction with the p > [Auto Backlight Cor-
rection] setting. Note that the automatic backlight correction is not avail-
able in the following cases.
- In mode, when using a cinema-look filter other than [Cinema
Standard].
- When using the [ü SCN: Night Scene], [ý SCN: Snow], [þ SCN:
Beach], [ÿ SCN: Sunset] or [œ SCN: Spotlight] recording program.
* Except in mode when using a cinema-look filter other than [Cinema Stan-
dard].
Manual Focus Adjustment
Autofocus may not work well on the following subjects. In such case,
focus manually.
Operating modes:
POINTS TO CHECK
• Adjust the zoom before you start the procedure.
1 Open the manual focus screen.
• Reflective surfaces
• Subjects with low contrast
or without vertical lines
• Fast moving subjects
• Through wet windows
• Night scenes
[FUNC.] > [< Focus]
Video 105
2 Touch a subject that appears inside the < frame.
• The Touch AF mark (I) will flash and the focusing distance will be
adjusted automatically. You have the option to further adjust the
focus manually as necessary.
• You can touch [D] instead to adjust the focus manually without
activating the Touch AF function.
• The manual focus controls appear.
• Touch [D] again to return the camcorder to autofocus.
3 Touch and hold [F] or [E] to adjust the focus.
• The center of the screen will be magnified to help you focus more
easily. You can also turn off this function with the p > [Focus
Assistance] setting.
• The focusing distance displayed will change as you adjust the focus.
The focusing distance will be displayed for about 2 seconds. You can
change the units used for the distance display with the q >
[Distance Units] setting.
• If you wish to focus on faraway subjects such as mountains or
fireworks, touch and hold [F] until the focusing distance changes
to G.
4 Touch [X] to lock the focus at the selected distance.
During manual focus, [D] will appear on the screen.
NOTES
• During manual focus, you can touch inside the frame to activate the
Touch AF function and autofocus on a subject.
106
Video
Tele Macro
Using tele macro, the camcorder can focus at a shorter distance (up to
50 cm (1.6 ft.) from the subject at full telephoto), allowing you get
closer shots of small subjects like flowers and insects. This function
also adds a soft focus to the background, so the subject not only looks
larger but it also stands out more.
Operating modes:
* In mode, tele macro will be activated automatically when you zoom in to full
telephoto and bring the camcorder up close to the subject.
POINTS TO CHECK
• Select a recording program other than [Š SCN: Fireworks].
* Touch again to turn off the tele macro function.
• The camcorder will automatically adjust the zoom to the telephoto
end.
NOTES
• Any of the following actions will deactivate the tele macro function.
- Turning off the camcorder.
- Pressing T.
- Setting the camcorder to mode.
- Zooming out toward T (wide angle).
- Changing the recording program to [Š SCN: Fireworks].
• Tele macro cannot be turned on/off while recording.
*
[FUNC.] > [ZOOM] > [W]* (tele macro) > [X]
Video 107
White Balance
The white balance function helps you to accurately reproduce colors
under different lighting conditions so that white objects will always look
truly white in your recordings.
Operating modes:
POINTS TO CHECK
• Set the recording program to [’ Programmed AE].
* When you select [Å Custom WB], set the custom white balance with the fol-
lowing procedure before touching [X].
To set the custom white balance
Point the camcorder at a white object, so it fills the whole screen,
and touch [Set WB].
When the adjustment is completed, Å stops flashing and disappears.
The camcorder will retain the custom white balance even if you turn it off.
Options ( Default value)
[Ã Automatic]
The camcorder automatically sets the white bal-
ance for natural looking colors.
[¼ Daylight] To record outdoors.
[ Tungsten] To record under tungsten and tungsten-type
(3-wavelength) fluorescent lighting.
[Å Custom WB] Use the custom white balance setting to make
white subjects appear white under colored lighting.
[FUNC.] > [ÄWhite Balance] > Desired option* >
[ ]X
108
Video
NOTES
• When you select the custom white balance:
- Set [Zoom Type] (A50) to [ Optical].
- Reset the white balance when you change locations or the lighting or
other conditions change.
- Depending on the light source, Å may keep flashing. The result will
still be better than with [ÃAutomatic].
• Custom white balance may provide better results in the following cases:
- Changing lighting conditions
- Close-ups
- Subjects in a single color (sky, sea or forest)
- Under mercury lamps, certain types of fluorescent lights and LED
lights
Self Timer
Operating modes:
* For movies only.
1 Press .
2 Activate the self timer.
•< will appear on the screen.
• Repeat, selecting [jOff], to turn off the self timer.
Movies: In record pause mode, press Y.
The camcorder starts recording after a 10-second countdown. The
countdown appears on the screen.
Photos: In record pause mode, touch [PHOTO].
• The camcorder will record the photo after a 10-second countdown. The
countdown appears on the screen.
• Photos cannot be recorded while the camcorder is set to mode.
*
[ Other Settings] > > p [Self Timer] >
[iOn <] > [X]
Video 109
NOTES
• Once the countdown has begun, any of the following actions will cancel
the self timer.
- Pressing Y, when recording movies.
- Touching [PHOTO], when recording photos.
- Turning off the camcorder.
- Changing the camcorder’s operating mode.
- Closing the LCD panel to set the camcorder to standby mode.
Audio Recording Level
You can adjust the audio recording level of the built-in or an external
microphone. You can display the audio level indicator while recording.
Operating modes:
Manual Adjustment of the Audio Recording Level
1 Open the manual audio recording level adjustment screen.
• The audio level indicator and current audio recording level will appear
on the screen. When p > [Audio Mix] is set to [i
i
i
ii On], two
audio level indicators will appear, the top one for the built-in
microphone, and the bottom one for the external audio.
• Touch [m] (automatic) to return the camcorder to automatic audio
recording levels.
[FUNC.] > [ [ä Mic. Level] >n] (manual)
Using audio mix (A 113)
External audio
Built-in microphone
110
Video
2 Touch and hold [Ï] or [Ð] to adjust the audio recording level as
necessary.
As a guideline, adjust the audio recording level so that the audio level
meter will go to the right of the -12 dB mark (yellow area) only
occasionally.
3 Touch [X] to lock the audio recording level at the current level.
To display the audio level indicator
Usually, the audio level indicator will be displayed only after activating
the manual adjustment of the audio recording level. You can choose to
display it also when the audio level is adjusted automatically.
NOTES
• When you are using a microphone connected to the MIC terminal
including the WM-V1 Wireless Microphone, the audio level indicator will
be displayed automatically.
• When the audio level meter reaches the red point (0 dB), the sound may
be distorted.
• If the audio level is too high and the sound gets distorted, activate the
microphone attenuator with the p >
>
>
>> [Microphone Attenuator] set-
ting.
• We recommend using headphones to check the sound level while
adjusting the audio recording level or when the microphone attenuator
is activated.
[FUNC.] > [ [ä Mic. Level] >m] (automatic) >
[Audio Level Indicator] > [X]
Video 111
Using Headphones
Use headphones for playback or to check the audio level while record-
ing. The headphones are connected to the AV OUT/× terminal, which
is used for both the headphones and the audio/video output. Before
connecting the headphones, follow the procedure below to change the
function of the terminal from AV output to × (headphones) output.
Operating modes:
1 Press .
2 Change the function of the terminal to headphones output.
3 Connect the headphones to the AV OUT/× terminal.
4 Adjust the volume as necessary.
* You can also drag your finger along the [Headphones] bar.
•Ó will appear on the screen.
[ Other Settings] > > q [AV/Headphones] >
[ ]ÓHeadphones] > [K
[Volume] > > [Ô] or [Õ]* to adjust the volume [X]
112
Video
To adjust the volume during playback
In mode, and in mode during slideshow playback, adjust
the headphones volume the same way you adjust the speaker’s vol-
ume (A55, 122).
IMPORTANT
• When using headphones, make sure to lower the volume to an appro-
priate level.
• Do not connect the headphones to the AV OUT/× terminal if the Ó
icon does not appear on the screen. The noise output in such case may
be harmful to your hearing.
NOTES
• Use commercially available headphones with a ∅3.5 mm minijack.
• Even if [AV/Headphones] was set to [Ó Headphones] in a playback
mode, the function of the AV OUT/× terminal will return automatically to
AV output when you turn off the camcorder.
Using an External Microphone
When recording in very quiet surroundings, the built-in microphone
may pick up the sound of the camcorder’s internal machinery. In such
case, we recommend using an external microphone.
Operating modes:
Using the WM-V1 Wireless Microphone
Using the optional WM-V1 Wireless Microphone, you can reliably
record sound even when recording subjects at a distance exceeding
the practical range of the built-in microphone. You can also mix and
record audio from the WM-V1 with audio from the built-in microphone.
For details on connecting and using the WM-V1, refer to the instruction
manual supplied with the microphone.
Video 113
Using Commercially Available Microphones
You can also use commercially available condenser microphones with
their own power supply. You can connect almost any stereo micro-
phone with a ∅3.5 mm plug but audio recording levels may vary.
Connect the external microphone
to the MIC terminal.
NOTES
• When you are using a microphone connected to the MIC terminal, the
audio level indicator will be displayed automatically.
• When an external microphone is connected to the camcorder, p
> [Wind Screen] will automatically be set to [j Off à].
• If the audio level is too high and the sound gets distorted, adjust the
audio recording level manually (A109) or activate the microphone
attenuator with the p > [Microphone Attenuator] setting.
Audio Mix
When recording, you can mix audio from the built-in microphone with
external audio from the MIC terminal and adjust the mix balance for
original sound effects. The external audio input can be from the
optional WM-V1 Wireless Microphone or a commercially available
external microphone.
Operating modes:
1 Connect the external microphone to the MIC terminal.
2 Press .
114
Video
3 Activate the audio mix.
4 Adjust the audio mix balance as necessary.
Touch [INT] (more of the sound from the built-in microphone) or [EXT]
(more of the sound from the external microphone) or drag your finger
along the audio mix bar to adjust the mix balance as desired.
5 Touch [X] to set the audio mix and close the menu.
Capturing Video Snapshot Scenes and Photos from a Movie
You can capture video snapshot scenes or photos from a previously
recorded scene. For example, you may want to print photos from video
recorded at a party or create a small video clip using video snapshot
scenes from the highlights of an event.
Operating modes:
Capturing a Video Snapshot Scene
1 Play back the scene or story from which you want to capture the
video snapshot scene.
2 Press Y to capture the video snapshot scene.
The camcorder captures the video snapshot scene for about 4
seconds (the blue frame serves as a visual progress bar), and then
enters playback pause mode. You can change the length of the video
snapshot scenes you capture to 2 or 8 seconds with the r >
[Video Snapshot Length] setting.
3 Touch [Ñ] to stop the playback.
[ Other Settings] > > p [Audio Mix] > [iOn]
Video 115
NOTES
• A video snapshot scene can be captured only during playback; it can-
not be captured during playback pause mode.
• The captured video snapshot scene is saved to the same memory that
contains the source scene.
• Video snapshot scenes cannot be captured from any of the following
types of scenes.
- Scenes shorter than 1 second
- /& % Scenes that were edited using the supplied software
VideoBrowser and were then transferred back to the camcorder.
• When the source scene is itself a video snapshot scene, you may not
be able to capture a video snapshot scene depending on the length of
the source scene and the length currently selected for video snapshot
scenes.
• When you start capturing a video snapshot scene less than 1 second
from the end of the scene, the video snapshot scene will be captured
starting from the beginning of the following scene.
• During the playback of video snapshot scenes captured from a previ-
ously recorded movie, you may notice some anomalies in the picture/
sound at the point where the playback switches to a new scene.
Capturing Photos
The size of the captured photos will be 1920x1080 and it cannot be
changed.
Please read the IMPORTANT section before using an Eye-Fi card.
1 Play back the scene or story from which you want to capture the
photo.
2 Pause the playback at the point you want to capture.
3 Touch [PHOTO].
4 Touch the screen and then touch [Ñ] to stop the playback.
IMPORTANT
• When capturing photos on an Eye-Fi card, photos will be uploaded
automatically if you are within the range of a configured network. Always
verify that Eye-Fi cards have been approved in the country/region of
use. See also Using an Eye-Fi card (A146).
116
Video
NOTES
• The data code of the photos will reflect the date and time of recording of
the original scene.
• Photos captured from a scene with a lot of fast movement may be
blurred.
• Photos will be recorded on the memory selected for recording photos.
Dividing Scenes
You can divide scenes in order to leave out the best parts and later cut
out the rest.
Operating modes:
1 Play back the scene you want to divide.
2 Pause the playback at the point where you want to divide the
scene.
3 Open the scene division screen.
4 Bring the scene to a precise point, if necessary.
Playback controls will appear on the screen (A55). Use any special
playback modes (fast playback, frame reverse/advance) as necessary
to locate the desired point.
5 Divide the scene.
• The video from the division point to the end of the scene will appear
as a new scene in the index screen.
[Edit] > [Divide]
[µ Divide] > [Yes]
Video 117
NOTES
• When advancing/reversing frames while dividing the scenes, the interval
between frames is about 0.5 seconds.
• If the scene cannot be divided at the point where you paused the play-
back, advance/reverse a frame and then divide the scene.
• During the playback of a scene that was divided, you may notice some
anomalies in the picture/sound at the point where the scene was cut.
• The following scenes cannot be divided:
- Video snapshot scenes and other scenes that are too short (less than
3 seconds).
- /& % Scenes that were edited using the supplied software
VideoBrowser and were then transferred back to the camcorder.
• Scenes cannot be divided within 1 second from the beginning or the
end of the scene.
118
Photos
Photos
Refer to this chapter for details on viewing photos and other
photo-related operations.
Viewing Photos
Operating modes:
1 Press T.
2 Open the [ Photos] index screen, if it is not displayed.
3 Look for the photo you want to play back.
Move the zoom lever toward T to show 15 photos per page; move it
toward S to show 6 photos per page.
[G] > [ Photos]
Photos 119
4 Touch the photo you wish to view.
• The photo is displayed in single photo view.
• Drag your finger left/right to browse through the photos one by one.
To return to the index screen from single photo view
1 Touch the screen to display the playback controls.
2 Touch [f].
Photo Jump Function
When you have recorded a large number of photos, you can jump eas-
ily through the photos using the scroll bar.
1 Touch the screen to display the playback controls.
2 Jump through the photos using the scroll bar.
! Open the [G Index Selection] screen (A 58).
" Memory being read.
# Drag your finger left/right for the next/previous index page*.
$ Display the next/previous index page.
* While browsing through index pages, a larger scroll bar will appear at the
bottom of the screen for a few seconds. When you have a large number of
photos it may be more convenient to drag your finger along the scroll bar.
[h] > Drag your finger left and right along the scroll
bar > [K]
Produktspezifikationen
| Marke: | Canon |
| Kategorie: | Camcorder |
| Modell: | Vixia HF R32 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Canon Vixia HF R32 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Camcorder Canon
22 September 2024
13 September 2024
28 August 2024
27 August 2024
27 August 2024
20 August 2024
19 August 2024
15 August 2024
14 August 2024
13 August 2024
Bedienungsanleitung Camcorder
- Camcorder Samsung
- Camcorder 3M
- Camcorder Sanyo
- Camcorder BenQ
- Camcorder Gembird
- Camcorder Genius
- Camcorder Hama
- Camcorder HP
- Camcorder Lexibook
- Camcorder Macally
- Camcorder Medion
- Camcorder Nedis
- Camcorder Philips
- Camcorder SilverCrest
- Camcorder Sony
- Camcorder T'nB
- Camcorder Trust
- Camcorder Panasonic
- Camcorder OK
- Camcorder Linksys
- Camcorder Maginon
- Camcorder Bresser
- Camcorder Denver
- Camcorder Intenso
- Camcorder König
- Camcorder National Geographic
- Camcorder Renkforce
- Camcorder Trevi
- Camcorder Braun
- Camcorder Kenwood
- Camcorder Sharp
- Camcorder Pyle
- Camcorder Salora
- Camcorder Aiptek
- Camcorder Coby
- Camcorder Lenco
- Camcorder Mpman
- Camcorder Nilox
- Camcorder Polaroid
- Camcorder Jay-Tech
- Camcorder JVC
- Camcorder Xiaomi
- Camcorder Hitachi
- Camcorder Hyundai
- Camcorder Toshiba
- Camcorder Olympus
- Camcorder Zoom
- Camcorder Garmin
- Camcorder GOCLEVER
- Camcorder Lamax
- Camcorder Prixton
- Camcorder Mio
- Camcorder Sencor
- Camcorder ViewSonic
- Camcorder Marshall
- Camcorder Nikkei
- Camcorder Samson
- Camcorder SBS
- Camcorder Fujifilm
- Camcorder MINOX
- Camcorder Nikon
- Camcorder Ricoh
- Camcorder DJI
- Camcorder Dragon Touch
- Camcorder EnVivo
- Camcorder Midland
- Camcorder Vtech
- Camcorder Kodak
- Camcorder Agfa
- Camcorder Easypix
