Seite 1/40
Š2014 CADEL srl | All rights reserved â tutti i diritti riservati
en THERMOSTOVES
installation use and maintenance manual,
demetra
2DEMETRA
EN
Summary
1 MANUAL SIMBOLOGY 3 .....................................
2 DEAR CUSTOMER 3 ..............................................
3 CAUTIONS .........................................................3
4 WARRANTY CONDITIONS 4 ................................
5 SPARE PARTS 5 .....................................................
6 WARNINGS FOR THE CORRECT DISPOSAL OF
THE PRODUCT 5 ...........................................................
7 PACKAGING AND HANDLING 5 ......................
7.1 PACKAGING .................................................5
7.2 STOVE HANDLING.........................................5
7.3 TRANSPORT ...................................................5
8 CHIMNEY FLUE 6 ................................................
8.1 INTRODUCTION .............................................6
8.2 CHIMNEY FLUE 6 ..............................................
8.3 TECHNICAL FEATURES 7 ..................................
8.4 HEIGHT-DEPRESSION .....................................8
8.5 MAINTENANCE .............................................8
8.6 CHIMNEY POT 8 ...............................................
8.7 CHIMNEY COMPONENTS 9 .............................
8.8 EXTERNAL AIR INLET 9 ......................................
8.9 CHIMNEY FLUE CONNECTION 10 ...................
8.10
EXAMPLES OF CORRECT INSTALLATION ...
11
9 FUEL 12 ...............................................................
9.1 FUEL ..............................................................12
10 INSTALLATION 14 ...............................................
10.1 INTRODUCTION ..........................................14
10.2
DESCRIPTION OF THE RANGE DEMETRA ...
14
10.3 OVERALL DIMENSIONS 15 ..............................
10.4 IDENTIFICATION DATA 16 ...............................
10.5 ON ISSUE ACCESSORIES 16 ............................
10.6 ASSEMBLING ..............................................17
10.7 CONNECTION DIAGRAM CIRCULATION
DEVICE THERMOSTAT 18 ........................................
10.8 WIRING DIAGRAM CIRCULATION DEVICE
THERMOSTAT 18 ......................................................
10.9 REAR CONNECTION DIAGRAM 19 ...............
10.10
HYDRAULIC CONNECTION DIAGRAMS ...
19
10.11 PROCEDURES AND CHECKS BEFORE
CONNECTING THE RANGE 22 ...............................
10.12 FEEDWATER CHARACTERISTICS 22 ..............
10.13 FILLING THE SYSTEM 23 .................................
10.14 CONNECTING THE SAFETY HEAT
EXCHANGER (OPTIONAL) 23 .................................
10.15 POWERING OF BOILER 23 ............................
10.16 GENERAL INSTALLATION..........................23
10.17 LEVELLING 25 ................................................
10.18 ELECTRIC CONNECTION 25 .........................
11 USE 25 ................................................................
11.1 ATTENTION ..................................................25
11.2 INTRODUCTION ..........................................25
11.3 POSITION COMMANDS 26 .............................
11.4 MAIN CONTROL PANEL 27 ............................
11.5 SMOKE BYPASS 27 ..........................................
11.6 GENERAL CHECKS 27 .....................................
11.7 ADJUSTMENT ..............................................28
11.8 SUMMERTIME OPERATION 30 ........................
11.9 SPRING AND AUTUMN OPERATION 30 .........
11.10 FUEL LOADING 30 .........................................
11.11 ADVERSE WEATHER CONDITIONS 31 ..........
11.12 CREOSOTE DANGER ...............................31
11.13 FIRE EXTINGUISHING IN CASE OF FIRE 31 ....
12 MAINTEINANCE ..............................................32
12.1 INTRODUCTION ..........................................32
12.2
BURNING POT AND ASH TRAY CLEANING .....
32
12.3 FUME PIPES ANNUAL CLEANING 32 ............
12.4 GENERAL CLEANING ...............................32
12.5
CLEANING OF PAINTED METAL PANELS .....
33
12.6 CLEANING OF CERAMIC PANELS 33 ..........
12.7 GLASS CLEANING 33 ....................................
12.8 OVEN CLEANING 33 .....................................
12.9 COOKTOP CLEANING 33 ..............................
12.10 FUME PASSAGES CLEANING 33 ..................
12.11 EXTRAORDINARY CLEANING 33 ..................
12.12 GASKET REPLACEMENT 34 .........................
12.13 HEART BREAK 34 ............................................
13 IN CASE OF ANOMALY 35 ................................
13.1 PROBLEM SOLVING 35 ...................................
14 TECHNICAL DATAS 37 .......................................
14.1 FEATURES ....................................................37
3
DEMETRA
EN
1
MANUAL SIMBOLOGY
⢠The icons with the stylized îgures indicates whom the subject dealt in the paragraph is addressed to (between
the User and/or the Authorized Technician and/or the Specialized Stove-repairer).
⢠WARNING symbols indicates an important note.
USER
AUTHORISED TECHNICIAN
(ONLY to interpret or the Stove-manufacturer or the Authorized
Technician of Technical Assistance Service approved by the Stove-
manufacturer)
SPECIALIZED STOVE-REPAIRER
CAUTION:
READ CAREFULLY THE NOTE
CAUTION:
DANGER OR IRREVERSIBLE DAMAGE POSSIBILITY
2 DEAR CUSTOMER
⢠Our products are designed and manufactured in compliance with standards EN 13240 for wood stoves,
EN 14785 for pellet stoves, EN 13229 for îre places, EN 12815 for wood cooker stoves, C.P.R. 305/2011 for
manufacturing products, Re n.1935/2004 for materials and objects which are in contact with foods, Dir.
2006/95/CEE for low tension, Dir.2004/108/EC for Electromagnetic compatibility.
⢠Read carefully the instruction contained in this manual to obtain the best efîciency.
⢠This instruction manual is an integral part of the product: make sure it is delivered with the appliance also in
case of sold to others. In case of loss please ask a copy to your local Technical Assistance Service.
⢠All local regulations, including those referring to national European standards, must be respected during
appliance installation.
In Italy biomass system installation below 35 kW must comply with MD 37/08. Every qualiîed
installer who own these requirements, has to issue the certiîcate of conformity for the
installed system (âsystemâ means: stove + chimney + air inlet).
⢠According to (EU) No. 305/2011 regulation, the â Declaration of Performanceâ is available online at the web
sites www.cadelsrl.com / www.free-point.it.
3 CAUTIONS
⢠All the pictures carried in this manual are only for indicative and explanatory purpose and could therefore
slightly differ from your appliance.
⢠The referring appliance is those you purchased.
⢠In case of doubts or difîculties in the comprehension or for problems not described in this manual, please
promptly contact your distributor or installer.
⢠It is forbidden to modify the appliance without authorization.
